control A and the integrated garage door opener depends on the garage door drive system. Several attempts may be required. You should test every position for at least 25 seconds before trying another position. X Press and hold button B on remote control A until indicator lamp : lights up green. If indicator lamp : lights up green or flashes, then programming has been suc- cessful.
X Release button B of garage door drive
remote control A.
X If indicator lamp : lights up red: repeat the programming procedure for the corre- sponding button on the rear-view mirror. When doing so, vary the distance between remote control A and the rear-view mirror.
i If the indicator lamp flashes green after successful programming, the garage door system is using a rolling code. After pro-
gramming, you must synchronise the garage door opener integrated in the rear- view mirror with the receiver of the garage door system.
Synchronising the rolling code Your vehicle must be within range of the garage door or exterior gate drive. Make sure that neither your vehicle nor any persons/ objects are present within the sweep of the door or gate. Observe the safety notes when performing the rolling code synchronisation. X Turn the key to position 2 in the ignition
lock.
X Press the programming button of the door
or gate drive (see the door or gate drive operating instructions, e.g. under "Pro- gramming of additional remote controls"). i Usually, you now have 30seconds to ini-
tiate the next step.
X Press previously programmed button ;,
= or ? of the integrated garage door opener until the door closes. The rolling code synchronisation is then complete.
Problems when programming If you have problems when programming the integrated garage door opener, please note the following: RCheck the transmitter frequency of garage door drive remote control A. This can usu- ally be found on the back of the remote control.
RReplace the batteries in garage door
remote control A. This increases the like- lihood that garage door remote control A will transmit a strong and precise signal to the integrated garage door opener in the rear-view mirror.
RWhen programming, hold remote control
A at varying distances and angles from the button which you are programming. Try var- ious angles at a distance between 5and
354 Features
30 cm or at the same angle but at varying distances.
RIf there is another remote control for the same garage door drive, perform the pro- gramming steps again using this remote control. Before performing these steps, make sure that new batteries have been fitted in garage door drive remote control A.
RNote that some remote controls transmit only for a limited period (the indicator lamp on the remote control goes out). Press but- ton B on remote control A again before transmission ends.
RAlign the aerial cable of the garage door
opener unit. This can improve signal recep- tion/transmission.
Opening or closing the garage door Once programmed, the integrated garage door opener will assume the function of the garage door system's remote control. Please also read the operating instructions for the garage door system. X Turn the key to position 2 in the ignition
lock.
X Press button ;, = or ? which you have programmed to operate the garage door. Garage door system with a fixed code: indi- cator lamp : lights up green. Garage door system with a rolling code: indicator lamp : flashes green.
i The transmitter will transmit a signal for as long as the button is pressed. The trans- mission is halted after a maximum of ten seconds and indicator lamp : lights up yellow. Press button ;, = or ? again if necessary.
Clearing the memory X Turn the key to position 2 in the ignition
lock.
X Press buttons ; and ?.
The indicator lamp lights up yellow.
X Press and hold buttons ; and ? until the
indicator lamp turns green.
i Make sure that you clear the memory of the integrated garage door opener before selling the vehicle.
Frequencies Europe Country
Radio type approval num- ber Frequency range (MHz)
AD (Andorra) 20 July
AT (Austria)
MHz: 27, 30, 40, 433, 868
Article 6 of Directive 1999/5/EC R&TTE 18 May 05
MHz: 27, 40, 433, 868BE (Belgium) Article 6 of Directive
BG (Bulga- ria)
CH (Switzer- land)
CY (Cyprus)
1999/5/EC R&TTE 18 May 05
MHz: 27, 40, 433, 868
Article 6 of Directive 1999/5/EC R&TTE 12 April 07
MHz: 27, 40, 433, 868
Article 6 of Directive 1999/5/EC R&TTE14357
27 May 05
MHz: 27, 40, 433, 868
Article 6 of Directive 1999/5/EC R&TTE 5 May 05
MHz: 27, 40, 433, 868Features
355
Country
EE (Estonia)
DE (Ger- many)
DK (Den- mark)
CZ (Czech Republic)
Radio type approval num- ber Frequency range (MHz) General Licence GL-30/R/ 2000 Reg. No. 844 13 May 05
MHz: 27, 40, 433
Article 6 of Directive 1999/5/EC R&TTE 20 April 05
MHz: 27, 40, 433, 868
Article 6 of Directive 1999/5/EC R&TTE7519301 29 April 05
