2010 Toyota FJ Cruiser Owners Manual

FCC Warning: Any unauthorized changes or modifications to this equipment will void the user’s authority to operate this device.

●Laser products

• Do not take this unit apart or attempt to make any changes yourself.

This is an intricate unit that uses a laser pickup to retrieve information from the surface of compact discs. The laser is carefully shielded so that its rays remain inside the cabinet. Therefore, never try to disas- semble the player or alter any of its parts since you may be exposed to laser rays and dangerous voltages.

• This product utilizes a laser.

Use of controls or adjustments or performance of procedures other than those specified herein may result in hazardous radiation expo- sure.

NOTICE

■To prevent battery discharge

Do not leave the audio system on longer than necessary with the engine off.

■To avoid damaging the audio system

Take care not to spill drinks or other fluids over the audio system.

213

3-2. Using the audio system Using the radio

Type A

Power

Volume

Station selector

Adjusting the frequency

Scanning for receivable stations

Seeking the frequency

AM/FM mode buttons

Type B

Power

Volume

AM·SAT/FM mode buttons

Adjusting the frequency (AM, FM mode) or channel (SAT mode)

Scanning for receivable stations

Seeking the frequency

Station selector

Display text message (SAT mode)

214

3-2. Using the audio system

Setting station presets (excluding XM® Satellite Radio)

Search for desired stations by turning

or

or

pressing “∧” or “∨” on

or

Press and hold the button (from

or ) that the station is to be set to until you hear a beep.

or

to

Scanning radio stations (excluding XM® Satellite Radio) ■ Scanning the preset radio stations

Press and hold

or

until you hear a beep.

Preset stations will be played for 5 seconds each. When the desired station is reached, press the button once again.

■ Scanning all radio stations within range

Press

or

All stations with reception will be played for 5 seconds each. When the desired station is reached, press the button once again.

XM® Satellite Radio for type B (if equipped) ■ Receiving XM® Satellite Radio

Press

and select the XM® band.

The display changes as follows each time pressed. AM → SAT1 → SAT2 → SAT3

is

215

3-2. Using the audio system

Turn

to select the desired channel in the all catego-

ries or press “∧” or “∨” on channel in the current category.

to select the desired

■ Setting XM® Satellite Radio channel presets

Select the desired channel. Press and hold the button (from to

) that the channel is to be set to until you hear a beep.

■ Changing the channel category

Press “∧” or “∨” on the

■ Scanning XM® Satellite Radio channels

● Scanning channels in the current category

Press When the desired channel is reached, press again.

● Scanning preset channels

Press and hold When the desired channel is reached, press again.

until you hear a beep.

■ Displaying text information

Press The display will show up to 10 characters. The display changes as follows each time the button is pressed. ● CH NAME ● TITLE (SONG/PROGRAM TITLE) ● NAME (ARTIST NAME/FEATURE) ● CH NUMBER

216

3-2. Using the audio system

■When the battery is disconnected

Stations presets are erased.

■Reception sensitivity

●Cargo loaded on the roof luggage carrier, especially metal objects, may

adversely affect the reception of XM® Satellite Radio.

●Maintaining perfect radio reception at all times is difficult due to the con- tinually changing position of the antenna, differences in signal strength and surrounding objects, such as trains, transmitters, etc.

●The radio antenna is mounted on the right-side front fender. The antenna

can be removed from the base by turning it.

■XM® Satellite Radio

An XM® Satellite Radio is a tuner designed exclusively to receive broadcasts provided under a separate subscription. Availability is limited to the 48 con- tiguous U.S. states and 10 Canadian provinces. ●XM® subscriptions

For detailed information about XM® Satellite Radio or to subscribe: U.S.A.— Visit on the web at www.xmradio.com or call 1-800-967-2346. Canada— Visit on the web at www.xmradio.ca or call 1-877-438-9677.

●Radio ID

You will need the radio ID when activating XM® service or reporting a

problem. Select “CH000” using number will appear.

