1. Release the two rear clips (1). 2. Lift the battery cover up toward
the front of the vehicle to release it from the pivot points (2) and remove.
3. Reverse Steps 1 and 2 to reinstall the battery cover.
Cadillac XTS Owner Manual 2016 - crc - 5/19/15
(GMNA-Localizing-U.S/Canada-9234768)
314
Vehicle Care
The vehicle has a remote positive (+) terminal under a trim cover. It is under the battery cover on the driver side of the engine compartment. See Engine Compartment Overview 0 246. Always use this remote positive terminal.
The vehicle has a remote negative (−) ground location. It is located on the driver side of the engine compartment. See Engine Compartment Overview 0 246. Always use this remote ground location, instead of the terminal on the battery. These posts are used instead of a direct connection to the battery. 1. Check the other vehicle.
It must have a 12-volt battery with a negative ground system.
Caution
If the other vehicle does not have a 12-volt system with a negative ground, both vehicles can be damaged. Only use a vehicle that has a 12-volt system with a negative ground for jump starting.
2. Position the two vehicles so
that they are not touching.
3. Set the parking brake firmly.
Vehicles with an automatic transmission should be in P (Park). See Shifting Into Park 0 195.
Caution
If any accessories are left on or plugged in during the jump starting procedure, they could be damaged. The repairs would not be covered by the vehicle warranty. Whenever possible, turn off or unplug all accessories on either vehicle when jump starting.
Cadillac XTS Owner Manual 2016 - crc - 5/19/15
(GMNA-Localizing-U.S/Canada-9234768)
4. Turn the ignition to OFF and
switch off all lights and accessories in both vehicles, except the hazard warning flashers if needed. { Warning
An electric fan can start up even when the engine is not running and can injure you. Keep hands, clothing, and tools away from any underhood electric fan.
{ Warning
Using a match near a battery can cause battery gas to explode. People have been hurt doing this, and some have been blinded. Use a flashlight if you need more light. Battery fluid contains acid that can burn you. Do not get it on you. If you accidentally get it in
(Continued)
Warning (Continued)
your eyes or on your skin, flush the place with water and get medical help immediately.
{ Warning
Fans or other moving engine parts can injure you badly. Keep your hands away from moving parts once the engine is running.
5. Connect one end of the red
positive (+) cable to the jump start remote positive (+) terminal for the discharged battery.
6. Connect the other end of the
red positive (+) cable to the positive (+) terminal of the good battery.
7. Connect one end of the black
negative (–) cable to the negative (–) terminal of the good battery.
Vehicle Care
315
8. Connect the other end of the
black negative (–) cable to the remote negative (–) post for the discharged battery.
9. Start the engine in the vehicle with the good battery and run the engine at idle speed for at least four minutes.
10. Try to start the vehicle that had
the dead battery. If it will not start after a few tries, it probably needs service.
Caution
If the jumper cables are connected or removed in the wrong order, electrical shorting may occur and damage the vehicle. The repairs would not be covered by the vehicle warranty. Always connect and remove the jumper cables in the correct order, making sure that the cables do not touch each other or other metal.
Cadillac XTS Owner Manual 2016 - crc - 5/19/15
(GMNA-Localizing-U.S/Canada-9234768)
316
Vehicle Care
Jumper Cable Removal Reverse the sequence exactly when removing the jumper cables. After starting the disabled vehicle and removing the jumper cables, allow it to idle for several minutes.
Towing the Vehicle
Caution
Incorrectly towing a disabled vehicle may cause damage. The damage would not be covered by the vehicle warranty. Do not lash or hook to suspension components. Use the proper straps around the tires to secure the vehicle.
Have the vehicle towed on a wheel lift tow truck. A flatbed car carrier could damage the vehicle. The wheel lift tow truck must raise the rear of the vehicle and wheel dollies must be used to lift the front wheels off the ground. Consult your dealer or a professional towing service if the disabled vehicle must be towed.
