towing capabilities of your vehicle and more information. 112 Following break-in, engine speed and load can be gradually increased. Ignition Positions Use the key to turn the ignition switch to four different positions. A (LOCK): This position locks the ignition and transmission. It is a theft-deterrent feature. You will only be able to remove the key when the ignition is turned to LOCK. If your key seems stuck in LOCK and Notice: you cannot turn it, be sure you are using the correct key; if so, is it all the way in? Turn the key only with your hand. Using a tool to force it could break the key or the ignition switch. If none of these works, then your vehicle needs service. B (ACCESSORY): This position lets you use things like the radio and the windshield wipers when the engine is off. Lengthy operation of features such as the radio in the accessory ignition position may drain the battery and prevent your vehicle from starting. Do not operate your vehicle in the accessory ignition position for a long period of time. C (RUN): This is the position for driving. The battery could be drained if you leave the key in the ACCESSORY or RUN position with the engine off. You may not be able to start your vehicle if the battery is allowed to drain for an extended period of time. D (START): This position starts the engine. 113 Key In the Ignition Never leave your vehicle with the keys inside, as it is an easy target for joy riders or thieves. If you leave the key in the ignition and park your vehicle, a chime will sound, when you open the driver’s door. Always remember to remove your key from the ignition and take it with you. This will lock your ignition and transmission. Also, always remember to lock the doors. The battery could be drained if you leave the key in the ignition while your vehicle is parked. You may not be able to start your vehicle after it has been parked for an extended period of time. Retained Accessory Power (RAP) Your vehicle has a Retained Accessory Power (RAP) feature which lets certain features of your vehicle to continue to work up to 20 minutes after the ignition key is turned to LOCK. The radio, power windows, the overhead console and the sunroof, if the vehicle has one, work when the ignition key is in RUN or ACCESSORY. Once the key is turned from RUN to LOCK, these features continue to work for up to 20 minutes, or until a door is opened. 114 Starting the Engine Place the transmission in the proper gear. Move your shift lever to PARK (P) or NEUTRAL (N). Your engine will not start in any other position -- this is a safety feature. To restart when you are already moving, use NEUTRAL (N) only. Notice: Do not try to shift to PARK (P) if your vehicle is moving. If you do, you could damage the transmission. Shift to PARK (P) only when your vehicle is stopped. Starting Procedure 1. With your foot off the accelerator pedal, turn the ignition key to START. When the engine starts, let go of the key. The idle speed will goes as your engine gets warm. Do not race the engine immediately after starting it. Operate the engine and transmission gently to let the oil to warm up and lubricate all moving parts. Your vehicle has a Computer-Controlled Cranking System. This feature assists in starting the engine and protects components. If the ignition key is turned to the START position, and then released when the engine begins cranking, the engine continues cranking for a few seconds or until the vehicle starts. If the engine does not start and the key is held in START for many seconds, cranking stops after 15 seconds to prevent cranking motor damage. To prevent gear damage, this system also prevents cranking if the engine is already running. Engine cranking can be stopped by turning the ignition switch to the ACCESSORY or LOCK position. Notice: Cranking the engine for long periods of time, by returning the key to the START position immediately after cranking has ended, can overheat and damage the cranking motor, and drain the battery. Wait at least 15 seconds between each try, to allow the cranking motor to cool down. 2. If the engine does not start after 5-10 seconds, especially in very cold weather (below 0°F or −18°C), it could be ﬂooded with too much gasoline. Try pushing the accelerator pedal all the way to the ﬂoor and holding it there as you hold the key in START for up to a maximum of 15 seconds. Wait at least 15 seconds between each try, to allow the cranking motor to cool down. When the engine starts, let go of the key and accelerator. If the vehicle starts brieﬂy but then stops again, do the same thing. This clears the extra gasoline from the engine. Do not race the engine immediately after starting it. Operate the engine and transmission gently until the oil warms up and lubricates all moving parts. Notice: Your engine is designed to work with the electronics in your vehicle. If you add electrical parts or accessories, you could change the way the engine operates. Before adding electrical equipment, check with your dealer. If you do not, your engine might not perform properly. Any resulting damage would not be covered by your vehicle’s warranty. 115 Adjustable Throttle and Brake Pedal If your vehicle has this feature, you can change the position of the throttle and brake pedals. This feature is designed for shorter drivers, since the pedals cannot move farther away from the standard position, but can move closer for better pedal reach. If your vehicle has this feature, it can be programmed to work with the memory function. See Memory Seat, Mirrors, and Pedals on page 12. The vehicle must be in PARK (P) for this feature to operate. The switch used to adjust the pedals is located on the steering column. Press the switch forward or backward to move the pedals closer or farther away from you. 116 Engine Coolant Heater Your vehicle may have an engine coolant heater. In very cold weather, 0°F (−18°C) or colder, the engine coolant heater can help. You will get easier starting and better fuel economy during engine warm-up. Usually, the coolant heater should be plugged in a minimum of four hours prior to starting your vehicle. At temperatures above 32°F (0°C), use of the coolant heater is not required. Your vehicle may also have an internal thermostat in the plug end of the cord. This will prevent operation of the engine coolant heater when the temperature is at or above 0°F (−18°C) as noted on the cord. To Use the Engine Coolant Heater 1. Turn off the engine. 2. Open the hood and unwrap the electrical cord. The cord is located on the driver’s side of the engine compartment next to the battery box facing the engine. 3. Plug it into a normal, grounded 110-Volt AC outlet. {CAUTION: Plugging the cord into an ungrounded outlet could cause an electrical shock. Also, the wrong kind of extension cord could overheat and cause a ﬁre. You could be seriously injured. Plug the cord into a properly grounded three-prong 110-volt AC outlet. If the cord will not reach, use a heavy-duty three-prong extension cord rated for at least 15 amps. 4. Before starting the engine, be sure to unplug and store the cord as it was before to keep it away from moving engine parts. If you do not, it could be damaged. How long should you keep the coolant heater plugged in? The answer depends on the outside temperature, the kind of oil you have, and some other things. Instead of trying to list everything here, we ask that you contact your dealer in the area where you will be parking your vehicle. The dealer can give you the best advice for that particular area. Active Fuel Management™ Your vehicle’s V8 engine may have Active Fuel Management™. This system allows the engine to operate on either all or half of its cylinders, depending on your driving conditions. When less power is required, such as cruising at a constant vehicle speed, the system will operate in the half cylinder mode, allowing your vehicle to achieve better fuel economy. When greater power demands are required, such as accelerating from a stop, passing, or merging onto a freeway, the system will maintain full-cylinder operation. 117 Automatic Transmission Operation There are several different positions for your gear shift lever. PARK (P): This position locks the rear wheels. It is the best position to use when you start the engine because your vehicle cannot move easily. {CAUTION: It is dangerous to get out of your vehicle if the shift lever is not fully in PARK (P) with the parking brake ﬁrmly set. Your vehicle can roll. Do not leave your vehicle when the engine is running unless you have to. If you have left the engine running, the vehicle can move suddenly. You or others could be injured. To be sure your vehicle will not move, even when you are on fairly level ground, always set your parking brake and move the shift lever to PARK (P). See Shifting Into Park (P) on page 127. If you are pulling a trailer, see Towing a Trailer on page 362. 118 {CAUTION: If you have four-wheel drive, your vehicle will be free to roll — even if your shift lever is in PARK (P) — if your transfer case is in NEUTRAL. So, be sure the transfer case is in a drive gear — not in NEUTRAL. See Four-Wheel Drive on page 122. See Shifting Into Park (P) on page 127. Make sure the shift lever is fully in PARK (P) before starting the engine. Your vehicle has an automatic transmission shift lock control system. You have to fully apply the regular brakes ﬁrst and then press the shift lever button before you can shift from PARK (P) when the ignition key is in RUN. If you cannot shift out of PARK (P), ease pressure on the shift lever and push the shift lever all the way into PARK (P) as you maintain brake application. Then press the shift lever button and move the shift lever into another gear. See Shifting Out of Park (P) on page 129. REVERSE (R): Use this gear to back up. Notice: Shifting to REVERSE (R) while your vehicle is moving forward could damage the transmission. The repairs would not be covered by your warranty. Shift to REVERSE (R) only after your vehicle is stopped. To rock your vehicle back and forth to get out of snow, ice, or sand without damaging your transmission, see If Your Vehicle is Stuck in Sand, Mud, Ice, or Snow on page 348. 