MHz: 27, 40, 433, 868
Article 6 of Directive 1999/5/EC R&TTE 11 May 05
MHz: 27, 40, 433, 868
000438/2005, 000439/2005, 000440/2005
000441/2005, 000445/2005, 000446/2005
000447/2005
MHz: 27, 40, 433, 868
Article 6 of Directive 1999/5/EC R&TTE10668
13 May 05
MHz: 27, 40, 433, 868
Article 6 of Directive 1999/5/EC R&TTE10668
13 May 05
27, 30, 40, 433, 868
GI (Gibraltar) Article 6 of DirectiveFR (France)
FI (Finland)
ES (Spain)
1999/5/EC R&TTE13 May 05 (UK) MHz: 27, 40, 418, 433, 868
Country
Radio type approval num- ber Frequency range (MHz)
GR (Greece) Article 6 of Directive
1999/5/EC R&TTE11409/18/4/2005
18 May 05
MHz: 27, 40, 433, 868HR (Croatia) SDR 224/06
HU (Hun- gary)
IC (Canary Islands)
IE (Ireland)
IS (Iceland)
MHz: 27, 40, 433, 868
Article 6 of Directive 1999/5/EC R&TTE 18 May 05
MHz: 27, 40, 433, 868
000438/2005, 000439/2005
000440/2005, 000441/2005
000445/2005, 000446/2005
000447/2005, 3rd June 2005
MHz: 27, 40, 433, 868
Article 6 of Directive 1999/5/EC R&TTE 18 May 05
MHz: 27, 40, 433, 868
Article 6 of Directive 1999/5/EC R&TTE 18 May 05
MHz: 27, 40, 433, 868356 Features
Country
IT (Italy)
LI (Liechten- stein)
LT (Lithua- nia)
LU (Luxem- bourg)
LV (Latvia)
MC (Mon- aco)
Radio type approval num- ber Frequency range (MHz) DGPGSR/II/347487/ FOR/15347
DGPGSR/II/347487/ FOR/15348
DGPGSR/II/347487/ FOR/15350
DGPGSR/II/347487/ FOR/15357
DGPGSR/II/347487/ FOR/15358
DGPGSR/II/347487/ FOR/15359
MHz: 27, 40, 433, 868
Article 6 of Directive 1999/5/EC R&TTE 14357
27 May 05
MHz: 27, 40, 433, 868
Article 6 of Directive 1999/5/EC R&TTE27.4-1B-1609 6 May 05
MHz: 27, 40, 433, 868
Article 6 of Directive 1999/5/EC R&TTE150405/9538 24
May 05
MHz: 27, 40, 433, 868
Article 6 of Directive 1999/5/EC R&TTE 27.4-1B-1609 26 April 06
MHz: 27, 40, 433, 868
Article 6 of Directive 1999/5/EC R&TTE10668
13 May 05
MHz: 27, 40, 433, 868Country
MT (Malta)
NL (Nether- lands)
Radio type approval num- ber Frequency range (MHz) Article 6 of Directive 1999/5/EC R&TTE 18 May 05
MHz: 27, 40, 433, 868
Article 6 of Directive 1999/5/EC R&TTE 18 May 05
MHz: 27, 40, 433, 868NO (Norway) Article 6 of Directive
PL (Poland)
1999/5/EC R&TTE05/02424-SA644 18
May 05
MHz: 27, 40, 433, 868
Article 6 of Directive 1999/5/EC R&TTE 21 April 05
MHz: 27, 40, 433, 868PT (Portugal) ANCOM-S08399/05
RO (Roma- nia)
RU (Russian Federation)
27, 40, 433, 868
Article 6.4 of Directive 1999/5/EC R&TTE MHz: 27, 30, 40, 433, 868
POCC DE.MJ05.H00015 13
May 05
MHz: 433SE (Sweden) Article 6 of Directive
1999/5/EC R&TTE 18 May 05
MHz: 27, 40, 433, 868SI (Slovenia) Article 6 of Directive 1999/5/EC R&TTE 500-1/2005-437 9 May 05
MHz: 27, 40, 433, 868Country
SK (Slova- kia)
UK (United Kingdom)
Africa Country
EG (Egypt)
Radio type approval num- ber Frequency range (MHz) Article 6 of Directive 1999/5/EC R&TTE Slovak 206/11/2005 4 May 05
MHz: 27, 40, 433, 868
Article 6 of Directive 1999/5/EC R&TTE 18 May 05
MHz: 27, 40, 418, 433, 868Radio type approval num- ber Frequency range (MHz) W-KLE-17/08 Mar. 06
MHz: 27, 30, 40, 418, 433, 868RE (Réunion) Article 6 of Directive
ZA (South Africa)
America Country
BB (Barba- dos)
CL (Chile)
GF (French Guyana)
1999/5/EC R&TTE 11 July 05
MHz: 27, 40, 433, 868
11 October 2005
MHz: 27, 40, 433Radio type approval num- ber Frequency range (MHz) Registration not required MHz: 27, 40, 433, 868
38447/F-23 No.3.3634
MHz: 40, 433
Article 6 of Directive 1999/5/EC R&TTE10668
13 May 05
MHz: 27, 30, 40, 433, 868Features
357
Country
GP (Guade- loupe)
MQ (Martini- que)
Radio type approval num- ber Frequency range (MHz) Article 6 of Directive 1999/5/EC R&TTE10668
13 May 05
MHz: 27, 30, 40, 433, 868
Article 6 of Directive 1999/5/EC R&TTE 11 July 05
MHz: 27, 30, 40, 433, 868MX (Mexico) MHz: 280 to 390
Asia Country
AE (United Arab Emi- rates) JO (Jordan)
KW (Kuwait)
LB (Leba- non)
SA (Saudi Arabia)
SY (Syria) TR (Turkey)
Radio type approval num- ber Frequency range (MHz) 1623/5/10-2/26/76
MHz: 433TRC/LPD/2005/23
MHz: 27, 30, 40, 433, 868
5 October 2005
MHz: 27, 30, 40, 418, 433, 868
2920/O&M/2006 / 3 July 05
MHz: 27, 40, 433, 868
11_02_05/5024-5-6
MHz: 418, 433
279/4/14 / 05 March 06
National Certification 23
July 07
MHz: 433358 Features
Australia Country
AU (Aus- tralia)
NZ (New Zealand)
Radio type approval num- ber Frequency range (MHz) 28 June MHz: 27, 30, 40, 433, 868
20 March 06
MHz: 27, 30, 40, 433Floormats G WARNING Make sure that there is sufficient clearance around the pedals when floormats are used, and that the floormats are properly secured. The floormats must be correctly secured at all times using the securing knob and retainers. Before you drive off, check the floormats and secure them if necessary. A floormat which is not properly secured can slip and thereby interfere with the movement of the pedals. Do not place floormats on top of one another.
