cause dangerous handling characteristics in loss of control.

resulting

Toyota recommends all four tires, or at least both of the front or rear tires be replaced at a time as a set. See “If you have a flat tire” on page 245 for tire change procedure. When a tire is replaced, the wheel should always be balanced. An unbalanced wheel may affect ve- hicle handling and tire life. Wheels can get out of balance with regular use and should therefore be balanced occasionally. When replacing a tubeless tire, the air valve should also be replaced with a new one.

To equalize tire wear and help ex- tend tire life, Toyota recommends that you rotate your tires accord- ing to the maintenance schedule. (For scheduled maintenance infor- mation, please refer to the “Sched- uled Maintenance Guide” or “Own- er’s Supplement”.) However, the most appropriate tim- ing for tire rotation may vary ac- cording to your driving habits and road surface conditions. See “If you have a flat tire” on page 245 in Section 4 for tire change proce- dure.

Manual

295

2004 RAV4 from Mar. ’04 Prod. (OM42568U)

’04 Rav4_U (L/O 0403)

When rotating tires, check for uneven wear and damage. Abnormal wear is usually caused by incorrect tire pres- sure, improper wheel alignment, out- of- balance wheels, or severe braking. Initial adjustment of the tire pres- sure warning system is necessary after you have rotated your tires. See “Tire pressure warning sys- tem” on page 131 in Section 1- 7.

Installing snow tires and chains WHEN TO USE SNOW TIRES OR CHAINS Snow tires or chains are recommended when driving on snow or ice. On wet or dry roads, conventional tires provide better traction than snow tires. SNOW TIRE SELECTION If you need snow tires, select tires of the same size, construction and load capacity as the originally installed tires. Also, on four- wheel drive models, all the tires must be the same brand and have the same tread patterns. Do not use tires other than those men- tioned above. Do not install studded tires without first checking local regulations for possible restrictions.

CAUTION

the

following

Observe instructions. Otherwise, an accident may occur re- sulting in death or serious injuries. (cid:1) Do not use snow tires other than the manufacturer’s recommended si- ze, as this may cause dangerous handling characteristics resulting in loss of control.

296

(cid:1) Four- wheel drive models:

Do not use snow tires of different brands, sizes, construction or tread patterns, as this may cause danger- ous handling characteristics result- ing in loss of control.

SNOW TIRE INSTALLATION Snow tires should be installed on all wheels. Installing snow tires on the front wheels only can lead to an excessive difference in road grip capability between the front and rear tires, which could cause loss of vehicle control. When storing removed tires, you should store them in a cool dry place. Mark the direction of rotation and be sure to install them in the same direction when replacing.

CAUTION

(cid:1) Do not drive with the snow tires

incorrectly inflated.

(cid:1) Never drive over 120 km/h (75 mph)

with any type of snow tires.

2004 RAV4 from Mar. ’04 Prod. (OM42568U)

’04 Rav4_U (L/O 0403)

Side chain

NOTICE

CAUTION

If the wrong combination of tire and chain is used, the chains could dam- age the vehicle body.

the

rear driving

CHAIN INSTALLATION Install the chains on the front tires as tightly as possible. Do not use tire tires. Retighten chains on chains after km (1/4—1/2 mile). When installing chains on your tires, care- fully follow the instructions of the chain manufacturer. If wheel covers are used, they will be scratched by the chain band, so remove the covers before putting on the chains.

0.5—1.0

Cross chain

TIRE CHAIN SELECTION Use the tire chains of correct size. For 215/70R16 and 235/60R16 tires, use the following type chains.

mm (in.) 3 (0.12) A Diameter of side chain 10 (0.39) B Width of side chain 30 (1.18) C Length of side chain 4 (0.16) D Diameter of cross chain 14 (0.55) E Width of cross chain F Length of cross chain 25 (0.98) Regulations regarding the use of tire chains vary according to location or type of road, so always check local reg- ulations before installing chains.

(cid:1) Do not exceed 50 km/h (30 mph) or recom- is

the chain manufacturer’s mended speed lower.

limit, whichever

(cid:1) Drive carefully avoiding bumps, holes, and sharp turns, which may cause the vehicle to bounce.

(cid:1) Avoid sharp turns or locked- wheel braking, as use of chains may ad- versely affect vehicle handling.

(cid:1) When driving with chains installed, to drive carefully. Slow be sure down before entering curves to avoid losing control of the vehicle. Otherwise an accident may occur.