119 NEUTRAL (N): In this position, the engine does not connect with the wheels. To restart when you are already moving, use NEUTRAL (N) only. {CAUTION: Shifting into a drive gear while your engine is running at high speed is dangerous. Unless your foot is ﬁrmly on the brake pedal, your vehicle could move very rapidly. You could lose control and hit people or objects. Do not shift into a drive gear while your engine is running at high speed. Notice: Shifting out of PARK (P) or NEUTRAL (N) with the engine running at high speed may damage the transmission. The repairs would not be covered by your warranty. Be sure the engine is not running at high speed when shifting your vehicle. DRIVE (D): This position is for normal driving. It provides the best fuel economy for your vehicle. If you need more power for passing, and you are: (cid:127) Going less than about 35 mph (55 km/h), push the accelerator pedal about halfway down. (cid:127) Going about 35 mph (55 km/h) or more, push the accelerator all the way down. You will shift down to the next gear and have more power. Downshifting the transmission in slippery road conditions could result in skidding, see “Skidding” under Loss of Control on page 318. DRIVE (D) can be used when towing a trailer, carrying a heavy load, driving on steep hills, or for off-road driving. You may want to shift the transmission to THIRD (3) or, if necessary, a lower gear selection if the transmission shifts too often. THIRD (3): This position is also used for normal driving. It reduces vehicle speed more than DRIVE (D) without using your brakes. You might choose THIRD (3) instead of DRIVE (D) when driving on hilly, winding roads, when towing a trailer, so there is less shifting between gears and when going down a steep hill. 120 To shift to the THIRD (3) position, you must ﬁrst press the large button on the shift handle. While the button is pressed, move the shifter in the THIRD (3) position. SECOND (2): This position reduces vehicle speed even more than THIRD (3) without using your brakes. You can use SECOND (2) on hills. It can help control your speed as you go down steep mountain roads, but then you would also want to use your brakes off and on. To shift to the SECOND (2) position, you must ﬁrst press the large button on the shift handle. While the button is pressed, move the shifter in the SECOND (2) position. You can also use SECOND (2) for starting the vehicle from a stop on slippery road surfaces. FIRST (1): This position reduces vehicle speed even more than SECOND (2) without using your brakes. You can use it on very steep hills, or in deep snow or mud. If the shift lever is put in FIRST (1) while the vehicle is moving forward, the transmission will not shift into ﬁrst gear until the vehicle is going slowly enough. To shift to the FIRST (1) position, you must ﬁrst press the large button on the shift handle. While the button is pressed, move the shifter in the FIRST (1) position. Notice: Spinning the tires or holding the vehicle in one place on a hill using only the accelerator pedal may damage the transmission. The repair will not be covered by your warranty. If you are stuck, do not spin the tires. When stopping on a hill, use the brakes to hold the vehicle in place. 121 Four-Wheel Drive If your vehicle has four-wheel drive, the engine’s driving power can be sent to all four wheels for extra traction. To get the most satisfaction out of four-wheel drive, you must be familiar with its operation. Read the part that follows before using four-wheel drive. You should use Two-Wheel High for most normal driving conditions. Notice: Driving on clean, dry pavement in Four-Wheel-Drive High or Four-Wheel-Drive Low for an extended period of time may cause premature wear on your vehicle’s powertrain. Do not drive on clean, dry pavement in Four-Wheel-Drive High or Four-Wheel-Drive Low for extended periods of time. Automatic Transfer Case If your vehicle has four-wheel drive, the transfer case knob is located to the right of the steering wheel on the instrument panel. 122 Use this knob to shift into and out of four-wheel drive 2 m (Two-Wheel High): This setting is for driving in most street and highway situations. Your front axle is not engaged in two-wheel drive. It also provides the best fuel economy. AUTO (Automatic Four-Wheel Drive): This setting is ideal for use when road conditions are variable. When driving your vehicle in automatic four-wheel drive, the front axle is engaged, but the vehicle’s power is sent to the rear wheels. When the vehicle senses a loss of traction, the system will automatically engage four-wheel drive. Driving in this mode results in slightly lower fuel economy than Two-Wheel High. 4 m (Four-Wheel High): This setting should be used when you need extra traction, such as on snowy or icy roads or in most off-road situations. This setting also engages your front axle to help drive your vehicle. 4 n (Four-Wheel Low): This setting also engages your front axle and delivers extra torque. It sends maximum power to all four wheels. You might choose this setting if you are driving off-road in deep sand, deep mud, and climbing or descending steep hills. {CAUTION: Shifting the transfer case to NEUTRAL can cause your vehicle to roll even if the transmission is in PARK (P). You or someone else could be seriously injured. Be sure to set the parking brake before placing the transfer case in NEUTRAL. See Parking Brake on page 126. NEUTRAL: Shift the vehicle’s transfer case to NEUTRAL only when towing your vehicle. See Recreational Vehicle Towing on page 355 for more information. An indicator light in the knob will show you which position the transfer case is in. The indicator lights will come on brieﬂy when you turn on the ignition and one will stay on. If the lights do not come on, you should take your vehicle to your dealer for service. An indicator light will ﬂash while shifting the transfer case. It will stay on when the shift is complete. If for some reason the transfer case cannot make a requested shift, it will return to the last chosen setting. If the service Four-Wheel Drive Warning Light on the instrument panel cluster stays on, you should take your vehicle to your dealer for service. See Service Four-Wheel Drive Warning Light on page 216 for further information. 123 Shifting Into Four-Wheel High or Automatic Four-Wheel Drive Turn the knob to Four-Wheel High or Automatic Four-Wheel Drive. This can be done at any speed unless you are shifting out of Four-Wheel Low. The indicator light will ﬂash while shifting. It will remain on when the shift is complete. Shifting Into Two-Wheel High Turn the knob to Two-Wheel High. This can be done at any speed unless you are shifting out of Four-Wheel Low. Shifting Into Four-Wheel Low To shift to Four-Wheel Low, the vehicle’s engine must be running and the vehicle must be stopped or moving less than 2 mph (3.2 km/h) with the transmission in NEUTRAL (N). The preferred method for shifting into Four-Wheel Low is to have your vehicle moving 1 or 2 mph (1.6 to 3.2 km/h). Turn the knob to Four-Wheel Low. You must wait for the Four-Wheel Low indicator light to stop ﬂashing and stay on before shifting the transmission into gear. 124 If you turn the knob to Four-Wheel Low when your vehicle is in gear and/or moving, the Four-Wheel Low indicator light will ﬂash for 30 seconds and not complete the shift unless your vehicle is moving less than 2 mph (3.2 km/h) and the transmission is in NEUTRAL (N). After 30 seconds, the transfer case will return to the setting last chosen. Shifting Out of Four-Wheel Low To shift from Four-Wheel Low to Four-Wheel High, Auto Four-Wheel Drive, or Two-Wheel High, your vehicle must be stopped or moving less than 2 mph (3.2 km/h) with the transmission in NEUTRAL (N) and the engine running. The preferred method for shifting out of Four-Wheel Low is to have your vehicle moving 1 or 2 mph (1.6 to 3.2 km/h). Turn the knob to Four-Wheel High, Auto Four-Wheel Drive, or Two-Wheel High. You must wait for the Four-Wheel High, Auto Four-Wheel Drive, or Two-Wheel High indicator light to stop ﬂashing and stay off before shifting your transmission into gear. If the knob is turned to Four Wheel-High, Auto Four-Wheel Drive, or Two-Wheel High when your vehicle is in gear and/or moving, the Four-Wheel High, Auto Four-Wheel Drive, or Two-Wheel High indicator light will ﬂash for 30 seconds. It will not complete the shift unless your vehicle is moving less than 2 mph (3.2 km/h) with the transmission in NEUTRAL (N). Shifting into NEUTRAL Before shifting the transfer case to NEUTRAL, ﬁrst make sure the vehicle is parked so that it will not roll. 1. Set the parking brake. 2. Start the vehicle. 3. Put the transmission in NEUTRAL (N). 4. Shift the transfer case to Two-Wheel High. 5. Turn the transfer case knob all of the way past Four-Wheel Low and hold it there for a minimum of 10 seconds. The neutral indicator light will come on. 6. With the engine running, shift the transmission to REVERSE (R) for one second, then shift the transmission to DRIVE (D) for one second, to ensure that the transfer case is in NEUTRAL. 7. Turn the engine off, by turning the key to ACCESSORY. 8. Place the transmission shift lever in PARK (P). 9. Turn the ignition to LOCK. Shifting Out of NEUTRAL To shift the transfer case out of NEUTRAL, do the following: 1. Set the parking brake and apply the regular brake pedal. 2. Turn the ignition to RUN with the engine off. 3. Put the transmission in NEUTRAL (N). 4. Turn the transfer case knob to the desired position (Two-Wheel High, Four-Wheel High, or Auto Four-Wheel Drive). 5. After the transfer case has shifted out of NEUTRAL, the indicator light will go out. 6. Release the parking brake. 7. Start the engine and shift the transmission to the desired position. 