Example: floormat on the driver's side X Driver's and front-passenger seat: slide
the corresponding seat backwards.
X Rear seats: slide the corresponding front
seat forwards.
X To fit: lay the floormat in the footwell. X Press studs : onto retainers ;.
X To remove: pull the floormat from retain-
ers ;.
X Remove the floormats.
Infrared reflective windscreen
The infrared reflecting glass prevents the vehicle interior from becoming too hot. It also blocks radio waves up into the gigahertz range. To enable operation of radio-controlled equip- ment, e.g. toll recording systems, areas on the windscreen are permeable to radio waves :. In these areas, you can install radio-controlled systems. These areas can best be seen from outside the vehicle by observing the light reflected off the windscreen.
Retrofitted anti-glare film Retrofitted anti-glare film on the inside of the windows can interfere with radio/mobile telephone reception. This is particularly the case for conductive or metallic-coated films. You can obtain information about anti-glare film from a qualified specialist workshop.
Useful information ............................ 360
Engine compartment ........................ 360
Service ............................................... 364
Care .................................................... 366359
360 Engine compartment
Useful information
i This Owner's Manual describes all mod- els, series and optional equipment for your vehicle that were available at the time of going to press. National variations are pos- sible. Note that your vehicle may not be equipped with all of the functions descri- bed. This is also the case for systems and functions relevant to safety.
i Read the information on qualified special-
ist workshops: (Y page 25).
Engine compartment Bonnet Active bonnet (pedestrian protection) Operating principle ! An active bonnet that had been triggered
must be repaired at a qualified specialist workshop. The active bonnet function will then be available again. The additional pedestrian protection provided by the active bonnet will then be restored.
i The active bonnet is only available in cer- tain countries. It is available for all models, except for AMG vehicles.
The active bonnet can reduce the risk of injury to pedestrians in certain accident situations. Raising the active bonnet increases the clear- ance to hard components, such as the engine. If the active bonnet has been triggered, it will be raised in the area of the bonnet hinges by approximately 100 mm. The active bonnet is triggered by pyrotechnics. For the drive to the workshop, reset the trig- gered active bonnet yourself. After being reset, the active bonnet rests in the area of the bonnet hinges on the seals, and the bon- net hinges do not engage. For this reason, we recommend that you do not exceed a maxi- mum top speed of 130 km/h on the way to the workshop. If the active bonnet has been
triggered, pedestrian protection may be limi- ted. Resetting G WARNING There is a risk of injury if the bonnet is open, even if the engine is not running. Some engine components can become very hot. To avoid the risk of burns, only touch those components described in the Owner's Manual and observe the relevant safety notes. G WARNING Make sure that nobody can become trapped as you close the bonnet.
X With your hand flat near the bonnet hinges (arrows), push down active bonnet : until it rests on the seals.
Opening the bonnet G WARNING Do not pull the release lever while the vehicle is in motion. If you do so, the bonnet may open up and block your view. G WARNING There is a risk of injury if the bonnet is open, even if the engine is not running. Some engine components can become very hot.
To avoid the risk of burns, only touch those components described in the Owner's Manual and observe the relevant safety notes. G WARNING The radiator fan between the radiator and the engine can start automatically, even if the key has been removed from the ignition lock. For this reason, you must not reach into the fan rotation area. You could otherwise be injured. Vehicles with a petrol engine: The elec- tronic ignition system uses high voltage. For this reason, you must never touch ignition system components (ignition coil, ignition cables, spark plug connectors or test socket) while: Rthe engine is running Rthe engine is being started Rthe ignition is switched on and the engine
is being cranked by hand
You could otherwise suffer an electric shock and be seriously or even fatally injured. Vehicles with a diesel engine: The elec- tronic injection control uses high voltage. For this reason, you must never touch injection system components while: Rthe engine is running Rthe engine is being started Rthe ignition is switched on You could otherwise suffer an electric shock and be seriously or even fatally injured. G WARNING The windscreen wipers and wiper linkage could be set in motion. When the bonnet is open, you or others could be injured by the wiper linkage. Make sure that the windscreen wipers are switched off. Remove the key or make sure that no ignition position has been selected with KEYLESS-GO. All indicator lamps must be off in the instrument panel.
! Make sure that the windscreen wipers are not folded away from the windscreen. Oth-
Engine compartment
361
erwise, you could damage the windscreen wipers or the bonnet.
X Make sure that the windscreen wipers are
switched off.
X Pull release lever : on the bonnet.
The bonnet is released.
X Reach into the gap, pull bonnet catch han-
dle ; up and lift the bonnet. If you lift the bonnet by approximately 40 cm, the bonnet is opened and held open automatically by the gas-filled strut.
Closing the bonnet G WARNING Make sure that nobody can become trapped as you close the bonnet.
362 Engine compartment
X Lower the bonnet and let it fall from a
height of approximately 20 cm.
