2015 Toyota Avalon Owners Manual

Open door warning light (warning buzzer)*1
Indicates that a door or the trunk is not fully closed

Correction procedure

Check that all the doors and the trunk are closed.

Refuel the vehicle.

Fasten the seat belt.

the

If front passenger’s seat is occupied, the front passenger’s seat belt also needs to be fastened to make the warning light (warning buzzer) off.

P. 399

fuel

level warning

Low light

Indicates remaining fuel is approximately 2.6 gal. (9.7
L, 2.1 Imp. gal.) or less

light

Seat belt reminder (warning buzzer)*2
Warns the driver and/or front passenger to fasten their seat belts

Master warning light

A buzzer sounds and the warning light comes on and flashes to indicate that the master warning system has detected a malfunc- tion.

AVALON (U)_(OM41456U)

392

7-2. Steps to take in an emergency

Warning light

Warning light/Details

Correction procedure

Tire pressure warning light

When the light comes on: Low tire inflation pressure such as

• Natural causes

(P. 394)

• Flat tire (P. 400)

the

tire

Adjust inflation pressure to the specified level.

The light will turn off after a few minutes. In case the light does not turn off even if the tire inflation pressure is adjusted, have the system checked by your Toyota dealer.

When the light comes on after blinking for 1 minute: Malfunction in the tire pres- sure warning system

Have the system checked by your Toyota dealer.

AVALON (U)_(OM41456U)

7-2. Steps to take in an emergency

393

*1: Open door warning buzzer:

A buzzer will sound if the vehicle reaches a speed of 3 mph (5 km/h) or more with any door open. *2: Driver’s seat belt buzzer:

The driver’s seat belt buzzer sounds to alert the driver that his or her seat belt is not fastened. Once the engine switch is turned to IGNITION ON mode, the buzzer sounds for 6 seconds. If the vehicle reaches a speed of 12 mph (20 km/h), the buzzer sounds once. If the seat belt is still unfas- tened after 30 seconds, the buzzer will sound intermittently for 10 seconds. Then, if the seat belt is still unfastened, the buzzer will sound in a different tone for 20 more seconds. Front passenger’s seat belt buzzer: The front passenger’s seat belt buzzer sounds to alert the front passenger that his or her seat belt is not fastened. The buzzer sounds once if the vehicle reaches a speed of 12 mph (20 km/h). If the seat belt is still unfas- tened after 30 seconds, the buzzer will sound intermittently for 10 seconds. Then, if the seat belt is still unfastened, the buzzer will sound in a different tone for 20 more seconds.

AVALON (U)_(OM41456U)

394

7-2. Steps to take in an emergency

■SRS warning light

This warning light system monitors the airbag sensor assembly, front impact sensors, side impact sensors (front), side impact sensors (rear), driver’s seat belt buckle switch, front passenger occupant classification system, “AIR BAG ON” indicator light, “AIR BAG OFF” indicator light, front passenger’s seat belt buckle switch, seat belt pretensioners, airbags, interconnecting wiring and power sources. (P. 35)

■Front passenger detection sensor, seat belt reminder and warning

buzzer If luggage is placed on the front passenger seat, the front passenger detec- tion sensor may cause the warning light to flash and the warning buzzer to sound even if a passenger is not sitting in the seat.

■If the malfunction indicator lamp comes on while driving

First check the following: ●Is the fuel tank empty?

If it is, fill the fuel tank immediately.

●Is the fuel tank cap loose?

If it is, tighten it securely.

The light will go off after several driving trips. If the light does not go off even after several trips, contact your Toyota dealer as soon as possible.

■Electric power steering system warning light (warning buzzer)

When the battery charge becomes insufficient or the voltage temporarily drops, the electric power steering system warning light may come on and the warning buzzer may sound.

■When the tire pressure warning light comes on

Check the tire inflation pressure and adjust to the appropriate level. Push- ing the tire pressure warning reset switch will not turn off the tire pressure warning light.

■The tire pressure warning light may come on due to natural causes The tire pressure warning light may come on due to natural causes such as natural air leaks and tire inflation pressure changes caused by temper- ature. In this case, adjusting the tire inflation pressure will turn off the warning light (after a few minutes).

AVALON (U)_(OM41456U)

7-2. Steps to take in an emergency

395

■When a tire is replaced with a spare tire

The compact spare tire is not equipped with a tire pressure warning valve and transmitter. If a tire goes flat, the tire pressure warning light will not turn off even though the flat tire has been replaced with the spare tire. Replace the spare tire with the repaired tire and adjust the tire inflation pressure. The tire pressure warning light will go off after a few minutes.

■Conditions that the tire pressure warning system may not function

properly The tire pressure warning system will be disabled in the following condi- tions: (When the condition becomes normal, the system will work properly.) ●If tires not equipped with tire pressure warning valves and transmitters

are used

●If the ID code on the tire pressure warning valves and transmitters is not

registered in the tire pressure warning computer.