125 Parking Brake To set the parking brake, hold the regular brake pedal down with your foot and pull up on the parking brake lever located between the seats. If the ignition is on, the brake system warning light on the instrument panel cluster will come on. See Brake System Warning Light on page 206. To release the parking brake, hold the regular brake pedal down. Pull the parking brake lever up until you can press in the button at the end of the lever. Hold the button in as you move the parking brake lever all the way down. Notice: Driving with the parking brake on can overheat the brake system and cause premature wear or damage to brake system parts. Verify that the parking brake is fully released and the brake warning light is off before driving. If you are towing a trailer and you must park on a hill, see Towing a Trailer on page 362. 126 To shift into PARK (P), do the following: 1. Hold the brake pedal down with your foot and set the parking brake. 2. Move the shift lever into PARK (P) by pressing the button on the side of the shift lever and pushing the lever all the way toward the front of the vehicle. 3. Turn the ignition key to LOCK. 4. Remove the key and take it with you. You know your vehicle is in PARK (P) if the key can be removed from the ignition. Shifting Into Park (P) {CAUTION: It can be dangerous to get out of your vehicle if the shift lever is not fully in PARK (P) with the parking brake ﬁrmly set. Your vehicle can roll. If you have left the engine running, the vehicle can move suddenly. You or others could be injured. To be sure your vehicle will not move, even when you are on fairly level ground, use the steps that follow. With four-wheel drive, your vehicle will be free to roll — even if your shift lever is in PARK (P) — if your transfer case is in NEUTRAL. So, be sure the transfer case is in a drive gear — not in NEUTRAL. See Four-Wheel Drive on page 122. Always put the shift lever fully in PARK (P) with the parking brake ﬁrmly set. If you are pulling a trailer, see Towing a Trailer on page 362. 127 If you have to leave your vehicle with the engine running, be sure your vehicle is in PARK (P) and your parking brake is ﬁrmly set before you leave it. After you have moved the shift lever into PARK (P), hold the regular brake pedal down. Then, see if you can move the shift lever away from PARK (P) without ﬁrst pressing the button on the console shift lever. If you can, it means that the shift lever was not fully locked into PARK (P). Leaving Your Vehicle With the Engine Running {CAUTION: It can be dangerous to leave your vehicle with the engine running. Your vehicle could move suddenly if the shift lever is not fully in PARK (P) with the parking brake ﬁrmly set. If you have four-wheel drive, your vehicle will be free to roll – even if your lever is in PARK (P) – if your transfer case is in NEUTRAL. So be sure the transfer case is in a drive gear – not NEUTRAL. See Four-Wheel Drive on page 122. And, if you leave the vehicle with the engine running, it could overheat and even catch ﬁre. You or others could be injured. Do not leave your vehicle with the engine running unless you have to. 128 Torque Lock If you are parking on a hill and you do not shift your transmission into PARK (P) properly, the weight of the vehicle may put too much force on the parking pawl in the transmission. You may ﬁnd it difficult to pull the shift lever out of PARK (P). This is called “torque lock.” To prevent torque lock, set the parking brake and then shift into PARK (P) properly before you leave the driver’s seat. To ﬁnd out how, see Shifting Into Park (P) on page 127. When you are ready to drive, move the shift lever out of PARK (P) before you release the parking brake. If torque lock does occur, you may need to have another vehicle push yours a little uphill to take some of the pressure from the parking pawl in the transmission, so you can pull the shift lever out of PARK (P). Shifting Out of Park (P) Your vehicle has an automatic transmission shift lock control system. You have to fully apply the regular brakes ﬁrst and then press the shift lever button before you can shift from PARK (P) when the ignition is in RUN. See Automatic Transmission Operation on page 118. 129 Parking Over Things That Burn {CAUTION: Things that can burn could touch hot exhaust parts under your vehicle and ignite. Do not park over papers, leaves, dry grass, or other things that can burn. 130 Engine Exhaust {CAUTION: Engine exhaust can kill. It contains the gas carbon monoxide (CO), which you cannot see or smell. It can cause unconsciousness and death. You might have exhaust coming in if: (cid:127) Your exhaust system sounds strange or different. (cid:127) Your vehicle gets rusty underneath. (cid:127) Your vehicle was damaged in a collision. CAUTION: (Continued) (cid:127) Your vehicle was damaged when driving over high points on the road or over road debris. (cid:127) Repairs were not done correctly. (cid:127) Your vehicle or exhaust system has been modiﬁed improperly. If you ever suspect exhaust is coming into your vehicle: (cid:127) Drive it only with all the windows down to blow out any CO; and (cid:127) Have your vehicle ﬁxed immediately. CAUTION: (Continued) 131 {CAUTION: It can be dangerous to get out of your vehicle if the shift lever is not fully in PARK (P) with the parking brake ﬁrmly set. Your vehicle can roll. Do not leave your vehicle when the engine is running unless you have to. If you have left the engine running, the vehicle can move suddenly. You or others could be injured. To be sure your vehicle will not move, even when you are on fairly level ground, always set your parking brake and move the shift lever to PARK (P). Running the Engine While Parked It is better not to park with the engine running. But if you ever have to, here are some things to know. {CAUTION: Idling the engine with the climate control system off could allow dangerous exhaust into your vehicle. See the earlier caution under Engine Exhaust on page 131. Also, idling in a closed-in place can let deadly carbon monoxide (CO) into your vehicle even if the climate control fan is at the highest setting. One place this can happen is a garage. Exhaust — with CO — can come in easily. NEVER park in a garage with the engine running. Another closed-in place can be a blizzard. See Winter Driving on page 344. 132 {CAUTION: If your vehicle has four-wheel drive, it will be free to roll — even if the shift lever is in PARK (P) — if the transfer case is in NEUTRAL. So be sure the transfer case is in a drive gear — not in NEUTRAL. See Four-Wheel Drive on page 122. Follow the proper steps to be sure your vehicle will not move. See Shifting Into Park (P) on page 127. If you are pulling a trailer, see Towing a Trailer on page 362. Mirrors Manual Rearview Mirror Your vehicle may have this feature. While sitting in a comfortable driving position, adjust the rearview mirror so you can see clearly behind your vehicle. Grip the mirror in the center to move it up or down and side to side. The day/night control, located at the bottom of the mirror, adjusts the mirror to reduce headlamp glare from behind during evening or dark conditions. Turn the control clockwise for night use; return it to the center for daytime use. Manual Rearview Mirror with OnStar® Your vehicle may have a rearview mirror with the OnStar® system. Control buttons for the OnStar® system are at the bottom of the mirror. See your dealer for more information on the OnStar® system and how to subscribe to OnStar®. Also, see OnStar® System on page 145 for more information about the services OnStar® provides. 133 Mirror Operation While sitting in a comfortable driving position, adjust the rearview mirror so you can see clearly behind your vehicle. Grip it in the center to move it up or down and side to side. The day/night control, located at the bottom of the mirror, adjusts the mirror to reduce headlamp glare from behind during evening or dark conditions. Move the control to the right for night conditions. Return it to the center for daytime use. Automatic Dimming Rearview Mirror with OnStar® and Compass Your vehicle may have an automatic-dimming rearview mirror with a compass and the OnStar® system. There are three additional buttons for the OnStar® system. See your dealer for more information on the system and how to subscribe to OnStar®. See OnStar® System on page 145 for more information about the services OnStar® provides. O (On/Off): This is the on/off button. 134 Automatic Dimming Mirror Operation The automatic dimming mirror function is turned on automatically each time the ignition is started. To operate the automatic dimming mirror, do the following: 1. Make sure the green indicator light, located to the left of the on/off button, is lit. If it’s not, press and hold the on/off button until the green light comes on, indicating that the mirror is in automatic dimming mode. 2. Turn off the automatic dimming mirror function by pressing and holding the on/off button until the green indicator light turns off. Compass Operation Press the on/off button once to turn the compass on or off. There is a compass display in the window in the upper right corner of the mirror face. The compass displays a maximum of two characters. For example, “NE” is displayed for north-east. Compass Calibration Press and hold the on/off button to activate the compass calibration mode. CAL will be displayed in the compass window on the mirror. The compass can be calibrated by driving the vehicle in circles at 5 mph (8 km/h) or less until the display reads a direction. Compass Variance Compass variance is the difference between earth’s magnetic north and true geographic north. The mirror is set to zone eight upon leaving the factory. It will be necessary to adjust the compass to compensate for compass variance if you live outside zone eight. Under certain circumstances, such as during a long distance cross-country trip, it will be necessary to adjust for compass variance. If not adjusted to account for compass variance, your compass could give false readings. To adjust for compass variance, do the following: 1. Find your current location and variance zone number on the following zone map. 2. Press and hold the on/off button for six seconds. Release the button when (FOR ZONE) is displayed. The number shown is the current zone number. 