2013 Honda Civic Hybrid Owners Manual

previous display.

(- Button Press to scroll downwards.

SOURCE Button Press to set your selection.

Button

Press to go to the next display.

MENU Button Press to go to Vehicle Menu.

Continued

Index

Home

91

13 CIVIC HYBRID-31TR26100.book 92 ページ ２０１２年１２月１８日　火曜日　午後２時５９分

uuGauges and intelligent Multi-Information Display (i-MID)uintelligent Multi-Information Display (i-MID)

1Customized Features

You can exit the customizing screen at any time by pressing the MENU button.

Fuel Consumption History

Maintenance info

Trip Meter Reset

Select Trip/Odometer

QRG

TOC

â–  Customization flow Press the MENU button. Vehicle Menu

Vehicle Information

Odometer/Trip Meter

Adjust Clock *

Index

Home

92

* Not available on all models

13 CIVIC HYBRID-31TR26100.book 93 ページ ２０１２年１２月１８日　火曜日　午後２時５９分

uuGauges and intelligent Multi-Information Display (i-MID)uintelligent Multi-Information Display (i-MID)

Customize Settings

Driving support system setup *

Forward Collision Warning Distance

Display Setup

Trip Computer Setup

Select Wallpaper

Import Wallpaper Delete Wallpaper Trip Meter Item to Display Welcome Screen Color Theme Turn by Turn Display *

Language Selection Adjust Outside Temp. Display

Trip A reset trigger Trip B reset trigger Display km/miles Fuel Efficiency Backlight

QRG

TOC

* Not available on all models

Index

Home

Continued

93

QRG

TOC

13 CIVIC HYBRID-31TR26100.book 94 ページ ２０１２年１２月１８日　火曜日　午後２時５９分

uuGauges and intelligent Multi-Information Display (i-MID)uintelligent Multi-Information Display (i-MID)

Interior Light Dimming Time

Lighting Setup

Headlight Auto Off Timer

Auto Light Sensitivity Auto Door Lock

Door Lock Mode Auto Door Unlock Keyless Lock Acknowledgment

Security Relock Timer

Door Setup

Default All

Index

Home

94

13 CIVIC HYBRID-31TR26100.book 95 ページ ２０１２年１２月１８日　火曜日　午後２時５９分

uuGauges and intelligent Multi-Information Display (i-MID)uintelligent Multi-Information Display (i-MID)

â–  List of customizable options

Setup Group

Customizable Features

Description

Selectable settings

Vehicle Information

Odometer/ Trip Meter

Adjust Clock*1

Fuel Consumption History

Maintenance Information

Show the fuel consumption history.

—

Reset the Maintenance MinderTM.

No/Yes

Trip Meter Reset

Reset the trip meter.

Trip A/Trip B

Select Trip/Odometer

Switch between odometer, trip meter A, and trip meter B.

Odometer/Trip A/Trip B

Select Time Display

Select time display 12 hour or 24 hour and adjust the time.

12 h*2/24 h

*1: Models without navigation system *2: Default Setting

QRG

TOC

Index

Home

Continued

95

13 CIVIC HYBRID-31TR26100.book 96 ページ ２０１２年１２月１８日　火曜日　午後２時５９分

uuGauges and intelligent Multi-Information Display (i-MID)uintelligent Multi-Information Display (i-MID)

QRG

TOC

Index

Home

96

Setup Group

Customizable Features

Description

Selectable settings

Customize Settings

Driving Support System Setup *

Forward Collision Warning Distance

Select Wallpaper

Import Wallpaper

Delete Wallpaper

Changes at which distance FCW alerts, or turns FCW on and off.

Long/Normal*2/Short/Off

Select the full-size analogue clock or the wallpaper.

Import an image file for a new wallpaper.

Clock*2/Image 1/Image 2/ Image 3

Three images can be stored.

2 Importing wallpapers

from USB P. 99

Delete an image file for a wallpaper.

Image 1/Image 2/Image 3

Display Setup

Trip Meter Item to Display

Select an item to be displayed along with average fuel economy.

Range*2/Elapsed Time/ Average Speed

Welcome Screen

Select whether the welcome screen comes on or not when you turn the ignition switch to ON (w.

On*2/Off

Color Theme

Changes the color of the screen.

Blue*2/Red/Amber/Gray

Turn by Turn Display*1, *3

Select whether the turn-by-turn display comes on or not during the route guidance.

On*2/Off

Language Selection

Changes the displayed language.

English*2/French/Spanish

*1: Models with navigation system *2: Default Setting *3: Refer to the navigation system manual for complete details.