297

2004 RAV4 from Mar. ’04 Prod. (OM42568U)

’04 Rav4_U (L/O 0403)

Replacing wheels WHEN TO REPLACE YOUR WHEELS If you have wheel damage such as bending, cracks or heavy corrosion, the wheel should be replaced. If you fail to replace a damaged wheel, the tire may slip off the wheel or cause loss of handling control. WHEEL SELECTION When replacing wheels, care should be taken to ensure that the wheels are re- placed by ones with the same load ca- pacity, diameter, rim width, and offset. Correct replacement wheels are available at your Toyota dealer. A wheel of a different size or type may adversely affect handling, wheel and bear- ing life, brake cooling, speedometer/odom- eter calibration, stopping ability, headlight aim, bumper height, vehicle ground clear- ance, and tire or snow chain clearance to the body and chassis.

298

Replacement with used wheels is not rec- ommended as they may have been sub- jected to rough treatment or high mileage and could fail without warning. Also, bent wheels which have been straightened may have structural damage and therefore should not be used. Never use an inner tube in a leaking wheel which is designed for a tubeless tire.

CAUTION

the

following

instructions. Observe Otherwise, an accident may occur re- sulting in death or serious injuries. (cid:1) Do not use wheels other than the manufacturer’s recommended size, as this may cause dangerous han- dling characteristics in loss of control.

resulting

(cid:1) Four- wheel drive models:

Do not use wheels of different brands, sizes and types, as this may cause dangerous handling characteristics resulting in loss of control.

Aluminum wheel precautions (cid:1) When aluminum wheels, check tight after driving your vehicle the first 1600
km (1000 miles).

the wheel nuts are

installing that

repaired, or (cid:1) If you have changed your the wheel nuts are still tight after driving 1600 km (1000 miles).

rotated, tires, check

that

(cid:1) When using tire chains, be careful not

to damage the aluminum wheels.

(cid:1) Use only Toyota wheel nuts and for your aluminum

wrench designed wheels.

(cid:1) When balancing your wheels, use only Toyota balance weights or equivalent and a plastic or rubber hammer.

(cid:1) As with any wheel, periodically check your aluminum wheels for damage. If damaged, replace immediately.

2004 RAV4 from Mar. ’04 Prod. (OM42568U)

’04 Rav4_U (L/O 0403)

SECTION 7- 3

DO- IT- YOURSELF MAINTENANCE Electrical components Checking battery condition Battery recharging precautions Checking and replacing fuses Adding washer fluid Replacing light bulbs

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

300
301
302
303
304

299

2004 RAV4 from Mar. ’04 Prod. (OM42568U)

’04 Rav4_U (L/O 0403)

Checking battery condition— —Precautions

CAUTION

BATTERY PRECAUTIONS The battery produces flammable and explosive hydrogen gas. (cid:1) Do not cause a spark from the bat-

tery with tools.

(cid:1) Do not smoke or light a match near

the battery.

The electrolyte contains poisonous and corrosive sulfuric acid. (cid:1) Avoid contact with eyes, skin or

clothes.

(cid:1) Never ingest electrolyte. (cid:1) Wear protective safety glasses when

working near the battery.

(cid:1) Keep children away from the bat-

tery.

(cid:1) If electrolyte gets on your skin, thoroughly wash the contact area. If you feel pain or burning, get medi- cal attention immediately.

(cid:1) If electrolyte gets on your clothes, there is a possibility of its soaking through to your skin, so immediate- ly take off the exposed clothing and follow the procedure above, if nec- essary.

(cid:1) If you accidentally swallow electro- lyte, drink a large quantity of water or milk. Follow with milk of magne- sia, beaten raw egg or vegetable oil. Then go immediately for emer- gency help.

EMERGENCY MEASURES (cid:1) If electrolyte gets

in your eyes, flush your eyes with clean water immediately immediate medical attention. If possible, con- tinue to apply water with a sponge or cloth while en route to the medi- cal office.

and get

300

—Checking battery exterior

Ground cable

Terminals

Hold- down clamp

Before checking the battery, remove the battery cover. (See “(c) Jump starting” on page 241 in Section 4.) Check the battery for corroded or loose terminal connections, cracks, or loose hold- down clamp. a. If the battery is corroded, wash it off with a solution of warm water and bak- ing soda. Coat the outside of the termi- nals with grease to prevent further cor- rosion.

b. If the terminal connections are loose, their clamp nuts—but do not

tighten overtighten.