, and the receiver's 8-character ID

●Satellite tuner

The tuner supports only Audio Services (Music and Talk) and the accom- panying Text Information of XM® Satellite Radio.

217

3-2. Using the audio system

■If the satellite radio does not operate normally

If a problem occurs with the XM® tuner, a message will appear on the dis- play. Refer to the table below to identify the problem, and take the suggested corrective action.

ANTENNA

UPDATING

NO SIGNAL

LOADING

OFF AIR

-----

The XM® antenna is not connected. Check whether the XM® antenna cable is attached securely. There is a short-circuit in the antenna or the sur- rounding antenna cable. See a Toyota certified dealer. You have not subscribed to the XM® Satellite Radio. The radio is being updated with the latest encryption code. Contact the XM® Satellite Radio for subscription information. When a contract is canceled, you can choose the “CH000” and all free-to-air channels. The premium channel you selected is not autho- rized. Wait for about 2 seconds until the radio returns to the previous channel or “CH001”. If it does not change automatically, select another channel. If you want to listen to the premium chan- nel, contact the XM® Satellite Radio. The XM® signal is too weak at the current location. Wait until your vehicle reaches a location with a stronger signal. The unit is acquiring audio or program information. Wait until the unit has received the information. The channel you selected is not broadcasting any programming. Select another channel. There is no song/program title or artist name/fea- ture associated with the channel at that time. No action needed.

218

3-2. Using the audio system

---

The channel you selected is no longer available. Wait for about 2 seconds until the radio returns to the previous channel or “CH001”. If it does not change automatically, select another channel.

Contact the XM® Listener Care Center at 1-800-967-2346 (U.S.A.) or 1-877-438-9677 (Canada).

■Certifications for the radio tuner

This equipment has been tested and found to comply with the limits for a class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. How- ever, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by trying one or more of the following: ●Reorienting or relocate the receiving antenna. ●Increasing the separation between the equipment and receiver. ●Connecting the equipment into an outlet on a circuit different from that to

which the receiver is connected.

●Consulting the dealer or an experienced radio/TV technician for help.

NOTICE

■To prevent damage, remove the antenna in the following cases.

●The antenna will touch the ceiling of a garage. ●A cover will be put on the vehicle.

219

3-2. Using the audio system Using the CD player

Type A

Power

Volume

CD selection (with external CD changer only)

CD eject

Reverse

Fast-forward

Search playback

Random playback

Repeat play

Display text message

Playback

Track selection

Type B

Power

Volume

CD selection

Fast-forward

Playback

CD eject

Reverse

CD load

Search playback

Random playback

Repeat play

Track selection

Display text message

220

3-2. Using the audio system

Loading CDs

■ Loading a CD (type A)

Insert a CD.

■ Loading a CD (type B)

Press

“WAIT” is shown on the display. Insert a CD when the indicator on the slot turns from amber to green. The display changes from “WAIT” to “LOAD”.

■ Loading multiple CDs (type B only)

Press and hold

until you hear a beep.

“WAIT” is shown on the display. Insert a CD when the indicator on the slot turns from amber to green. The display changes from “WAIT” to “LOAD”. The indicator on the slot turns to amber when the CD is inserted. Insert the next CD when the indicator on the slot turns from amber to green again. Repeat the procedure for the remaining CDs. To stop the operation, press

Ejecting CDs

■ Ejecting a CD (type A)

Press

and remove the CD.

■ Ejecting a CD (type B)

To select the CD to be ejected, press (∧). The number of the CD selected is shown on the display.

(∨) or

221

3-2. Using the audio system

Press

and remove the CD.

■ Ejecting all the CDs (type B only)

Press and hold CDs.

until you hear a beep, and then remove the

Selecting and scanning a track

■ Selecting a track

Press “∧” to move up or “∨” to move down using until the desired track number is displayed.

or

■ Scanning tracks

or

Press The first 10 seconds of each track will be played. Press the switch again when the desired track is reached.