Recreational Vehicle Towing Recreational vehicle towing means towing the vehicle behind another vehicle such as a motor home. The two most common types of recreational vehicle towing are known as dinghy towing and dolly towing. Dinghy towing is towing the vehicle with all four wheels on the ground. Dolly towing is towing the vehicle with two wheels on the ground and two wheels up on a device known as a dolly. Here are some important things to consider before recreational vehicle towing: . What is the towing capacity of the towing vehicle? Be sure to read the tow vehicle manufacturer's recommendations.
. What is the distance that will be
traveled? Some vehicles have restrictions on how far and how long they can tow.
Cadillac XTS Owner Manual 2016 - crc - 5/19/15
(GMNA-Localizing-U.S/Canada-9234768)
Is the proper towing equipment going to be used? See your dealer or trailering professional for additional advice and equipment recommendations. Is the vehicle ready to be towed? Just as preparing the vehicle for a long trip, make sure the vehicle is prepared to be towed.
Caution
Use of a shield mounted in front of the vehicle grille could restrict airflow and cause damage to the transmission. The repairs would not be covered by the vehicle warranty. If using a shield, only use one that attaches to the towing vehicle.
Dinghy Towing
Vehicle Care
317
towed, a dolly should be used. See the following information on dolly towing. Dolly Towing from the Front (Front-Wheel Drive)
Caution
If the vehicle is towed with all four wheels on the ground, the drivetrain components could be damaged. The repairs would not be covered by the vehicle warranty. Do not tow the vehicle with all four wheels on the ground.
The vehicle was not designed to be towed with all four wheels on the ground. If the vehicle must be
Vehicles with front-wheel drive can be dolly towed from the front. To dolly tow the vehicle from the front: 1. Attach the dolly to the tow vehicle following the dolly manufacturer instructions.
2. Drive the front wheels onto the
dolly.
Cadillac XTS Owner Manual 2016 - crc - 5/19/15
(GMNA-Localizing-U.S/Canada-9234768)
318
Vehicle Care
3. Shift the transmission to
P (Park).
4. Firmly set the parking brake. 5. Use an adequate clamping
device designed for towing to ensure that the front wheels are locked into the straight-ahead position.
6. Secure the vehicle to the dolly
following the manufacturer instructions.
7. Release the parking brake only after the vehicle being towed is firmly attached to the towing vehicle.
8. Turn the ignition to OFF.
Dolly Towing from the Front (All-Wheel Drive)
Dolly Towing from the Rear
Vehicles with All-Wheel Drive cannot be dolly towed.
The vehicle cannot be dolly towed from the rear.
Cadillac XTS Owner Manual 2016 - crc - 5/19/15
(GMNA-Localizing-U.S/Canada-9234768)
Appearance Care
Exterior Care
Locks Locks are lubricated at the factory. Use a de-icing agent only when absolutely necessary, and have the locks greased after using. See Recommended Fluids and Lubricants 0 339. Washing the Vehicle To preserve the vehicle's finish, wash it often and out of direct sunlight.
Caution
Do not use petroleum-based, acidic, or abrasive cleaning agents as they can damage the vehicle's paint, metal, or plastic parts. If damage occurs, it would not be covered by the vehicle warranty. Approved cleaning products can be obtained from
(Continued)
Caution (Continued)
your dealer. Follow all manufacturer directions regarding correct product usage, necessary safety precautions, and appropriate disposal of any vehicle care product.
Caution
Avoid using high-pressure washes closer than 30 cm (12 in) to the surface of the vehicle. Use of power washers exceeding 8,274 kPa (1,200 psi) can result in damage or removal of paint and decals.
The e symbol is on any underhood compartment electrical center that should not be power washed. This could cause damage that would not be covered by the vehicle warranty.