X Check that the bonnet has engaged prop-
erly. If the bonnet can be raised slightly, it is not properly engaged. Open it again and close it with a little more force.
Radiator Vehicles with a diesel engine: do not cover the radiator. Do not use thermal mats, insect protection covers or anything similar. Doing so can cause the Onboard Diagnostics Sys- tem to display inaccurate values. Some of these values are legally required and must always be correct.
Engine oil General notes Depending on your driving style, the vehicle consumes up to 0.8 l of oil per 1,000 km. The oil consumption may be higher than this when the vehicle is new or if you frequently drive at high engine speeds. Depending on the engine, the oil dipstick may be installed at a different location. When checking the oil level: Rpark the vehicle on a level surface. Rthe engine should be switched off for
approximately five minutes if the engine is at normal operating temperature.
Rif the engine is not at normal operating temperature, e.g. if the engine was only started briefly, wait about 30 minutes before carrying out the measurement.
Checking the oil level using the oil dip- stick
Example: vehicles with a petrol engine
Example: vehicles with a diesel engine X Pull oil dipstick : out of the oil dipstick
tube.
X Wipe off oil dipstick :. X Slowly slide oil dipstick : into the guide
tube to the stop, and take it out again. If the level is between MIN mark = and MAX mark ;, the oil level is correct.
X If the oil level has dropped to MIN mark = or below, add 1.0 litre of engine oil.
Adding engine oil G WARNING If engine oil comes into contact with hot engine parts, it may ignite and you could burn yourself. Do not spill any engine oil on hot engine parts.
Engine compartment
363
X Replace cap : on the filler neck and turn
clockwise. Make sure that the cap locks securely into place.
X Check the oil level again with the oil dip-
stick (Y page 362).
For further information on engine oil, see (Y page 428).
Other service products Checking the coolant level G WARNING The cooling system is pressurised. Therefore, only unscrew the cap once the engine has cooled down. The coolant temperature dis- play must be less than 70 †. Otherwise, you could be scalded if hot coolant escapes.
H Environmental note When topping up the oil, take care not to spill any. If oil enters the soil or waterways, it is harmful to the environment.
! Only use engine oils and oil filters that have been approved for vehicles with a service system. You can obtain a list of the engine oils and oil filters tested and approved in accordance with the Mercedes-Benz Specifications for Service Products at any Mercedes-Benz Service Centre. Damage to the engine or exhaust system is caused by the following: Rusing engine oils and oil filters that have
not been specifically approved for the service system
Rchanging the engine oil and oil filter after missing the change interval required by the service system
Rusing engine oil additives
! Do not add too much oil. Topping up with too much engine oil can result in damage to the engine or to the catalytic converter. Have excess engine oil siphoned off.
Example: engine oil filler cap X Turn cap : anti-clockwise and remove it. X Top up the engine oil.
If the oil level is at or below the MIN mark on the oil dipstick, add 1.0 litre of engine oil.
X Park the vehicle on a level surface.
Only check the coolant level if the vehicle is on a level surface and the engine has cooled down.
X Turn the key to position 2 in the ignition
lock (Y page 159). On vehicles with KEYLESS-GO, press the Start/Stop button twice (Y page 159).
X Check the coolant temperature gauge in
the multifunction display. The coolant temperature must be below 70 †.
X Turn the key to position 0 (Y page 159) in
the ignition lock.
364 Service
X Slowly turn cap : half a turn anti-clock- wise to allow excess pressure to escape.
X Turn cap : further anti-clockwise and
remove it. If the coolant is at the level of marker bar = in the filler neck when cold, there is enough coolant in coolant expansion tank ;. If the coolant level is approximately 1.5 cm above marker bar = in the filler neck when warm, there is enough coolant in coolant expansion tank ;.
X If necessary, top up with coolant that has been tested and approved by Mercedes- Benz.
X Replace cap : and turn it clockwise as far
as it will go.
For further information on coolant, see (Y page 429).
Topping up the windscreen washer sys- tem/headlamp cleaning system G WARNING Windscreen washer fluid/antifreeze is highly flammable. Avoid spilling windscreen washer fluid/antifreeze on hot engine components as it can ignite and burn. Severe burns could be the result.
Example: washer fluid reservoir
Example: washer fluid reservoir in AMG vehicles X To open: pull cap : upwards by the tab. X Top up with the premixed washer fluid. X To close: press cap : onto the filler neck
until it engages.
The washer fluid reservoir is used for both the windscreen washer system and the headlamp cleaning system. Further information on windscreen washer fluid/antifreeze (Y page 430).
Service ASSYST PLUS Service messages The ASSYST PLUS service interval display informs you of the next service due date. Information on the type of service and service intervals (see separate Service Booklet). You can obtain further information from a Mercedes-Benz Service Centre.
i The ASSYST PLUS service interval display
does not show any information on the engine oil level. Observe the notes on the engine oil level (Y page 362).
The multifunction display shows a service message for a few seconds, e.g.: Next service A in .. days Service A due Service A overdue by ... days The letter indicates which service is due. A stands for a minor service and B for a major service. A number or another letter may be displayed after the letter. This figure indicates any necessary additional maintenance work to be performed. If you notify a qualified specialist workshop of this display, you will receive a statement on the associated costs. The ASSYST PLUS service interval display does not take into account any periods of time during which the battery is disconnec- ted. Maintaining the time-dependent service schedule: X Note down the service due date displayed in the multifunction display before discon- necting the battery.
or X After reconnecting the battery, subtract
the battery disconnection periods from the service date shown on the display.
