shifted into P (Park).
GMC Yukon/Yukon XL Owner Manual - 2013 - CRC 2nd edition - 8/15/12
Black plate (47,1)
NO CHANGE: No change will be made to this feature. The current setting will remain. To select a setting, press the set/ reset button while the desired setting is displayed on the DIC.
REMOTE DOOR LOCK This feature allows you to select the type of feedback you will receive when locking the vehicle with the Remote Keyless Entry (RKE) transmitter. You will not receive feedback when locking the vehicle with the RKE transmitter if the doors are open. See Remote Keyless Entry (RKE) System Operation on page 2‑3 for more information.
Instruments and Controls
5-47
Press the customization button until REMOTE DOOR LOCK appears on the DIC display. Press the set/reset button once to access the settings for this feature. Then press the customization button to scroll through the following settings: OFF: There will be no feedback when you press the lock button on the RKE transmitter. LIGHTS ONLY: The exterior lamps will flash when you press the lock button on the RKE transmitter. HORN ONLY: The horn will sound on the second press of the lock button on the RKE transmitter. HORN & LIGHTS (default): The exterior lamps will flash when you press the lock button on the RKE transmitter, and the horn will sound when the lock button is pressed again within five seconds of the previous command. NO CHANGE: No change will be made to this feature. The current setting will remain.
To select a setting, press the set/ reset button while the desired setting is displayed on the DIC.
REMOTE DOOR UNLOCK This feature allows you to select the type of feedback you will receive when unlocking the vehicle with the Remote Keyless Entry (RKE) transmitter. You will not receive feedback when unlocking the vehicle with the RKE transmitter if the doors are open. See Remote Keyless Entry (RKE) System Operation on page 2‑3 for more information. Press the customization button until REMOTE DOOR UNLOCK appears on the DIC display. Press the set/ reset button once to access the settings for this feature. Then press the customization button to scroll through the following settings: LIGHTS OFF: The exterior lamps will not flash when you press the unlock button on the RKE transmitter.
GMC Yukon/Yukon XL Owner Manual - 2013 - CRC 2nd edition - 8/15/12
Black plate (48,1)
5-48
Instruments and Controls
LIGHTS ON (default): The exterior lamps will flash when you press the unlock button on the RKE transmitter. NO CHANGE: No change will be made to this feature. The current setting will remain. To select a setting, press the set/ reset button while the desired setting is displayed on the DIC.
DELAY DOOR LOCK This feature allows you to select whether or not the locking of the vehicle's doors and liftgate will be delayed. When locking the doors and liftgate with the power door lock switch and a door or the liftgate is open, this feature will delay locking the doors and liftgate until five seconds after the last door is closed. You will hear three chimes to signal that the delayed locking feature is in use. The key must be out of the ignition for this feature to work. You can temporarily override delayed locking by pressing the
power door lock switch twice. See Delayed Locking on page 2‑8 for more information. Press the customization button until DELAY DOOR LOCK appears on the DIC display. Press the set/reset button once to access the settings for this feature. Then press the customization button to scroll through the following settings: OFF: There will be no delayed locking of the vehicle's doors. ON (default): The doors will not lock until 5 seconds after the last door or the liftgate is closed. NO CHANGE: No change will be made to this feature. The current setting will remain. To select a setting, press the set/ reset button while the desired setting is displayed on the DIC.
EXIT LIGHTING This feature allows you to select the amount of time you want the exterior lamps to remain on when it
is dark enough outside. This happens after the key is turned from ON/RUN to LOCK/OFF. Press the customization button until EXIT LIGHTING appears on the DIC display. Press the set/reset button once to access the settings for this feature. Then press the customization button to scroll through the following settings: OFF: The exterior lamps will not turn on. 30 SECONDS (default): The exterior lamps will stay on for 30 seconds. 1 MINUTE: The exterior lamps will stay on for 1 minute. 2 MINUTES: The exterior lamps will stay on for 2 minutes. NO CHANGE: No change will be made to this feature. The current setting will remain. To select a setting, press the set/ reset button while the desired setting is displayed on the DIC.
GMC Yukon/Yukon XL Owner Manual - 2013 - CRC 2nd edition - 8/15/12
Black plate (49,1)
Instruments and Controls
5-49
APPROACH LIGHTING This feature allows you to select whether or not to have the exterior lights turn on briefly during low light periods after unlocking the vehicle using the Remote Keyless Entry (RKE) transmitter. Press the customization button until APPROACH LIGHTING appears on the DIC display. Press the set/reset button once to access the settings for this feature. Then press the customization button to scroll through the following settings: OFF: The exterior lights will not turn on when you unlock the vehicle with the RKE transmitter. ON (default): If it is dark enough outside, the exterior lights will turn on briefly when you unlock the vehicle with the RKE transmitter. The lights will remain on for 20 seconds or until the lock button on the RKE transmitter is pressed, or the vehicle is no longer off. See
Remote Keyless Entry (RKE) System Operation on page 2‑3 for more information. NO CHANGE: No change will be made to this feature. The current setting will remain. To select a setting, press the set/ reset button while the desired setting is displayed on the DIC.
CHIME VOLUME This feature allows you to select the volume level of the chime. Press the customization button until CHIME VOLUME appears on the DIC display. Press the set/reset button once to access the settings for this feature. Then press the customization button to scroll through the following settings: NORMAL: The chime volume will be set to a normal level. LOUD: The chime volume will be set to a loud level.
NO CHANGE: No change will be made to this feature. The current setting will remain. There is no default for chime volume. The volume will stay at the last known setting. To select a setting, press the set/ reset button while the desired setting is displayed on the DIC.
PARK TILT MIRRORS If your vehicle has this feature, it allows you to select whether or not the outside mirror(s) will automatically tilt down when the vehicle is shifted into R (Reverse). See Park Tilt Mirrors on page 2‑19
for more information.GMC Yukon/Yukon XL Owner Manual - 2013 - CRC 2nd edition - 8/15/12
Black plate (50,1)
5-50
Instruments and Controls
Press the customization button until PARK TILT MIRRORS appears on the DIC display. Press the set/reset button once to access the settings for this feature. Then press the customization button to scroll through the following settings: OFF (default): Neither outside mirror will be tilted down when the vehicle is shifted into R (Reverse). DRIVER MIRROR: The driver outside mirror will be tilted down when the vehicle is shifted into R (Reverse). PASSENGER MIRROR: The passenger outside mirror will be tilted down when the vehicle is shifted into R (Reverse). BOTH MIRRORS: The driver and passenger outside mirrors will be tilted down when the vehicle is shifted into R (Reverse). NO CHANGE: No change will be made to this feature. The current setting will remain.