Vehicle Care
319
If using an automatic car wash, follow the car wash instructions. The windshield wiper and rear window wiper, if equipped, must be off. Remove any accessories that may be damaged or interfere with the car wash equipment. Rinse the vehicle well, before washing and after, to remove all cleaning agents completely. If they are allowed to dry on the surface, they could stain. Dry the finish with a soft, clean chamois or an all-cotton towel to avoid surface scratches and water spotting. Finish Care Application of aftermarket clearcoat sealant/wax materials is not recommended. If painted surfaces are damaged, see your dealer to have the damage assessed and repaired. Foreign materials such as calcium chloride and other salts, ice melting agents, road oil and tar, tree sap, bird droppings, chemicals from industrial chimneys, etc., can damage the vehicle's finish if they remain on painted surfaces. Wash
Cadillac XTS Owner Manual 2016 - crc - 5/19/15
(GMNA-Localizing-U.S/Canada-9234768)
320
Vehicle Care
the vehicle as soon as possible. If necessary, use non-abrasive cleaners that are marked safe for painted surfaces to remove foreign matter. Occasional hand waxing or mild polishing should be done to remove residue from the paint finish. See your dealer for approved cleaning products. Do not apply waxes or polishes to uncoated plastic, vinyl, rubber, decals, simulated wood, or flat paint as damage can occur.
Caution
Machine compounding or aggressive polishing on a basecoat/clearcoat paint finish may damage it. Use only non-abrasive waxes and polishes that are made for a basecoat/ clearcoat paint finish on the vehicle.
To keep the paint finish looking new, keep the vehicle garaged or covered whenever possible.
Protecting Exterior Bright Metal Moldings
Caution
Failure to clean and protect the bright metal moldings can result in a hazy white finish or pitting. This damage would not be covered by the vehicle warranty.
The bright metal moldings on the vehicle are aluminum, chrome or stainless steel. To prevent damage always follow these cleaning instructions: . Be sure the molding is cool to the touch before applying any cleaning solution.
. Use only approved cleaning
solutions for aluminum, chrome or stainless steel. Some cleaners are highly acidic or contain alkaline substances and can damage the moldings.
. Always dilute a concentrated
cleaner according to the manufacturer’s instructions.
. Do not use cleaners that are not
intended for automotive use.
. Use a nonabrasive wax on the vehicle after washing to protect and extend the molding finish.
Cleaning Exterior Lamps/ Lenses, Emblems, Decals, and Stripes Use only lukewarm or cold water, a soft cloth, and a car washing soap to clean exterior lamps, lenses, emblems, decals, and stripes. Follow instructions under "Washing the Vehicle" previously in this section. Lamp covers are made of plastic, and some have a UV protective coating. Do not clean or wipe them when dry. Do not use any of the following on lamp covers: . Abrasive or caustic agents. . Washer fluids and other cleaning
agents in higher concentrations than suggested by the manufacturer.
Cadillac XTS Owner Manual 2016 - crc - 5/19/15
(GMNA-Localizing-U.S/Canada-9234768)
. Solvents, alcohols, fuels, or other harsh cleaners. Ice scrapers or other hard items. . Aftermarket appearance caps or
covers while the lamps are illuminated, due to excessive heat generated.
Caution
Failure to clean lamps properly can cause damage to the lamp cover that would not be covered by the vehicle warranty.
Caution
Using wax on low gloss black finish stripes can increase the gloss level and create a non-uniform finish. Clean low gloss stripes with soap and water only.
Air Intakes Clear debris from the air intakes, between the hood and windshield when washing the vehicle. Windshield and Wiper Blades Clean the outside of the windshield with glass cleaner. Clean rubber blades using a lint-free cloth or paper towel soaked with windshield washer fluid or a mild detergent. Wash the windshield thoroughly when cleaning the blades. Bugs, road grime, sap, and a buildup of vehicle wash/wax treatments may cause wiper streaking. Replace the wiper blades if they are worn or damaged. Damage can be caused by extreme dusty conditions, sand, salt, heat, sun, snow, and ice. Weatherstrips Apply Dielectric silicone grease on weatherstrips to make them last longer, seal better, and not stick or squeak. Lubricate weatherstrips at least once a year. Hot, dry climates
Vehicle Care
321
may require more frequent application. Black marks from rubber material on painted surfaces can be removed by rubbing with a clean cloth. See Recommended Fluids and Lubricants 0 339. Tires Use a stiff brush with tire cleaner to clean the tires.
Caution
Using petroleum-based tire dressing products on the vehicle may damage the paint finish and/ or tires. When applying a tire dressing, always wipe off any overspray from all painted surfaces on the vehicle.