Hiding a service message X Press the % or a button on the steer-
ing wheel.
Service 365
Displaying service messages X Switch the ignition on. X Press the = or ; button on the steer- ing wheel to select the Serv. menu. X Press the 9 or : button to select the ASSYST PLUS submenu and confirm by pressing the a button. The service due date appears in the multi- function display.
Information about Service Resetting the ASSYST PLUS service inter- val display ! If the ASSYST PLUS service interval dis- play has been inadvertently reset, this set- ting can be corrected at a qualified special- ist workshop. Have service work carried out as described in the Service Booklet. This may otherwise lead to increased wear and damage to the major assemblies or the vehicle.
A qualified specialist workshop, e.g. a Mercedes-Benz Service Centre, will reset the ASSYST PLUS service interval display after the service work has been carried out. You can also obtain further information on main- tenance work, for example. Special service requirements Arduous operating conditions or increased loads on the vehicle will require some service work to be performed more often than for a vehicle in normal use. Such arduous condi- tions include regular city driving with frequent intermediate stops and use in mountainous terrain or on poor road surfaces. For example, if the vehicle is used under ardu- ous operating conditions, have air filters, engine oil and oil filters changed frequently and check the wheels often. Further informa- tion can be obtained at a qualified specialist workshop, e.g. a Mercedes-Benz Service Centre.
366 Care
Driving abroad An extensive Mercedes-Benz Service network is also available in other countries. The Service Hotline's current telephone numbers for use when you are abroad are to be found in the "Mercedes-Benz Service24h" section of the Service Booklet.
AdBlue® service display i For BlueTEC vehicles only. To function properly, BlueTEC exhaust gas aftertreatment must be operated with the reducing agent AdBlue®. AdBlue® is topped up as part of the service. Under normal oper- ating conditions, a full tank of AdBlue® should last until the next service due date. Depending on how and where the vehicle is used, there may be an increase in the AdBlue® consumption, resulting in the next service due date being brought forward. Certain display messages show that AdBlue® must be topped up, e.g. Refill AdBlue See Owner's Manual Refill AdBlue No start in: .. km A warning tone also sounds. You can no longer start the engine when the AdBlue® supply has been used up (Y page 306). Top up AdBlue®(Y page 178). Before taking a trip with your vehicle outside Europe, have the AdBlue® supply checked at a qualified specialist workshop. If necessary, have AdBlue® topped up. Before a longer stay outside of Europe, consult a qualified special- ist workshop. Observe the notes on AdBlue®(Y page 427). You can obtain further information about BlueTEC exhaust gas aftertreatment and AdBlue® from any Mercedes-Benz Service Centre.
Care General notes H Environmental note Dispose of empty packaging and cleaning cloths in an environmentally responsible man- ner.
! For cleaning your vehicle, do not use any
of the following: Rdry, rough or hard cloths Rabrasive cleaning agents Rsolvents Rcleaning agents containing solvents Do not scrub. Do not touch the surfaces or protective films with hard objects, e.g. a ring or ice scraper. You could otherwise scratch or damage the surfaces and protective film. ! Do not park up the vehicle for an extended period straight after cleaning it, particularly after having cleaned the wheels with wheel cleaner. Wheel cleaners could cause increased corrosion of the brake discs and brake pads/linings. For this reason, you should drive for a few minutes after clean- ing. Braking heats the brake discs and the brake pads/linings, thus drying them. The vehicle can then be parked up.
Regular care of your vehicle is a condition for retaining the quality in the long term. Use care products and cleaning agents rec- ommended and approved by Mercedes-Benz.
Washing the vehicle and cleaning the paintwork Automatic car wash G WARNING Braking efficiency is reduced after washing the vehicle. This could cause an accident. For this reason, following a car wash, drive with particular care until the brakes are dry.
G WARNING The vehicle is braked when the HOLD function or DISTRONIC PLUS is activated. Therefore, deactivate the HOLD function and DISTRONIC PLUS before the vehicle is washed in an auto- matic car wash.
! Make sure that:
Rthe side windows and sliding sunroof are
closed completely.
Rthe blower for the ventilation/heating is switched off (OFF button is depressed). Rthe windscreen wiper switch is at posi-
tion 0.
The vehicle could otherwise be damaged. ! In car washes with a towing mechanism, make sure that the automatic transmission is in transmission position N, otherwise the vehicle could be damaged. RVehicles with a key:
do not remove the key from the ignition lock. Do not open the driver's door or front-passenger door when the engine is switched off. Otherwise, the automatic transmission selects park position P automatically and locks the wheels. You can prevent this by shifting the auto- matic transmission to N beforehand.
RVehicles with KEYLESS-GO:
do not open the driver's door or front- passenger door when the engine is switched off. Otherwise, the automatic transmission selects park position P automatically and locks the wheels.
Observe the following to make sure that the automatic transmission stays in position N: X Make sure the vehicle is stationary and the
ignition is switched off.
X Turn the key to position 2 (Y page 159) in
the ignition lock. Use the key instead of the Start/Stop but- ton on vehicles with KEYLESS-GO. X Depress and hold the brake pedal.
Care 367
X Shift the automatic transmission to posi-
tion N.