Fast-forwarding and reversing tracks

To fast-forward or reverse. Type A: Press and hold Type B: Press and hold

) or ) or

). ).

Selecting a CD (with CD changer only)

■ Selecting the desired CD (∨) or (∨) or

Type A: Press Type B: Press

(∧). (∧).

■ Selecting loaded CDs Press and hold The first 10 seconds of the first track on each CD will be played. Press the switch again when the desired CD is reached.

until you hear a beep.

or

222

3-2. Using the audio system

Repeat play

■ Repeating a track

Press

(RPT) or

(RPT).

■ Repeating all of the tracks on a CD (with CD changer only)

Press and hold

(RPT) or

(RPT) until you hear a beep.

Random playback

■ Current CD

(RAND) or

Press Tracks are played in a random order until the button is pressed once more.

(RAND).

■ All CDs (with CD changer only) (RAND) or

Press and hold beep. Tracks on all loaded CDs are played in a random order until the button is pressed once more.

(RAND) until you hear a

Switching the display

Press

or

Each time the switch is pressed, the display changes in the order of Track no./Elapsed time→CD title→Track name.

223

3-2. Using the audio system

■Display

Up to 12 characters can be displayed at a time. If there are 13 characters or more, pressing and holding 1 second or more will display the remaining characters. A maximum of 24 characters can be displayed. is pressed for 1 second or more again or has not been If pressed for 6 seconds or more, the display will return to the first 12 charac- ters. Depending on the contents recorded, the characters may not be displayed properly or may not be displayed at all.

or

for

or

■Canceling random playback

Press

(RAND) or

(RAND) again.

■Canceling repeat play (RPT) or

Press

■Error messages

(RPT) again.

“ERROR”:This indicates a trouble either in the CD or inside the player.

The CD may be dirty, damaged or inserted up-side down.

■Discs that can be used

Discs with the marks shown below can be used. Playback may not be possible depending on recording format or disc fea- tures, or due to scratches, dirt or deterioration.

CDs with copy-protect features may not be used.

■CD player protection feature

To protect the internal components, playback is automatically stopped when a problem is detected while the CD player is being used.

■If CDs are left inside the CD player or in the ejected position for

extended periods CDs may be damaged and may not play properly.

224

3-2. Using the audio system

■Lens cleaners

Do not use lens cleaners. Doing so may damage the CD player.

NOTICE

■CDs and adapters that cannot be used

Do not use the following types of CDs or 3 in. (8 cm) CD adapters or Dual Disc. Doing so may damage the CD player and/or the CD insert/eject function.

●CDs that have a diameter that is not 4.7

in. (12 cm)

●Low-quality and deformed CDs

●CDs with a transparent or translucent

recording area

225

3-2. Using the audio system

NOTICE

●CDs that have had tape, stickers or CD- R labels attached to them, or that have had the label peeled off

■CD player precautions

Failure to follow the precautions below may result in serious damage to the CDs or the player itself. ●Do not insert anything other than CDs into the CD slot. ●Do not apply oil to the CD player. ●Store CDs away from direct sunlight. ●Never try to disassemble any part of the CD player.

●Do not insert more than one CD at a

time

226

3-2. Using the audio system Playing back MP3 and WMA discs

Type A

Power

Volume

File selection

Disc eject

Fast-forward

Folder selection

Reverse

File selection

Search playback

Repeat play

Display text message

Random playback

Playback

Type B

Power

Volume

Disc selection

Playback

File selection

Fast-forward Disc load

Disc eject

Reverse

Search playback

Random playback

Repeat play

Display text message

File selection

Folder selection

227

3-2. Using the audio system

Loading MP3 and WMA discs

■ Loading a disc (type A)

Insert a disc.

■ Loading a disc (type B)

Press “WAIT” is shown on the display. Insert a disc when the indicator on the slot turns from amber to green. The display changes from “WAIT” to “LOAD”.

