2010 Toyota Corolla Owners Manual

(Type A) Rear turn signal lights (Type B) Stop/tail and rear side marker lights License plate lights Back-up lights Personal lights or Per- sonal/Interior lights Interior light Trunk light

⎯

⎯

B: HB3 halogen bulbs D: Wedge base bulbs (amber) F: H11 halogen bulbs

Type

Exterior

Interior

A: HB4 halogen bulbs C: Wedge base bulbs (clear) E: Single end bulbs (clear) G: Double end bulbs

436

6-1. Specifications Fuel information

You must only use unleaded gasoline in your vehicle. Select octane rating 87 (Research Octane Number 91) or higher. Use of unleaded gasoline with an octane rating lower than 87 may result in engine knocking. Persistent knocking can lead to engine damage. At minimum, the gasoline you use should meet the specifications of ASTM D4814 in the U.S.A. and CGSB3.5-M93 in Canada.

■Fuel tank opening for unleaded gasoline

To help prevent incorrect fueling, your Toyota has a fuel tank opening that only accommodates the special nozzle on unleaded fuel pumps.

■If your engine knocks

●Consult your Toyota dealer. ●You may occasionally notice light knocking for a short time while acceler-

ating or driving uphill. This is normal and there is no need for concern.

■Gasoline quality

In very few cases, driveability problems may be caused by the brand of gas- oline you are using. If driveability problems persist, try changing the brand of gasoline. If this does not correct the problem, consult your Toyota dealer.

■Gasoline quality standards

●Automotive manufacturers in the U.S., the Europe and Japan have developed a specification for fuel quality called World-Wide Fuel Charter (WWFC) that is expected to be applied worldwide.

●The WWFC consists of four categories that are based on required emis-

sion levels. In the U.S., category 4 has been adopted.

●The WWFC improves air quality by lowering emissions in vehicle fleets,

and improves customer satisfaction through better performance.

437

6-1. Specifications

■Toyota recommends the use of gasoline containing detergent additives ●Toyota recommends the use of gasoline that contains detergent additives

to avoid build-up of engine deposits.

●All gasoline sold in the U.S. contains detergent additives to clean and/or

keep clean intake systems.

■Toyota recommends the use of cleaner burning gasoline

Cleaner burning gasoline, including reformulated gasoline that contains oxy- genates such as ethanol or MTBE (Methyl Tertiary Butyl Ether) is available in many areas. Toyota recommends the use of cleaner burning gasoline and appropriately blended reformulated gasoline. These types of gasoline provide excellent vehicle performance, reduce vehicle emissions and improve air quality.

■Toyota does not recommend blended gasoline

●Toyota allows the use of oxygenate blended gasoline where the oxygen-

ate content is up to 10% ethanol or 15% MTBE.

●If you use gasohol in your Toyota, be sure that it has an octane rating no

lower than 87.

●Toyota does not recommend the use of gasoline containing methanol.

■Toyota does not recommend gasoline containing MMT

Some gasoline contains octane enhancing additive called MMT (Methylcy- clopentadienyl Manganese Tricarbonyl). Toyota does not recommend the use of gasoline that contains MMT. If fuel containing MMT is used, your emission control system may be adversely affected. The malfunction indicator lamp on the instrument cluster may come on. If this happens, contact your Toyota dealer for service.

438

6-1. Specifications

NOTICE

■Notice on fuel quality

●Do not use improper fuels. If improper fuels are used the engine will be

damaged.

●Do not use leaded gasoline.

Leaded gasoline can cause damage to your vehicle’s catalytic converters causing the emission control system to malfunction.

●Do not use gasohol other than that stated here.

Other gasohol may cause fuel system damage or vehicle performance problems.

●Using unleaded gasoline with an octane number or rating lower than that

stated here will cause persistent heavy knocking. At worst, this will lead to engine damage.

■Fuel-related poor driveability

If after using a different type of fuel, poor driveability is encountered (poor hot starting, vaporization, engine knocking, etc.), discontinue the use of that type of fuel.