Wheels and Trim — Aluminum or Chrome Use a soft, clean cloth with mild soap and water to clean the wheels. After rinsing thoroughly with clean water, dry with a soft, clean towel. A wax may then be applied.
Cadillac XTS Owner Manual 2016 - crc - 5/19/15
(GMNA-Localizing-U.S/Canada-9234768)
322
Vehicle Care
Caution
Caution (Continued)
Chrome wheels and other chrome trim may be damaged if the vehicle is not washed after driving on roads that have been sprayed with magnesium, calcium, or sodium chloride. These chlorides are used on roads for conditions such as ice and dust. Always wash the chrome with soap and water after exposure.
Caution
To avoid surface damage, do not use strong soaps, chemicals, abrasive polishes, cleaners, brushes, or cleaners that contain acid on aluminum or chrome-plated wheels. Use only approved cleaners. Also, never drive a vehicle with aluminum or chrome-plated wheels through an automatic car wash that uses silicone carbide tire cleaning
(Continued)
brushes. Damage could occur and the repairs would not be covered by the vehicle warranty.
Brake System Visually inspect brake lines and hoses for proper hook-up, binding, leaks, cracks, chafing, etc. Inspect disc brake pads for wear and rotors for surface condition. Inspect drum brake linings/shoes for wear or cracks. Inspect other brake parts, including drums, wheel cylinders, calipers, parking brake, master cylinder, brake fluid reservoir, vacuum pipes, electric vacuum pump including bracket, and vent hose, if equipped. Steering, Suspension, and Chassis Components Visually inspect steering, suspension, and chassis components for damaged, loose, or missing parts or signs of wear at least once a year.
Inspect power steering for proper hook-up, binding, leaks, cracks, chafing, etc. Visually check constant velocity joint boots and axle seals for leaks. Body Component Lubrication Lubricate all key lock cylinders, hood hinges, liftgate hinges, and the steel fuel door hinges, unless the components are plastic. Applying silicone grease on weatherstrips with a clean cloth will make them last longer, seal better, and not stick or squeak. Underbody Maintenance At least twice a year, spring and fall, use plain water to flush any corrosive materials from the underbody. Take care to thoroughly clean any areas where mud and other debris can collect. Do not directly power wash the transfer case and/or front/rear axle output seals. High pressure water can overcome the seals and contaminate the fluid. Contaminated
Cadillac XTS Owner Manual 2016 - crc - 5/19/15
(GMNA-Localizing-U.S/Canada-9234768)
fluid will decrease the life of the transfer case and/or axles and should be replaced. Sheet Metal Damage If the vehicle is damaged and requires sheet metal repair or replacement, make sure the body repair shop applies anti-corrosion material to parts repaired or replaced to restore corrosion protection. Original manufacturer replacement parts will provide the corrosion protection while maintaining the vehicle warranty. Finish Damage Quickly repair minor chips and scratches with touch-up materials available from your dealer to avoid corrosion. Larger areas of finish damage can be corrected in your dealer's body and paint shop. Chemical Paint Spotting Airborne pollutants can fall upon and attack painted vehicle surfaces causing blotchy, ring-shaped discolorations, and small, irregular
dark spots etched into the paint surface. See “Finish Care” previously in this section.
Interior Care To prevent dirt particle abrasions, regularly clean the vehicle's interior. Immediately remove any soils. Newspapers or dark garments can transfer color to the vehicle’s interior. Use a soft bristle brush to remove dust from knobs and crevices on the instrument cluster. Using a mild soap solution, immediately remove hand lotions, sunscreen, and insect repellent from all interior surfaces or permanent damage may result. Use cleaners specifically designed for the surfaces being cleaned to prevent permanent damage. Apply all cleaners directly to the cleaning cloth. Do not spray cleaners on any switches or controls. Remove cleaners quickly.
Vehicle Care
323
Before using cleaners, read and follow all safety instructions on the label. While cleaning the interior, open the doors and windows to get proper ventilation. To prevent damage, do not clean the interior using the following cleaners or techniques: . Never use a razor or any other
sharp object to remove soil from any interior surface.