* Not available on all models

13 CIVIC HYBRID-31TR26100.book 97 ページ ２０１２年１２月１８日　火曜日　午後２時５９分

uuGauges and intelligent Multi-Information Display (i-MID)uintelligent Multi-Information Display (i-MID)

Setup Group

Customizable Features

Description

Selectable settings

Adjust Outside Temp. Display

Trip A reset trigger

Adjusts the temperature reading by a few degrees.

-5°F ~ ±0°F*1 ~ +5°F (U.S.) -3°C ~ ±0°C*1 ~ +3°C (Canada)

Changes the setting of how to reset trip meter A, average fuel economy A, average speed A, and elapsed time A.

With refuel/IGN Off/Manual only*1

Trip Computer Setup

Trip B reset trigger

Changes the setting of how to reset trip meter B, average fuel economy B, average speed B, and elapsed time B.

With refuel/IGN Off/Manual only*1

Customize Settings

Lighting Setup

*1: Default Setting

Display km/ miles

Fuel Efficiency Backlight

Interior Light Dimming Time

Headlight Auto Off Timer

Auto Light Sensitivity

Changes the displayed measurement on the i-MID and instant fuel economy gauge. In Auto, these measurements change in accordance with a change made to the speedometer measurement.

Auto*1/km/miles

Turns the ambient meter feature on and off.

On*1/Off

Changes the length of time the interior lights stay on after you close the doors.

60 sec/30 sec*1/15 sec

Changes the length of time the exterior lights stay on after you close the driver’s door.

60 sec/30 sec/15 sec*1/0 sec

Changes the timing for the headlights to come on. Max/High/Mid*1/Low/Min

QRG

TOC

Index

Home

Continued

97

QRG

TOC

13 CIVIC HYBRID-31TR26100.book 98 ページ ２０１２年１２月１８日　火曜日　午後２時５９分

uuGauges and intelligent Multi-Information Display (i-MID)uintelligent Multi-Information Display (i-MID)

Setup Group

Customizable Features

Description

Selectable settings

Auto Door Lock

Changes the setting for the automatic locking feature.

Off/With Vehicle Speed*1/ Shift from P

Door Lock Mode

Sets up either the driver’s door or all doors to unlock on the first operation of the remote or ignition key.

Door Setup

Auto Door Unlock

Changes the setting for when the doors unlock automatically.

Driver Door*1/All Doors

Off/Driver Door with Shift to P*1/All Doors with Shift to P/Driver Door with IGN Off/All Doors with IGN Off

Keyless Lock Acknowledgment

LOCK/UNLOCK- The exterior lights flash. LOCK (2nd push)- The beeper sounds.

On*1/Off

Security Relock Timer

Changes the time it takes for the doors to relock and the security system to set after you unlock the vehicle without opening any door.

Default All

Cancels/Resets all the customized settings as default.

90 sec/60 sec/30 sec*1

Cancel

Reset All Defaults

Customize Settings

*1: Default Setting

Index

Home

98

13 CIVIC HYBRID-31TR26100.book 99 ページ ２０１２年１２月１８日　火曜日　午後２時５９分

uuGauges and intelligent Multi-Information Display (i-MID)uintelligent Multi-Information Display (i-MID)

â–  Example for customizing wallpapers You can customize the display from clock or wallpaper.

1Customized Features

• When importing wallpaper files, the image must be in the USB flash drive’s root directory. Images in a folder cannot be imported.

• The file format of the image that can be imported

is BMP (bmp) or JPEG (jpg).

• The individual file size limit is 2 MB. • The maximum image size is 1,920 x 936 pixels. If the image size was less than 480 x 234 pixels, the image is displayed in the middle of the screen with the extra area appearing in black.

• Up to 255 files can be selected. • The file name must be fewer than 64 characters.

â–  Importing wallpapers from USB You can import up to three images, one at a time for wallpaper from a USB flash drive.

Select Import Wallpaper, from Customize Settings and properly connect a USB flash drive to store an image.

1. Connect the USB flash drive to the adapter

cable.

2 USB Adapter Cable P. 145

2. Press the MENU button.

3. Select Customize Settings, with the (+ /

(- button, then press the SOURCE button.

4. Select Display Setup with the (+ / (- button, then press the SOURCE button.

Continued

QRG

TOC

Index

Home

99

QRG

TOC

13 CIVIC HYBRID-31TR26100.book 100 ページ ２０１２年１２月１８日　火曜日　午後２時５９分

uuGauges and intelligent Multi-Information Display (i-MID)uintelligent Multi-Information Display (i-MID)

5. Select Import Wallpaper, with the (+ /

(- button, then press the SOURCE button. u The file names are displayed on

the screen.

6. Press the (- button until the file

name you want to store appears on the center of the display, then press the SOURCE button.

7. The preview of the imported data is

displayed. Press the SOURCE button if it is OK.

8. Press the SOURCE button to save the

image file.