2004 RAV4 from Mar. ’04 Prod. (OM42568U)

’04 Rav4_U (L/O 0403)

c. Tighten

the hold- down clamp only enough to keep the battery firmly in place. Overtightening may damage the battery case. After checking battery cover.

the battery, reinstall

the

—Checking battery condition

Type A

Green

Dark

Clear or light yellow

NOTICE

Type B

(cid:1) Be sure the engine and all accesso- ries are off before performing main- tenance.

(cid:1) When checking the battery, remove the ground cable from the negative terminal (“-” mark) first and rein- stall it last.

(cid:1) Be careful not to cause a short cir-

cuit with tools.

(cid:1) Take care no solution gets into the

battery when washing it.

Blue

White

Red

CHECKING BY INDICATOR Check the battery condition by the indi- cator color.

Indicator color

Type A

Type B

Green

Blue

Dark

White

Clear or

light yellow

Red

Condition Condition

Good

Charging necessary. Have battery checked by your Toyota dealer.

Have battery checked by your Toyota dealer.

Battery recharging precautions During recharging, the battery is pro- ducing hydrogen gas. Therefore, before recharging: 1. If recharging with the battery installed on the vehicle, be sure to disconnect the ground cable.

2. Be sure the power switch on the re- charger the charger cables to the battery and when disconnecting them.

is off when connecting

CAUTION

(cid:1) Always charge the battery in an un- confined area. Do not charge the battery in a garage or closed room where there is not sufficient ventila- tion.

(cid:1) Only do a slow charge (5 A or less). Charging at a quicker rate is dangerous. The battery may ex- plode, causing personal injuries.

NOTICE

Never recharge the battery while the engine is running. Also, be sure all accessories are turned off.

301

2004 RAV4 from Mar. ’04 Prod. (OM42568U)

’04 Rav4_U (L/O 0403)

Checking and replacing fuses

Good

Blown

Good

Blown

Type A

Type B

302

If the headlights or other electrical components do not work, check the fuses. If any of the fuses are blown, they must be replaced. See “Fuse locations” on page 277 in Sec- tion 7- 1 for locations of the fuses. Turn the ignition switch and inoperative component off. Pull the suspected fuse straight out and check it. Determine which fuse may be causing the problem. The lid of the fuse box shows the name of the circuit for each fuse. See page 316 in Section 8 of this manual for the functions controlled by each circuit.

Type A fuses can be pulled out by using the pull- out tool. The location of the pull- out tool is shown in the illustration. If you are not sure whether the fuse has blown, try replacing the suspected fuse with one that you know is good. If the fuse has blown, push a new fuse into the clip. Only install a fuse with the amperage rat- ing designated on the fuse box lid. If you do not have a spare fuse, in an emergency you can pull out the “RADIO” or “A/C” fuse, which may be dispensable for normal driving, and use it if its amper- age rating is the same. If you cannot use one of the same amper- age, use one that is lower, but as close to the rating as possible. If the amperage is fuse might blow out again but this does not indicate anything wrong. Be sure to get the correct fuse as soon as possible and return the substitute to its original clip. It is a good idea to purchase a set of spare fuses and keep them in your ve- hicle for emergencies.

that specified,

lower

than

the

2004 RAV4 from Mar. ’04 Prod. (OM42568U)

’04 Rav4_U (L/O 0403)

Adding washer fluid

NOTICE

Do not use engine antifreeze or any other substitute because it may dam- age your vehicle’s paint.

the new

If fuse immediately blows out, there is a problem with the electrical sys- tem. Have your Toyota dealer correct it as soon as possible.

CAUTION

Never use a fuse with a higher am- perage rating, or any other object, in place of a fuse. This may cause ex- tensive damage and possibly a fire.

If any washer does not work or wind- shield washer fluid level warning light comes on, the washer tank may be empty. Check the washer fluid level on the level gauge. If the washer fluid lev- el is below “LOW”, add washer fluid. You may use plain water as washer fluid. However, in cold areas where tempera- tures range below the freezing point, use washer fluid containing antifreeze. This product is available at your Toyota dealer and most auto parts stores. Follow the manufacturer’s directions for how much to mix with water.

303

2004 RAV4 from Mar. ’04 Prod. (OM42568U)

following

illustrations show how

Replacing light bulbs— The to gain access to the bulbs. When replacing a bulb, make sure the ignition switch and light switch are off. Use bulbs with the wattage ratings given in the table.

CAUTION

(cid:1) To prevent burning yourself, do not replace the light bulbs while they are hot.