. Never use a brush with stiff
bristles.
. Never rub any surface
aggressively or with too much pressure.
. Do not use laundry detergents or
dishwashing soaps with degreasers. For liquid cleaners, use approximately 20 drops per 3.8 L (1 gal) of water. A concentrated soap solution will create streaks and attract dirt. Do not use solutions that contain strong or caustic soap.
. Do not heavily saturate the upholstery when cleaning.
Cadillac XTS Owner Manual 2016 - crc - 5/19/15
(GMNA-Localizing-U.S/Canada-9234768)
324
Vehicle Care
. Do not use solvents or cleaners
containing solvents.
Interior Glass To clean, use a terry cloth fabric dampened with water. Wipe droplets left behind with a clean dry cloth. If necessary, use a commercial glass cleaner after cleaning with plain water.
Caution
To prevent scratching, never use abrasive cleaners on automotive glass. Abrasive cleaners or aggressive cleaning may damage the rear window defogger.
Cleaning the windshield with water during the first three to six months of ownership will reduce tendency to fog. Speaker Covers Vacuum around a speaker cover gently, so that the speaker will not be damaged. Clean spots with water and mild soap.
Coated Moldings Coated moldings should be cleaned. . When lightly soiled, wipe with a
sponge or soft, lint-free cloth dampened with water.
. When heavily soiled, use warm
soapy water.
Fabric/Carpet/Suede Start by vacuuming the surface using a soft brush attachment. If a rotating vacuum brush attachment is being used, only use it on the floor carpet. Before cleaning, gently remove as much of the soil as possible: . Gently blot liquids with a paper towel. Continue blotting until no more soil can be removed.
. For solid soils, remove as much as possible prior to vacuuming.
To clean: 1. Saturate a clean, lint-free colorfast cloth with water. Microfiber cloth is recommended to prevent lint transfer to the fabric or carpet.
2. Remove excess moisture by
gently wringing until water does not drip from the cleaning cloth. 3. Start on the outside edge of the
soil and gently rub toward the center. Fold the cleaning cloth to a clean area frequently to prevent forcing the soil in to the fabric.
4. Continue gently rubbing the soiled area until there is no longer any color transfer from the soil to the cleaning cloth. If the soil is not completely removed, use a mild soap solution followed only by plain water.
5.
If the soil is not completely removed, it may be necessary to use a commercial upholstery cleaner or spot lifter. Test a small hidden area for colorfastness before using a commercial upholstery cleaner or spot lifter. If ring formation occurs, clean the entire fabric or carpet. After cleaning, use a paper towel to blot excess moisture.
Cadillac XTS Owner Manual 2016 - crc - 5/19/15
(GMNA-Localizing-U.S/Canada-9234768)
Cleaning High Gloss Surfaces and Vehicle Information and Radio Displays Use a microfiber cloth on high gloss surfaces or vehicle displays. First, use a soft bristle brush to remove dirt that can scratch the surface. Then gently clean by rubbing with a microfiber cloth. Never use window cleaners or solvents. Periodically hand wash the microfiber cloth separately, using mild soap. Do not use bleach or fabric softener. Rinse thoroughly and air dry before next use.
Caution
Do not attach a device with a suction cup to the display. This may cause damage and would not be covered by the vehicle warranty.
Instrument Panel, Leather, Vinyl, Other Plastic Surfaces, Low Gloss Paint Surfaces, and Natural Open Pore Wood Surfaces Use a soft microfiber cloth dampened with water to remove dust and loose dirt. For a more thorough cleaning, use a soft microfiber cloth dampened with a mild soap solution.
Vehicle Care
325
Caution (Continued)
the appearance and feel of leather or soft trim, and are not recommended.
Do not use cleaners that increase gloss, especially on the instrument panel. Reflected glare can decrease visibility through the windshield under certain conditions.