Index

Home

100

13 CIVIC HYBRID-31TR26100.book 101 ページ ２０１２年１２月１８日　火曜日　午後２時５９分

uuGauges and intelligent Multi-Information Display (i-MID)uintelligent Multi-Information Display (i-MID)

9. Select the location you want to store the

image file in with the (+ / (- button, then press the SOURCE button.

10. Press the MENU button to exit the

customize screen.

QRG

TOC

Continued

Index

Home

101

13 CIVIC HYBRID-31TR26100.book 102 ページ ２０１２年１２月１８日　火曜日　午後２時５９分

uuGauges and intelligent Multi-Information Display (i-MID)uintelligent Multi-Information Display (i-MID)

1. Press the MENU button.

2. Select Customize Settings with the (+ / (- button, then press the SOURCE button.

3. Select Display Setup with the (+ / (- button, then press the SOURCE button.

4. Select Select Wallpaper with the (+ / (-

button, then press the SOURCE button.

5. Select the image file you want with the (+ / (- button, then press the SOURCE button. u When the scroll is stopped, the

thumbnail is displayed.

6. Press the MENU button to exit the

customize screen.

â–  Selecting a wallpaper

QRG

TOC

Index

Home

102

13 CIVIC HYBRID-31TR26100.book 103 ページ ２０１２年１２月１８日　火曜日　午後２時５９分

QRG

Controls

This chapter explains how to operate the various controls necessary for driving.

Setting the Clock .............................. 104
Locking and Unlocking the Doors

Key Types and Functions .................. 105
Locking/Unlocking the Doors from the Outside .......................................... 107
Locking/Unlocking the Doors from the Inside ............................................. 109
Childproof Door Locks ..................... 110
Auto Door Locking/Unlocking .......... 111
Opening and Closing the Trunk....... 112
Security System

Immobilizer System .......................... 115
Security System Alarm...................... 115
Opening and Closing the Windows..... 117

* Not available on all models

Operating the Switches Around the Steering Wheel Ignition Switch................................. 119
Turn Signals ..................................... 120
Light Switches.................................. 120
Daytime Running Lights ................... 123
Wipers and Washers ........................ 124
Brightness Control ........................... 125
Rear Defogger/Heated Door Mirror* Button ........................................... 126
Adjusting the Steering Wheel........... 127

Adjusting the Mirrors

Interior Rearview Mirror ................... 128
Power Door Mirrors ......................... 128

Adjusting the Seats

Adjusting the Seat Positions............. 129

Interior Lights/Interior Convenience Items Interior Lights .................................. 134
Interior Convenience Items .............. 135

Climate Control System

Using Automatic Climate Control .... 140
Automatic Climate Control Sensors ......142

Index

Home

103

1Clock

You can customize the clock display to show the 12 hour clock or 24 hour clock.

2 Customized Features P. 91

Models with navigation system The clock is automatically updated through the navigation system, so the time does not need to be adjusted.

13 CIVIC HYBRID-31TR26100.book 104 ページ ２０１２年１２月１８日　火曜日　午後２時５９分

Setting the Clock

QRG

Models without navigation system Clock You can adjust the time in the clock display, using the CLOCK knob with the ignition switch in ON (w.

1. Press the CLOCK knob to access the clock

adjustment mode screen.

2. Turn the CLOCK knob to adjust the hours.

3. Press the CLOCK knob. The display

switches to minute adjustment.

4. Turn the CLOCK knob to adjust the

minutes.

5. Press the CLOCK knob to complete clock

adjustment.

TOC

CLOCK Knob

Index

Home

104

13 CIVIC HYBRID-31TR26100.book 105 ページ ２０１２年１２月１８日　火曜日　午後２時５９分

Locking and Unlocking the Doors

Key Types and Functions This vehicle comes with the following keys:

â–  Master Keys

Use the key to start and stop the engine, and to lock and unlock all the doors. You can also use the remote transmitter to lock and unlock all the doors and to open the trunk.

Continued

1Key Types and Functions

All the keys have an immobilizer system. The immobilizer system helps to protect against vehicle theft.

2 Immobilizer System P. 115

The keys contain precision electronics. Adhere to the following advice to prevent damage to the electronics: • Do not leave the keys in direct sunlight, or in

locations with high temperature or high humidity. • Do not drop the keys or set heavy objects on them. • Keep the keys away from liquids. • Do not take the keys apart except for replacing the

battery.

If the circuits in the keys are damaged, the engine may not start, and the remote transmitter may not work. If the keys do not work properly, have them inspected by a dealer.

QRG

TOC

Index

Home

105

13 CIVIC HYBRID-31TR26100.book 106 ページ ２０１２年１２月１８日　火曜日　午後２時５９分

uuLocking and Unlocking the DoorsuKey Types and Functions

QRG

â–  Valet Key

Gray

Can be used to start and stop the engine, and lock and unlock driver’s door.