■When refueling with gasohol

Take care not to spill gasohol. It can damage your vehicle's paint.

439

6-1. Specifications Tire information

Typical tire symbols

Full-size tire

Compact spare tire

Tire size DOT and Tire Identification Number (TIN) Uniform tire quality grading For details, see “Uniform Tire Quality Grading” that follows. Location of treadwear indicators

(→P. 443) (→P. 442)

(→P. 329)

440

6-1. Specifications

Tire ply composition and materials Plies are layers of rubber-coated parallel cords. Cords are the strands which form the plies in a tire. Radial tires or bias-ply tires A radial tire has “RADIAL” on the sidewall. A tire not marked “RADIAL” is a bias-ply tire. TUBELESS or TUBE TYPE A tubeless tire does not have a tube and air is directly filled in the tire. A tube type tire has a tube inside the tire and the tube main- tains the air pressure. Load limit at maximum cold tire inflation pressure

(→P. 332) (→P. 434)

Maximum cold tire inflation pressure This means the pressure to which a tire may be inflated. Summer tires or all season tires (→P. 333) An all season tire has “M+S” on the sidewall. A tire not marked “M+S” is a summer tire. (→P. 400) “TEMPORARY USE ONLY” A compact spare tire is identified by the phrase “TEMPORARY USE ONLY” molded into its sidewall. This tire is designed for temporary emergency use only.

441

6-1. Specifications

Typical DOT and Tire Identification Number (TIN)

Identification Number

DOT symbol* Tire (TIN) Tire manufacturer's identifica- tion mark Tire size code Manufacturer's optional type code (3 or 4 letters) Manufacturing week Manufacturing year

tire

*: The DOT symbol certifies that the tire conforms to applicable Federal Motor Vehicle Safety Standards.

442

Tire size

■ Typical tire size information

■ Tire dimensions

6-1. Specifications

The illustration indicates typical tire size.

Tire use (P = Passenger car, T = Temporary use) Section width (millimeters) Aspect ratio (tire height to section width) Tire construction code (R = Radial, D = Diagonal) Wheel diameter (inches) Load index (2 or 3 digits) Speed symbol (alphabet with one letter)

Section width Tire height Wheel diameter

443

6-1. Specifications

Tire section names

Bead Sidewall Shoulder Tread Belt Inner liner Reinforcing rubber Carcass Rim lines Bead wires Chafer

Uniform Tire Quality Grading

This information has been prepared in accordance with regulations issued by the National Highway Traffic Safety Administration of the U.S.A. Department of Transportation. It provides the purchasers and/or prospective purchasers of Toyota vehicles with information on uniform tire quality grading.

Your Toyota dealer will help answer any questions you may have as you read this information.

■ DOT quality grades

All passenger vehicle tires must conform to Federal Safety Requirements in addition to these grades. Quality grades can be found where applicable on the tire sidewall between tread shoulder and maximum section width. For example: Treadwear 200 Traction AA Temperature A

444

6-1. Specifications

■ Treadwear

The treadwear grade is a comparative rating based on the wear rate of the tire when tested under controlled conditions on a speci- fied government test course. For example, a tire graded 150 would wear one and a half (1-1/2) times as well on the government course as a tire graded 100. The relative performance of tires depends upon the actual conditions of their use, however, and may depart significantly from the norm due to variations in driving habits, service practices and differences in road characteristics and climate.

■ Traction AA, A, B, C

The traction grades, from highest to lowest, are AA, A, B and C, and they represent the tire's ability to stop on wet pavement as measured under controlled conditions on specified government test surfaces of asphalt and concrete. A tire marked C may have poor traction performance. Warning: The traction grade assigned to this tire is based on braking (straight ahead) traction tests and does not include cornering (turn- ing) traction.