●If the tire inflation pressure is 73 psi (500 kPa, 5.1 kgf/cm2 or bar) or

higher

The tire pressure warning system may be disabled in the following condi- tions: (When the condition becomes normal, the system will work properly.) ●If electronic devices or facilities using similar radio wave frequencies are

nearby.

●If a radio set at a similar frequencies is in use in the vehicle ●If a window tint that affects the radio wave signals is installed ●If there is a lot of snow or ice on the vehicle, particularly around the

wheels or wheel housings

●If non-genuine Toyota wheels are used. (Even if you use Toyota wheels, the tire pressure warning system may not work properly with some types of tires.)

●If tire chains are used

■If the tire pressure warning light frequently comes on after blinking

for 1 minute If the tire pressure warning light frequently comes on after blinking for 1
minute when the engine switch is turned to IGNITION ON mode, have it checked by your Toyota dealer.

■Warning buzzer

In some cases, the buzzer may not be heard because of noisy place or an audio sound.

AVALON (U)_(OM41456U)

396

7-2. Steps to take in an emergency

CAUTION

■If both the ABS and the brake system warning lights remain on

Stop your vehicle in a safe place immediately and contact your Toyota dealer. The vehicle will become extremely unstable during braking, and the ABS system may fail, which could cause an accident resulting in death or serious injury.

■When the electric power steering system warning light comes on

The steering wheel may become extremely heavy. If the steering wheel becomes heavier than usual when operating, hold firmly and operate using more force than usual. ■If the tire pressure warning light comes on

Be sure to observe the following precautions. Failure to do so could cause a loss of vehicle control and result in death or serious injury. ●Stop your vehicle in a safe place as soon as possible. Adjust the tire

inflation pressure immediately.

●If the tire pressure warning light comes on even after tire inflation pres- sure adjustment, it is probable that you have a flat tire. Check the tires. If a tire is flat, change it with the spare tire and have the flat tire repaired by the nearest Toyota dealer.

●Avoid abrupt maneuvering and braking. If the vehicle tires deteriorate,

you could lose control of the steering wheel or the brakes.

■If a blowout or sudden air leakage should occur

The tire pressure warning system may not activate immediately.

AVALON (U)_(OM41456U)

7-2. Steps to take in an emergency

397

CAUTION

■Maintenance of the tires

Each tire, including the spare (if provided), should be checked monthly when cold and inflated to the inflation pressure recommended by the vehicle manufacturer on the vehicle placard or tire inflation pressure label (tire and load information label). (If your vehicle has tires of a dif- ferent size than the size indicated on the vehicle placard or tire inflation pressure label [tire and load information label], you should determine the proper tire inflation pressure for those tires.) As an added safety feature, your vehicle has been equipped with a tire pressure monitoring system (TPMS-tire pressure warning system) that illuminates a low tire pressure telltale (tire pressure warning light) when one or more of your tires is significantly under-inflated. Accordingly, when the low tire pressure telltale (tire pressure warning light) illumi- nates, you should stop and check your tires as soon as possible, and inflate them to the proper pressure. Driving on a significantly under- inflated tire causes the tire to overheat and can lead to tire failure. Under-inflation also reduces fuel efficiency and tire tread life, and may affect the vehicle’s handling and stopping ability. Please note that the TPMS (tire pressure warning system) is not a sub- stitute for proper tire maintenance, and it is the driver’s responsibility to maintain correct tire pressure, even if under-inflation has not reached the level to trigger illumination of the TPMS low tire pressure telltale (tire pressure warning light). Your vehicle has also been equipped with a TPMS (tire pressure warn- ing system) malfunction indicator to indicate when the system is not operating properly. The TPMS (tire pressure warning system) malfunc- tion indicator is combined with the low tire pressure telltale (tire pressure warning light). When the system detects a malfunction, the telltale will flash for approximately one minute and then remain continuously illumi- nated. This sequence will continue upon subsequent vehicle start-ups as long as the malfunction exists. When the malfunction indicator is illu- minated, the system may not be able to detect or signal low tire pres- sure as intended.

AVALON (U)_(OM41456U)

398

7-2. Steps to take in an emergency

CAUTION

TPMS (tire pressure warning system) malfunctions may occur for a vari- ety of reasons, including the installation of replacement or alternate tires or wheels on the vehicle that prevent the TPMS (tire pressure warning system) from functioning properly. Always check the TPMS (tire pres- sure warning system) malfunction telltale after replacing one or more tires or wheels on your vehicle to ensure that the replacement or alter- nate tires and wheels allow the TPMS (tire pressure warning system) to continue to function properly.

NOTICE

■To ensure the tire pressure warning system operates properly

Do not install tires with different specifications or makers, as the tire pressure warning system may not operate properly.