1Valet Key

When you need to leave a key with a third party, leave the valet key.

â–  Key Number Tag

Contains a number that you will need if you purchase a replacement key.

1Key Number Tag

Keep the key number tag separate from the key in a safe place outside of your vehicle.

If you wish to purchase an additional key, contact a dealer.

If you lose your key and you cannot start the engine, contact a dealer.

TOC

Index

Home

106

13 CIVIC HYBRID-31TR26100.book 107 ページ ２０１２年１２月１８日　火曜日　午後２時５９分

uuLocking and Unlocking the DoorsuLocking/Unlocking the Doors from the Outside

Locking/Unlocking the Doors from the Outside â–  Using the Remote Transmitter

LED

Unlock Button

â–  Locking the doors Press the lock button. Once:

uSome exterior lights flash, all the doors

lock, and the security system sets.

Twice (within five seconds after the first push):

uA beeper sounds and verifies the security

system is set.

Lock Button

â–  Unlocking the doors Press the unlock button. Once:

uSome exterior lights flash twice, and the

driver’s door unlocks.

Twice:

uThe remaining doors unlock.

Continued

1Using the Remote Transmitter

If you do not open a door within 30 seconds of unlocking the vehicle with the remote transmitter, the doors will automatically relock. You can change the relock timer setting.

2 Customized Features P. 91

If the interior light switch is in the door activated position, the interior lights come on when you press the unlock button. No doors opened: The lights fade out after 30 seconds. Doors relocked with the remote: The lights go off immediately.

2 Interior Lights P. 134

The remote transmitter uses low-power signals, so the operating range may vary depending on the surroundings.

The remote will not lock the vehicle when a door is open.

If the distance at which it works varies, the battery is probably low. If the LED does not come on when you press a button, the battery is dead.

2 Replacing the Button Battery P. 289

You can customize the door unlock mode setting.

2 Customized Features P. 91

QRG

TOC

Index

Home

107

13 CIVIC HYBRID-31TR26100.book 108 ページ ２０１２年１２月１８日　火曜日　午後２時５９分

uuLocking and Unlocking the DoorsuLocking/Unlocking the Doors from the Outside

â–  Locking/Unlocking the Doors Using a Key

Fully insert the key and turn it.

Lock

Unlock

â–  Locking a Door Without Using a Key

passenger’s door

■ Locking the driver’s and front Push the lock tab forward a or push the master door lock switch in the lock direction b, and close the door.

■ Locking the rear passengers’ doors Push the lock tab forward and close the door.

â–  Lockout prevention system The doors cannot be locked when the key is in the ignition switch, and any door is open.

1Locking/Unlocking the Doors Using a Key

When you lock the driver’s door with a key, all the other doors lock at the same time. When unlocking, the driver’s door unlocks first. Turn the key a second time within a few seconds to unlock the remaining doors.

You can customize the door unlock mode setting.

2 Customized Features P. 91

1Locking a Door Without Using a Key

When you lock the driver’s door, all the other doors lock at the same time. Make sure you have the key in your hand before locking the door to prevent it from being locked in the vehicle.

QRG

TOC

Index

Home

108

13 CIVIC HYBRID-31TR26100.book 109 ページ ２０１２年１２月１８日　火曜日　午後２時５９分

uuLocking and Unlocking the DoorsuLocking/Unlocking the Doors from the Inside

Locking/Unlocking the Doors from the Inside â–  Using the Lock Tab

To Lock

Lock Tab

To Unlock

â–  Locking a door Push the lock tab forward.

â–  Unlocking a door Pull the lock tab rearward.

1Using the Lock Tab

When you lock the door using the lock tab on the driver’s door, all the other doors lock at the same time.

When you unlock the door using the lock tab on the driver’s door, only the driver’s door will unlock.

â–  Unlocking Using the Inner Handle of Front Doors Pull the front door inner handle.

Inner Handle

uThe door unlocks and opens in one

motion.

1Unlocking Using the Inner Handle of Front Doors

The inner front door handles are designed to allow front seat occupants to open the door in one motion. However this feature requires that front seat occupants never pull a front door inner handle while the vehicle is in motion.

Children should always ride in a rear seat where childproof door locks are provided.

2 Childproof Door Locks P. 110

Continued

QRG

TOC

Index

Home

109

13 CIVIC HYBRID-31TR26100.book 110 ページ ２０１２年１２月１８日　火曜日　午後２時５９分

uuLocking and Unlocking the DoorsuChildproof Door Locks

â–  Using the Master Door Lock Switch

Press the master door lock switch in as shown to lock or unlock all doors.

To Lock

1Using the Master Door Lock Switch

When you lock/unlock each front door using the master lock switch, all the other doors lock/unlock at the same time.