■ Temperature A, B, C

The temperature grades are A (the highest), B, and C, represent- ing the tire's resistance to the generation of heat and its ability to dissipate heat when tested under controlled conditions on a speci- fied indoor laboratory test wheel. Sustained high temperature can cause the material of the tire to degenerate and reduce tire life, and excessive temperature can lead to sudden tire failure. The grade C corresponds to a level of performance which all passen- ger car tires must meet under the Federal Motor Vehicle Safety Stan- dard No.109. Grades B and A represent higher levels of performance on the labo- ratory test wheel than the minimum required by law.

445

6-1. Specifications

Warning: The temperature grades for this tire are established for a tire that is properly inflated and not overloaded. Excessive speed, underinflation, or excessive loading, either sepa- rately or in combination, can cause heat buildup and possible tire fail- ure.

Glossary of tire terminology

Tire related term

Meaning

Cold tire inflation pres- sure

Maximum inflation pressure

Recommended infla- tion pressure

Accessory weight

Curb weight

Maximum loaded vehi- cle weight

Tire pressure when the vehicle has been parked for three hours or more, or has not been driven more than 1 mile or 1.5 km under that condition The maximum cold inflated pressure to which a tire may be inflated, shown on the sidewall of the tire Cold tire inflation pressure recommended by a manufacturer The combined weight (in excess of those stan- dard items which may be replaced) of auto- matic transmission, power steering, power brakes, power windows, power seats, radio and heater, to the extent that these items are available as factory-installed equipment (whether installed or not) The weight of a motor vehicle with standard equipment, including the maximum capacity of fuel, oil and coolant, and if so equipped, air conditioning and additional weight optional engine The sum of: (a) Curb weight (b) Accessory weight (c) Vehicle capacity weight (d) Production options weight

446

6-1. Specifications

Tire related term

Normal occupant weight

Occupant distribution

Production options weight

Rim

Rim diameter (Wheel diameter) Rim size designation

Rim type designation

Rim width Vehicle capacity weight (Total load capacity)

Vehicle maximum load on the tire

Vehicle normal load on the tire

Meaning

150 lb. (68 kg) times the number of occupants specified in the second column of Table 1* that follows Distribution of occupants in a vehicle as speci- fied in the third column of Table 1* below The combined weight of installed regular pro- duction options weighing over 5 lb. (2.3 kg) in excess of the standard items which they replace, not previously considered in curb weight or accessory weight, including heavy duty brakes, ride levelers, roof rack, heavy duty battery, and special trim A metal support for a tire or a tire and tube assembly upon which the tire beads are seated

Nominal diameter of the bead seat

Rim diameter and width The industry manufacturer's designation for a rim by style or code Nominal distance between rim flanges The rated cargo and luggage load plus 150 lb. (68 kg) times the vehicle's designated seating capacity The load on an individual tire that is determined by distributing to each axle its share of the maximum loaded vehicle weight, and dividing by two The load on an individual tire that is determined by distributing to each axle its share of curb weight, accessory weight, and normal occu- pant weight (distributed in accordance with Table 1* below), and dividing by two

447

6-1. Specifications

Tire related term

Weather side

Bead

Bead separation

Bias ply tire

Carcass

Chunking

Cord

Cord separation

Cracking

CT

Extra load tire

Groove

Innerliner

448

Meaning

The surface area of the rim not covered by the inflated tire The part of the tire that is made of steel wires, wrapped or reinforced by ply cords and that is shaped to fit the rim A breakdown of the bond between components in the bead A pneumatic tire in which the ply cords that extend to the beads are laid at alternate angles substantially less than 90 degrees to the cen- terline of the tread The tire structure, except tread and sidewall rubber which, when inflated, bears the load The breaking away of pieces of the tread or sidewall The strands forming the plies in the tire The parting of cords from adjacent rubber com- pounds Any parting within the tread, sidewall, or inner- liner of the tire extending to cord material A pneumatic tire with an inverted flange tire and rim system in which the rim is designed with rim flanges pointed radially inward and the tire is designed to fit on the underside of the rim in a manner that encloses the rim flanges inside the air cavity of the tire A tire designed to operate at higher loads and at higher inflation pressures than the corre- sponding standard tire The space between two adjacent tread ribs The layer(s) forming the inside surface of a tubeless tire that contains the inflating medium within the tire