To select a setting, press the set/ reset button while the desired setting is displayed on the DIC.
EASY EXIT RECALL If your vehicle has this feature, it allows you to select your preference for the automatic easy exit seat feature. See Memory Seats on page 3‑7 for more information. Press the customization button until EASY EXIT RECALL appears on the DIC display. Press the set/reset button once to access the settings for this feature. Then press the customization button to scroll through the following settings: DOOR BUTTON ONLY: No automatic seat exit recall will occur. The recall will only occur after pressing the easy exit seat button. BUTTON & KEY OUT (default): If the features are enabled through the EASY EXIT SETUP menu, the driver seat will move back when the
key is removed from the ignition or after pressing the easy exit seat button. The automatic easy exit seat movement will only occur one time after the key is removed from the ignition. If the automatic movement has already occurred, and you put the key back in the ignition and remove it again, the seat will stay in the original exit position, unless a memory recall took place prior to removing the key again. NO CHANGE: No change will be made to this feature. The current setting will remain. To select a setting, press the set/ reset button while the desired setting is displayed on the DIC.
EASY EXIT SETUP If your vehicle has this feature, it allows you to select which areas will recall with the automatic easy exit seat feature. It also allows you to turn off the automatic easy exit
GMC Yukon/Yukon XL Owner Manual - 2013 - CRC 2nd edition - 8/15/12
Black plate (51,1)
feature. See Memory Seats on page 3‑7 and EASY EXIT RECALL earlier for more information. Press the customization button until EASY EXIT SETUP appears on the DIC display. Press the set/reset button once to access the settings for this feature. Then press the menu up/down button to scroll through the following settings: OFF: No automatic seat exit will recall. SEAT ONLY (Default): The driver seat will recall. NO CHANGE: No change will be made to this feature. The current setting will remain. To select a setting, press the set/ reset button while the desired setting is displayed on the DIC.
Instruments and Controls
5-51
MEMORY SEAT RECALL If your vehicle has this feature, it allows you to select your preference for the remote memory seat recall feature. See Memory Seats on page 3‑7 for more information. Press the customization button until MEMORY SEAT RECALL appears on the DIC display. Press the set/ reset button once to access the settings for this feature. Then press the customization button to scroll through the following settings: OFF (default): No remote memory seat recall will occur. ON: The driver seat and, on some vehicles, the outside mirrors will automatically move to the stored driving position when the unlock button on the Remote Keyless Entry (RKE) transmitter is pressed. On some vehicles with the adjustable throttle and brake pedal feature, the pedals will also automatically move.
NO CHANGE: No change will be made to this feature. The current setting will remain. To select a setting, press the set/ reset button while the desired setting is displayed on the DIC.
REMOTE START If your vehicle has this feature, it allows you to turn the remote start off or on. The remote start feature allows you to start the engine from outside of the vehicle using the Remote Keyless Entry (RKE) transmitter. See Remote Vehicle Start on page 2‑5 for more information. Press the customization button until REMOTE START appears on the DIC display. Press the set/reset button once to access the settings for this feature. Then press the customization button to scroll through the following settings: OFF: The remote start feature will be disabled.
GMC Yukon/Yukon XL Owner Manual - 2013 - CRC 2nd edition - 8/15/12
Black plate (52,1)
5-52
Instruments and Controls
ON (default): The remote start feature will be enabled. NO CHANGE: No change will be made to this feature. The current setting will remain. To select a setting, press the set/ reset button while the desired setting is displayed on the DIC.
FACTORY SETTINGS This feature allows you to set all of the customization features back to their factory default settings. Press the customization button until FACTORY SETTINGS appears on the DIC display. Press the set/reset button once to access the settings for this feature. Then press the customization button to scroll through the following settings:
RESTORE ALL (default): The customization features will be set to their factory default settings. DO NOT RESTORE: The customization features will not be set to their factory default settings. To select a setting, press the set/ reset button while the desired setting is displayed on the DIC.
EXIT FEATURE SETTINGS This feature allows you to exit the feature settings menu. Press the customization button until PRESS V TO EXIT FEATURE SETTINGS appears in the DIC display. Press the set/reset button once to exit the menu. If you do not exit, pressing the customization button again will return you to the beginning of the feature settings menu.
Exiting the Feature Settings Menu The feature settings menu will be exited when any of the following occurs:
The vehicle is no longer in ON/RUN. The trip/fuel or vehicle information DIC buttons are pressed. The end of the feature settings menu is reached and exited. . A 40 second time period has
elapsed with no selection made.
GMC Yukon/Yukon XL Owner Manual - 2013 - CRC 2nd edition - 8/15/12
Black plate (53,1)
Universal Remote System See Radio Frequency Statement on page 13‑21 for information regarding Part 15 of the Federal Communications Commission (FCC) rules and Industry Canada Standards RSS-GEN/210/220/310.
Universal Remote System Programming
Vehicles with the Universal Remote System will have these buttons located in the headliner. This system provides a way to replace up to three remote control transmitters used to activate
Instruments and Controls
5-53
devices such as garage door openers, security systems, and home automation devices. Do not use this system with any garage door opener that does not have the stop and reverse feature. This includes any garage door opener model manufactured before April 1, 1982. Read the instructions completely before attempting to program the transmitter. Because of the steps involved, it may be helpful to have another person assist with programming the transmitter. Be sure to keep the original remote control transmitter for use in other vehicles, as well as for future programming. Only the original remote control transmitter is needed for Fixed Code programming.