3. Scroll through the zone numbers that appear in the window on the mirror by pressing the on/off button. Once you ﬁnd your zone number, release the button. After about four seconds, the mirror will return to the compass display, and the new zone number will be set. 135 Automatic Dimming Rearview Mirror with OnStar®, Compass and Temperature Display Your vehicle may have this feature. When on, an automatic dimming mirror automatically dims to the proper level to minimize glare from lights behind you after dark. The mirror also includes a dual display in the upper right corner of the mirror face. The compass reading and the outside temperature will both appear in the display at the same time. P(On/Off): This is the on/off button. Automatic Dimming Mirror Operation The automatic dimming mirror function is turned on automatically each time the ignition is started. To operate the automatic dimming mirror, do the following: 1. Make sure the green indicator light, located to the left of the on/off button, is lit. If it’s not, press and hold the on/off button until the green light comes on, indicating that the mirror is in automatic dimming mode. 136 2. Turn off the automatic dimming mirror function by pressing and holding the on/off button until the green indicator light turns off. Temperature and Compass Display Press the on/off button, located to the far left, brieﬂy to turn the compass/temperature display on or off. If the display reads CAL, you will need to calibrate the compass. For more information on calibration, see below. To adjust between Fahrenheit and Celsius, do the following: 1. Press and hold the on/off button until either a ﬂashing F or C appears. 2. Press the button again to change the display to the desired unit of measurement. After approximately four seconds of inactivity, the new unit will be locked in and the display will return. If an abnormal temperature reading is displayed for an extended period of time, please consult your dealer. Under certain circumstances, a delay in updating the temperature is normal. Compass Variance The mirror is set in zone eight upon leaving the factory. It will be necessary to adjust the compass to compensate for compass variance if you live outside of zone eight. Under certain circumstances, as during a long distance cross-country trip, it will be necessary to adjust for compass variance. Compass variance is the difference between earth’s magnetic north and true geographic north. If not adjusted to account for compass variance, your compass could give false readings. To adjust for compass variance, do the following: 1. Find your current location and variance zone number on the following zone map. 2. Press and hold the on/off button until a Z and a zone number appear in the display. The compass is now in zone mode. 3. Keep pressing the on/off button until the desired zone number appears in the display. Release the button. After approximately four seconds of inactivity, the new zone number will be locked in and the compass/temperature display will return. 4. Calibrate the compass as described next. 137 Compass Calibration The compass may need calibration if one of the following occurs: (cid:127) After approximately ﬁve seconds, the display does not show a compass heading (N for North, for example), there may be a strong magnetic ﬁeld interfering with the compass. Such interference may be caused by a magnetic antenna mount, magnetic note pad holder or a similar magnetic item. (cid:127) The compass does not display the correct heading and the compass zone variance is set correctly. In order to calibrate, CAL must be displayed in the mirror compass windows. If CAL is not displayed, press and hold the on/off button until CAL is displayed. The compass can be calibrated by driving the vehicle in circles at 5 mph (8 km/h) or less until the display reads a direction. Passenger Airbag Indicator The vehicle may be equipped with a passenger airbag indicator, on the mirror glass, just above the buttons. If the vehicle has this feature, the mirror will display the word ON, or an airbag symbol in Canada, when the passenger airbag is enabled. For more information, see Passenger Sensing System on page 82. Cleaning the Mirror When cleaning the mirror, use a paper towel or similar material dampened with glass cleaner. Do not spray glass cleaner directly on the mirror as that may cause the liquid cleaner to enter the mirror housing. Automatic Dimming Rearview Mirror with Compass Your vehicle may have an automatic-dimming rearview mirror with a compass. O (On/Off): This is the on/off button for the automatic dimming feature and compass. 138 Automatic Dimming Mirror Operation The automatic dimming mirror function is turned on automatically each time the ignition is started. To operate the automatic dimming mirror, do the following: 1. Make sure the green indicator light, located to the left of the on/off button, is lit. If it’s not, press and hold the on/off button until the green light comes on, indicating that the mirror is in automatic dimming mode. 2. Turn off the automatic dimming mirror function by pressing and holding the on/off button until the green indicator light turns off. Compass Operation Press the on/off button once to turn the compass on or off. There is a compass display in the window in the upper right corner of the mirror face. The compass displays a maximum of two characters. For example, “NE” is displayed for north-east. Compass Calibration Press and hold the on/off button to activate the compass calibration mode. CAL will be displayed in the compass window on the mirror. The compass can be calibrated by driving the vehicle in circles at 5 mph (8 km/h) or less until the display reads a direction. Compass Variance Compass variance is the difference between earth’s magnetic north and true geographic north. The mirror is set to zone eight upon leaving the factory. It will be necessary to adjust the compass to compensate for compass variance if you live outside zone eight. Under certain circumstances, such as during a long distance cross-country trip, it will be necessary to adjust for compass variance. If not adjusted to account for compass variance, your compass could give false readings. 139 3. Scroll through the zone numbers that appear in the window on the mirror by pressing the on/off button. Once you ﬁnd your zone number, release the button. After about four seconds, the mirror will return to the compass display, and the new zone number will be set. Automatic Dimming Rearview Mirror with Compass and Temperature Display If the vehicle is equipped with an automatic mirror, it will, when on, automatically dim to the proper level to minimize glare from lights behind you after dark. The mirror also includes a display in the upper right corner of the mirror face. The compass reading and the outside temperature will both appear in the display at the same time. The dual display can be turned on or off by brieﬂy pressing either the TEMP or the COMP button. To adjust for compass variance, do the following: 1. Find your current location and variance zone number on the following zone map. 2. Press and hold the on/off button for six seconds. Release the button when (FOR ZONE) is displayed. The number shown is the current zone number. 140 Automatic Dimming Mirror Operation The automatic dimming mirror function is turned on automatically each time the ignition is started. To operate the automatic dimming mirror, do the following: 1. Make sure the green indicator light, located to the left of the on/off button, is lit. If it’s not, press and hold the on/off button until the green light comes on, indicating that the mirror is in automatic dimming mode. 2. Turn off the automatic dimming mirror function by pressing and holding the on/off button until the green indicator light turns off. Temperature Display The temperature can be displayed by pressing the TEMP button. Pressing the TEMP button once brieﬂy, will toggle the temperature reading on and off. To alternate the temperature reading between Fahrenheit and Celsius, press and hold the TEMP button until the display blinks F and C. Press and release the TEMP button to toggle between the Fahrenheit and Celsius readings. After approximately four seconds of inactivity, the display will stop blinking and display the last selection made. If an abnormal reading is displayed, for an extended period of time, please consult your dealer. Under certain circumstances, a delay in updating the temperature is normal. Compass Operation Press the COMP button once brieﬂy to turn the compass on or off. When the ignition and the compass feature are on, the compass will show two character boxes for approximately two seconds. After two seconds, the mirror will display the compass heading. 141 Compass Variance The mirror is set in zone eight upon leaving the factory. It will be necessary to adjust the compass to compensate for compass variance if you live outside zone eight. Under certain circumstances, as during a long distance cross-country trip, it will be necessary to adjust for compass variance. Compass variance is the difference between earth’s magnetic north and true geographic north. If not adjusted to account for compass variance, your compass could give false readings. To adjust for compass variance, do the following: 1. Find your current location and variance zone number on the following zone map. 2. Press and hold the COMP button until a zone number appears in the display. Compass Calibration The compass may need calibration if one of the following occurs: (cid:127) (cid:127) After approximately ﬁve seconds, the display If CAL is displayed while driving in the vehicle. does not show a compass heading (N for North, for example), there may be a strong magnetic ﬁeld interfering with the compass. Such interference may be caused by a magnetic antenna mount, magnetic note pad holder or a similar magnetic item. (cid:127) The compass does not display the correct heading and the compass zone variance is set correctly. In order to calibrate, CAL must be displayed in the mirror compass windows. If CAL is not displayed, press and hold the COMP button until CAL is displayed. The compass can be calibrated by driving the vehicle in circles at 5 mph (8 km/h) or less until the display reads a direction. 