AVALON (U)_(OM41456U)

7-2. Steps to take in an emergency

399

If a warning message is displayed

The multi-information display shows warnings of system mal- functions, incorrectly performed operations, messages that indi- cate a need for maintenance and reminder messages. When a message is shown, perform the correction procedure appropri- ate to the message.

Master warning light The master warning light also comes on or flashes in order to indicate that a message is cur- rently being displayed on the multi- information display. Multi-information display

If any of the warning message is shown again after its correction pro- cedure has been performed, contact your Toyota dealer.

■Warning buzzer

In some cases, the buzzer may not be heard because of noisy place or an audio sound.

AVALON (U)_(OM41456U)

400
7-2. Steps to take in an emergency If you have a flat tire

Your vehicle is equipped with a spare tire. The flat tire can be replaced with the spare tire. For details about tires: P. 334

CAUTION

■If you have a flat tire

Do not continue driving with a flat tire. Driving even a short distance with a flat tire can damage the tire and the wheel beyond repair, which could result in an accident.

Before jacking up the vehicle ● Stop the vehicle on a hard, flat surface. ● Set the parking brake. ● Shift the shift lever to P. ● Stop the engine. ● Turn on the emergency flashers. (P. 380)

AVALON (U)_(OM41456U)

7-2. Steps to take in an emergency

401

Location of the spare tire, jack and tools

Luggage floor cover Jack Jack handle Spare tire Tool tray Wheel nut wrench

AVALON (U)_(OM41456U)

402

7-2. Steps to take in an emergency

CAUTION

■Using the tire jack

Observe the following precautions. Improper use of the tire jack may cause the vehicle to suddenly fall off the jack, leading to death or serious injury. ●Do not use the tire jack for any purpose other than replacing tires or

installing and removing tire chains.

●Only use the tire jack that comes with this vehicle for replacing a flat

tire. Do not use it on other vehicles, and do not use other tire jacks for replacing tires on this vehicle.

●Put the jack properly in its jack point. ●Do not put any part of your body under the vehicle while it is supported

by the jack.

●Do not start the engine or drive the vehicle while the vehicle is sup-

ported by the jack.

●Do not raise the vehicle while someone is inside. ●When raising the vehicle, do not put an object on or under the jack. ●Do not raise the vehicle to a height greater than that required to

replace the tire.

●Use a jack stand if it is necessary to get under the vehicle. ●When lowering the vehicle, make sure that there is no-one near the vehicle. If there are people nearby, warn them vocally before lowering.

AVALON (U)_(OM41456U)

7-2. Steps to take in an emergency

403

Taking out the jack and jack handle

Remove cover.

the

luggage

floor

Remove the jack.

AVALON (U)_(OM41456U)

404

7-2. Steps to take in an emergency

Taking out the spare tire

Remove the luggage floor cover. (P. 403) Remove the tool tray.

Loosen the center fastener that secures the spare tire.

CAUTION

■When storing the spare tire

Be careful not to catch fingers or other body parts between the spare tire and the body of the vehicle.

AVALON (U)_(OM41456U)

7-2. Steps to take in an emergency

405

Replacing a flat tire

Chock the tires.

Flat tire Left-hand side Right-hand side Left-hand side Right-hand side

Wheel chock positions

Behind the rear right-hand side tire Behind the rear left-hand side tire In front of the front right-hand side tire In front of the front left-hand side tire

Front

Rear

Slightly loosen the wheel nuts (one turn).

Turn the tire jack portion “A” by hand until the notch of the jack is in contact with the jack point. The jack point guides are located under the rocker panel. They indicate the jack point positions.

AVALON (U)_(OM41456U)

406

7-2. Steps to take in an emergency

Raise the vehicle until the tire is slightly raised off the ground.

Remove all the wheel nuts and the tire. When resting the tire on the ground, place the tire so that the wheel design faces up to avoid scratching the wheel surface.

AVALON (U)_(OM41456U)

7-2. Steps to take in an emergency

407

CAUTION

■Replacing a flat tire

●Do not touch the disc wheels or the area around the brakes immedi-

ately after the vehicle has been driven. After the vehicle has been driven the disc wheels and the area around the brakes will be extremely hot. Touching these areas with hands, feet or other body parts while changing a tire, etc. may result in burns.

●Failure to follow these precautions could cause the wheel nuts to

loosen and the tire to fall off, resulting in death or serious injury. • Have the wheel nuts tightened with a torque wrench to 76 ft•lbf (103

N•m, 10.5 kgf•m) as soon as possible after changing wheels.

• When installing a tire, only use wheel nuts that have been specifi-

cally designed for that wheel.

• If there are any cracks or deformations in the bolt screws, nut threads or bolt holes of the wheel, have the vehicle inspected by your Toyota dealer.

• When installing the wheel nuts, be sure to install them with the tapered

ends facing inward. (P. 346)

AVALON (U)_(OM41456U)

408

7-2. Steps to take in an emergency

Installing the spare tire

Remove any dirt or foreign mat- ter from the wheel contact sur- face. If foreign matter is on the wheel contact surface, the wheel nuts may loosen while the vehicle is in motion, causing the tire to come off. Install the spare tire and loosely tighten each wheel nut by hand by approximately the same amount. Tighten the wheel nuts until the tapered portion comes into loose contact with the disc wheel seat.