The programmed buttons should be erased when the vehicle is sold or the lease ends. See “Erasing Universal Home Remote Buttons” in this section. Park the vehicle outside of the garage when programming a garage door. Be sure that people and objects are clear of the garage door or gate that is being programmed. Programming Universal Home Remote — Rolling Code For questions or help programming the Universal Home Remote System, call 1-866-572-2728 or go to www.learcar2u.com. Most garage door openers sold after 1996 are Rolling Code units. Programming a garage door opener involves time-sensitive actions, so read the entire procedure before starting. Otherwise, the device will time out and the procedure will have to be repeated.
GMC Yukon/Yukon XL Owner Manual - 2013 - CRC 2nd edition - 8/15/12
Black plate (54,1)
5-54
Instruments and Controls
To program up to three devices: 1. From inside the vehicle, press the two outside buttons at the same time for one to two seconds, and immediately release them.
hanging antenna wire is attached to the motor-head unit and may be a colored button. Press this button. After pressing this button, complete the following steps in less than 30 seconds. Immediately return to the vehicle. Press and hold the Universal Home Remote button that will be used to control the garage door until the garage door moves. The indicator light, above the selected button, should slowly blink. This button may need to be held for up to 20 seconds. Immediately, within one second, release the button when the garage door moves. The indicator light will blink rapidly until programming is complete.
3.
4.
To program another Rolling Code device such as an additional garage door opener, a security device, or home automation device, repeat Steps 1 through 5, choosing a different function button in Step 3
than what was used for the garage door opener. If these instructions do not work, the garage door opener is probably a Fixed Code unit. Follow the programming instructions that follow for a Fixed Code garage door opener. Programming Universal Home Remote — Fixed Code For questions or help programming the Universal Home Remote System, call 1-866-572-2728 or go to www.learcar2u.com.2.
In the garage, locate the garage door opener receiver (motor-head unit). Find the “Learn” or “Smart” button. It can usually be found where the
5. Press and release the same
button again. The garage door should move, confirming that programming is successful and complete.
GMC Yukon/Yukon XL Owner Manual - 2013 - CRC 2nd edition - 8/15/12
Black plate (55,1)
Most garage door openers sold before 1996 are Fixed Code units. Programming a garage door opener involves time-sensitive actions, so read the entire procedure before starting. Otherwise, the device will time out and the procedure will have to be repeated.
Instruments and Controls
5-55
To program up to three devices: 1. To verify that the garage door opener is a Fixed Code unit, remove the battery cover on the hand-held transmitter supplied by the manufacturer of the garage door opener motor. If there is a row of dip switches similar to the graphic above, the garage door opener is a Fixed Code unit. If you do not see a row of dip switches, return to the previous section for Programming Universal Home Remote — Rolling Code. Your hand-held transmitter can have between 8 to 12 dip switches depending on the brand of transmitter.
The garage door opener receiver (motor head unit) could also have a row of dip switches that can be used when programming the Universal Home Remote. If the total number of switches on the motor head and hand-held transmitter are different, or if the dip switch settings are different, use the dip switch settings on the motor head unit to program the Universal Home Remote. The motor head dip switch settings can also be used when the original hand-held transmitter is not available.
Example of Eight Dip Switches
with Two Positions
GMC Yukon/Yukon XL Owner Manual - 2013 - CRC 2nd edition - 8/15/12
Black plate (56,1)
5-56
Instruments and Controls
2. Write down the 8 to 12 switch
settings from left to right as follows:
buttons to put the Universal Home Remote into programming mode.
Example of Eight Dip Switches
with Three Positions
The panel of switches might not appear exactly as they do in the examples above, but they should be similar. The switch positions on the hand-held transmitter could be labeled as follows:
A switch in the up position could be labeled as Up, +, or On. A switch in the down position could be labeled as Down, −, or Off. A switch in the middle position could be labeled as Middle, 0, or Neutral.
When a switch is in the up position, write “Left.” When a switch is in the down position, write “Right.” If a switch is set between the up and down position, write “Middle.” The switch settings written down in Step 2 now become the button strokes to be entered into the Universal Home Remote in Step 4. Be sure to enter the switch settings written down in Step 2, in order from left to right, into the Universal Home Remote, when completing Step 4.
3. From inside your vehicle, first
firmly press all three buttons at the same time for about three seconds. Release the
A. Left Button (Up, +, or On) B. Middle Button (Middle, 0,
or Neutral)
C. Right Button (Down, −,
or Off)
GMC Yukon/Yukon XL Owner Manual - 2013 - CRC 2nd edition - 8/15/12
Black plate (57,1)
4. The indicator lights will blink
5. After entering all of the switch
8. Press and release the same
Instruments and Controls
5-57
slowly. Enter each switch setting from Step 2 into your vehicle's Universal Home Remote. You will have two and one-half minutes to complete Step 4. Now press one button on the Universal Home Remote for each switch setting as follows: If you wrote “Left,” press the left button (A) in the vehicle. If you wrote “Right,” press the right button (C) in the vehicle. If you wrote “Middle,” press the middle button (B) in the vehicle.
button again. The garage door should move, confirming that programming is successful and complete.
To program another Fixed Code device such as an additional garage door opener, a security device, or home automation device, repeat Steps 1-8, choosing a different button in Step 6 than what was used for the garage door opener.
positions, once again firmly press and release all three buttons at the same time. The indicator lights will turn on.
6. Press and hold the button that
will be used to control the garage door until the garage door moves. The indicator light above the selected button should slowly blink. This button may need to be held for up to 55 seconds. Immediately release the button when the garage door moves. The indicator light will blink rapidly until programming is complete.
7.
GMC Yukon/Yukon XL Owner Manual - 2013 - CRC 2nd edition - 8/15/12
Black plate (58,1)
5-58
Instruments and Controls
Universal Remote System Operation Press and hold the appropriate button for at least half of a second. The indicator light will come on while the signal is being transmitted. Reprogramming Universal Home Remote Buttons Any of the three buttons can be reprogrammed by repeating the instructions.
Erasing Universal Home Remote Buttons The programmed buttons should be erased when the vehicle is sold or the lease ends. To erase either Rolling Code or Fixed Code settings on the Universal Home Remote device: 1. Press and hold the two outside
buttons at the same time for approximately 20 seconds, until the indicator lights, located directly above the buttons, begin to blink rapidly.