142 Passenger Airbag Indicator The mirror may be equipped with a passenger airbag indicator on the mirror glass, just above the buttons. If the vehicle has this feature the mirror will display the word ON, or an airbag symbol in Canada, when the passenger airbag is enabled. For more information see Passenger Sensing System on page 82. Cleaning the Mirror When cleaning the mirror, use a paper towel or similar material dampened with glass cleaner. Do not spray glass cleaner directly on the mirror as that may cause the liquid cleaner to enter the mirror housing. 143 3. Press the COMP button on the bottom of the mirror until the new zone number appears in the display. After you stop pressing the button, the display will show a compass direction within a few seconds. The mirrors can be manually folded inward to prevent damage when going through an automatic car wash. To fold, push the mirror toward the vehicle. To return the mirror to its original position, push outward. Be sure to return both mirrors to their original unfolded position before driving. Outside Curb View Assist Mirror If the vehicle has this feature, the passenger’s outside mirror will adjust to a preset tilt position while the vehicle is in REVERSE (R) gear. Curb view assist may be useful when you are parallel parking. The mirror will return to normal position when the vehicle is shifted out of REVERSE (R) gear. Automatic mirror movement in either direction will follow a short delay. You may be able to turn this feature on or off through the Driver Information Center (DIC). See DIC Vehicle Customization on page 229. Outside Manual Mirrors If the vehicle has the manual outside mirrors, adjust each outside mirror so that a little of the vehicle and the area behind it can be seen while sitting in a comfortable, driving position. Both mirrors can be manually folded inward by pulling them towards the vehicle. Push the mirrors away from the vehicle, to the normal position, before driving. Outside Power Mirrors Your vehicle may have this feature. The power mirror control is located on the driver’s door. Turn the knob counterclockwise or clockwise to adjust the driver’s or passenger’s mirror so that you can see a little of the side of your vehicle. After adjusting the position of the mirrors, turn the knob to the center position so that the mirrors cannot move. If the travel position in any direction of the mirror is reached, it will enter a ratcheting mode. This action is harmless. It is a warning that the mirror can go no further. To stop this action, back the mirror up by moving the knob in the opposite direction. 144 Outside Convex Mirror OnStar® System {CAUTION: A convex mirror can make things (like other vehicles) look farther away than they really are. If you cut too sharply into the right or left lane, you could hit a vehicle. Check your inside mirror or glance over your shoulder before changing lanes. The passenger’s outside mirror is convex. A convex mirror’s surface is curved so more can be seen from the driver’s seat. Outside Heated Mirrors Your vehicle may have this feature. When you operate the rear window defogger, the defogger also warms the heated driver’s and passenger’s outside rearview mirrors to help clear them of ice, snow and condensation. OnStar® uses several innovative technologies and live advisors to provide you with a wide range of safety, security, information, and convenience services. If your airbags deploy, the system is designed to make an automatic call to OnStar® Emergency advisors who can request emergency services be sent to your location. If you lock your keys in the vehicle, call OnStar® at 1-888-4-ONSTAR and they can send a signal to unlock your doors. If you need roadside assistance, press the OnStar® button and they can contact Roadside Service for you. 145 OnStar® service is provided to you subject to the OnStar® Terms and Conditions. You may cancel your OnStar® service at any time by contacting OnStar® as provided below. A complete OnStar® Owner’s Guide and the OnStar® Terms and Conditions are included in the vehicle’s OnStar® Subscriber glove box literature. For more information, visit onstar.com or onstar.ca, contact OnStar® at 1–888–4–ONSTAR (1–888–466–7827) or TTY 1–877–248–2080, or press the OnStar® button to speak with an OnStar® advisor 24 hours a day, 7 days a week. Not all OnStar® features are available on all vehicles. To check if your vehicle is equipped to provide the services described below, or for a full description of OnStar® services and system limitations, see the OnStar® Owner’s Guide in your glove box or visit onstar.com. OnStar® Services For new vehicles equipped with OnStar®, the Safe & Sound Plan, or the Directions & Connections® Plan is included for one year from the date of purchase. You can extend this plan beyond the ﬁrst year, or upgrade to the Directions & Connections® Plan. For more information, press the OnStar® button to speak with an advisor. Some OnStar® services (such as Remote Door Unlock or Stolen Vehicle Location Assistance) may not be available until you register with OnStar®. Available Services with Safe & Sound® Plan (cid:127) Automatic Notiﬁcation of Airbag Deployment (cid:127) Advanced Automatic Crash Notiﬁcation (AACN) (If equipped) (cid:127) Link to Emergency Services (cid:127) Roadside Assistance 146 (cid:127) Stolen Vehicle Location Assistance (cid:127) AccidentAssist (cid:127) Remote Door Unlock/Vehicle Alert (cid:127) OnStar® Vehicle Diagnostics (cid:127) GM® Goodwrench® On Demand Diagnostics (cid:127) OnStar® Hands-Free Calling with 30 complimentary minutes (cid:127) OnStar® Virtual Advisor Available Services included with Directions & Connections® Plan (cid:127) All Safe and Sound Plan Services (cid:127) Driving Directions - Advisor delivered or OnStar® Turn-by-Turn Navigation (If equipped) (cid:127) RideAssist (cid:127) Information and Convenience Services OnStar® Hands-Free Calling OnStar® Hands-Free Calling allows eligible OnStar® subscribers to make and receive calls using voice commands. Hands-Free Calling is fully integrated into the vehicle, and can be used with OnStar® Pre-Paid Minute Packages. Hands-Free Calling may also be linked to a Verizon Wireless service plan, depending on eligibility. To ﬁnd out more, refer to the OnStar® Owner’s Guide in the vehicle’s glove box, visit www.onstar.com or www.onstar.ca, or speak with an OnStar® advisor by pressing the OnStar® button or calling 1-888-4-ONSTAR (1-888-466-7827). OnStar® Virtual Advisor OnStar® Virtual Advisor is a feature of OnStar® Hands-Free Calling that uses your minutes to access location-based weather, local traffic reports, and stock quotes. By pressing the phone button and giving a few simple voice commands, you can browse through the various topics. See the OnStar® Owner’s Guide for more information. 147 OnStar® Steering Wheel Controls Your vehicle may have a Talk/Mute button that can be used to interact with OnStar® Hands-Free Calling. See Audio Steering Wheel Controls on page 297 for more information. On some vehicles, you may have to hold the button for a few seconds and give the command “ONSTAR” in order to activate the OnStar® Hands-Free Calling feature. On some vehicles, the mute button can be used to dial numbers into voicemail systems, or to dial phone extensions. See the OnStar® Owner’s Guide for more information. How OnStar® Service Works In order to provide you with OnStar® services, your vehicle’s OnStar® system has the capability of recording and transmitting vehicle information. This information is automatically sent to an OnStar® Call Center at the time of an OnStar® button press, Emergency button press or if your airbags or AACN system deploys. The vehicle information usually includes your GPS location and, in the event of a crash, additional information regarding the accident that your vehicle has been involved in (e.g. the direction from which your vehicle was hit). When you use the Virtual Advisor feature of OnStar® Hands-Free Calling, your vehicle also sends OnStar® your GPS location so that we can provide you with location-based services. 148 OnStar® service cannot work unless your vehicle is in a place where OnStar® has an agreement with a wireless service provider for service in that area. OnStar® service also cannot work unless you are in a place where the wireless service provider OnStar® has hired for that area has coverage, network capacity and reception when the service is needed, and technology that is compatible with the OnStar® service. Not all services are available everywhere, particularly in remote or enclosed areas, or at all times. OnStar® service that involves location information about your vehicle cannot work unless GPS satellite signals are unobstructed and available in that place as well. Your vehicle must have a working electrical system (including adequate battery power) for the OnStar® equipment to operate. There are other problems OnStar® cannot control that may prevent OnStar® from providing OnStar® service to you at any particular time or place. Some examples are damage to important parts of your vehicle in an accident, hills, tall buildings, tunnels, weather or wireless phone network congestion. Your Responsibility You may need to increase the volume of your radio to hear the OnStar® advisor. If the light next to the OnStar® buttons is red, this means that your system is not functioning properly and should be checked by a dealer. If the light appears clear (no light is appearing), your OnStar® subscription has expired. You can always press the blue OnStar® button to conﬁrm that your OnStar® equipment is active. Universal Home Remote System Universal Home Remote System (With Three Round LED) The Universal Home Remote System provides a way to replace up to three hand-held Radio-Frequency (RF) transmitters used to activate devices such as garage door openers, security systems, and home lighting. 