■ Loading multiple discs (type B only)

until you hear a beep.

Press and hold “WAIT” is shown on the display. Insert a disc when the indicator on the slot turns from amber to green. The display changes from “WAIT” to “LOAD”. The indicator on the slot turns to amber when the disc is inserted. Insert the next disc when the indicator on the slot turns from amber to green again. Repeat the procedure for the remaining discs. To stop the operation, press

Ejecting MP3 and WMA discs

■ Ejecting a disc (type A)

Press

and remove the disc.

■ Ejecting a disc (type B)

To select the disc to be ejected, press (∧). The number of the disc selected is shown on the display. Press

and remove the disc.

(∨) or

228

3-2. Using the audio system

■ Ejecting all the discs (type B only)

Press and hold discs.

until you hear a beep, and then remove the

Selecting a disc (type B only)

■ Selecting the desired disc (∧).

(∨) or

Press

Selecting a folder

■ Selecting folders one at a time

To select the desired folder, press “∧” or “∨” on

or

■ Selecting the desired folder by cueing the first file of each

folder Press and hold The first 10 seconds of the first file in the each folder will be played. When the desired folder is reached, press the switch once again.

until you hear a beep.

or

■ Returning to the first folder

Press and hold “∨” on

or

until you hear a beep.

Selecting and scanning files

■ Selecting one file at a time

To select the desired file, turn the

or

or press “∧” or

“∨” on

or

229

3-2. Using the audio system

■ Selecting the desired file by cueing the files in the folder

Press

or

The first 10 seconds of all files in the folder will be played. When the desired file is reached, press the switch once again.

Fast-forwarding and reversing files

To fast-forward or reverse. Type A: Press and hold Type B: Press and hold

) or ) or

). ).

Repeat play

■ Repeating a file

Press

(RPT) or

(RPT).

■ Repeating all of the files in the folder

Press and hold

(RPT) or

(RPT) until you hear a beep.

Random playback

■ Playing files from a particular folder in random order

Press

(RAND) or

(RAND).

■ Playing all of the files on a disc in random order

(RAND) or

(RAND) until you hear a

Press and hold beep.

Switching the display

Press

or

Each time the switch is pressed, the display changes in the order of Folder no./File no./Elapsed time→Folder name→File name→Album title (MP3 only)→Track title→Artist name.

230

3-2. Using the audio system

■Display

Up to 12 characters can be displayed at a time. If there are 13 characters or more, pressing and holding 1 second or more will display the remaining characters. A maximum of 24 characters can be displayed. If is pressed for 1 second or more again or has not been pressed for 6 seconds or more, the display will return to the first 12 charac- ters. Depending on the contents recorded, the characters may not be displayed properly or may not be displayed at all.

for

or

or

■Canceling random playback

Press

(RAND) or

(RAND) again.

■Canceling repeat play (RPT) or

Press

■Error messages

(RPT) again.

“ERROR”: This indicates a trouble either in the CD or inside the player.

The CD may be dirty, damaged or inserted up-side down.

“NO MUSIC”:This indicates that the MP3/WMA file is not included in the CD.

■Discs that can be used

Discs with the marks shown below can be used. Playback may not be possible depending on recording format or disc fea- tures, or due to scratches, dirt or deterioration.

■MP3 and WMA player protection feature

To protect the internal components, playback is automatically stopped when a problem is detected while the MP3 and WMA player is being used.

■If discs are left inside the MP3 and WMA player or in the ejected posi-

tion for extended periods Discs may be damaged and may not play properly.

231

3-2. Using the audio system

■Lens cleaners

Do not use lens cleaners. Doing so may damage the MP3 and WMA player.