To Unlock

Master Door Lock Switch

Childproof Door Locks The childproof door locks prevent the rear doors from being opened from the inside regardless of the position of the lock tab.

â–  Setting the Childproof Door Locks

Slide the lever in the rear door to the lock position, and close the door.

â–  When opening the door Open the door using the outside door handle.

Unlock

Lock

1Childproof Door Locks

To open the door from the inside when the childproof door lock is on, put the lock tab in the unlock position, lower the rear window, put your hand out of the window, and pull the outside door handle.

QRG

TOC

Index

Home

110

13 CIVIC HYBRID-31TR26100.book 111 ページ ２０１２年１２月１８日　火曜日　午後２時５９分

uuLocking and Unlocking the DoorsuAuto Door Locking/Unlocking

Auto Door Locking/Unlocking Your vehicle locks all doors and unlocks the driver’s door automatically when a certain condition is met.

■ Auto Door Locking ■ Drive lock mode All doors lock when the vehicle’s speed reaches about 10 mph (15 km/h).

■ Auto Door Unlocking ■ Park unlock mode The driver’s door unlocks when the shift lever is moved into (P with the brake pedal depressed.

1Auto Door Locking/Unlocking

You can turn off or change to another auto door locking/unlocking setting using the intelligent multi- information display.

2 Customized Features P. 91

QRG

TOC

Index

Home

111

13 CIVIC HYBRID-31TR26100.book 112 ページ ２０１２年１２月１８日　火曜日　午後２時５９分

Opening and Closing the Trunk

QRG

Precautions for Opening/Closing the Trunk â–  Opening the trunk Open the trunk all the way.

u If it is not fully opened, the trunk lid may begin to close under its own weight.

â–  Closing the trunk Keep the trunk lid closed while driving to:

uAvoid possible damage. uPrevent exhaust gas from leaking into the vehicle. 2 Carbon Monoxide Gas P. 64

Using the Trunk Opener

Pulling the trunk release to the lower left of the driver’s seat unlocks and opens the trunk.

Trunk Release

TOC

Index

Home

112

13 CIVIC HYBRID-31TR26100.book 113 ページ ２０１２年１２月１８日　火曜日　午後２時５９分

uuOpening and Closing the TrunkuUsing the Remote Transmitter

â–  Locking the trunk opener You can lock the trunk release with the master key.

1Locking the trunk opener

If you need to give the key to someone else, give them the valet key.

Using the Remote Transmitter

Trunk Release Button

Press the trunk release button for approximately one second to unlock and open the trunk.

QRG

TOC

Index

Home

113

13 CIVIC HYBRID-31TR26100.book 114 ページ ２０１２年１２月１８日　火曜日　午後２時５９分

uuOpening and Closing the TrunkuEmergency Trunk Opener

QRG

Emergency Trunk Opener

The trunk release lever allows you to open the trunk from inside for your safety.

Lever

Slide the release lever in the direction of the arrow.

1Emergency Trunk Opener

Parents should decide if their children should be shown how to use this feature.

TOC

Index

Home

114

13 CIVIC HYBRID-31TR26100.book 115 ページ ２０１２年１２月１８日　火曜日　午後２時５９分

Security System

Immobilizer System The immobilizer system prevents a key that has not been pre-registered from starting the engine. Each key contains electronic transmitters that use electronic signals to verify the key.

Pay attention to the following when inserting the key into the ignition switch:

• Do not allow objects that emit strong radio waves near the ignition switch.

• Make sure the key is not covered by or touching a metal object.

• Do not bring a key from another vehicle’s immobilizer system near the

ignition switch.

Security System Alarm The security system alarm activates when the doors, trunk, or hood are opened without the key, or remote transmitter.

â–  When the security system alarm activates The horn sounds intermittently and all of the exterior lights flash.

â–  To deactivate the security system alarm Unlock the vehicle using the key, or remote transmitter, or turn the ignition switch to ON (w. The system, along with the horn and flashing lights, is deactivated.

Continued

1Immobilizer System

NOTICE Leaving the ignition key in the vehicle can result in theft or accidental movement of the vehicle.

Always take the ignition key with you whenever you leave the vehicle unattended.

Do not alter the system or add other devices to it. Doing so may damage the system and make your vehicle inoperable.

1Security System Alarm

The security alarm continues for a maximum of two minutes until the security system deactivates.

QRG

TOC

Index

Home

115

13 CIVIC HYBRID-31TR26100.book 116 ページ ２０１２年１２月１８日　火曜日　午後２時５９分

uuSecurity SystemuSecurity System Alarm

QRG

TOC

Index

Home

116

■ Setting the security system alarm The security system alarm automatically sets when the following conditions have been met: • The ignition switch is in LOCK (0, and the key has been removed from the

ignition switch.

• The hood and trunk are closed. • All doors are locked with the key or the remote transmitter.