149 Universal Home Remote System (With One Triangular LED) The Universal Home Remote System provides a way to replace up to three hand-held radio-frequency (RF) transmitters used to activate devices such as garage door openers, security systems, and home lighting. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: 1. This device may not cause harmful interference. 2. This device must accept any interference received, including interference that may cause undesired operation. The FCC Grant of Equipment Authorization Certiﬁcate number is CB2SAHL3. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: 1. This device may not cause harmful interference. 2. This device must accept any interference received, including interference that may cause undesired operation. The FCC Grant of Equipment Authorization Certiﬁcate number is KOBGTE05A. This device complies with RSS-210 of Industry Canada. Operation is subject to the following two conditions: 1. This device may not cause interference. 2. This device must accept any interference received, including interference that may cause undesired operation of the device. The Canadian Registration ID number is 3521A-GTE05A. Changes or modiﬁcations to this system by other than an authorized service facility could void authorization to use this equipment. 150 This device complies with RSS-210 of Industry Canada. Operation is subject to the following two conditions: 1. This device may not cause interference. 2. This device must accept any interference received, including interference that may cause undesired operation of the device. The Canadian Registration ID number is 2791021849A. Changes or modiﬁcations to this system by other than an authorized service facility could void authorization to use this equipment. Universal Home Remote System Operation (With Three Round LED) Your vehicle may have the Universal Home Remote System. If there are three round Light Emitting Diode (LED) above the Universal Home Remote System buttons, follow the instructions below. If there is one triangular LED above the Universal Home Remote System buttons, follow the instructions under Universal Home Remote System Operation (with one triangular LED). This system provides a way to replace up to three remote control transmitters used to activate devices such as garage door openers, security systems, and home lighting. Do not use the this system with any garage door opener that does not have the stop and reverse feature. This includes any garage door opener model manufactured before April 1, 1982. 151 Read the instructions completely before attempting to program the transmitter. Because of the steps involved, it may be helpful to have another person available to assist you in programming the transmitter. Be sure to keep the original remote control transmitter for use in other vehicles, as well as, for future programming. You only need the original remote control transmitter for ﬁxed code programming. It is also recommended that upon the sale or lease termination of the vehicle, the programmed buttons should be erased for security purposes. See “Erasing your Universal Home Remote Buttons” later in this section. Be sure that people and objects are clear of the garage door or security device you are programming. When programming a garage door, it is advised to park outside of the garage. 152 If you do not know if your garage door opener is a ﬁxed code or rolling code device, open your garage door opener’s remote control battery cover. Your garage door opener is a ﬁxed code device if there is a panel of switches. If not, your garage door opener is a rolling code device. Programming Universal Home Remote — Fixed Code Fixed Code garage door openers are used for garage doors produced prior to 1996. Fixed code uses the same coded signal every time, which is manually programmed by setting DIP switches for a unique personal code. Follow these steps to program up to three channels: 1. Remove the battery cover of the hand-held transmitter. 2. Write down the eight to 12 coding switch settings from left to right. When the switch is in the up position, write “on,” and when a switch is in the down position, write “off”. If a switch is set between the up and down position, write “middle”. 3. Enter these positions into the Universal Home Remote System as follows. Press and release all three buttons at the same time to put the device into programming mode. Example of Switch Settings Example 153 4. The indicator light will blink slowly. In order from left to right, and within two and one-half minutes, enter each switch setting into the Universal Home Remote System. Push one button for each switch as follows: (cid:127) Left button = “on” switch position. (cid:127) Right button = “off” switch position. (cid:127) Middle button = “middle” switch position. 5. After entering the switch settings, press and release all three buttons at the same time. The indicator lights will turn on. 6. Press and hold the button you would like to use to control the garage door until the garage door moves. The indicator light above the selected button should slowly blink. You may need to hold the button from ﬁve to 55 seconds. 7. Immediately release the button when the garage door moves. The indicator light will blink rapidly until programming is complete. 154 8. Press and release the button again. The garage door should move, conﬁrming that programming is successful and complete. To program another device such as an additional garage door opener, a security device, or home lighting, repeat Steps 1 through 8, choosing a different function button in Step 7 than what you used for the garage door opener. Programming Universal Home Remote — Rolling Code Rolling code garage door openers are used for garage doors produced after 1996 and are code protected. Rolling code means the coded signal is changed every time your remote control garage door opener is used. Programming a rolling code garage door opener involves time-sensitive actions, so read the entire procedure before you begin. If you do not follow these actions, the device will time out and you will have to repeat the procedure. Follow these steps to program up to three channels: 1. Press the two outside buttons at the same time for one to two seconds, and immediately release them. 2. Go to the garage. Locate the garage door motor head and press and release the “learn” button. After pressing the “learn” button, you have 10 to 30 seconds to complete Step 4 depending on your garage control unit. If you cannot locate the “learn” button, refer to the owners guide for your garage door opener. 3. Press and hold the button you would like to use to control the garage door until the garage door moves. The indicator light, above the selected button, should slowly blink. You may need to hold the button from ﬁve to 20 seconds. 4. Immediately release the button when the garage door moves. The indicator light will blink rapidly until programming is complete. 5. Press and release the button again. The garage door should move, conﬁrming that programming is successful and complete. To program another device such as an additional garage door opener, a security device, or home lighting, repeat Steps 1 through 6, choosing a different function button in Step 4 than what you used for the garage door opener. Using Universal Home Remote Press and hold the appropriate button for at least half of a second. The indicator light will come on while the signal is being transmitted. 155 Reprogramming Universal Home Remote Buttons You can reprogram any of the three buttons by repeating the instructions. Erasing Universal Home Remote Buttons You should erase the programmed buttons when you sell the vehicle or terminate your lease. To erase either rolling code or ﬁxed code on the Universal Home Remote device, do the following: 1. Press and hold the two outside buttons at the same time for approximately 20 seconds, until the indicator lights, located directly above the buttons, begin to blink rapidly. 2. Once the indicator lights begin to blink, release both buttons. The codes from all button will be erased. For additional information on Universal Home Remote, see Customer Assistance Offices on page 530. 156 Universal Home Remote System Operation (With One Triangular LED) Your vehicle may have the Universal Home Remote System. If there is one triangular Light Emitting Diode (LED) above the Universal Home Remote buttons, follow the instructions below. If your vehicle has three round LED above the Universal Home Remote buttons, follow the instructions under Universal Home Remote System Operation (with three round LED). Do not use the Universal Home Remote with any garage door opener that does not have the stop and reverse feature. This includes any garage door opener model manufactured before April 1, 1982. If you have a newer garage door opener with rolling codes, please be sure to follow Steps 6 through 8 to complete the programming of your Universal Home Remote Transmitter. Read the instructions completely before attempting to program the Universal Home Remote. Because of the steps involved, it may be helpful to have another person available to assist you in the programming steps. Keep the original hand-held transmitter for use in other vehicles as well as for future Universal Home Remote programming. It is also recommended that upon the sale of the vehicle, the programmed Universal Home Remote buttons should be erased for security purposes. See “Erasing Universal Home Remote Buttons” later in this section or, for assistance, see Customer Assistance Offices on page 530. Be sure that people and objects are clear of the garage door or gate operator you are programming. When programming a garage door, it is advised to park outside of the garage. It is recommended that a new battery be installed in your hand-held transmitter for quicker and more accurate transmission of the radio-frequency signal. Programming Universal Home Remote Follow these steps to program up to three channels: 1. Press and hold down the two outside Universal Home Remote buttons, releasing only when the Universal Home Remote indicator light begins to ﬂash, after 20 seconds. Do not hold down the buttons for longer than 30 seconds and do not repeat this step to program a second and/or third hand-held transmitter to the remaining two Universal Home Remote buttons. 