2. Once the indicator lights begin to
blink, release both buttons. The codes from all buttons will be erased.
For help or information on the Universal Home Remote System, call the customer assistance phone number under Customer Assistance Offices (U.S. and Canada) on page 13‑5 or Customer Assistance Offices (Mexico) on page 13‑5.
GMC Yukon/Yukon XL Owner Manual - 2013 - CRC 2nd edition - 8/15/12
Black plate (1,1)
Lighting
Exterior Lighting
Exterior Lamp Controls . . . . . . . . 6-1
Exterior Lamps OffReminder . . . . . . . . . . . . . . . . . . . . 6-2
Headlamp High/Low-Beam
Changer . . . . . . . . . . . . . . . . . . . . . 6-2
Flash-to-Pass . . . . . . . . . . . . . . . . . 6-2
Daytime RunningLamps (DRL) . . . . . . . . . . . . . . . . 6-3
Automatic Headlamp
System . . . . . . . . . . . . . . . . . . . . . . 6-3
Hazard Warning Flashers . . . . . 6-5
Turn and Lane-ChangeSignals . . . . . . . . . . . . . . . . . . . . . . 6-5
Fog Lamps . . . . . . . . . . . . . . . . . . . . 6-6
AuxiliaryRoof-Mounted Lamp . . . . . . . . . 6-6
Interior Lighting
Instrument Panel Illumination
Control . . . . . . . . . . . . . . . . . . . . . . 6-7
Dome Lamps . . . . . . . . . . . . . . . . . 6-7
Reading Lamps . . . . . . . . . . . . . . . 6-8Lighting Features
Entry Lighting . . . . . . . . . . . . . . . . . 6-8
Exit Lighting . . . . . . . . . . . . . . . . . . . 6-8
Battery Load Management . . . . 6-8
Battery Power Protection . . . . . . 6-9Lighting
6-1
Exterior Lighting
Exterior Lamp Controls
The exterior lamp control is on the instrument panel to the left of the steering wheel. There are four positions: O (Off): Turns off the automatic headlamps and Daytime Running Lamps (DRL). Turn the headlamp control to the off position again to turn the automatic headlamps or DRL back on. For vehicles first sold in Canada, the off position will only work when the vehicle is shifted into P (Park).
GMC Yukon/Yukon XL Owner Manual - 2013 - CRC 2nd edition - 8/15/12
Black plate (2,1)
6-2
Lighting
AUTO (Automatic): Automatically turns on the headlamps at normal brightness, together with the following: . Parking Lamps
Instrument Panel Lights Taillamps License Plate Lamps
; (Parking Lamps): Turns on the parking lamps together with the following:
Instrument Panel Lights Taillamps License Plate Lamps
2 (Headlamps): Turns on the headlamps together with the following lamps listed below. . Parking Lamps
Instrument Panel Lights Taillamps License Plate Lamps
When the headlamps are turned on while the vehicle is on, the headlamps will turn off automatically 10 minutes after the ignition is turned off. When the headlamps are turned on while the vehicle is off, the headlamps will stay on for 10 minutes before automatically turning off to prevent the battery from being drained. Turn the headlamp control to off and then back to the headlamp on position to make the headlamps stay on for an additional 10 minutes.
Exterior Lamps Off Reminder A reminder chime will sound when the headlamps or parking lamps are manually turned on and the ignition is off and a door is open. To disable the chime, turn the light off.
Headlamp High/ Low-Beam Changer 5 3 (Headlamp High/Low Beam Changer): To change the headlamps from low to high beam, push the turn signal lever toward the instrument panel. To return to low-beam headlamps, pull the lever toward you. Then release it.
When the high beams are on, this indicator light on the instrument cluster will also be on.
Flash-to-Pass This feature lets you use the high-beam headlamps to signal a driver in front of you that you want to pass. It works even if the headlamps are in the automatic position.
GMC Yukon/Yukon XL Owner Manual - 2013 - CRC 2nd edition - 8/15/12
Black plate (3,1)
To use it, pull the turn signal lever toward you, then release it. If the headlamps are in the automatic position or on low beam, the high-beam headlamps will turn on. They will stay on as long as you hold the lever toward you. The high-beam indicator on the instrument cluster will come on. Release the lever to return to normal operation.
Daytime Running Lamps (DRL) Daytime Running Lamps (DRL) can make it easier for others to see the front of your vehicle during the day. Fully functional daytime running lamps are required on all vehicles first sold in Canada. The DRL system comes on when the following conditions are met:
The ignition is on. The exterior lamp control is in AUTO.
The transmission is not in Park. The light sensor determines it is daytime.
When the DRL system is on, only the DRL lamps are on. The taillamps, sidemarker, instrument panel lights, and other lamps will not be on. When it begins to get dark, the automatic headlamp system switches from DRL to the headlamps. To turn off the DRL lamps, turn the exterior lamp control to the OFF position and then release. For vehicles first sold in Canada, the transmission must be in the P (Park) position before the DRL lamps can be turned off.
Automatic Headlamp System When it is dark enough outside, the automatic headlamp system turns on the headlamps at the normal brightness, along with the taillamps,
Lighting
6-3
sidemarker, parking lamps, and the instrument panel lights. The radio lights will also be dim. To turn off the automatic headlamp system, turn the exterior lamps switch to the off position and then release it. For vehicles first sold in Canada, the transmission must be in the P (Park) position before the automatic headlamp system can be turned off.
The vehicle has a light sensor located on the top of the instrument panel which regulates when the automatic headlamps turn on. Do not cover the sensor, otherwise the headlamps will come on whenever the ignition is on.