■MP3 and WMA files

MP3 (MPEG Audio LAYER3) is a standard audio compression format. Files can be compressed to approximately 1/10 of their original size by using MP3 compression. WMA (Windows Media® Audio) is a Microsoft® audio compression format. This format compresses audio data to a size smaller than that of the MP3 format. There is a limit to the MP3 and WMA file standards and to the media/formats recorded by them that can be used. ●MP3 file compatibility

• Compatible standards

MP3 (MPEG1 LAYER3, MPEG2 LSF LAYER3)

• Compatible sampling frequencies

MPEG1 LAYER3: 32, 44.1, 48 (kHz) MPEG2 LSF LAYER3: 16, 22.05, 24 (kHz) • Compatible bit rates (compatible with VBR)

MPEG1 LAYER3: 64, 80, 96, 112, 128, 160, 192, 224, 256, 320 (kbps) MPEG2 LSF LAYER3: 64, 80, 96, 112, 128, 144, 160 (kbps)

• Compatible channel modes: stereo, joint stereo, dual channel and

monaural

●WMA file compatibility

• Compatible standards

WMA Ver. 7, 8, 9

• Compatible sampling frequencies

32, 44.1, 48 (kHz)

• Compatible bit rates (only compatible with 2-channel playback)

Ver. 7, 8: CBR 48, 64, 80, 96, 128, 160, 192 (kbps) Ver. 9: CBR 48, 64, 80, 96, 128, 160, 192, 256, 320 (kbps)

●Compatible media

Media that can be used for MP3 and WMA playback are CD-Rs and CD- RWs. Playback in some instances may not be possible, depending on the status of the CD-R or CD-RW. Playback may not be possible or the audio may jump if the disc is scratched or marked with fingerprints.

232

3-2. Using the audio system

●Compatible disc formats

The following disc formats can be used. • Disc formats: CD-ROM Mode 1 and Mode 2

CD-ROM XA Mode 2, Form 1 and Form 2
• File formats: ISO9660 Level 1, Level 2, (Romeo, Joliet)

MP3 and WMA files written in any format other than those listed above may not play correctly, and their file names and folder names may not be displayed correctly.

Items related to standards and limitations are as follows. • Maximum directory hierarchy: 8 levels • Maximum length of folder names/file names: 32 characters • Maximum number of folders: 192 (including the root) • Maximum number of files per disc: 255

●File names

The only files that can be recognized as MP3/WMA and played are those with the extension .mp3 or .wma.

●Multi-sessions

As the audio system is compatible with multi-sessions, it is possible to play discs that contain MP3 and WMA files. However, only the first session can be played.

●ID3 and WMA tags

ID3 tags can be added to MP3 files, making it possible to record the track title and artist name, etc. The system is compatible with ID3 Ver. 1.0, 1.1, and Ver. 2.2, 2.3 ID3 tags. (The number of characters is based on ID3 Ver. 1.0 and 1.1.) WMA tags can be added to WMA files, making it possible to record the track title and artist name in the same way as with ID3 tags.

●MP3 and WMA playback

When a disc containing MP3 or WMA files is inserted, all files on the disc are first checked. Once the file check is finished, the first MP3 or WMA file is played. To make the file check finish more quickly, we recommend you do not write in any files other than MP3 or WMA files or create any unnec- essary folders. If the discs contain a mixture of music data and MP3 or WMA format data, only music data can be played.

233

3-2. Using the audio system

●Extensions

If the file extensions .mp3 and .wma are used for files other than MP3 and WMA files, they will be mistakenly recognized and played as MP3 and WMA files. This may result in large amounts of interference and damage to the speakers.

●Playback

• To play MP3 file with steady sound quality, we recommend a fixed bit

rate of 128 kbps and a sampling frequency of 44.1 kHz.

• CD-R or CD-RW playback may not be possible in some instances,

depending on the characteristics of the disc.

• There is a wide variety of freeware and other encoding software for MP3 and WMA files on the market, and depending on the status of the encoding and the file format, poor sound quality or noise at the start of playback may result. In some cases, playback may not be possible at all.

• When files other than MP3 or WMA files are recorded on a disc, it may take more time to recognize the disc and in some cases, playback may not be possible at all.