2. Position the end of your hand-held transmitter about 1 to 3 inches (3 to 8 cm) away from the Universal Home Remote buttons while keeping the indicator light in view. 3. Simultaneously press and hold both the desired Universal Home Remote button and the hand-held transmitter button. Do not release the buttons until Step 4 has been completed. Some entry gates and garage door openers may require you to substitute Step 3 with the procedure noted in “Gate Operator and Canadian Programming” later in this section. 157 4. The indicator light will ﬂash slowly at ﬁrst and then rapidly after Universal Home Remote successfully receives the frequency signal from the hand-held transmitter. Release both buttons. 6. Locate in the garage, the garage door opener receiver (motor-head unit). Locate the “Learn” or “Smart” button. This can usually be found where the hanging antenna wire is attached to the motor-head unit. 5. Press and hold the newly-trained Universal Home Remote button and observe the indicator light. If the indicator light stays on continuously, programming is complete and your device should activate when the Universal Home Remote button is pressed and released. To program the remaining two Universal Home Remote buttons, begin with Step 2 under “Programming Universal Home Remote.” Do not repeat Step 1 as this will erase all of the programmed channels. If the indicator light blinks rapidly for two seconds and then turns to a constant light, continue with Steps 6 through 8 following to complete the programming of a rolling-code device, most commonly, a garage door opener. 7. Firmly press and release the “Learn” or “Smart” button. The name and color of the button may vary by manufacturer. You will have 30 seconds to start Step 8. 8. Return to the vehicle. Firmly press and hold the programmed Universal Home Remote button for two seconds, then release. Repeat the press/hold/release sequence a second time, and depending on the brand of the garage door opener or other rolling code device, repeat this sequence a third time to complete the programming. The Universal Home Remote should now activate the rolling-code device. To program the remaining two Universal Home Remote buttons, begin with Step 2 of “Programming Universal Home Remote.” Do not repeat Step 1, as this will erase all previous programming from the Universal Home Remote buttons. 158 Gate Operator and Canadian Programming Canadian radio-frequency laws require transmitter signals to time out or quit after several seconds of transmission. This may not be long enough for Universal Home Remote to pick up the signal during programming. Similarly, some U.S. gate operators are manufactured to time out in the same manner. If you live in Canada, or you are having difficulty programming a gate operator or garage door opener by using the “Programming Universal Home Remote” procedures, regardless of where you live, replace Step 3 under “Programming Universal Home Remote” with the following: Continue to press and hold the Universal Home Remote button while you press and release every two seconds (cycle) the hand-held transmitter button until the frequency signal has been successfully accepted by the Universal Home Remote. The Universal Home Remote indicator light will ﬂash slowly at ﬁrst and then rapidly. Proceed with Step 4 under “Programming Universal Home Remote” to complete. Using Universal Home Remote Press and hold the appropriate Universal Home Remote button for at least half of a second. The indicator light will come on while the signal is being transmitted. Erasing Universal Home Remote Buttons To erase programming from the three Universal Home Remote buttons do the following: 1. Press and hold down the two outside buttons until the indicator light begins to ﬂash, after 20 seconds. Do not hold the two outside buttons for longer than 30 seconds. 2. Release both buttons. The Universal Home Remote is now in the training (learning) mode and can be programmed at any time beginning with Step 2 under “Programming Universal Home Remote” shown earlier in this section. Individual buttons cannot be erased, but they can be reprogrammed. See “Reprogramming a Single Universal Home Remote Button” following this section. 159 Reprogramming a Single Universal Home Remote Button To program a device to Universal Home Remote using a Universal Home Remote button previously trained, follow these steps: 1. Press and hold the desired Universal Home Remote button. Do not release the button. 2. The indicator light will begin to ﬂash after 20 seconds. While still holding the Universal Home Remote button, proceed with Step 2 under “Programming Universal Home Remote” shown earlier in this section. For additional information on Universal Home Remote, see Customer Assistance Offices on page 530. Storage Areas Glove Box To open, pull up on the handle. Use the key to lock and unlock. 160 Overhead Console Your vehicle may have this feature. The overhead console may include reading lamps, a Universal Home Remote and a sunroof switch. See Sunroof on page 164 and Universal Home Remote System (With Three Round LED) on page 149 or Universal Home Remote System (With One Triangular LED) on page 150 for more information. Center Console Storage Area Squeeze the front lever on the center console while lifting the top to open it. Your vehicle’s console will have cupholders located on the front and rear of the storage compartment. The console may also contain one or more of the following components: (cid:127) Rear Seat Audio Controls (cid:127) Rear Seat Accessory Power Outlets (cid:127) Rear Climate Control To open the center armrest compartment, lift the cover by pulling up on the latch handle located underneath the front edge of the armrest. Luggage Carrier {CAUTION: If you try to carry something on top of your vehicle that is longer or wider than the luggage carrier — like paneling, plywood, a mattress and so forth — the wind can catch it as you drive along. This can cause you to lose control. What you are carrying could be violently torn off, and this could cause you or other drivers to have a collision, and of course damage your vehicle. You may be able to carry something like this inside. But, never carry something longer or wider than the luggage carrier on top of your vehicle. If your vehicle has a luggage carrier, it will allow you to load things on top of your vehicle. The luggage carrier has side rails attached to the roof, places to use for tying things down and may have sliding crossrails. These let you load some other things on top of your vehicle, as long as they are not wider or longer than the luggage carrier. To slide the crossrails to where you want them, pull up on the lever on each side of the crossrail. This releases the crossrail and allows you to slide it. When the crossrail is where you want it, press down on the levers to lock it into place. Notice: Loading cargo on the luggage carrier that weighs more than 220 lbs (100 kg) or hangs over the rear or sides of the vehicle may damage your vehicle. Load cargo so that it rests on the slats as far forward as possible and against the side rails, making sure to fasten it securely. Do not exceed the maximum vehicle capacity when loading your vehicle. For more information on vehicle capacity and loading, see Loading Your Vehicle on page 349. 161 To remove the rear ﬂoor storage lid, do the following: 1. Press the latch release and lift up the latch handle. 2. Raise the lid slightly to unhook it. 3. Pull the lid toward you to release it from the forward mounting tabs. To reinstall the rear ﬂoor storage lid, reverse the previous steps. Make sure the lid is secure by applying slight pressure to the latch until you hear it click. Convenience Net Your vehicle may have this feature. A convenience net in the rear of your vehicle helps keep small items in place during sharp turns or quick stops and starts. The net is not designed to retain these items during off-road use. The net is not for larger, heavier items. To prevent damage or loss of cargo as you are driving, check now and then to make sure the luggage carrier is locked and cargo is still securely fastened. When the luggage carrier is not in use, place the crossrails at the following positions for wind noise reduction. Place one crossrail at the rear most point of the vehicle and the other crossrail above the opening of the rear door. Rear Floor Storage Lid {CAUTION: If any removable convenience item is not secured properly, it can move around in a collision or sudden stop. People in the vehicle could be injured. Be sure to secure any such item properly. Your vehicle has a rear cargo area with a removable storage lid. 162 To use the convenience net, do the following: 1. Attach the upper loops to the retainers on both sides of the liftgate opening. The label should be in the upper passenger’s side corner, visible from the rear of the vehicle. 2. Attach the lower hooks to the rear cargo tie downs on the ﬂoor. Cargo Cover If your vehicle has a cargo cover, you can use it to cover items in the cargo area of your vehicle. To install the cargo cover, do the following: 1. Align the endcap with the pocket in the trim panel located behind the rear seat. 2. Squeeze the opposite endcap, align it with the pocket located on the opposite side of the trim panel and release. 3. Grasp the handle and unroll the cover. 4. Latch the posts into the sockets on the inside of the vehicle to secure it. To remove the cargo cover, do the following: 1. Release the cover from the latch posts and carefully roll it back up. 2. Squeeze one endcap and remove it from the pocket in the trim panel. 