GMC Yukon/Yukon XL Owner Manual - 2013 - CRC 2nd edition - 8/15/12
Black plate (4,1)
6-4
Lighting
The system may also turn on the headlamps when driving through a parking garage or heavy overcast weather. This is normal. There is a delay in the transition between the daytime and nighttime operation of the Daytime Running Lamps (DRL) and the automatic headlamp systems so that driving under bridges or bright overhead street lights does not affect the system. The DRL and automatic headlamp system are only affected when the light sensor detects a change in lighting lasting longer than the delay. If the vehicle is started in a dark garage, the automatic headlamp system comes on immediately. Once the vehicle leaves the garage, it takes approximately one minute for the automatic headlamp system to change to DRL if it is bright enough outside. During that delay, the instrument cluster may not be as bright as usual. Make sure the instrument panel brightness control
is in the full bright position. See Instrument Panel Illumination Control on page 6‑7. To idle the vehicle with the automatic headlamp system off, turn the control to the off position. The headlamps will also stay on after you exit the vehicle. This feature can be programmed using the Driver Information Center (DIC). See Vehicle Personalization (With DIC Buttons) on page 5‑45. If the vehicle is not equipped with DIC buttons, exit lighting is automatic. When it is dark enough outside, the exterior lamps remain on for 30 seconds after the ignition is moved from ON/RUN to LOCK/OFF. For vehicles without a radio, the instrument panel light remains on for 30 seconds with the driver door closed. For vehicles with a radio, the instrument panel light remains on for 10 minutes with the driver
door closed. See Retained Accessory Power (RAP) on page 9‑25. The regular headlamp system can be turned on when needed. Lights On with Wipers If the windshield wipers are activated in daylight with the engine on, and the exterior lamp control is in AUTO, the headlamps, parking lamps, and other exterior lamps come on. The transition time for the lamps coming on varies based on wiper speed. When the wipers are not operating, these lamps turn off. Move the exterior lamp control to P or ; to disable this feature.
GMC Yukon/Yukon XL Owner Manual - 2013 - CRC 2nd edition - 8/15/12
Black plate (5,1)
Hazard Warning Flashers
Turn and Lane-Change Signals
| (Hazard Warning Flashers): Press this button to make the front and rear turn signal lamps flash on and off. Press again to turn the flashers off. When the hazard warning flashers are on, the vehicle's turn signals will not work.
Move the lever all the way up or down to signal a turn. An arrow on the instrument cluster flashes in the direction of the turn or lane change. Raise or lower the lever for less than one second until the arrow starts to flash to signal a lane change. This causes the turn signals to automatically flash three times. It will flash six times if tow-haul mode is active. Holding the turn signal lever for more than
Lighting
6-5
one second will cause the turn signals to flash until you release the lever. The lever returns to its starting position whenever it is released. If after signaling a turn or a lane change the arrows flash rapidly or do not come on, a signal bulb may be burned out. Have any burned out bulbs replaced. If a bulb is not burned out, check the fuse. See Fuses and Circuit Breakers on page 10‑34.
Turn Signal On Chime If the turn signal is left on for more than 1.2 km (0.75 mi), a chime will sound at each flash of the turn signal and the message TURN SIGNAL ON will also appear in the Driver Information Control (DIC). To turn the chime and message off, move the turn signal lever to the off position.
GMC Yukon/Yukon XL Owner Manual - 2013 - CRC 2nd edition - 8/15/12
Black plate (6,1)
6-6
Lighting
Fog Lamps
For vehicles with fog lamps, the control is located next to the exterior lamp control on the instrument panel, to the left of the steering column. The ignition must be in the ON/RUN position for the fog lamps to come on. # (Fog Lamps): Press to turn the fog lamps on or off. A light will come on in the instrument cluster. When the fog lamps are turned on, the parking lamps automatically turn on.
When the headlamps are changed to high beam, the fog lamps also go off. When the high-beam headlamps are turned off, the fog lamps will come on again. Some localities have laws that require the headlamps to be on with the fog lamps.
Auxiliary Roof-Mounted Lamp If the vehicle has this feature, this button includes wiring provisions for a dealer or a qualified service center to install an auxiliary roof lamp.
This button is on the overhead console.
When the wiring is connected to an auxiliary roof-mounted lamp, pressing the bottom of the button will activate the lamp and illuminate an indicator light at the bottom of this button. Pressing the top of the button will turn off the roof-mounted lamp and indicator. The emergency roof lamp circuit is fused at 30 amps, so the total current draw of the attached lamps should be less than this value. The attachment points for the roof lamp circuits are two blunt cut wires located above the overhead console, a dark green switched power wire and a black ground wire. For more information on roof mount emergency lamp installation, please visit the GM Upfitter website at www.gmupfitter.com or contact your dealer. If the vehicle has this button, the vehicle may have the snow plow prep package. See Adding a Snow Plow or Similar Equipment on page 9‑81.
GMC Yukon/Yukon XL Owner Manual - 2013 - CRC 2nd edition - 8/15/12
Black plate (7,1)
Lighting
6-7
k (Dome Off): Press the button in and the dome lamps remain off when a door is opened. Press the button again to return it to the extended position so that the dome lamps come on when a door is opened.
Interior Lighting
Instrument Panel Illumination Control
D (Instrument Panel Brightness): This feature controls the brightness of the instrument panel lights and is located next to the exterior lamps control. Push the knob to extend out and then it can be turned.
Turn the knob clockwise or counterclockwise to brighten or dim the instrument panel lights. Turning the knob to the farthest clockwise position turns on the dome lamps.
Dome Lamps The dome lamps are located in the overhead console. They come on when any door is opened and turn off after all the doors are closed. Turn the instrument panel brightness knob located below the dome lamp override button, clockwise to the farthest position to manually turn on the dome lamps. The dome lamps remain on until the knob is turned counterclockwise.
Dome Lamp Override The dome lamp override button is located next to the exterior lamps control.
GMC Yukon/Yukon XL Owner Manual - 2013 - CRC 2nd edition - 8/15/12
Black plate (8,1)
6-8
Lighting
Reading Lamps For vehicles with reading lamps they are located on the overhead console. To turn on the reading lamps, press the button located next to each lamp. To turn them off, press the button again. The vehicle may also have reading lamps in other locations. To turn the lamps on or off, press the button located next to the lamp. The lamps are fixed and cannot be adjusted.
Lighting Features
Entry Lighting The vehicle has an illuminated entry feature. When the doors are opened, the dome lamps will come on if the dome override button is in the extended position. If the dome override button is pressed in, the lamps will not come on.
Exit Lighting The interior lamps come on when the key is removed from the ignition. They turn off automatically in 20 seconds. The lights do not come on if the dome override button is pressed in.