Tapered portion

Disc wheel seat

AVALON (U)_(OM41456U)

3

Lower the vehicle.

7-2. Steps to take in an emergency

409

Firmly tighten each wheel nut two or three times in the order shown in the illustration. Tightening torque: 76 ft•lbf (103 N•m, 10.5 kgf•m)

Stow the flat tire, tire jack and all tools.

AVALON (U)_(OM41456U)

410

7-2. Steps to take in an emergency

■The compact spare tire

●The compact spare tire is identified by the label “TEMPORARY USE

ONLY” on the tire sidewall. Use the compact spare tire temporarily, and only in an emergency.

●Make sure to check the tire inflation pressure of the compact spare tire.

(P. 437)

■After completing the tire change

The tire pressure warning system must be reset. (P. 336)

■When using the compact spare tire

As the compact spare tire is not equipped with a tire pressure warning valve and transmitter, low inflation pressure of the spare tire will not be indicated by the tire pressure warning system. Also, if you replace the compact spare tire after the tire pressure warning light comes on, the light remains on.

■When the compact spare tire is equipped

The vehicle becomes lower when driving with the compact spare tire compared to when driving with standard tires.

■If you have a flat front tire on a road covered with snow or ice

Install the compact spare tire on one of the rear wheels of the vehicle. Perform the following steps and fit tire chains to the front tires:

Replace a rear tire with the compact spare tire. Replace the flat front tire with the tire removed from the rear of the vehi- cle. Fit tire chains to the front tires.

AVALON (U)_(OM41456U)

7-2. Steps to take in an emergency

411

CAUTION

■When using the compact spare tire

●Remember that the compact spare tire provided is specifically designed for use with your vehicle. Do not use your compact spare tire on another vehicle.

●Do not use more than one compact spare tires simultaneously. ●Replace the compact spare tire with a standard tire as soon as possi-

ble.

●Avoid sudden acceleration, abrupt steering, as well as sudden braking

and shifting operation to engine braking. ■When the compact spare tire is attached

The vehicle speed may not be correctly detected, and the following sys- tems may not operate correctly: • ABS & Brake assist • VSC • TRAC • Cruise control (if equipped) • Dynamic radar cruise control

• Rear view monitor system (if

• Navigation system (if equipped)

equipped)

(if equipped)

• PCS (if equipped) • EPS

AVALON (U)_(OM41456U)

412

7-2. Steps to take in an emergency

CAUTION

■Speed limit when using the compact spare tire

Do not drive at speeds in excess of 50 mph (80 km/h) when a compact spare tire is installed on the vehicle. The compact spare tire is not designed for driving at high speeds. Fail- ure to observe this precaution may lead to an accident causing death or serious injury.

■After using the tools and jack

Before driving, make sure all the tools and jack are securely in place in their storage location to reduce the possibility of personal injury during a collision or sudden braking.

NOTICE

■Driving with tire chains and the compact spare tire

Do not fit tire chains to the compact spare tire. Tire chains may damage the vehicle body and adversely affect driving performance.

■When replacing the tires

When removing or fitting the wheels, tires or the tire pressure warning valve and transmitter, contact your Toyota dealer as the tire pressure warning valve and transmitter may be damaged if not handled correctly.

AVALON (U)_(OM41456U)

7-2. Steps to take in an emergency

413

If the engine will not start

If the engine will not start even though correct starting proce- dures are being followed (P. 159), consider each of the follow- ing points:

The engine will not start even though the starter motor operates normally. One of the following may be the cause of the problem: ● There may not be sufficient fuel in the vehicle’s tank.

Refuel the vehicle.

● The engine may be flooded.

Try to restart the engine again following correct starting procedures. (P. 159)

● There may be a malfunction in the engine immobilizer system.

(P. 66)

The starter motor turns over slowly, the interior lights and head- lights are dim, or the horn does not sound or sounds at a low volume. One of the following may be the cause of the problem: ● The battery may be discharged. (P. 419) ● The battery terminal connections may be loose or corroded.

The starter motor does not turn over The engine starting system may be malfunctioning due to an electrical problem such as electronic key battery depletion or a blown fuse. However, an interim measure is available to start the engine. (P. 414)

AVALON (U)_(OM41456U)

414

7-2. Steps to take in an emergency

The starter motor does not turn over, the interior lights and head- lights do not turn on, or the horn does not sound. One of the following may be the cause of the problem: ● One or both of the battery terminals may be disconnected. ● The battery may be discharged. (P. 419) ● There may be a malfunction in the steering lock system.

Contact your Toyota dealer if the problem cannot be repaired, or if repair procedures are unknown.