(cid:1) Halogen bulbs have pressurized gas inside and require special handling. They can burst or shatter if scratched or dropped. Hold a bulb only by its plastic or metal case. Do not touch the glass part of a bulb with bare hands.

NOTICE

Only use a bulb of the listed type.

304

’04 Rav4_U (L/O 0403)

the

The inside of the lens of exterior lights such as headlights may temporarily fog up when the lens becomes wet in the rain or in a car wash. This is not a problem because the is caused by fogging temperature difference between the outside and the windshield fogs up in the rain. However, if there large drop of water on the inside of the lens, or if there is water pooled light, contact your Toyota dealer.

inside of

inside

lens,

is a

just

like

the

the

Light bulbs

Headlights

Parking and front side marker lights

Front turn signal lights

Front fog lights

Rear turn signal lights

Stop/tail and rear side marker lights

Back- up lights

High mounted stop light

Bulb No. 9003

168

7440

—

7440

921

7440

W Type

60/55

21

51

21

16

21

10

7443

21/5

License plate light

168

Interior lights

Personal light

—

—

A: HB2 halogen bulbs B: Wedge base bulbs C: HB4 halogen bulbs D: Double end bulbs

2004 RAV4 from Mar. ’04 Prod. (OM42568U)

’04 Rav4_U (L/O 0403)

—Headlights

1. Open the hood. Unplug the connec-

tor. Remove the rubber cover. If the connector is tight, wiggle it.

2. Release

the bulb retaining spring and remove the bulb. Install a new bulb and the bulb retaining spring.

3. Install the rubber cover and fit

it securely on the boss. Plug in the connector.

To install a bulb, align the tabs of the bulb with the mounting hole.

the cutouts of

Make sure the rubber cover fits securely on the bulb base and the mounting body. Aiming is not necessary after replacing the bulb. When aiming adjustment is nec- essary, contact your Toyota dealer.

305

2004 RAV4 from Mar. ’04 Prod. (OM42568U)

’04 Rav4_U (L/O 0403)

—Parking and front side marker lights

—Front turn signal lights

—Front fog lights

306

2004 RAV4 from Mar. ’04 Prod. (OM42568U)

’04 Rav4_U (L/O 0403)

1. Remove the bolts and the cover clip. The steps for removing and installing the cover clip is shown in the following il- lustrations.

Removing clip

2. Unplug the connector while depress-

ing the lock release.

If the connector is tight, wiggle it.

Installing clip

307

2004 RAV4 from Mar. ’04 Prod. (OM42568U)

’04 Rav4_U (L/O 0403)

—Rear turn signal, stop/tail, rear side marker and back- up lights

3. Turn the bulb counterclockwise and

remove it.

4. Install a new bulb and the connector into the mounting hole by turning it clockwise.

308

2004 RAV4 from Mar. ’04 Prod. (OM42568U)

’04 Rav4_U (L/O 0403)

—High mounted stoplight

a: Stop/tail and rear side marker light b: Back- up light c: Rear turn signal light

309

2004 RAV4 from Mar. ’04 Prod. (OM42568U)

—License plate light

Use a Flat- bladed screwdriver.

310

’04 Rav4_U (L/O 0403)

2004 RAV4 from Mar. ’04 Prod. (OM42568U)

’04 Rav4_U (L/O 0403)

SECTION 8

SPECIFICATIONS Specifications Dimensions and weights Engine Fuel Service specifications Tires Fuses

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

312
313
313
313
316
316

311

2004 RAV4 from Mar. ’04 Prod. (OM42568U)

’04 Rav4_U (L/O 0403)

* 1: Unladen vehicle * 2: With steel wheel spare tire and half * 3: With aluminum wheel spare tire and

spare tire cover

half spare tire cover * 4: With full spare tire cover * 5: With over fender * 6: Two- wheel drive models * 7: Four- wheel drive models * 8: With roof rails * 9: With automatic transmission * 10: With manual transmission

Dimensions and weights

215/70R16 tires

235/60R16 tires

4205 (165.6) 4210 (165.7)* 2
4215 (165.9)* 3
4255 (167.5)* 4
1735
1785

(68.3) (70.3)* 5
(65.7)* 6
(66.1)* 7
(67.1)* 6, 8
(67.5)* 7, 8
(98.0) (59.3)* 7
(59.4)* 6
(58.9)* 7
(59.1)* 6
(761)* 7, 9
(826)* 7, 10
(919)* 6, 9
(985)* 6, 10

1670
1680
1705
1715

2490

1505
1510

1495
1500

345
375
417
447

4220 (166.1) 4225 (166.3)* 3
4255 (167.5)* 4

1785

(70.3)

1670
1705

(65.7) (67.1)* 8

2490

(98.0)

1525

(60.0)

1520

(59.8)

345
375
417
447

(761)* 7, 9
(826)* 7, 10
(919)* 6, 9
(985)* 6, 10

Overall length

mm (in.)