• Microsoft®, Windows®, and Windows Media® are the registered trade-

marks of Microsoft Corporation in the U.S. and other countries.

NOTICE

■CDs and adapters that cannot be used (→P. 225) ■CD player precautions (→P. 226)

234

3-2. Using the audio system Optimal use of the audio system

Type A

Type B

Displays the current mode Changes the following set- ting Sound quality and volume balance (→P. 236) The sound quality and bal- ance setting can be changed to produce the best sound.

Using the AUDIO CONTROL function

■ Changing sound quality modes

selects the mode to be changed in the

or

Pressing following order. BAS → TRE → FAD → BAL

235

3-2. Using the audio system

■ Adjusting sound quality

Turning

or

adjusts the level.

Sound qual-

ity mode

Mode displayed

Level

-5 to 5
-5 to 5

Turn to the

left

Turn to the

right

Low

High

F7 to R7

Shifts to rear

BAS TRE

FAD

BAL

L7 to R7

Shifts to left

Shifts to

front

Shifts to

right

Bass Treble

Front/rear volume balance Left/right volume balance

■Trademark owned by SRS Labs, Inc.

The audio systems utilize SRS FOCUS® and SRS TruBass® audio enhancement technologies, under license from SRS Labs, Inc., in all modes except AM radio mode.

FOCUS, TruBass, SRS and Inc. FOCUS and TruBass technologies are incorporated under license from SRS Labs, Inc.

symbols are trademarks of SRS Labs,

236

3-2. Using the audio system

■Trademark owned by New Transducers Limited

This vehicle incorporates NXT flat panel speaker technology by New Transducers Limited, UK. is a registered trademarks of New Transducers Limited.

237

3-2. Using the audio system Operating the sub woofer∗

Pressing the switch, to oper- ate the sub woofer.

To stop it, press the switch again.

238

∗: If equipped

3-2. Using the audio system Changing display color (type B only)

Display color can be changed by following the procedure below.

Select the function of which you want to change the display color.

Turn the audio system off by pressing

for more than 5 seconds. “TEXT MODE” will

Push appear on the display, and then the system is turned off. Turn the system on.

Change the display color by turning the knob, the display color changes as follows: Amber → Yellow → Yellowgreen → Green → Turquoiseblue → Blue → Purple → Magenta → Red

. When you turn

Set the display color by pressing briefly. The name of the function of which the color was changed will appear on the display. If you want to set that display color for all the function displays, press the knob for 2 seconds. “ALL CHANGE” will appear on the display. To continue to change the display color of other functions, select the function of which you want to change the display color, and repeat steps 5 to 6. Turn the system off by pressing change function ends.

. The display color

239

3-2. Using the audio system Using the AUX adapter

This adapter can be used to connect a portable audio device and lis- ten to it through the vehicle’s speakers.

Connect the portable audio device.

Type A

Press

240

3-2. Using the audio system

Type B

Press

■Operating portable audio devices connected to the audio system

The volume can be adjusted using the vehicle’s audio controls. All other adjustments must be made on the portable audio device itself.

■When using a portable audio device connected to the power outlet or

cigarette lighter Noise may occur during playback. Use the power source of the portable audio device.

241

3-2. Using the audio system Using the steering wheel audio switches∗

Some audio features can be controlled using the switches on the steering wheel.

Volume Radio: Select radio stations CD: Select files (MP3 and WMA) and discs Power on, select audio source

tracks,

Turning on the power

Press

when the audio system is turned off.

The audio system can be turned off by holding the switch down until the system turns off.

Changing the audio source

when the audio system is turned on. The audio source

Press changes as follows each time CD player without changer:

is pressed.

FM1→FM2→CD→AUX→AM

CD player with changer:

FM1→FM2→CD changer→AUX→AM→SAT1→SAT2→SAT3

242

∗: If equipped

3-2. Using the audio system

Adjusting the volume

Press “+” on volume.

to increase the volume and “–” to decrease the

Press and hold “+” or “–” on the volume.