Emergency start function When the engine does not start, the following steps can be used as an interim measure to start the engine if the engine switch is functioning normally:

Set the parking brake. Shift the shift lever to P. Turn the engine switch to ACCESSORY mode. Press and hold the engine switch for about 15 seconds while depressing the brake pedal firmly.

Even if the engine can be started using the above steps, the system may be malfunctioning. Have the vehicle inspected by your Toyota dealer.

AVALON (U)_(OM41456U)

7-2. Steps to take in an emergency

415

If the shift lever cannot be shifted from P

If the shift lever cannot be shifted with your foot on the brake pedal, there may be a problem with the shift lock system (a sys- tem to prevent accidental operation of the shift lever). Have the vehicle inspected by your Toyota dealer immediately. The following steps may be used as an emergency measure to ensure that the shift lever can be shifted:

Set the parking brake. Turn the engine switch to ACCESSORY mode. Depress the brake pedal. Pry the cover up with a flathead screwdriver or equivalent tool. To prevent damage to the cover, cover the tip of the screwdriver with a rag.

Press the shift lock override button. The shift lever can be shifted while the button is pressed.

AVALON (U)_(OM41456U)

416

7-2. Steps to take in an emergency

If the electronic key does not operate properly

If communication between the electronic key and vehicle is interrupted (P. 102) or the electronic key cannot be used because the battery is depleted, the smart key system and wire- less remote control cannot be used. In such cases, the doors and trunk can be opened and the engine can be started by fol- lowing the procedure below.

Locking and unlocking the doors and unlocking the trunk ■ Doors

Use the mechanical key (P. 90) in order to perform the following operations: Locks all the doors Unlocks the door rearward Turning unlocks the driver’s door. Turn- ing the key once again within 5
seconds unlocks the other doors.

key

the

■ Trunk

P. 116

AVALON (U)_(OM41456U)

7-2. Steps to take in an emergency

417

Starting the engine

Ensure that the shift lever is in P and depress the brake pedal. Touch the Toyota emblem side of the electronic key to the engine switch. The engine switch will turn to IGNI- TION ON mode. When the smart key system is deactivated in customization set- ting, the engine switch will turn to ACCESSORY mode. Firmly depress the brake pedal. A message indicating how to start the engine will be displayed on the multi-information display. Press the engine switch.

In the event that the engine still cannot be started, contact your Toyota dealer.

AVALON (U)_(OM41456U)

418

7-2. Steps to take in an emergency

■Stopping the engine

Shift the shift lever to P and press the engine switch as you normally do when stopping the engine.

■Replacing the key battery

As the above procedure is a temporary measure, it is recommended that the electronic key battery be replaced immediately when the battery is depleted. (P. 350)

■Changing engine switch modes

Release the brake pedal and press the engine switch in step The engine does not start and modes will be changed each time the switch is pressed.(P. 160)

above.

■When the electronic key does not work properly

●Make sure that the smart key system has not been deactivated in the cus-

tomization setting. If it is off, turn the function on. (Customizable features P. 455)

●Check if battery-saving mode is set. If it is set, cancel the function.

(P. 101)

AVALON (U)_(OM41456U)

7-2. Steps to take in an emergency

419

If the vehicle battery is discharged

The following procedures may be used to start the engine if the vehicle’s battery is discharged. You can also call your Toyota dealer or a qualified repair shop.

If you have a set of jumper (or booster) cables and a second vehicle with a 12-volt battery, you can jump start your vehicle by following the steps below.

Open the hood (P. 319) Connect the jumper cables according to the following procedure:

Connect a positive jumper cable clamp to the positive (+) battery terminal on your vehicle. Connect the clamp on the other end of the positive cable to the positive (+) battery terminal on the second vehicle. Connect a negative cable clamp to the negative (-) battery termi- nal on the second vehicle. Connect the clamp at the other end of the negative cable to a solid, stationary, unpainted metallic point away from the battery and any moving parts, as shown in the illustration.

Start the engine of the second vehicle. Increase the engine speed slightly and maintain at that level for approximately 5 minutes to recharge the battery of your vehicle.

AVALON (U)_(OM41456U)

420

7-2. Steps to take in an emergency

Open and close any of the doors of your vehicle with the engine switch off. Maintain the engine speed of the second vehicle and start the engine of your vehicle by turning the engine switch to IGNITION ON mode. Once the vehicle’s engine has started, remove the jumper cables in the exact reverse order from which they were connected.

Once the engine starts, have the vehicle inspected at your Toyota dealer as soon as possible.

AVALON (U)_(OM41456U)

7-2. Steps to take in an emergency

421

■Starting the engine when the battery is discharged

The engine cannot be started by push-starting.

■To prevent battery discharge

●Turn off the headlights and the audio system while the engine is off. ●Turn off any unnecessary electrical components when the vehicle is running

at a low speed for an extended period, such as in heavy traffic.