X Release the brake pedal. X Release the electric parking brake. X Switch off the ignition and leave the key in
the ignition lock.
You can wash the vehicle in an automatic car wash from the very start. Wash off excess dirt before cleaning the vehi- cle in an automatic car wash. After using an automatic car wash, wipe off wax from the windscreen and the wiper blades. This will prevent smears and reduce wiping noises caused by residue on the wind- screen.
Washing by hand In some countries, washing by hand is only allowed at specially equipped washing bays. Observe the legal requirements for each indi- vidual country. X Do not use hot water and do not wash the
vehicle in direct sunlight.
X Use a soft sponge to clean. X Use a mild cleaning agent, such as a car shampoo approved by Mercedes-Benz.
X Thoroughly hose down the vehicle with a
gentle jet of water.
X Do not point the water jet directly towards
the air inlets.
X Use plenty of water and rinse out the
sponge frequently.
X Rinse the vehicle with clean water and dry
thoroughly with a chamois.
X Do not let the cleaning agent dry on the
paintwork.
When using the vehicle in winter, remove all traces of road salt deposits carefully and as soon as possible.
368 Care
High-pressure cleaning equipment G WARNING Do not use high-pressure cleaners with circu- lar-jet nozzles (dirt grinders) to clean your vehicle, in particular the tyres. You could oth- erwise damage the tyres and cause an acci- dent.
! Always maintain a distance of at least 30 cm between the vehicle and the high- pressure cleaner nozzle. Information about the correct distance is available from the equipment manufacturer. Move the high-pressure cleaner nozzle around when cleaning your vehicle. Do not aim directly at any of the following: Rtyres Rdoor gaps, roof gaps, joints etc. Relectrical components Rbattery Rconnectors Rlights Rseals Rtrim elements Rventilation slots Damaged seals or electrical components can lead to leaks or failures.
Cleaning the paintwork ! Do not affix:
Rstickers Rfilms Rmagnetic plates or similar items to painted surfaces. You could otherwise damage the paintwork.
Scratches, corrosive deposits, areas affected by corrosion and damage caused by inade- quate care cannot always be completely repaired. In such cases, visit a qualified spe- cialist workshop.
X Remove impurities immediately, where
possible, whilst avoiding rubbing too hard. X Soak insect remains with insect remover and rinse off the treated areas afterwards. X Soak bird droppings with water and rinse
off the treated areas afterwards.
X Remove coolant, brake fluid, tree resin, oils, fuels and greases by rubbing gently with a cloth soaked in petroleum ether or lighter fluid.
X Use tar remover to remove tar stains. X Use silicone remover to remove wax.
Care and treatment of matt paintwork ! Never polish the vehicle or the light alloy
wheels. Polishing makes the paintwork shiny.
! The following may cause the paint to
become shiny and thus reduce the matt effect: RVigorous rubbing with unsuitable mate-
rials.
RFrequent use of car washes. RWashing the vehicle in direct sunlight. ! Never use paint cleaner, buffing or pol- ishing products, or gloss preserver, e.g. wax. These products are only suitable for high-gloss surfaces. Their use on vehicles with matt finish leads to considerable sur- face damage (shiny, spotted areas). Always have paintwork repairs performed at a qualified specialist workshop, e.g. a Mercedes-Benz Service Centre.
! Do not use wash programs with a hot wax
treatment under any circumstances.
Observe these notes if your vehicle has a clear matt finish. This will help you to avoid damage to the paintwork due to incorrect treatment. These notes also apply to light-alloy wheels with a clear matt finish.
i The vehicle should preferably be washed by hand using a soft sponge, car shampoo and plenty of water.
i Use only insect remover and car shampoo
from the range of recommended and approved Mercedes-Benz care products.
Cleaning vehicle parts Cleaning the wheels ! Do not use acidic wheel cleaning products to remove brake dust. This could damage wheel bolts and brake components.
! Do not park up the vehicle for an extended period straight after cleaning it, particularly after having cleaned the wheels with wheel cleaner. Wheel cleaners could cause increased corrosion of the brake discs and brake pads/linings. For this reason, you should drive for a few minutes after clean- ing. Braking heats the brake discs and the brake pads/linings, thus drying them. The vehicle can then be parked up.
Cleaning the windows G WARNING Switch off the windscreen wipers and remove the key from the ignition lock before cleaning the windscreen or the wiper blades. On vehi- cles with KEYLESS-GO, press the Start/Stop button repeatedly until all indicator lamps in the instrument cluster have gone off. The windscreen wipers could otherwise move and injure you.
! Do not use dry cloths, abrasive products, solvents or cleaning agents containing sol- vents to clean the inside of the windows. Do not touch the insides of the windows with hard objects, e.g. an ice scraper or ring. There is otherwise a risk of damaging the windows.
! Clean the water drainage channels of the windscreen and the rear window at regular
Care 369
intervals. Deposits such as leaves, petals and pollen may under certain circumstan- ces prevent water from draining away. This can lead to corrosion damage and damage to electronic components.
X Clean the inside and outside of the win- dows with a damp cloth and a cleaning agent that is recommended and approved by Mercedes-Benz.
Cleaning the wiper blades G WARNING Switch off the windscreen wipers and remove the key from the ignition lock before cleaning the windscreen or the wiper blades. On vehi- cles with KEYLESS-GO, press the Start/Stop button repeatedly until all indicator lamps in the instrument cluster have gone off. The windscreen wipers could otherwise move and injure you.