â–  When the security system alarm sets The security system indicator in the instrument panel blinks. When the blinking interval changes after about 15 seconds, the security system is set.

â–  To cancel the security system alarm The security system is canceled when the vehicle is unlocked using the key or remote transmitter, or the ignition switch is turned to ON (w. The security system indicator goes off at the same time.

1Security System Alarm

Do not set the security system alarm when someone is in the vehicle or a window is open. The system can accidentally activate when: • Unlocking the door with the lock tab. • Opening the trunk with the trunk release or the

emergency trunk opener.

If the battery goes dead after you have set the security system alarm, the security alarm may go off once the battery is recharged or replaced. If this occurs, deactivate the security system alarm by unlocking a door using the key or remote transmitter.

Do not attempt to alter this system or add another device to it.

â–  Panic Mode

PANIC Button

â–  The PANIC button on the remote

transmitter

If you press the PANIC button for approximately one second, the following will occur for about 30 seconds: • The horn sounds. • Some exterior lights flash.

â–  Canceling panic mode Press any button on the remote transmitter, or turn the ignition switch to ON (w.

13 CIVIC HYBRID-31TR26100.book 117 ページ ２０１２年１２月１８日　火曜日　午後２時５９分

Opening and Closing the Windows

Opening/Closing the Power Windows The power windows can be opened and closed when the ignition switch is in ON (w, using the switches on the doors. The driver’s side switches can be used to open and close all of the windows.

The power window lock button on the driver’s side must be switched off (not pushed in, indicator off) to open and close the windows from anywhere other than the driver’s seat.

When the power window lock button is pushed in, the indicator comes on and you can only operate the driver’s window. Turn the power window lock button on when children are in the vehicle.

â–  Opening/Closing Windows with Auto-Open/Close Function

Driver’s Window Switch

On Off

Power Window Lock Button

â–  Automatic operation To open: Push the switch down firmly. To close: Pull the switch up firmly.

Indicator

The window opens or closes completely. To stop the window at any time, push or pull the switch briefly.

â–  Manual operation To open: Push the switch down lightly. To close: Pull the switch up lightly.

Release the switch when the window reaches the desired position.

Continued

1Opening/Closing the Power Windows

3WARNING

Closing a power window on someone’s hands or fingers can cause serious injury.

Make sure your passengers are away from the windows before closing them.

The power windows can be operated for up to 10 minutes after you turn the ignition switch off. Opening either front door cancels this function.

Auto Reverse If a power window senses resistance when closing automatically, it will stop closing and reverse direction.

The driver’s window auto reverse function is disabled when you continuously pull up the switch.

The auto reverse function stops sensing when the window is almost closed to ensure that it fully closes.

QRG

TOC

Index

Home

117

13 CIVIC HYBRID-31TR26100.book 118 ページ ２０１２年１２月１８日　火曜日　午後２時５９分

uuOpening and Closing the WindowsuOpening/Closing the Power Windows

â–  Opening/Closing Windows without Auto-Open/Close Function

Close

Open

To open: Push the switch down. To close: Pull the switch up.

Release the switch when the window reaches the desired position.

QRG

TOC

Index

Home

118

13 CIVIC HYBRID-31TR26100.book 119 ページ ２０１２年１２月１８日　火曜日　午後２時５９分

Operating the Switches Around the Steering Wheel

Ignition Switch

(0 LOCK: Insert and remove the key in this position.

(q ACCESSORY: Operate the audio system and other accessories in this position.

(w ON: This is the position when driving.

(e START: This position is for starting the engine. The switch returns to ON (w when you let go of the key.

1Ignition Switch

You cannot take the key out unless the shift lever is in (P.

If you open the driver’s door when the key is in LOCK (0 or ACCESSORY (q, a warning buzzer will sound to remind you to take the key out. When this happens, the following messages appear on the intelligent multi-information display (i-MID): • In LOCK (0: REMOVE KEY • In ACCESSORY (q: RETURN IGNITION SWITCH

TO LOCK (0) POSITION The buzzer will stop when you take the key out.

If the key won’t turn from LOCK (0 to ACCESSORY (q, turn the key while moving the steering wheel left and right. The steering wheel will unlock, allowing the key to turn.

QRG

TOC

Index

Home

119

13 CIVIC HYBRID-31TR26100.book 120 ページ ２０１２年１２月１８日　火曜日　午後２時５９分

uuOperating the Switches Around the Steering WheeluTurn Signals

QRG

Turn Signals

Right Turn

Left Turn

Light Switches â–  Manual Operation

High Beams

Flashing the high beams

Low Beams

Turns on parking, side marker, tail, and rear license plate lights Turns on headlights, parking, side marker, tail, and rear license plate lights

TOC

Index

Home

120

The turn signals can be used when the ignition switch is in ON (w.