Overall width

mm (in.)

Overall height* 1

mm (in.)

Wheelbase

mm (in.)

Front tread

mm (in.)

Rear tread

mm (in.)

Vehicle capacity weight (occupants + luggage)

kg (lb.)

Towing capacity (trailer weight + cargo weight)

kg (lb.)

312

680 (1500)

680 (1500)

2004 RAV4 from Mar. ’04 Prod. (OM42568U)

’04 Rav4_U (L/O 0403)

Engine Model:

2AZ- FE

Type:

Fuel Fuel type:

Unleaded gasoline, Octane Rating 87
(Research Octane Number 91) or higher

4 cylinder in line, 4 cycle, gasoline

Fuel tank capacity, L (gal., Imp. gal.):

Bore and stroke, mm (in.):

88.5 (cid:1) 96.0 (3.48 (cid:1) 3.78)

Displacement, cm3 (cu. in.):

2362 (144.1)

56 (14.8, 12.3)

Service specifications ENGINE Valve clearance (engine cold), mm (in.):

Intake Exhaust

0.19—0.29 (0.007—0.012) 0.30—0.40 (0.012—0.016)

Spark plug type:

DENSO NGK

SK20R11
IFR6A11

Spark plug gap, mm (in.):

1.1 (0.043)

ENGINE LUBRICATION Oil capacity (drain and refill), L (qt., Imp. qt.):

With filter Without filter

3.8 (4.0, 3.3) 3.6 (3.8, 3.2) “Toyota Genuine Motor Oil” in your Toyota vehicle. Use Toyota approved “Toyota Genuine Motor Oil” or equivalent to grade and viscosity. Oil grade:

following

is used

satisfy

the

API grade SL “Energy- Conserving” or ILSAC multigrade engine oil

313

2004 RAV4 from Mar. ’04 Prod. (OM42568U)

’04 Rav4_U (L/O 0403)

Recommended oil viscosity:

SAE 5W- 30

COOLING SYSTEM Total capacity, L (qt., Imp. qt.):

With manual transaxle With automatic transaxle

6.6 (7.0, 5.9) 6.8 (7.2, 6.0)

CLUTCH Pedal free play, mm (in.):

5—15 (0.2—0.6)

Fluid type:

Coolant type:

SAE J1703 or FMVSS No.116 DOT 3

Outside temperature

Please contact your Toyota dealer for fur- ther details.

“Toyota Super Long Life Coolant” is used in your Toyota vehicle at factory fill. In order to avoid technical problems, only use “Toyota Super Long Life Coolant” or similar high quality ethylene glycol based non- silicate, non- amine, non- nitrite, and non- borate coolant with long- life hybrid organic acid technology. (Coolant with long- life hybrid organic acid technology is a combination of low phosphates and organic acids.) Do not use plain water alone. Please contact your Toyota dealer for further details.

BATTERY Open voltage* at 20(cid:1)C (68(cid:1)F):

MANUAL TRANSAXLE Oil capacity, L (qt., Imp. qt.):

Two- wheel drive models

2.5 (2.6, 2.2)

Four- wheel drive models

3.4 (3.6, 3.0)

Oil type:

Gear oil API GL- 4 or GL- 5

Recommended oil viscosity:

SAE 75W- 90

12.6—12.8 V 12.2—12.4 V 11.8—12.0 V

Fully charged Half charged Discharged

* : Voltage that is checked 20 minutes af- ter the key is removed with all the lights turned off Charging rates:

314

5 A max.

2004 RAV4 from Mar. ’04 Prod. (OM42568U)

’04 Rav4_U (L/O 0403)

AUTOMATIC TRANSAXLE Fluid capacity (drain and refill), L (qt., Imp. qt.):

TRANSFER (four- wheel drive models) Oil capacity, L (qt., Imp. qt.):

Up to 3.5 (3.7, 3.0)

Fluid type:

Toyota Genuine ATF Type T- IV

in

listed

Guide”

is necessary

Change automatic transmission fluid only as necessary. Generally, to change it automatic transmission fluid only if your vehicle is driven under one of the Special Operating Conditions your “Scheduled Maintenance or “Owner’s Manual Supplement”. When changing the automatic transmission fluid, use only “Toyota Genuine ATF Type T- IV” to aid (ATF JWS3309 or NWS6500) in assuring optimum transaxle performance. Notice: Using automatic transmission fluid other than “Toyota Genuine ATF Type T- IV” may cause deterioration in shift quality, locking up of your trans- mission accompanied by vibration, and ultimately damage the automatic trans- mission of your vehicle. Please contact your Toyota dealer for fur- ther details.