Battery Load Management The vehicle has Electric Power Management (EPM) that estimates the battery's temperature and state of charge. It then adjusts the voltage for best performance and extended life of the battery. When the battery's state of charge is low, the voltage is raised slightly to quickly bring the charge back up. When the state of charge is high, the voltage is lowered slightly to prevent overcharging. If the vehicle has a voltmeter gauge or a voltage display on the Driver Information Center (DIC), you may see the voltage move up or down. This is normal. If there is a problem, an alert will be displayed.
GMC Yukon/Yukon XL Owner Manual - 2013 - CRC 2nd edition - 8/15/12
Black plate (9,1)
Lighting
6-9
Battery Power Protection This feature shuts off the dome and reading lamps if they are left on for more than 10 minutes when the ignition is off. This will keep the battery from running down.
The battery can be discharged at idle if the electrical loads are very high. This is true for all vehicles. This is because the generator (alternator) may not be spinning fast enough at idle to produce all the power that is needed for very high electrical loads. A high electrical load occurs when several of the following are on, such as: headlamps, high beams, fog lamps, rear window defogger, climate control fan at high speed, heated seats, engine cooling fans, trailer loads, and loads plugged into accessory power outlets.
EPM works to prevent excessive discharge of the battery. It does this by balancing the generator's output and the vehicle's electrical needs. It can increase engine idle speed to generate more power, whenever needed. It can temporarily reduce the power demands of some accessories. Normally, these actions occur in steps or levels, without being noticeable. In rare cases at the highest levels of corrective action, this action may be noticeable to the driver. If so, a Driver Information Center (DIC) message might be displayed, such as BATTERY LOW START VEHICLE. If this message displays, it is recommended that the driver reduce the electrical loads as much as possible and restart the vehicle. See Battery Voltage and Charging Messages on page 5‑35.
GMC Yukon/Yukon XL Owner Manual - 2013 - CRC 2nd edition - 8/15/12
Black plate (10,1)
6-10
Lighting
2 NOTES
GMC Yukon/Yukon XL Owner Manual - 2013 - CRC 2nd edition - 8/15/12
Black plate (1,1)
Infotainment System
Introduction
Infotainment . . . . . . . . . . . . . . . . . . . 7-1
Theft-Deterrent Feature . . . . . . . 7-2
Overview (Radio withCD (MP3)) . . . . . . . . . . . . . . . . . . . 7-3
Overview (Radio with CD, USB,
and DVD (MP3)) . . . . . . . . . . . . . 7-5
Operation . . . . . . . . . . . . . . . . . . . . . 7-6Radio
AM-FM Radio . . . . . . . . . . . . . . . . 7-10
Satellite Radio . . . . . . . . . . . . . . . 7-11
Radio Reception . . . . . . . . . . . . . 7-14
Rear Side WindowAntenna . . . . . . . . . . . . . . . . . . . . 7-15
Satellite Radio Antenna . . . . . . 7-16Audio Players
CD Player . . . . . . . . . . . . . . . . . . . 7-16
CD/DVD Player . . . . . . . . . . . . . . 7-21
Auxiliary Devices . . . . . . . . . . . . 7-31Rear Seat Infotainment Rear Seat Entertainment
(RSE) System . . . . . . . . . . . . . . 7-36
Rear Seat Audio (RSA)
System . . . . . . . . . . . . . . . . . . . . . 7-46
Infotainment System 7-1
Introduction
Infotainment Read the following pages to become familiar with the audio system's features.
{ WARNING
Phone
Bluetooth . . . . . . . . . . . . . . . . . . . . 7-48
Trademarks and License Agreements
Trademarks and License
Agreements . . . . . . . . . . . . . . . . 7-55
Taking your eyes off the road for extended periods could cause a crash resulting in injury or death to you or others. Do not give extended attention to infotainment tasks while driving.
This system provides access to many audio and non audio listings. To minimize taking your eyes off the road while driving, do the following while the vehicle is parked: . Become familiar with the
operation and controls of the audio system.
GMC Yukon/Yukon XL Owner Manual - 2013 - CRC 2nd edition - 8/15/12
Black plate (2,1)
The vehicle has Retained Accessory Power (RAP). With RAP, the audio system can be played even after the ignition is turned off. See Retained Accessory Power (RAP) on page 9‑25 for more information. Navigation/Radio System For vehicles with a navigation radio system, see the separate Navigation System manual.
Theft-Deterrent Feature TheftLock® is designed to discourage theft of the vehicle's radio by learning a portion of the Vehicle Identification Number (VIN). The radio does not operate if it is stolen or moved to a different vehicle.
7-2
Infotainment System
. Set up the tone, speaker
adjustments, and preset radio stations.
For more information, see Defensive Driving on page 9‑3. This vehicle's audio system may be equipped with a noise reduction system which can work improperly if the audio amplifier, engine calibrations, exhaust system, microphones, radio, or speakers are modified or replaced. This could result in more noticeable engine noise at certain speeds. Notice: Contact your dealer before adding any equipment. Adding audio or communication equipment could interfere with the operation of the engine, radio, or other systems, and could damage them. Follow federal rules covering mobile radio and telephone equipment.
GMC Yukon/Yukon XL Owner Manual - 2013 - CRC 2nd edition - 8/15/12
Black plate (3,1)
Overview (Radio with CD (MP3))
Overview (Radio with CD (MP3))
A.
4 (Information)
Press to show information on the current station or track.
B. FAV (Favorites Pages)
Press to scroll through the favorite pages.
Infotainment System 7-3
C. MENU
Press to open the tone menu to adjust the bass, midrange, treble, fade, and balance. D. Buttons 1 - 6
Saves and selects favorite stations.
E. EQ (Equalizer)
Press to adjust the equalizer. F. f (Tone/Tune)
Press to set the bass or treble. Turn to manually select radio stations.
G. CAT (Category)
Press to display a list of XM categories.
H. H (Clock)
Press to set the clock.
GMC Yukon/Yukon XL Owner Manual - 2013 - CRC 2nd edition - 8/15/12
Black plate (4,1)
7-4
Infotainment System
I.
BAND
L. P (Power/Volume)
N. \ FWD (Forward)
Press to scroll through the available bands AM, FM, or XM if equipped.