■Charging the battery

The electricity stored in the battery will discharge gradually even when the vehicle is not in use, due to natural discharge and the draining effects of cer- tain electrical appliances. If the vehicle is left for a long time, the battery may discharge, and the engine may be unable to start. (The battery recharges automatically during driving.)

■When recharging or replacing the battery

●In some cases, it may not be possible to unlock the doors using the smart key system when the battery is discharged. Use the wireless remote control or the mechanical key to lock or unlock the doors.

●The engine may not start on the first attempt after the battery has recharged

but will start normally after the second attempt. This is not a malfunction.

●The engine switch mode is memorized by the vehicle. When the battery is reconnected, the system will return to the mode it was in before the battery was discharged. Before disconnecting the battery, turn the engine switch off. If you are unsure what mode the engine switch was in before the battery dis- charged, be especially careful when reconnecting the battery.

●Make sure that the key is not inside the vehicle when recharging or replac- ing the battery. The key may be locked in the vehicle if the alarm is acti- vated. (P. 69)

AVALON (U)_(OM41456U)

422

7-2. Steps to take in an emergency

CAUTION

■Avoiding battery fires or explosions

Observe the following precautions to prevent accidentally igniting the flam- mable gas that may be emitted from the battery: ●Make sure each jumper cable is connected to the correct terminal and that it is not unintentionally in contact with any other than the intended terminal. ●Do not allow the other end of the jumper cable connected to the “+” termi- nal to come into contact with any other parts or metal surfaces in the area, such as brackets or unpainted metal.

●Do not allow the + and - clamps of the jumper cables to come into contact

with each other.

●Do not smoke, use matches, cigarette lighters or allow open flame near

the battery.

■Battery precautions

The battery contains poisonous and corrosive acidic electrolyte, while related parts contain lead and lead compounds. Observe the following pre- cautions when handling the battery: ●When working with the battery, always wear safety glasses and take care not to allow any battery fluids (acid) to come into contact with skin, clothing or the vehicle body.

●Do not lean over the battery. ●In the event that battery fluid comes into contact with the skin or eyes, immediately wash the affected area with water and seek medical attention. Place a wet sponge or cloth over the affected area until medical attention can be received.

●Always wash your hands after handling the battery support, terminals, and

other battery-related parts.

●Do not allow children near the battery.

NOTICE

■When handling jumper cables

When connecting the jumper cables, ensure that they do not become entan- gled in the cooling fans or engine drive belt.

AVALON (U)_(OM41456U)

7-2. Steps to take in an emergency

423

If your vehicle overheats

The following may indicate that your vehicle is overheating:

● The needle of the engine coolant temperature gauge (P. 77)

enters the red zone or a loss of engine power is experienced. (For example, the vehicle speed does not increase.)

● Steam comes out from under the hood.

Correction procedures

Stop the vehicle in a safe place and turn off the air conditioning sys- tem, and then stop the engine. If you see steam: Carefully lift the hood after the steam subsides. If you do not see steam: Carefully lift the hood. After the engine has cooled down sufficiently, inspect the hoses and radiator core (radia- tor) for any leaks. Radiator Cooling fan If a large amount of coolant leaks, immediately contact your Toyota dealer. The coolant level is satisfactory if it is between the “F” and “L” lines on the reservoir. Reservoir “F” line “L” line Radiator cap

AVALON (U)_(OM41456U)

424

7-2. Steps to take in an emergency

Add engine coolant if neces- sary. Water can be used in an emer- gency if engine coolant is unavail- able.

Start the engine and turn the air conditioning system on to check that the radiator cooling fans operate and to check for coolant leaks from the radiator or hoses. The fans operate when the air conditioning system is turned on immedi- ately after a cold start. Confirm that the fans are operating by checking the fan sound and air flow. If it is difficult to check these, turn the air condition- ing system on and off repeatedly. (The fans may not operate in freezing temperatures.) If the fans are not operating: Stop the engine immediately and contact your Toyota dealer. If the fans are operating: Have the vehicle inspected at the nearest Toyota dealer.

AVALON (U)_(OM41456U)

7-2. Steps to take in an emergency

425

CAUTION

■When inspecting under the hood of your vehicle

Observe the following precautions. Failure to do so may result in serious injury such as burns. ●If steam is seen coming from under the hood, do not open the hood until

the steam has subsided. The engine compartment may be very hot.

●Keep hands and clothing (especially a tie, a scarf or a muffler) away from

the fans and belts.

●Do not loosen the radiator cap and the coolant reservoir cap while the engine and radiator are hot. High could spray out.

temperature steam or coolant

NOTICE

■When adding engine coolant

Wait until the engine has cooled down before adding engine coolant. When adding coolant, do so slowly. Adding cool coolant to a hot engine too quickly can cause damage to the engine.

■To prevent damage to the cooling system

Observe the following precautions: ●Avoid contaminating the coolant with foreign matter (such as sand or dust

etc.).

●Do not use any coolant additive.