0.9 (1.0, 0.8)

Oil type:

Hypoid gear oil API GL- 5
Recommended oil viscosity:

Above -18(cid:1)C (0(cid:1)F)

SAE 90

Below -18(cid:1)C (0(cid:1)F)

SAE 80W or 80W- 90

REAR DIFFERENTIAL (four- wheel drive models) Oil capacity, L (qt., Imp. qt.):

0.9 (1.0, 0.8)

Oil type:

Hypoid gear oil API GL- 5
Recommended oil viscosity:

Above -18(cid:1)C (0(cid:1)F)

SAE 90

Below -18(cid:1)C (0(cid:1)F)

SAE 80W or 80W- 90

BRAKES Minimum pedal clearance when depressed with the force of 490 N (50 kgf, 110 lbf) with the engine running, mm (in.):

118 (4.6)

Pedal free play, mm (in.):

1—6 (0.04—0.24)

Pad wear limit, mm (in.):

1.0 (0.04)

Lining wear limit, mm (in.):

1.0 (0.04)

Parking brake adjustment when pulled with the force of 196 N (20 kgf, 44 lbf):

6—8 clicks

Fluid type:

SAE J1703 or FMVSS No.116 DOT 3

STEERING Wheel free play:

Less than 30 mm (1.2 in.)

Power steering fluid type:

Automatic transmission fluid DEXRON(cid:2)II or III

315

2004 RAV4 from Mar. ’04 Prod. (OM42568U)

’04 Rav4_U (L/O 0403)

Fuses

Tires Tire size:

215/70R16 99S 235/60R16 100H

Cold tire inflation pressure, kPa (kgf/cm2 or bar, psi):

200 (2.0, 29)

Wheel size:

Steel wheel Aluminum Wheel

16 (cid:1) 6 1/2J 16 (cid:1) 7JJ

Wheel nut torque, N·m (kgf·m, ft·lbf): 103 (10.5, 76) NOTE: For a complete information on tires (e.g. replacing tires or replacing wheels), see “Checking tire inflation pres- sure” “Aluminum wheel precautions”, pages 291 through 298 in Section 7- 2.

through

316

Engine compartment

Instrument panel

Fuses (type A) 1. RADIO 15 A: Car audio system 2. DOME 10 A: Clock, personal light, in- terior lights, vanity lights, garage door opener, air conditioning system, wire- less remote control system, gauges and meters

3. CUT 30 A: “RADIO” and “DOME” fuses 4. A/C 5 A: Air conditioning system 5. MAIN 30 A: “H- LP RH” and “H- LP LH”

fuses

6. HAZ 10 A: Emergency flashers

2004 RAV4 from Mar. ’04 Prod. (OM42568U)

’04 Rav4_U (L/O 0403)

7. ALT- S 5 A: Charging system 8. IGN 15 A: Starting system, multiport injection system/sequential multi-

fuel port fuel injection system

9. EFI3 10 A: Multiport fuel injection sys- injection

tem/sequential multiport system, emission control system

fuel

10. EFI2 5 A: Multiport fuel injection sys- injection

tem/sequential multiport system

fuel

11. RADIO NO.2 30 A: Car audio system 12. ABS 2 30 A: Anti- lock brake system, vehicle stability control system, traction control system, brake assist system

13. EFI1 20 A: Multiport fuel injection sys- injection tem/sequential multiport system, automatic fluid temperature sensor, “EFI2” and “EFI3” fuses

transmission

fuel

14. H- LP RH 15 A: Right- hand headlight 15. H- LP LH 15 A: Left- hand headlight 16. ETCS 10 A: Electronic throttle control

system

17. ST 5 A: Starting system

18. STOP 10 A: Stop lights, high- mounted stoplight, anti- lock brake system, shift lock control system, multiport fuel in- jection system/sequential multiport fuel injection system, cruise control system