J. © SEEK
Press to turn the infotainment system on or off. Turn to adjust the volume.
Seeks the previous station.
M. s REV (Reverse)
K. ¨ SEEK
Seeks the next station.
Press to and hold to go backward fast through a track.
Press to and hold to fast forward through a track.
O. CD/AUX
Press to scroll through selecting the CD or a auxiliary device.
P. Z Eject
Press to eject the loaded CD.
GMC Yukon/Yukon XL Owner Manual - 2013 - CRC 2nd edition - 8/15/12
Black plate (5,1)
Overview (Radio with CD, USB, and DVD (MP3))
C. MENU
Infotainment System 7-5
Press to open the tone menu to adjust the bass, midrange, treble, fade, and balance.
D. DVD Slot E. Buttons 1 - 6
Saves and selects favorite stations.
F. EQ (Equalizer)
Press to adjust the equalizer settings.
G. f (Tone/Tune)
Press to set the bass or treble. Turn to manually select radio stations.
Overview (Radio with CD, USB, and DVD (MP3))
A.
4 (Information)
B. FAV (Favorites Pages)
H. Z DVD
Press to show information on the current station or track.
Press to scroll through the favorite pages.
Press to eject the loaded DVD.
GMC Yukon/Yukon XL Owner Manual - 2013 - CRC 2nd edition - 8/15/12
Black plate (6,1)
7-6
Infotainment System
I. CAT (Category)
Press to display a list of XM categories.
J. H (Clock)
Press to set the clock.
K. BAND
Press to scroll through the available bands AM, FM, or XM if equipped.
L. © SEEK
Seeks the previous station.
M. ¨ SEEK
Seeks the next station.
N. P (Power/Volume)
Press to turn the infotainment system on or off. Turn to adjust the volume.
O. CD Slot P. s REV (Reverse)
Press to and hold to go backward fast through a track.
Q. \ FWD (Forward)
Press to and hold to fast forward through a track.
R. Z CD
Press to eject the loaded CD.
S. DVD/CD/AUX
Press to scroll through selecting the DVD, CD, or an auxiliary device.
Operation Vehicles with a USB, CD, and DVD radio have a Bose® Surround Sound System. Some of its features are explained later in this section under, “Adjusting the Speakers (Balance/Fade).” Vehicles with a USB, CD, and DVD radio may have a Rear Seat Entertainment (RSE) system. See Rear Seat Entertainment (RSE) System on page 7‑36 for more information on the vehicle's RSE system. The DVD player is the top slot on the radio faceplate. The player is capable of reading the DTS programmed DVD Audio or DVD Video media, (DTS and DTS Digital Surround are registered trademarks of Digital Theater Systems, Inc.). Manufactured under license from Dolby Laboratories. Dolby and the double-D symbol are trademarks of Dolby Laboratories.
GMC Yukon/Yukon XL Owner Manual - 2013 - CRC 2nd edition - 8/15/12
Black plate (7,1)
Using the Radio O (Power/Volume): Press to turn the system on and off. Turn clockwise or counterclockwise to increase or decrease the volume. 4 (Information) (If Available): Press to switch the display between the radio station frequency and the time. While the ignition is off, press this button to display the time. Press to display additional text information related to the current FM-RDS or XM station; or CD, MP3, or WMA song. If information is available during XM, CD, MP3, or WMA playback, the song title information displays on the top line of the display and artist information displays on the bottom line. When information is not available, “NO INFO” displays. Speed Compensated Volume (SCV): Radios with Speed Compensated Volume (SCV) automatically adjusts the radio volume to compensate for road and
wind noise as the vehicle's speed changes while driving, so that the volume level stays consistent. To activate SCV: 1. Set the radio volume to the
desired level.
2. Press the MENU button to
display the radio setup menu.
3. Press the softkey under the
AUTO VOLUM (automatic volume) tab on the radio display.
4. Press the softkey under the
desired Speed Compensated Volume setting (OFF, Low, Med, or High) to select the level of radio volume compensation. The display times out after approximately 10 seconds. Each higher setting allows for more radio volume compensation at faster vehicle speeds.
Noise Compensation Technology: Vehicles with the LTZ package and a Bose Audio System include the Bose AudioPilot® noise compensation technology. When
Infotainment System 7-7
turned on, AudioPilot continuously adjusts the audio system equalization, to compensate for background noise, so that music always sounds the same at the set volume level. This feature is most effective at lower radio volume settings where background noise can affect how well the music is heard. At higher volume settings, where the music is much louder than the background noise, there might be little or no adjustments by AudioPilot. To activate: 1. Set the radio volume to the
desired level.
2. Press the MENU button to
display the radio setup menu.
3. Press the softkey under the
AUTO VOLUM (automatic volume) tab on the radio display. 4. Press the softkey under the ON tab. The display times out after approximately 10 seconds.
GMC Yukon/Yukon XL Owner Manual - 2013 - CRC 2nd edition - 8/15/12
Black plate (8,1)
7-8
Infotainment System
For additional information on AudioPilot, please visit www.bose.com/audiopilot. Setting the Tone (Bass/ Midrange/Treble) BASS/MID/TREB (Bass, Midrange, or Treble): To adjust the bass, midrange, or treble: 1. Press the f knob until the tone
control tabs display.
2. Highlight the desired tone
control tab by doing one of the following:
Pressing the f knob. Press the softkey under the desired tab.
3. Adjust the setting by doing one
of the following:
Turn the f knob clockwise or counterclockwise. Press the ¨ SEEK, or © SEEK button.
Press the \ FWD, or s REV button.
If a station's frequency is weak or if there is static, decrease the treble. To quickly adjust bass, midrange, or treble to the middle position, press the softkey positioned under the BASS, MID, or TREB tab for more than two seconds. A beep sounds and the level adjusts to the middle position. To quickly adjust all tone and speaker controls to the middle position, press the f knob for more than two seconds until a beep sounds. EQ (Equalization): Press this button to choose bass and treble equalization settings designed for different types of music. Selecting MANUAL or changing bass or treble, returns the EQ to the manual bass and treble settings. Unique EQ settings can be saved for each source.