! Do not pull on the wiper blade. Otherwise,
the wiper blade could be damaged.
! Do not clean wiper blades too often and do not rub them too hard. Otherwise, the graphite coating could be damaged. This could cause wiper noise.
! Hold the wiper arm securely when folding back. The windscreen could be damaged if the wiper arm hits against it suddenly.
X Fold the wiper arms away from the wind-
screen.
X Clean the wiper blades carefully using a
damp cloth.
X Fold the windscreen wipers back again
before switching on the ignition.
Cleaning the exterior lighting ! Only use cleaning agents or cleaning
cloths that are suitable for plastic lenses. Unsuitable cleaning agents or cleaning cloths could scratch or damage the plastic lenses of the exterior lighting.
370 Care
X Clean the plastic lenses of the exterior lighting using a wet sponge and a mild cleaning agent, e.g. Mercedes-Benz car shampoo or cleaning cloths.
Cleaning the reversing camera ! Do not clean the camera lens and the area around the reversing camera with a high- pressure cleaner.
Mirror turn signal ! Only use cleaning agents or cleaning
cloths that are suitable for plastic lenses. Unsuitable cleaning agents or cleaning cloths could scratch or damage the plastic lenses of the mirror turn signals.
X Clean the plastic lenses of the mirror turn signals in the exterior mirror housing using a wet sponge and mild cleaning agent, e.g. Mercedes-Benz car shampoo or cleaning cloths.
Cleaning the sensors ! If you clean the sensors with a high-pres-
sure cleaner, make sure that you keep a distance of at least 30 cm between the vehicle and the high-pressure cleaner noz- zle. Information about the correct distance is available from the equipment manufac- turer.
X Use clear water and a soft cloth to clean
camera lens :.
Cleaning the 360° camera ! Do not clean the camera lens and the area around the 360° camera with a high-pres- sure cleaner.360
X Make sure that the vehicle is stationary and that the key is in position 2 in the ignition lock.
X To open the cover of the 360° camera: with COMAND Online activated, press the W button. X Select System by turning cVd the COMAND controller and press W to con- firm. X Select 360° camera and press W to con- firm.
X Clean sensors : of the driving systems with water, car shampoo and a soft cloth.
X Select Open camera cover and press W to confirm. The cover of the 360° camera opens.
X To clean the 360° camera: clean camera lens : with clean water and a soft cloth.
i If you are travelling faster than 30 km/h or if the key is in position 0 or 1 in the igni- tion lock, the cover of the 360° camera closes automatically.
Cleaning the exhaust pipe ! Do not clean the exhaust pipe with acidic cleaning agents, such as sanitary or wheel cleaners.
Impurities combined with the effects of road grit and corrosive environmental factors may cause flash rust to form on the surface. You can restore the original shine of the exhaust pipe by cleaning it regularly, especially in win- ter and after washing. X Clean the exhaust pipe with a chrome care product tested and approved by Mercedes- Benz.
Cleaning the trailer tow hitch H Environmental note Dispose of oily and greasy cloths in an envi- ronmentally-responsible manner.
! Do not clean the ball coupling with a high-
pressure cleaner. Do not use solvents.
! Observe the note on care provided by the
trailer manufacturer.
Care 371
The ball coupling must be cleaned if it becomes dirty or corroded. X Remove rust on the ball of the ball coupling,
e.g. with a wire brush.
X Remove dirt with a clean, lint-free cloth or
a brush.
X After cleaning, lightly oil or grease ball cou-
pling :.
X Check that the vehicle's trailer tow hitch is
working properly.
i You can also have the maintenance work on the ball coupling and the trailer tow hitch carried out by a qualified specialist work- shop.
Interior care Cleaning the display ! For cleaning, do not use any of the fol-
lowing: Ralcohol-based thinner or petrol Rabrasive cleaning agents Rcommercially-available household clean-
ing agents
These may damage the display surface. Do not put pressure on the display surface when cleaning. This could lead to irrepara- ble damage to the display.
X Before cleaning the display, make sure that
it is switched off and has cooled down.
X Clean the display surface using a commer- cially available microfibre cloth and TFT/ LCD display cleaner.
X Dry the display surface using a dry micro-
fibre cloth.
Cleaning Night View Assist Plus ! Never clean the camera lens. When clean- ing the field of vision of the driving systems, make sure that you do not spray glass cleaner on the camera lens. If the camera
372 Care
lens is dirty, visit a qualified specialist work- shop.
! Do not allow cosmetics, insect repellent or sunscreen to come in contact with the plastic trim. This maintains the high-quality look of the surfaces.
X Wipe the plastic trim with a damp, lint-free
cloth, e.g. a microfibre cloth.
X Heavy soiling: use car care and cleaning products recommended and approved by Mercedes-Benz. The surface may change colour tempora- rily. Wait until the surface is dry again.
Cleaning the steering wheel and gear or selector lever X Thoroughly wipe with a damp cloth or use leather care agents that have been recom- mended and approved by Mercedes-Benz.
Cleaning wooden trim and trim ele- ments ! Do not use solvent-based cleaning agents such as tar remover, wheel cleaners, pol- ishes or waxes. There is otherwise a risk of damaging the surface.
X Wipe the wooden trim and trim elements with a damp, lint-free cloth, e.g. a microfi- bre cloth.