Tire related term

Innerliner separation

Intended outboard sidewall

Light truck (LT) tire

Load rating

Maximum load rating

Maximum permissible inflation pressure

Measuring rim

Open splice

Outer diameter

Overall width

Passenger car tire

6-1. Specifications

Meaning

The parting of the innerliner from cord material in the carcass (a) The sidewall that contains a whitewall, bears white lettering, or bears manufac- turer, brand, and/or model name molding that is higher or deeper than the same molding on the other sidewall of the tire, or

(b) The outward facing sidewall of an asym-

metrical tire that has a particular side that must always face outward when mounted on a vehicle

A tire designated by its manufacturer as prima- rily intended for use on lightweight trucks or multipurpose passenger vehicles The maximum load that a tire is rated to carry for a given inflation pressure The load rating for a tire at the maximum per- missible inflation pressure for that tire The maximum cold inflation pressure to which a tire may be inflated The rim on which a tire is fitted for physical dimension requirements Any parting at any junction of tread, sidewall, or innerliner that extends to cord material The overall diameter of an inflated new tire The linear distance between the exteriors of the sidewalls of an inflated tire, including eleva- tions due to labeling, decorations, or protective bands or ribs A tire intended for use on passenger cars, mul- tipurpose passenger vehicles, and trucks, that have a gross vehicle weight rating (GVWR) of 10,000 lb. or less.

449

6-1. Specifications

Tire related term

Ply

Ply separation

Pneumatic tire

Radial ply tire

Reinforced tire

Section width

Sidewall

Sidewall separation

Snow tire

Test rim

450

Meaning

A layer of rubber-coated parallel cords A parting of rubber compound between adja- cent plies A mechanical device made of rubber, chemi- cals, fabric and steel or other materials, that, when mounted on an automotive wheel, pro- vides the traction and contains the gas or fluid that sustains the load A pneumatic tire in which the ply cords that extend to the beads are laid at substantially 90 degrees to the centerline of the tread A tire designed to operate at higher loads and at higher inflation pressures than the corre- sponding standard tire The linear distance between the exteriors of the sidewalls of an inflated tire, excluding ele- vations due to labeling, decoration, or protec- tive bands That portion of a tire between the tread and bead The parting of the rubber compound from the cord material in the sidewall A tire that attains a traction index equal to or greater than 110, compared to the ASTM E-1136 Standard Reference Test Tire, when using the snow traction test as described in ASTM F-1805-00, Standard Test Method for Single Wheel Driving Traction in a Straight Line on Snow-and Ice-Covered Surfaces, and which is marked with an Alpine Symbol ( least one sidewall The rim on which a tire is fitted for testing, and may be any rim listed as appropriate for use with that tire

) on at

6-1. Specifications

Tire related term

Meaning

Tread

Tread rib

Tread separation

Treadwear indicators (TWI)

That portion of a tire that comes into contact with the road A tread section running circumferentially around a tire Pulling away of the tread from the tire carcass The projections within the principal grooves designed to give a visual indication of the degrees of wear of the tread The fixture used to hold the wheel and tire assembly securely during testing

Wheel-holding fixture *: Table 1 ⎯ Occupant loading and distribution for vehicle normal load

for various designated seating capacities

Designated seating capacity, Number of

occupants 2 through 4

5 through 10

11 through 15

16 through 20

Vehicle normal load, Number of occupants

Occupant distribution in a normally loaded vehi-

cle

2 in front

2 in front, 1 in second

seat

2 in front, 1 in second seat, 1 in third seat, 1

in fourth seat

2 in front, 2 in second seat, 2 in third seat, 1

in fourth seat

451

6-2. Customization Customizable features

Your vehicle includes a variety of electronic features that can be per- sonalized to your preferences. Programming these preferences requires specialized equipment and may be performed by your Toyota dealer. Some function settings are changed simultaneously with other functions being customized. Contact your Toyota dealer.