19. CIG 15 A: Cigarette lighter 20. POWER OUTLET 15 A: Power outlets 21. S- HTR 10 A: Seat heaters 22. PANEL 7.5 A: Instrument panel lights, gauges and meters, lights, instrument panel light control, outside rear view mirror defoggers, air condi- tioning system

front

fog

23. FR FOG 15 A: Front fog lights 24. HORN 10 A: Horn 25. TAIL 7.5 A: Tail lights, license plate

lights, instrument cluster lights

26. TAIL&PANEL 15 A:

“PANEL” and

“TAIL” fuses

27. ACC 7.5 A: Car audio system, shift lock control system, clock, power rear view mirrors

28. DEF 20 A: Rear window defogger 29. GAUGE 10 A: Back- up lights, electric cooling fans, air conditioning system, automatic transmission indicator lights, charging system

30. OBD 7.5 A: On- board diagnosis sys-

tem

31. IG2 10 A: Discharge warning

light, multiport fuel injection system/sequen- tial multiport injection system, starting system, gauges and meters, SRS airbag system

fuel

32. DOOR 20 A: Power door lock system 33. MIR HTR 10 A: Outside rear view mir-

ror defoggers

34. RR WIP 15 A: Rear window wiper and

washer

35. WIP 25 A: Windshield wipers and

washer

36. ECU

IG 10 A: Emergency

flashers, gauges and meters, anti- lock brake system, vehicle stability control system, traction control system, brake assist system, SRS airbag system, shift lock control system, cruise control system

Fuses (type B) 37. RDI 30 A: Electric cooling fan 38. CDS 30 A: Electric cooling fan 39. AM2 30 A: Discharge warning

light, multiport fuel injection system/sequen- tial multiport injection system, starting system, SRS airbag system, “IG2” fuse

fuel

317

2004 RAV4 from Mar. ’04 Prod. (OM42568U)

’04 Rav4_U (L/O 0403)

40. ABS 1 50 A: Anti- lock brake system 41. HTR 40 A: Air conditioning system 42. F- HTR or H- LP CLN 30 A: No circuit 43. PWR 30 A: Electric moon roof, power

windows

44. AM1 40 A: Power outlets, rear window IG”, “S- HTR” and

“ACC”, “RR WIP”,

“CIG”,

“ECU

defogger, “GAUGE”, “WIP” fuses

318

2004 RAV4 from Mar. ’04 Prod. (OM42568U)

’04 Rav4_U (L/O 0403)

SECTION 9

REPORTING SAFETY DEFECTS FOR U.S. OWNERS Reporting safety defects for U.S. owners Reporting safety defects for U.S. owners

. . . . . . . . . . . . . . . . . . . . . .

320

319

2004 RAV4 from Mar. ’04 Prod. (OM42568U)

’04 Rav4_U (L/O 0403)

To contact NHTSA, you may ei- ther call the Auto Safety Hotline toll- free at 1- 800- 424- 9393 (or 366- 0123 in Washington, D.C. area) or write to: NHTSA, U.S. Department of Transportation, Washington, D.C. 20590. You can also obtain other information about motor vehicle safety from the Hot- line.

Reporting safety defects for U.S. owners If you believe that your vehicle has a defect which could cause a crash or could cause injury or death, you should immediately in- form the National Highway Traffic Safety Administration (NHTSA) in addition to notifying Toyota Motor Sales, U.S.A., Inc. (Toll- free: 1- 800- 331- 4331). If NHTSA receives similar com- plaints, it may open an investiga- tion, and if it finds that a safety defect exists in a group of ve- hicles, it may order a recall and remedy However, NHTSA cannot become involved in individual problems between you, your dealer, or Toyota Motor Sales, U.S.A., Inc.

campaign.

320

2004 RAV4 from Mar. ’04 Prod. (OM42568U)

’04 Rav4_U (L/O 0403)

Foreword

Welcome to the growing group of value- conscious people who drive Toyotas. We are proud of the advanced engineering and quality construction of each vehicle we build. This Owner’s Manual explains the operation of your new Toyota. Please read it thoroughly and have all the occupants follow the instructions carefully. Doing so will help you enjoy many years of safe and trouble- free motoring. For important information about this manual and your Toyota, read the following pages carefully. When it comes to service, remember that your Toyota dealer knows your vehicle very well and is interested in your complete satisfaction. He will provide quality maintenance and any other assistance you may require. If there is not a Toyota dealer near you, or you need emergency assistance for any reason, please call the following number:

(cid:1) U.S. OWNERS: (cid:1) CANADIAN OWNERS: Toyota Canada Customer Interaction Centre

Toyota Customer Assistance Center

Toll- free: 1- 800- 331- 4331
Toll- free: 1- 888- TOYOTA- 8 (1- 888- 869- 6828)

Please leave this Owner’s Manual in this vehicle at the time of resale. The next owner will need this information also. All information and specifications in this manual are current at the time of printing. However, because of Toyota’s policy of continual product improvement, we reserve the right to make changes at any time without notice. Please note that this manual applies to all models and explains all equipment, including options. Therefore, you may find some explanations for equipment not installed on your vehicle.