AVALON (U)_(OM41456U)

7-2. Steps to take in an emergency

426
If the vehicle becomes stuck

Carry out the following procedures if the tires spin or the vehicle becomes stuck in mud, dirt or snow:

Stop the engine. Set the parking brake and shift the shift lever to P. Remove the mud, snow or sand from around the front wheels. Place wood, stones or some other material under the front wheels to help provide traction. Restart the engine. Shift the shift lever to D or R and release the parking brake. Then, while exercising caution, depress the accelerator pedal.

■When it is difficult to free the vehicle

Press

to turn off TRAC.

CAUTION

■When attempting to free a stuck vehicle

If you choose to push the vehicle back and forth to free it, make sure the surrounding area is clear to avoid striking other vehicles, objects or people. The vehicle may also lunge forward or lunge back suddenly as it becomes free. Use extreme caution.

■When shifting the shift lever

Be careful not to shift the shift lever with the accelerator pedal depressed. This may lead to unexpected rapid acceleration of the vehicle that may cause an accident resulting in death or serious injury.

AVALON (U)_(OM41456U)

7-2. Steps to take in an emergency

427

NOTICE

■To avoid damaging the transmission and other components

●Avoid spinning the front wheels and depressing the accelerator pedal

more than necessary.

●If the vehicle remains stuck even after these procedures are performed,

the vehicle may require towing to be freed.

AVALON (U)_(OM41456U)

428

7-2. Steps to take in an emergency

AVALON (U)_(OM41456U)

Vehicle specifications

429

8-1. Specifications

Maintenance data (fuel, oil level, etc.).......... 430
Fuel information ................ 439
Tire information ................. 442

8-2. Customization

Customizable features ...... 455

8-3. Items to initialize

Items to initialize ............... 461

AVALON (U)_(OM41456U)

8-1. Specifications

430
Maintenance data (fuel, oil level, etc.)

Dimensions and weight

Overall length Overall width Overall height* Wheelbase

Tread*

Front Rear Vehicle capacity weight (Occupants + luggage) *: Unladen vehicle

195.3 in. (4960 mm) 72.2 in. (1835 mm) 57.5 in. (1460 mm) 111.0 in. (2820 mm) 62.6 in. (1590 mm) 62.2 in. (1580 mm)

930 lb. (420 kg)

AVALON (U)_(OM41456U)

8-1. Specifications

431

Vehicle identification ■ Vehicle identification number

The vehicle identification number (VIN) is the legal identifier for your vehicle. This is the primary identification number for your Toyota. It is used in registering the ownership of your vehicle. This number is located on the top left of the instrument panel.

This number is also on the Cer- tification Label.

■ Engine number

The engine number is stamped on the engine block as shown.

AVALON (U)_(OM41456U)

432

8-1. Specifications

Engine

Model Type Bore and stroke Displacement Valve clearance (engine cold) Drive belt tension

Fuel

Fuel type Octane Rating Fuel tank capacity (Reference)

Lubrication system

3.5L 6-cylinder (2GR-FE) 6-cylinder V type, 4-cycle, gasoline 3.70  3.27 in. (94.0  83.0 mm) 210.9 cu. in. (3456 cm3)

Automatic adjustment

Automatic adjustment

Unleaded gasoline only 87 (Research Octane Number 91) or higher

17.0 gal. (64.35 L, 14.2 Imp. gal.)

Oil capacity Drain and refill (Reference*) With filter Without filter *: The engine oil capacity is a reference quantity to be used when changing the engine oil. Warm up and turn off the engine, wait more than 5 minutes, and check the oil level on the dipstick.

6.4 qt. (6.1 L, 5.4 Imp. qt.) 6.0 qt. (5.7 L, 5.0 Imp. qt.)

AVALON (U)_(OM41456U)

8-1. Specifications

433

■ Engine oil selection

“Toyota Genuine Motor Oil” is used in your Toyota vehicle. Use Toyota approved “Toyota Genuine Motor Oil” or equivalent to sat- isfy the following grade and viscosity. Oil grade: ILSAC GF-5 multigrade engine oil Recommended viscosity: SAE 0W-20
SAE 0W-20 is the best choice for good fuel economy and good starting in cold weather. If SAE 0W-20 is not available, SAE 5W-20 oil may be used. However, it must be replaced with SAE 0W-20 at the next oil change. How to read oil container label The International Lubricant Specification Advisory Commit- tee (ILSAC) Certification Mark is added to some oil containers to help you select the oil you should use.

Outside temperature

AVALON (U)_(OM41456U)

434

8-1. Specifications

Cooling system

Capacity

Coolant type

Ignition system

Spark plug

Make Gap

NOTICE

9.7 qt. (9.2 L, 8.1 Imp. qt.) Use either of the following:

• “Toyota Super Long Life Coolant” • Similar high-quality ethylene glycol-based non-silicate, non-amine, non-nitrite, and non-borate coolant with long-life hybrid organic acid technology Do not use plain water alone.