Item

Function

Default setting

Smart key system (if equipped) (→P. 23)

Smart key system Operation signal (Emergency flashers) Operation signal (Buzzer)

On

On

On

Customized

setting

Off

Off

Off

452

6-2. Customization

Item

Function

Default setting

Wireless remote control

On

Customized

setting

Off

Wireless remote con- trol (if equipped) (→P. 33)

Unlocking operation

Automatic door lock function to be activated if door is not opened after being unlocked Time elapsed before automatic door lock function is activated if door is not opened after being unlocked Operation signal (Emergency flashers) Operation signal (Buzzer) Door lock buzzer Panic function Trunk unlocking func- tion

Driver's door unlocked in one step, all doors unlocked in two

steps

All doors

unlocked in one

step

On

Off

60 seconds

30 seconds

120 seconds

On

On

On On

On

Off

Off

Off Off

Off

Trunk unlocking opera- tion

Press and hold

Press twice

One short press

453

6-2. Customization

Item

Function

Default setting

Customized

setting

Driver's door unlocked in one step, all doors unlocked in two

steps

All doors

unlocked in one

step

Off

Off

On

On

On

On

Off

Off

Door lock (vehicles with power door lock system) (→P. 38)

Unlocking using a key

Speed-detecting auto- matic door lock function (vehicles with smart key system) Opening driver's door unlocks all doors Shifting gears to P unlocks all doors. (vehi- cles with an automatic transmission) Shifting gears to posi- tion other than P locks all doors. (vehicles with an automatic transmis- sion)

454

Item

Function

Default setting

Time elapsed before lights turn off (vehicles with power door lock system) Operation when the doors are unlocked (vehicles with power door lock system) Vehicles with smart key system: Operation after the “ENGINE START STOP” switch is turned OFF Vehicles without smart key system: Operation after the engine switch is turned to the “LOCK” position Vehicle speed linked seat belt reminder buzzer

Illumination (→P. 264)

Seat belt reminder (→P. 384)

6-2. Customization

Customized

setting

7.5 seconds

30 seconds

15 seconds

On

Off

On

Off

On

Off

455

6-3. Initialization Items to initialize

The following items must be initialized for normal system operation in cases such as after maintenance is performed on the vehicle.

Item

When to initialize

Reference

Engine oil mainte- nance data (U.S.A. only) Tire pressure warning system (if equipped)

After changing engine oil

When changing the tire size.

P. 318

P. 330

456

Reporting safety defects for U.S. owners

If you believe that your vehicle has a defect which could cause a crash or could cause injury or death, you should immediately inform the National Highway Traffic Safety Administration (NHTSA) in addition to notifying Toyota Motor Sales, U.S.A., Inc. (Toll-free: 1-800-331-4331). If NHTSA receives similar complaints, it may open an investigation, and if it finds that a safety defect exists in a group of vehicles, it may order a recall and remedy campaign. However, NHTSA can- not become involved in individual problems between you, your dealer, or Toyota Motor Sales, U.S.A., Inc. To contact NHTSA, you may call the Vehicle Safety Hotline toll-free at 1-888-327-4236 to http:// www.safercar.gov ; or write to: Administrator, NHTSA, 1200 New Jersey Ave, S.E., Washington, DC 20590. You can also obtain other from http:// www.safercar.gov.

information about motor vehicle safety

(TTY: 1-800-424-9153); go

458

Seat belt instructions for Canadian owners (in French)

The following is a French explanation of seat belt instructions extracted from the seat belt section in this manual. See the seat belt section for more detailed seat belt instructions in English.

Utilisation correcte des ceintures de sécurité

qu'elle

● Tendez la sangle diagonale de sorte couvre complètement l'épaule, sans entrer en contact avec le cou ou glisser de l'épaule.