3. Remove the cargo cover from the other endcap so that you can remove the shade from the vehicle. {CAUTION: An improperly stored cargo cover could be thrown about the vehicle during a collision or sudden maneuver. You or others could be injured. If you remove the cover, always store it in the proper storage location. When you put it back, always be sure that it is securely reattached. 163 Press and release the back of the control in the overhead console to open the sunroof. Press the front of the control to close the sunroof. Once the sunroof is closed, press the forward side of the control to open the sunroof to the vent position. The sunroof has a sunshade which can be pulled forward to block sun rays. If it is in the closed position, it will open when the sunroof is opened. Cargo Tie Downs There are cargo tie downs in the rear of your vehicle that allow you to strap cargo in and keep it from moving. Sunroof The vehicle may be equipped with a power sliding sunroof. To open or close the sunroof, the ignition must be turned to RUN, ACCESSORY, or Retained Accessory Power (RAP) must be active. See Retained Accessory Power (RAP) on page 114. 164 Section 3 Instrument Panel Instrument Panel Overview ........................ 168 Hazard Warning Flashers .......................... 170 Other Warning Devices ............................. 170 Horn .......................................................... 170 Tilt Wheel .................................................. 171 Turn Signal/Multifunction Lever .................. 171 Turn and Lane-Change Signals ................. 172 Headlamp High/Low-Beam Changer .......... 173 Flash-to-Pass ............................................ 173 Windshield Wipers ..................................... 173 Windshield Washer .................................... 174 Rear Window Wiper/Washer ...................... 174 Headlamp Washer ..................................... 175 Cruise Control ........................................... 176 Headlamps ................................................ 179 Headlamps on Reminder ........................... 180 Daytime Running Lamps (DRL) ................. 180 Automatic Headlamp System ..................... 181 Fog Lamps ................................................ 182 Instrument Panel Brightness ...................... 182 Dome Lamps ............................................. 182 Dome Lamp Override ................................ 183 Entry Lighting ............................................ 183 Exit Lighting .............................................. 183 Reading Lamps ......................................... 183 Electric Power Management ...................... 184 Battery Run-Down Protection ..................... 185 Accessory Power Outlet(s) ........................ 185 Ashtray(s) and Cigarette Lighter ................ 186 Climate Controls ......................................... 186 Dual Climate Control System ..................... 186 Dual Automatic Climate Control System .... 189 Outlet Adjustment ...................................... 194 Rear Climate Control System .................... 195 Warning Lights, Gages, and Indicators ..... 197 Instrument Panel Cluster ........................... 198 Speedometer and Odometer ...................... 199 Trip Odometer ........................................... 199 Tachometer ............................................... 199 Safety Belt Reminder Light ........................ 200 Passenger Safety Belt Reminder Light ....... 200 Airbag Readiness Light ............................. 201 Passenger Airbag Status Indicator ............. 202 Charging System Light .............................. 205 Voltmeter Gage ......................................... 205 Brake System Warning Light ..................... 206 Anti-Lock Brake System Warning Light ...... 207 165 Section 3 Instrument Panel Audio System(s) ......................................... 236 Setting the Time ........................................ 238 Radio with CD (Base) ............................... 238 Radio with CD (MP3) ................................ 248 Radio with Six-Disc CD ............................. 258 Using an MP3 ........................................... 271 XM Radio Messages ................................. 277 Navigation/Radio System ........................... 280 Rear Seat Entertainment System ............... 280 Rear Seat Audio (RSA) ............................. 295 Theft-Deterrent Feature ............................. 296 Audio Steering Wheel Controls .................. 297 Radio Reception ........................................ 298 Care of Your CDs and DVDs .................... 299 Care of the CD and DVD Player ............... 299 Fixed Mast Antenna .................................. 299 XM™ Satellite Radio Antenna System ....... 300 Chime Level Adjustment ............................ 300 StabiliTrak® Service Light ........................... 207 StabiliTrak® Indicator Light ......................... 208 Engine Coolant Temperature Gage ............ 208 Tire Pressure Light .................................... 209 Malfunction Indicator Lamp ........................ 210 Oil Pressure Gage ..................................... 213 Change Engine Oil Light ........................... 214 Security Light ............................................ 214 Cruise Control Light .................................. 215 Reduced Engine Power Light .................... 215 Highbeam On Light ................................... 215 Service Four-Wheel Drive Warning Light ... 216 Check Gages Warning Light ...................... 216 Gate Ajar Light .......................................... 216 Fuel Gage ................................................. 217 Low Fuel Warning Light ............................ 217 Check Gas Cap Light ................................ 217 Driver Information Center (DIC) .................. 218 DIC Operation and Displays ...................... 219 DIC Warnings and Messages .................... 222 DIC Vehicle Customization ........................ 229 166 ✍ NOTES 167 Instrument Panel Overview 168 The main components of your instrument panel are the following: A. Exterior Lamp Control. See Headlamps on page 179. Dome Lamp Override Button. See Dome Lamp Override on page 183. Instrument Panel Brightness Control. See Instrument Panel Brightness on page 182. Fog Lamp Button (If Equipped). See Fog Lamps on page 182. B. Air Outlets. See Outlet Adjustment on page 194. C. Turn Signal/Multifunction Lever. See Turn Signal/Multifunction Lever on page 171. D. OnStar and Audio Steering Wheel Controls. See Audio Steering Wheel Controls on page 297. E. Instrument Panel Cluster. See Instrument Panel Cluster on page 198. F. Audio Steering Wheel Controls. See Audio Steering Wheel Controls on page 297. G. Ignition Switch. See Ignition Positions on page 113. H. Audio System. See Audio System(s) on page 236. I. Climate Controls. See Dual Climate Control System on page 186. J. Hood Release. See Hood Release on page 388. K. Driver Information Center (DIC) Steering Wheel Controls. See Driver Information Center (DIC) on page 218. L. Transfer Case Controls. See “Automatic Transfer Case” under Four-Wheel Drive on page 122. M. Shift Lever and StabiliTrak® (If Equipped) Button. See Shifting Into Park (P) on page 127 and StabiliTrak® System on page 309. N. Lighter. See Ashtray(s) and Cigarette Lighter on page 186. O. Accessory Power Outlets. See Accessory Power Outlet(s) on page 185. P. Parking Brake. See Parking Brake on page 126. Q. Rear Window Washer/Wiper. See “Rear Window Washer/Wiper” under Windshield Washer on page 174. R. Rear Window Defogger. See “Rear Window Defogger” under Dual Climate Control System on page 186 and Dual Automatic Climate Control System on page 189. S. Glove Box. See Glove Box on page 160. 169 Hazard Warning Flashers The hazard warning ﬂashers warn others. They also let police know you have a problem. Your front and rear turn signal lamps will ﬂash on and off. The hazard warning ﬂasher button is located on top of the steering column. The hazard warning ﬂashers work no matter what ignition position the key is in, and even if the key is not in the ignition. Press the button to make the front and rear turn signal lamps ﬂash on and off. Press the button again to turn the ﬂashers off. When the hazard warning ﬂashers are on, your turn signals will not work. Other Warning Devices If you carry reﬂective triangles, you can set them up at the side of the road about 300 feet (100 m) behind your vehicle. Horn To sound the horn, press the horn symbols on the steering wheel pad. 170 Tilt Wheel The steering wheel should be adjusted before you drive. Turn Signal/Multifunction Lever The tilt lever is located to the left of the steering column, under the turn signal lever. It can be raised to the highest level to give your legs more room when you enter and exit the vehicle. To tilt the wheel, hold the steering wheel and pull the lever toward you. Move the steering wheel to a comfortable level, then release the lever to lock the wheel in place. The lever on the left side of the steering column includes the following: (cid:127) G Turn and Lane Change Signals (cid:127) 23 Headlamp High/Low-Beam Changer (cid:127) Flash-to-Pass Feature (cid:127) N Windshield Wipers (cid:127) J Windshield Washer (cid:127) I Cruise Control 171 Turn and Lane-Change Signals The turn signal has two upward (for right) and two downward (for left) positions. These positions let you signal a turn or a lane change. To signal a turn, move the lever all the way up or down. When the turn is ﬁnished, the lever returns automatically. An arrow on the instrument panel cluster ﬂashes in the direction of the turn or lane change. To signal a lane change, raise or lower the lever until the arrow starts to ﬂash. Hold it there until you complete your lane change. The lever returns by itself when released. The bottom of the outside rearview mirrors might also have lane change indicators. As you signal a turn or a lane change, if the arrows ﬂash more quickly than normal, a signal bulb could be burned out and other drivers will not see your turn signal. If a bulb is burned out, replace it to help avoid an