DENSO FK20HR11
0.043 in. (1.1 mm)

■Iridium-tipped spark plugs

Use only iridium-tipped spark plugs. Do not adjust the spark plug gap.

AVALON (U)_(OM41456U)

8-1. Specifications

435

Electrical system

Battery

Open voltage at 68F (20C):

Charging rates

12.6  12.8 V Fully charged 12.2  12.4 V Half charged 11.8  12.0 V Discharged (Voltage is checked 20 minutes after the engine and all lights are turned off.) 5 A max.

Automatic transaxle Fluid capacity* Fluid type *: The fluid capacity is the quantity of reference.

6.9 qt. (6.5 L, 5.7 Imp. qt.) Toyota Genuine ATF WS

If replacement is necessary, contact your Toyota dealer.

NOTICE

■Automatic transmission fluid type

Using transmission fluid other than “Toyota Genuine ATF WS” may cause deterioration in shift quality, locking up of your transmission accompanied by vibration, and ultimately damage the transmission of your vehicle.

AVALON (U)_(OM41456U)

436

8-1. Specifications

Brakes Pedal clearance*1
Pedal free play Brake pad wear limit Parking brake lining wear limit Parking brake pedal travel*2
Fluid type

1.43 in. (36.4 mm) Min. 0.04  0.24 in. (1.0  6.0 mm) 0.04 in. (1.0 mm) 0.04 in. (1.0 mm) 7  10 clicks SAE J1703 or FMVSS No.116 DOT 3

*1: Minimum pedal clearance when depressed with a force of 110 lbf (490 N,

50 kgf) while the engine is running

*2: Parking brake pedal travel when depressed with a force of 67 lbf (300 N,

30.6 kgf).

Steering

Free play

Less than 1.2 in. (30 mm)

AVALON (U)_(OM41456U)

8-1. Specifications

437

Tires and wheels  Type A

Tire size

Tire inflation pressure (Recommended cold tire inflation pressure)

P215/55R17 93V Front

Rear

33 psi (230 kPa, 2.3 kgf/cm2 or bar)

33 psi (230 kPa, 2.3 kgf/cm2 or bar)

Wheel size Wheel nut torque

17  7 J 76 ft•lbf (103 N•m, 10.5 kgf•m)

 Type B

Tire size

Tire inflation pressure (Recommended cold tire inflation pressure)

P225/45R18 91V Front

Rear

33 psi (230 kPa, 2.3 kgf/cm2 or bar)

33 psi (230 kPa, 2.3 kgf/cm2 or bar)

Wheel size Wheel nut torque

18  7 1/2 J 76 ft•lbf (103 N•m, 10.5 kgf•m)

 Compact spare tire

Tire size Tire inflation pressure (Recommended cold tire inflation pressure) Wheel size Wheel nut torque

T155/70D17 110M

60 psi (420 kPa, 4.2 kgf/cm2 or bar)

17  4 T 76 ft•lbf (103 N•m, 10.5 kgf•m)

AVALON (U)_(OM41456U)

438

8-1. Specifications

Light bulbs

Light bulbs

Bulb No.

Type

Headlights Low beam (discharge bulbs) Low beam (halogen bulbs) High beam Fog lights* Front turn signal/parking lights Side marker lights Side turn signal lights Rear turn signal lights Back-up lights License plate lights Interior/front personal lights Interior/rear personal lights Vanity lights Door courtesy lights Trunk light

 9005
9005


7444NA W5W WY5W

921
921
W5W W6W

 7065
168
194

35
60
60
55
28/8

16
16
1.4
3.8

Exterior

Interior

A: D4S discharge bulbs B: HB3L+ halogen bulbs C: HB3 halogen bulbs D: H11 halogen bulbs E: Wedge base bulbs (amber) F: Wedge base bulbs (clear) G: Double end bulbs *: If equipped

AVALON (U)_(OM41456U)

8-1. Specifications

439

Fuel information

You must only use unleaded gasoline in your vehicle. Select unleaded gasoline with an octane rating of 87 (Research Octane Number 91) or higher required for optimum engine per- formance. Use of unleaded gasoline with an octane rating lower than 87 may result in engine knocking and significantly reduced performance. Persistent knocking can lead to engine damage and should be corrected by refueling with higher octane unleaded gasoline. At minimum, the gasoline you use should meet the specifications of ASTM D4814 in the U.S.A..

■Fuel tank opening for unleaded gasoline

To help prevent incorrect fueling, your vehicle has a fuel tank opening that only accommodates the special nozzle on unleaded fuel pumps.

■Gasoline quality

In very few cases, driveability problems may be caused by the brand of gaso- line you are using. If driveability problems persist, try changing the brand of gasoline. If this does not correct the problem, consult your Toyota dealer.

■Gasoline quality standards

●Automotive manufacturers in the U.S.A., Europe and Japan have developed