● Placez la sangle abdominale le plus bas possible sur les hanches.

● Réglez la position du dossier de siège. Asseyez-vous le dos le plus droit possible et calez- vous bien dans le siège.

● Ne vrillez pas la ceinture de

sécurité.

459

Guide de confort de ceinture de sécurité (sièges arrière extérieurs)

Si la sangle diagonale gêne la personne au niveau du cou, utilisez le guide confort de la ceinture de sécurité.

Sortez le guide confort de sa poche.

Engagez guide.

la ceinture dans

le

Le cordon élastique doit passer sous la ceinture de sécurité.

Bouclez, positionnez et lâchez la ceinture de sécurité.

ÉTAPE

ÉTAPE

ÉTAPE

460

Entretien et soin

■ Ceintures de sécurité

Nettoyez avec un chiffon ou une éponge humectée d'eau savonneuse vérifier régulièrement que les ceintures ne sont pas effilochées, entaillées, ou ne paraissent pas exagérément usées.

tiède. Profitez de

l'occasion pour

ATTENTION

■ Détérioration et usure des ceintures de sécurité

Inspectez les ceintures de sécurité périodiquement. Contrôlez qu'elles ne sont pas entaillées, effilochées, et que leurs ancrages ne sont pas desserrés. N'utilisez pas une ceinture de sécurité défectueuse avant qu'elle ne soit remplacée. Une ceinture de sécurité défectueuse n'apporte aucune garantie de protection de l'occupant en cas d'accident.

461

462

What to do if... What to do if...

A tire punctures

P. 393 If you have a flat tire

The engine does not start

P. 404 If the engine will not start P. 77 Engine immobilizer system P. 410 If the battery is discharged P. 408 If the electronic key does not oper-

ate properly

The shift lever cannot be moved out

P. 406 If the shift lever cannot be shifted

from P

The engine coolant temperature gauge enters the red zone

Steam can be seen coming from under the hood

P. 416 If your vehicle overheats

The key is lost

P. 407 If you lose your keys

The battery runs out

P. 410 If the battery is discharged

The doors cannot be locked

P. 38 Doors

The vehicle is stuck in mud or sand

P. 419 If the vehicle becomes stuck

A warning light or indicator light comes on

P. 382 If a warning light turns on or a

warning buzzer sounds...

473

What to do if...

Optitron type meters

Non-Optitron type meters

474

■Warning lights

or

or

or

Brake system warning light

P. 382

Charging system warn- ing light P. 382

Low engine oil pressure warning light P. 382

Malfunction indicator lamp

P. 383

SRS warning light

P. 383

ABS warning light

P. 383

Engine oil replacement reminder light P. 384

What to do if...

Tire pressure warning light P. 384

Low windshield washer fluid level warning light

P. 384

Electric power steering warning light P. 383

Open door warning light P. 384

Low fuel level warning light P. 384

Driver’s seat belt reminder light

P. 384

Front passenger’s seat belt reminder light P. 384

Smart key system warn- ing light

P. 391

475

GAS STATION INFORMATION

Auxiliary catch lever

Trunk opener

P. 309

P. 44

Fuel filler door

P. 73

Hood lock release lever

Fuel filler door opener

Tire inflation pressure

P. 309

P. 73

P. 434

Fuel tank capacity (Reference) Fuel type Cold tire inflation pressure

13.2 gal. (50 L, 10.9 Imp. gal.)

Unleaded gasoline only

P. 74, 428
P. 434

Engine oil capacity (Drain and refill ⎯ reference)

Engine oil type

1.8 L 4-cyl- inder (2ZR- FE) engine 2.4 L 4-cyl- inder (2AZ- FE) engine

With filter Without filter

With filter Without filter

qt. (L, Imp. qt.) 4.4 (4.2, 3.7) 4.1 (3.9, 3.4)

4.0 (3.8, 3.3) 3.8 (3.6, 3.2)

P. 429

476