 2004 TOYOTA MOTOR CORPORATION All rights reserved. This material may not be reproduced or copied, in whole or in part, without the written permission of Toyota Motor Corporation.

2004 RAV4 from Mar. ’04 Prod. (OM42568U)

’04 Rav4_U (L/O 0403)

U -2

Quick index (cid:1) If a service reminder indicator or warning buzzer comes on (cid:1) If your vehicle will not start (cid:1) If your engine stalls while driving (cid:1) If your vehicle overheats (cid:1) If you have a flat tire (cid:1) If your vehicle needs to be towed (cid:1) Tips for driving during break- in period (cid:1) How to start the engine (cid:1) General maintenance (cid:1) Complete index Gas station information Fuel type:

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

109
240
244
244
245
256
197
226
271
NO TAG

UNLEADED gasoline, Octane Rating 87 (Research Octane Number 91) or higher See page 197 for detailed information.

Fuel tank capacity:

56 L (14.8 gal., 12.3 Imp. gal.)

Engine oil:

API grade SL “Energy- Conserving” or ILSAC multigrade engine oil is recommended. See page 285 for detailed information.

Tire information: See pages 291 through 298. Tire inflation pressure: See page 316.

Publication No. OM42568U Part No. 01999-42568
Printed in Japan 01-0403-00 I

2004 RAV4 from Mar. ’04 Prod. (OM42568U)

’04 Rav4_U (L/O 0403)

Important information about this manual

Safety and vehicle damage warnings

Safety symbol

Throughout this manual, you will see safety and vehicle dam- age warnings. You must follow these warnings carefully to avoid possible injury or damage. The types of warnings, what they look like, and how they are used in this manual are explained as follows:

CAUTION

This is a warning against anything which may cause injury to people if the warning is ignored. You are informed about what you must or must not do in order to reduce the risk of injury to yourself and others.

NOTICE

This is a warning against anything which may cause damage to the vehicle or its equipment if the warning is ignored. You are informed about what you must or must not do in order to avoid or reduce the risk of damage to your vehicle and its equipment.

the safety symbol When you see shown above, it means: “Do not...”; “Do not do this”; or “Do not let this happen”.

ii

2004 RAV4 from Mar. ’04 Prod. (OM42568U)

’04 Rav4_U (L/O 0403)

Important information about your Toyota

Occupant restraint systems

Toyota encourages you and your family to take the time to read Section 1- 3 of this Owner’s Manual carefully. In terms of helping you understand how you can receive the maximum benefit of the occupant restraint systems this vehicle provides, Section 1- 3 of this Owner’s Manual is the most important Section for you and your family to read. Section 1- 3 describes the function and operation concern- ing seats, seat belts, SRS airbags and child restraint sys- tems of this vehicle and some potential hazards you should be aware of. These systems work together along with the overall structure of this vehicle in order to provide occupant restraint in the event of a crash. The effect of each system is enhanced when it is used properly and together with other systems. No single occupant restraint system can, by itself, provide you or your family with the equal level of restraint which these systems can provide when used together. That is why it is important for you and your family to understand the purpose and proper use of each of these systems and how they relate to each other.

The purpose of all occupant restraint systems is to help reduce the possibility of death or serious injury in the event of a collision. None of these systems, either individ- ually or together, can ensure that there is no injury in the event of collision. However, the more you know about these systems and how to use them properly, the greater your chances become of surviving an accident without death or serious injury.

Seat belts provide the primary restraint to all occupants of the vehicle, and every occupant of the vehicle should wear seat belts properly at all times. Children should always be secured in child restraint systems that are appropriate for their age and size. SRS (Supplemental Restraint System) airbags are, as their names imply, designed to work with, and be supplemental to, seat belts and are not substitutes for them. SRS airbags can be very effective in reducing the risk of head and chest injuries by preventing contact of the head and chest with interior portions of the vehicle.