X Heavy soiling: use car care and cleaning products recommended and approved by Mercedes-Benz.
Cleaning the seat covers ! Observe the following when cleaning: Rclean genuine leather covers carefully
with a damp cloth and then wipe the cov- ers down with a dry cloth. Make sure that the leather does not become soaked. It may otherwise become rough and cracked. Only use leather care agents that have been tested and approved by
X Fold down the camera cover by recess :.
X Use a soft cloth to clean the windscreen in
front of camera ;.
Cleaning the plastic trim G WARNING When cleaning the steering wheel boss and dashboard, do not use cockpit sprays or cleaning agents containing solvents. Cleaning agents containing solvents cause the surface to become porous, and as a result plastic parts may break away and be thrown around the interior when an airbag is deployed, which may result in severe injuries.
! Do not affix the following to plastic surfa-
ces: Rstickers Rfilms Rscented oil bottles or similar items You could otherwise damage the plastic.
Mercedes-Benz. You can obtain these from a qualified specialist workshop.
Rclean artificial leather covers with a cloth
moistened with a solution containing 1 % detergent (e.g. washing-up liquid).
Rclean cloth covers with a microfibre cloth
moistened with a solution containing 1 % detergent (e.g. washing-up liquid). Rub carefully, and always wipe entire seat sections to avoid leaving visible lines. Leave the seat to dry afterwards. Cleaning results depend on the type of dirt and how long it has been there. Rclean DINAMICA covers with a damp cloth. Make sure that you wipe entire seat sections to avoid leaving visible lines.
! Do not use microfibre cloths to clean gen- uine leather, artificial leather or DINAMICA covers. If used often, these can damage the cover.
i Note that regular care is essential to
make sure that the appearance and com- fort of the covers are retained over time.
Cleaning the seat belts ! Do not clean the seat belts using chemical cleaning agents. Do not dry the seatbelts at temperatures above 80 † or by exposing them to direct sunlight.
X Use clean, lukewarm water and soap solu-
tion.
Cleaning the roof lining and carpets X Roof lining: if it is very dirty, use a soft
brush or dry shampoo.
X Carpets: use the carpet and textile clean- ing agents recommended and approved by Mercedes-Benz.
Care 373
374
Useful information ............................ 376
Where will I find...? ........................... 376
Flat tyre ............................................. 378
Battery (vehicle) ................................ 382
Jump-starting .................................... 386
Towing and tow-starting .................. 388
Electrical fuses ................................. 391375
376 Where will I find...?
Useful information
Setting up the warning triangle
i This Owner's Manual describes all mod- els, series and optional equipment for your vehicle that were available at the time of going to press. National variations are pos- sible. Note that your vehicle may not be equipped with all of the functions descri- bed. This is also the case for systems and functions relevant to safety.
i Read the information on qualified special-
ist workshops: (Y page 25).
Where will I find...? Warning triangle Removing the warning triangle
Storage location of the warning triangle (example: vehicle with TIREFIT kit) Warning triangle : is located in the stowage well under the luggage compartment floor. X Open the tailgate. X Lift the luggage compartment floor up
(Y page 344).
i Depending on the vehicle's equipment,
warning triangle : may also be located in other places under the luggage compart- ment floor.
X Remove warning triangle :.
: Press-stud ; Reflectors = Feet X Fold feet = down and out to the side. X Pull side reflectors ; upwards to form a
triangle and lock them at the top using upper press-stud :.
First-aid kit
X Open the tailgate. X Remove first-aid kit : from the luggage
net.
i Check the expiry date on the first-aid kit at least once a year. Replace the contents if necessary, and replace any missing items.
Fire extinguisher
Vehicles with a TIREFIT kit
Where will I find...?
377
X Pull tab : upwards. X Remove fire extinguisher ;. i Have fire extinguisher ; refilled after each use and checked every one to two years. It may otherwise fail in an emer- gency. Observe the legal requirements for each individual country.
Vehicle tool kit General notes The vehicle tool kit can be found in the stow- age well under the luggage compartment floor. i Apart from certain country-specific varia- tions, vehicles are not equipped with a tyre- change tool kit. Some tools for changing a wheel are specific to the vehicle. For more information on which tools are required to perform a wheel change on your vehicle, consult a qualified specialist workshop. Necessary wheel-changing tools can include, for example: Rjack Rwheel chock Rwheel wrench Rratchet ring spanner Rcentring pin
: Wheel wrench ; Towing eye = Ratchet ring spanner ? Centring pin A Tyre sealant filler bottle B Tyre inflation compressor C Folding wheel chock D Jack E Wheel bolts X Lift the luggage compartment floor up
(Y page 344).
Vehicles with a "Minispare" emergency spare wheel
: Centring pin ; Velcro fastener = Folding wheel chock ? Ratchet ring spanner A Wheel wrench B Jack
378 Flat tyre
C Warning triangle D Wheel bolts E Towing eye X Lift the luggage compartment floor up
(Y page 344).
Flat tyre Preparing the vehicle Your vehicle may be equipped with: RMOExtended tyres (tyres with run-flat char-
acteristics) (Y page 378) Ra TIREFIT kit (Y page 379) Ran emergency spare wheel (only for certain
countries) (Y page 414)
Information on changing/fitting a wheel (Y page 404). Vehicle preparation is not necessary on vehi- cles with MOExtended tyres. X Stop the vehicle as far away as possible