Selecting a radio station

to continue increasing or decreasing

to select the radio mode.

Press Press “∧” or “∨” on To scan for receivable stations, press and hold the switch until you hear a beep.

to select a preset station.

Selecting a track/file

to select the CD mode.

Press Press “∧” or “∨” on

to select the desired track/file.

Selecting a disc in the CD player (CD player with changer only)

to select the CD mode.

Press Press and hold “∧” or “∨” on set.

until you want to listen to is

CAUTION

■To reduce the risk of an accident

Exercise care when operating the audio switches on the steering wheel.

243

3-3. Using the interior lights Interior lights list

Rear interior light (→P. 245) Front interior light (→P. 245) Personal lights (→P. 246) Engine switch light

■Illuminated entry system

When the interior light switch is in the DOOR position, the interior light and engine switch light automatically turns on/off according to whether the doors are locked/unlocked and whether the doors are open/closed and the engine switch position.

■To prevent the battery from being discharged

If the interior light remains on when the door is not fully closed and the inte- rior light switch is in the DOOR position, the light will go off automatically after 30 minutes.

244

3-3. Using the hand-free phone system (for cellular system

Interior lights

■Customization that can be configured at Toyota dealer

Settings (e.g. The time elapsed before lights turn off) can be changed. (Customizable features →P. 412)

Interior lights

Front

Rear

DOOR position OFF ON

DOOR position OFF ON

245

3-3. Using the hands-free phone system (for cellular phone)

Personal lights

Personal lights

On/off

■To prevent the battery from being discharged

The personal lights will automatically turn off in about 30 minutes after the key is removed from the engine switch.

246

3-4. Using the storage features List of storage features

Glove box

Auxiliary box Glove box Bottle holders Cup holders

Glove box

Pull up the lever.

247

3-4. Using the storage features

CAUTION

■Caution while driving

Glove box and cup holders (front)

Keep the glove box closed. Injuries may result in the event of an accident or sudden braking.

Cup holders (front)

Vehicles with an automatic transmission

248

3-4. Using the storage features

Cup holders (front)

Vehicles with a manual transmission

■Holding large cups

Vehicles with an automatic transmission

Remove the adapter.

249

3-4. Using the storage features

Cup holders (front)

Vehicles with a manual transmission

Remove the adapter.

CAUTION

■Items unsuitable for the cup holder

Do not place anything other than cups or aluminum cans in the cup holders. Other items may be thrown out of the holders in the event of an accident or sudden braking and cause injury. If possible, cover hot drinks to prevent burns.

250

3-4. Using the storage features

Cup holders (rear)

Cup holders (rear)

■Removing the mat

Pull up.

CAUTION

■Items unsuitable for the cup holder

Do not place anything other than cups or aluminum cans in the cup holders. Other items may be thrown out of the holders in the event of an accident or sudden braking and cause injury. If possible, cover hot drinks to prevent burns.

251

3-4. Using the storage features

Bottle holders

Bottle holders

■Bottle holders

Depending on their size or shape, some bottles may not fit in the holders.

NOTICE

■Items that should not be stowed in the bottle holders

Put the cap on before stowing a bottle. Do not place open bottles in the bot- tle holders, or glasses and paper cups containing liquid. The contents may spill and glasses may break.

252

3-4. Using the storage features

Auxiliary box

Auxiliary box

Push the button.

Pull up the lid.

CAUTION

■Items that should not be left in the auxiliary box

Do not leave anything flammable or deformable, such as a lighter or glasses in the box. If the interior of the vehicle becomes hot, flammable objects such as lighters may explode, and objects that can be damaged by heat, such as glasses or cellular phones may warp or crack.

■Caution while driving

Do not leave the auxiliary box open while driving. Items may fall out and cause death or serious injury in case of an accident or sudden stop.

253

Forward position: Flip down. Side position: Flip down, unhook, and swing to the side.

Flip down.