â–  One-touch turn signal When you lightly push up or down and release the turn signal lever, the exterior turn signals and turn signal indicator blink three times.

This feature can be used when signaling for a lane change.

Rotating the light switch turns the lights on and off, regardless of the position of the ignition switch. â–  High beams Push the lever forward until you hear a click. â–  Low beams When in high beams, pull the lever back to return to low beams. â–  Flashing the high beams Pull the lever back, and release it.

1Light Switches

If you remove the key from the ignition switch while the lights are on, a chime sounds when the driver’s door is opened.

Do not leave the lights on when the engine is off because it will cause the battery to discharge.

If you sense that the level of the headlights is abnormal, have the vehicle inspected by a dealer.

13 CIVIC HYBRID-31TR26100.book 121 ページ ２０１２年１２月１８日　火曜日　午後２時５９分

uuOperating the Switches Around the Steering WheeluLight Switches

â–  Automatic Lighting Control

Automatic lighting control can be used when the ignition switch is in ON (w.

1Automatic Lighting Control

We recommend that you turn on the lights manually when driving at night, in a dense fog, or in dark areas such as long tunnels or parking facilities.

When you turn the light switch to AUTO, the headlights and other exterior lights will switch on and off automatically depending on the ambient brightness.

The light sensor is in the location shown below. Do not cover this light sensor with anything; otherwise, the automatic lighting system may not work properly.

u You can change the auto

lig h t sensitivity setting. 2 Customized Features P. 91

Light Sensor

Adjust the auto light sensitivity as follows:

Setting

Max High Mid Low Min

The exterior lights come on when the ambient light is at

Bright

Dark

Continued

QRG

TOC

Index

Home

121

13 CIVIC HYBRID-31TR26100.book 122 ページ ２０１２年１２月１８日　火曜日　午後２時５９分

uuOperating the Switches Around the Steering WheeluLight Switches

QRG

TOC

Index

Home

122

â–  Headlight Integration with Wiper* The headlights automatically come on when the wipers are used several times within a certain intervals with the headlight switch in AUTO.

The headlights automatically go off a few minutes later if the wipers are stopped.

1Headlight Integration with Wiper*

This feature activates during the headlights are off in AUTO.

The instrument panel brightness does not change when the headlights come on.

■ Automatic Lighting Off Feature The headlights, all other exterior lights, and the instrument panel lights turn off within 15 seconds after you remove the key and close the driver’s door.

When the ambient light is at dark, the automatic lighting control feature overrides, and the headlights come on with or without the wipers sweeping more than several times.

uYou can change the headlight auto off timer setting.

2 Customized Features P. 91

If you turn the ignition switch to LOCK (0 with the headlight switch on, but do not open the door, the lights turn off after 10 minutes (three minutes, if the switch is in the AUTO position).

The lights turn on again when you unlock or open the driver’s door. If you unlock the door, but do not open it within 15 seconds, the lights go off. If you open the driver’s door, you will hear a lights on reminder chime.

* Not available on all models

13 CIVIC HYBRID-31TR26100.book 123 ページ ２０１２年１２月１８日　火曜日　午後２時５９分

uuOperating the Switches Around the Steering WheeluDaytime Running Lights

Daytime Running Lights The daytime running lights come on when the following conditions have been met: • The ignition switch is in ON (w.

• The headlight switch is off or in

• The parking brake is released.

The lights remain on even if you set the parking brake. Turning off the ignition switch will turn off the daytime running lights.

QRG

TOC

Index

Home

123

13 CIVIC HYBRID-31TR26100.book 124 ページ ２０１２年１２月１８日　火曜日　午後２時５９分

uuOperating the Switches Around the Steering WheeluWipers and Washers

QRG

Wipers and Washers

The windshield wipers and washers can be used when the ignition switch is in ON (w.

â–  MIST The wipers run at high speed until you release the lever.

â–  Wiper switch (OFF, INT, LO, HI) Change the wiper switch setting according to the amount of rain.

â–  Adjusting the delay Turn the adjustment ring to adjust the wiper delay.

Long delay

Short delay

â–  Washer Sprays while you pull the lever toward you. When you release the lever, the wipers make two or three more sweeps before stopping.

1Wipers and Washers

NOTICE Do not use the wipers when the windshield is dry. The windshield will get scratched, or the rubber blades will get damaged.

NOTICE In cold weather, the blades may freeze to the windshield, becoming stuck. Operating the wipers in this condition may damage the wipers. Use the defroster to warm the windshield, then turn the wipers on.

If the vehicle speeds up while the wipers are operating intermittently, the length of the wipe interval shortens. When the vehicle starts moving, the wipers make a single sweep. When the vehicle speeds up, the wiper operation’s shortest delay setting ( the same.