If the radio has a Bose audio system, the EQ settings are either MANUAL or TALK. Digital Signal Processing (DSP): Press the EQ button to change the DSP settings (only available on Bose systems with the LTZ option package). DSP settings provide a choice of different listening experiences. The following DSP settings are available: . Normal — Select this setting to
adjust the audio for normal mode. This provides the best sound quality for all seating positions.
. Driver — Select this setting to
adjust the audio for the driver to receive the best possible sound quality.
. Rear — Select this setting to
adjust the audio for the rear seat passengers to receive the best possible sound quality.
GMC Yukon/Yukon XL Owner Manual - 2013 - CRC 2nd edition - 8/15/12
Black plate (9,1)
Infotainment System 7-9
3. Adjust the setting by doing one
of the following:
Turn the f knob clockwise or counterclockwise. Press the ¨ SEEK, or © SEEK button. Press the \ FWD, or s REV button.
To quickly adjust all speaker and tone controls to the middle position, press the f knob for more than two seconds. If the Rear Seat Audio (RSA) is turned on, the radio disables FADE and mutes the rear speakers.
Radio Messages Calibration Error: The audio system has been calibrated for the vehicle from the factory. If Calibration Error displays, it means that the radio has not been configured properly for the vehicle and it must be returned to your dealer for service. Locked or Loc: One of these messages will display when the TheftLock® system has locked up the radio. Take the vehicle to your dealer for service. If any error occurs repeatedly or if an error cannot be corrected, contact your dealer.
. Surround (Centerpoint®) —
Select this setting to enable Bose Centerpoint. Centerpoint signal processing produces a surround sound listening experience from a CD or XM stereo digital audio source. Centerpoint delivers five independent audio channels from conventional two channel stereo recordings. (Not available for AM or FM.)
Adjusting the Speakers (Balance/Fade) BAL/FADE (Balance/Fade): To adjust the balance or fade: 1. Press the f knob until the
speaker control tabs display. 2. Highlight the desired speaker
control tab by doing one of the following:
Pressing the f knob. Press the softkey under the desired tab.
GMC Yukon/Yukon XL Owner Manual - 2013 - CRC 2nd edition - 8/15/12
Black plate (10,1)
7-10
Infotainment System
Radio
AM-FM Radio
Radio Data System (RDS) For radios with the Radio Data System (RDS) feature, it only works with FM stations that broadcast RDS information. This system relies upon receiving specific information from these stations and only works when the information is available. While the radio is tuned to an FM-RDS station, the station name or call letters displays. In rare cases, a radio station could broadcast incorrect information that causes the radio features to work improperly. If this happens, contact the radio station. 4 (Information) (RDS Features): For vehicles with RDS features, press 4 to display additional text information related to the current FM-RDS station. If information is available, the song title information displays on the top line of the
display and artist information displays on the bottom line. When information is not available, “NO INFO” displays. Finding a Station BAND: Press to switch between AM, FM, or XM™, if equipped. f (Tune): Turn to manually select radio stations. © SEEK: Press to seek the previous radio station. Press and hold for a few seconds until a beep sounds to scan for radio stations in descending order, press the © SEEK button again to stop scanning radio stations. The radio only seeks and scans stations with a strong signal that are in the selected band. ¨ SEEK: Press to seek the next radio station. Press and hold for a few seconds until a beep sounds to scan for radio stations in ascending order, press the ¨ SEEK button again to stop scanning radio
stations. The radio only seeks and scans stations with a strong signal that are in the selected band. s REV: Press to manually tune to a radio station in descending order. \ FWD: Press to manually tune to a radio station in ascending order. FAV (Favorites): Press to select different favorite pages for stored radio stations. Storing Radio Stations Drivers are encouraged to store radio station while the vehicle is parked, see Defensive Driving on page 9‑3. Tune to stored radio stations using the presets, favorites button, and steering wheel controls, if the vehicle has this feature. Up to 36 stations can be programmed as favorites using the sixbutton. Press the FAV button to go through up to six pages of favorites, each having six favorite stations available per page. Each
GMC Yukon/Yukon XL Owner Manual - 2013 - CRC 2nd edition - 8/15/12
Black plate (11,1)
page of favorites can contain any combination of AM, FM, or XM, if equipped, stations.
Storing a Radio Station as a Favorite To store a station as a favorite: 1. Tune to a radio station. 2. Press the FAV button to display the page where the station will be stored.
3. Press and hold one of the
six softkeys until a beep sounds.
4. Repeat Steps 1 through 3 to
store additional radio stations.
The number of favorites pages can be setup using the MENU button. To setup the number of favorites pages: 1. Press the MENU button. 2. Press the softkey located below
the FAV 1-6 tab.
3. Select the number of favorites pages by pressing the softkey located below the displayed page numbers.
4. Press the FAV button, or let the menu time out, to return to the original main radio screen showing the radio station frequency tabs and to begin the process of programming favorites.
Satellite Radio
SiriusXM® Satellite Radio Service SiriusXM is a satellite radio service that is based in the 48 contiguous United States and 10 Canadian provinces. SiriusXM Satellite Radio has a wide variety of programming and commercial-free music, coast-to-coast, and in digital-quality sound. A service fee is required to receive the SiriusXM service. If the service needs to be reactivated, the radio will display “No Subscription Please Renew on channel XM1.”
Infotainment System 7-11
For more information, contact SiriusXM at www.siriusxm.com or call 1-866-635-2349 (U.S) and www.xmradio.ca or call 1-877-209-0079 (Canada). 4 (Information) (SiriusXM Satellite Radio Service): For vehicles with SiriusXM, press 4 to display additional text information related to the current SiriusXM channel. If information is available, the song title information displays on the top line of the display and artist information displays on the bottom line. When information is not available, “NO INFO” displays. Finding a Channel BAND: Press to switch between AM, FM, or SiriusXM, if equipped. f (Tune): Turn to manually select an SiriusXM channel. © SEEK: Press to go to the previous SiriusXM channel. ¨ SEEK: Press to go to the next SiriusXM channel.
GMC Yukon/Yukon XL Owner Manual - 2013 - CRC 2nd edition - 8/15/12
Black plate (12,1)