3-5. Other interior features Sun visors

Front

Side

254

3-5. Other interior features Vanity mirrors

Open the cover.

255

3-5. Other interior features Clock

Adjusts the hours Adjusts the minutes

■The clock is displayed when

The engine switch is in the ACC or ON position.

■When disconnecting and reconnecting battery terminals

The time display will automatically be set to 1:00.

256

3-5. Other interior features Outside temperature display∗

the outside air

Displays temperature. The temperature range that can be displayed is from -22°F (-30°C) to 122°F (50°C). the outside air Switches temperature display between English/U.S. Cus- tomary System and metric.

■When – –°C or – –°F is displayed

The system may be malfunctioning. Take your vehicle to your Toyota dealer.

■The outside air temperature is displayed when

The engine switch is in the ON position.

■When disconnecting and reconnecting battery terminals

The display will automatically be set to the initial mode.

■Display

In the following situations, the correct outside temperature may not be dis- played, or the display may take longer than normal to change. ●When stopped, or driving at low speeds (less than 12 mph [20 km/h]) ●When the outside temperature has changed suddenly (at the entrance/

exit of a garage, tunnel, etc.)

∗: If equipped 257

3-5. Other interior features Power outlet (12V DC)

The power outlet can be used for 12 V accessories that run on less than 10A.

■The power outlet can be used when

The engine switch is in the ACC or ON position.

NOTICE

■To avoid damaging the power outlet

Close the power outlet lid when not in use. Foreign objects or liquids that enter the power outlet may cause a short cir- cuit.

■To prevent the fuse from being blown

Do not use an accessory that uses more than 12V/10A.

■To prevent the battery discharge

Do not use the power outlet longer than necessary when the engine is not running.

258

3-5. Other interior features Power outlet (115V AC)∗

The power outlet can be used for electrical appliances. ■ Operation

Main switch To use the power outlet, turn on the main switch. The power supply starts a few seconds after the main switch is pressed. Power outlet socket

∗: If equipped 259

3-5. Other interior features

Maximum available capacity of the power outlet

■ While the vehicle is being driven

The maximum capacity of the power outlet is always 115V AC/ 100W.

■ When the vehicle is stationary

The maximum capacity of the power outlet varies depending on the following conditions. ● The maximum capacity is 115V AC/400W when the following

condition applies: • The shift lever is in P or N. (automatic transmission) • The shift lever is in N and the clutch pedal is not depressed.

(manual transmission)

A maximum capacity of 400W can only be restored by turning the power outlet main switch off and then on again under condi- tion described above.

● The maximum capacity is 115V AC/100W when the following

condition applies: • The shift lever is moved to any positions other than P and N.

(automatic transmission)

• The clutch pedal is depressed. (manual transmission)

260

3-5. Other interior features

■The power outlet can be used when

The engine is started.

■The indicator light changes according the maximum available capacity,

as follows:

Indicates 115V AC/400W Indicates 115V AC/100W

■When the power outlet is in operation

The sound of the cooling fan may be heard from the right side of the luggage compartment. This is normal and does not indicate a malfunction. ■If the engine is started with the power outlet main switch on

The maximum capacity of the power supply may decrease to below the stan- dard, or may be cut off completely, even when the vehicle is stationary.

■The protection circuit may be activated to cut the power supply if any

of the following conditions apply: ●The engine is started with the power outlet main switch on. ●Use of electrical appliances exceeding the maximum capacity is

attempted. A sound may be heard when the protection circuit is activated. This is normal and does not indicate a malfunction.

●Electrical appliances, which consume power exceeding 100W, have

been used continuously for a long time period.

●The total power usage by all electrical features (headlights, air condition- ing, etc.) has exceeded the total vehicle maximum for an extended period of time.

261

3-5. Other interior features

■If the protection circuit is activated and the power supply is cut, con-

duct the following procedure:

Park the vehicle in a safe place, and then securely apply the park- ing brake. Check and ensure the following conditions • The shift lever is in P or N. (automatic transmission)