) and the LO setting become

Turn the washers off if no washer fluid comes out. The pump may get damaged.

The wiper motor is equipped with a breaker that may stop motor operation temporarily to prevent an overload. Wiper operation will return to normal within a few minutes, once the circuit has returned to normal.

If the wiper stops operating due to any obstacle such as the build-up of snow, park the vehicle in a safe place.

Rotate the wiper switch to OFF, and turn the ignition switch to ACCESSORY (q or LOCK (0, then remove the obstacle.

Pull to use washer.

Intermittent Time Adjustment Ring

MIST OFF INT: Low speed with intermittent LO: Low speed wipe HI: High speed wipe

TOC

Index

Home

124

13 CIVIC HYBRID-31TR26100.book 125 ページ ２０１２年１２月１８日　火曜日　午後２時５９分

uuOperating the Switches Around the Steering WheeluBrightness Control

Brightness Control

Control Knob

When the ignition switch is in ON (w, you can use the brightness control knob to adjust instrument panel brightness. Brighten: Turn the knob to the right. Dim: Turn the knob to the left.

You will hear a beeper when the brightness reaches minimum or maximum. The intelligent multi-information display (i-MID) will return to its original state several seconds after you adjust the brightness.

â–  Brightness level indicator The brightness level is shown on the i-MID while you are adjusting it. As the brightness level increases to the right, the instrument panel gets brighter.

1Brightness Control

Instrument panel brightness varies, depending on whether the exterior lights are on or off. The instrument panel dims to reduce glare when they are on.

Pressing the (display/information) button switches the display.

(Select/Reset) knob or the

If you turn the knob to the right until the brightness display is up to max, the beeper sounds. This cancels the reduced instrument panel brightness when the parking lights are on.

The brightness can be set differently for when the exterior lights are on, and when they are off.

QRG

TOC

Index

Home

125

13 CIVIC HYBRID-31TR26100.book 126 ページ ２０１２年１２月１８日　火曜日　午後２時５９分

uuOperating the Switches Around the Steering WheeluRear Defogger/Heated Door Mirror* Button

QRG

Rear Defogger/Heated Door Mirror* Button

Press the rear defogger and heated door mirror button to defog the rear window and mirrors when the ignition switch is in ON (w.

The rear defogger and heated door mirrors automatically switch off after 10-30 minutes depending on the outside temperature. However, if the outside temperature is 32°F (0°C) or below, they do not automatically switch off.

1Rear Defogger/Heated Door Mirror * Button

NOTICE When cleaning the inside of the rear window, be careful not to damage the heating wires.

It is critical to wipe the window from side to side along the defogger heating wires.

This system consumes a lot of power, so turn it off when the window has been defogged.

Also, do not use the system for a long period when the engine is idling. This may weaken the 12 volt battery, making it difficult to start the engine.

TOC

Index

Home

126

* Not available on all models

13 CIVIC HYBRID-31TR26100.book 127 ページ ２０１２年１２月１８日　火曜日　午後２時５９分

uuOperating the Switches Around the Steering WheeluAdjusting the Steering Wheel

Adjusting the Steering Wheel The steering wheel height and distance from your body can be adjusted so that you can comfortably grip the steering wheel in an appropriate driving posture.

To adjust

To lock

Lever

1. Pull the steering wheel adjustment lever up.

u The steering wheel adjustment lever is

under the steering column.

2. Move the steering wheel up or down, and

in or out. u Make sure you can see the instrument

panel gauges and indicators.

3. Push the steering wheel adjustment lever

down to lock the steering wheel in position. u After adjusting the position, make sure

you have securely locked the steering wheel in place by trying to move it up, down, in, and out.

1Adjusting the Steering Wheel

3WARNING

Adjusting the steering wheel position while driving may cause you to lose control of the vehicle and be seriously injured in a crash.

Adjust the steering wheel only when the vehicle is stopped.

Make any steering wheel adjustments before you start driving.

QRG

TOC

Index

Home

127

1Adjusting the Mirrors

Keep the inside and outside mirrors clean and adjusted for best visibility.

Adjust the mirrors before you start driving. 2 Adjusting the Seat Positions P. 129

13 CIVIC HYBRID-31TR26100.book 128 ページ ２０１２年１２月１８日　火曜日　午後２時５９分

Adjusting the Mirrors

QRG

Interior Rearview Mirror Adjust the angle of the rearview mirror when you are sitting in the correct driving position.

â–  Rearview Mirror with Day and Night Positions

Flip the tab to switch the position. The night position will help to reduce the glare from headlights behind you when driving after dark.

You can adjust the door mirrors when the ignition switch is in ON (w.

â–  Mirror position adjustment L/R selector switch: Select the left or right mirror. After adjusting the mirror, return the switch to the center position.

Mirror position adjustment switch: Press