Caution
Caution
Soaking or saturating leather, especially perforated leather, as well as other interior surfaces, may cause permanent damage. Wipe excess moisture from these surfaces after cleaning and allow them to dry naturally. Never use heat, steam, or spot removers. Do not use cleaners that contain silicone or wax-based products. Cleaners containing these solvents can permanently change (Continued)
Use of air fresheners may cause permanent damage to plastics and painted surfaces. If an air freshener comes in contact with any plastic or painted surface in the vehicle, blot immediately and clean with a soft cloth dampened with a mild soap solution. Damage caused by air fresheners would not be covered by the vehicle warranty.
Cadillac XTS Owner Manual 2016 - crc - 5/19/15
(GMNA-Localizing-U.S/Canada-9234768)
326
Vehicle Care
Cargo Cover and Convenience Net Wash with warm water and mild detergent. Do not use chlorine bleach. Rinse with cold water, and then dry completely. Care of Safety Belts Keep belts clean and dry. { Warning
Do not bleach or dye safety belts. It may severely weaken them. In a crash, they might not be able to provide adequate protection. Clean safety belts only with mild soap and lukewarm water.
Floor Mats
{ Warning
If a floor mat is the wrong size or is not properly installed, it can interfere with the pedals. Interference with the pedals can
(Continued)
Warning (Continued)
cause unintended acceleration and/or increased stopping distance which can cause a crash and injury. Make sure the floor mat does not interfere with the pedals.
Use the following guidelines for proper floor mat usage. . The original equipment floor mats were designed for your vehicle. If the floor mats need replacing, it is recommended that GM certified floor mats be purchased. Non-GM floor mats may not fit properly and may interfere with the pedals. Always check that the floor mats do not interfere with the pedals.
. Do not use a floor mat if the
vehicle is not equipped with a floor mat retainer on the driver side floor.
. Use the floor mat with the
correct side up. Do not turn it over.
. Do not place anything on top of
the driver side floor mat.
. Use only a single floor mat on
the driver side.
. Do not place one floor mat on
top of another.
The floor mats are held in place by button-type retainers. Removing and Replacing the Floor Mats
1. Pull up on the rear of the floor mat to unlock the retainers and remove.
Cadillac XTS Owner Manual 2016 - crc - 5/19/15
(GMNA-Localizing-U.S/Canada-9234768)
Vehicle Care
327
2. Reinstall by lining up the floor mat retainer openings over the carpet retainers and snap into position.
3. Make sure the floor mat is properly secured in place. Verify the floor mat does not interfere with the pedals.
Cadillac XTS Owner Manual 2016 - crc - 5/19/15
(GMNA-Localizing-U.S/Canada-9234768)
Service and Maintenance
328
Service and MaintenanceGeneral Information
General Information . . . . . . . . . . 328
Cadillac Premium Care Maintenance
Cadillac Premium Care
Maintenance . . . . . . . . . . . . . . . . 330
Maintenance Schedule
Maintenance Schedule . . . . . . . 330
Special Application Services
Special Application
Services . . . . . . . . . . . . . . . . . . . . 336
Additional Maintenance and Care
Additional Maintenance
and Care . . . . . . . . . . . . . . . . . . . . 336
Recommended Fluids, Lubricants, and Parts
Recommended Fluids and
Lubricants . . . . . . . . . . . . . . . . . . . 339
Maintenance Replacement
Parts . . . . . . . . . . . . . . . . . . . . . . . . 340
Maintenance Records
Maintenance Records . . . . . . . . 341
General Information Your vehicle is an important investment. This section describes the required maintenance for the vehicle. Follow this schedule to help protect against major repair expenses resulting from neglect or inadequate maintenance. It may also help to maintain the value of the vehicle if it is sold. It is the responsibility of the owner to have all required maintenance performed. Your dealer has trained technicians who can perform required maintenance using genuine replacement parts. They have up-to-date tools and equipment for fast and accurate diagnostics. Many dealers have extended evening and Saturday hours, courtesy transportation, and online scheduling to assist with service needs. Your dealer recognizes the importance of providing competitively priced maintenance and repair services. With trained technicians, the dealer is the place for routine maintenance such as oil
Cadillac XTS Owner Manual 2016 - crc - 5/19/15
(GMNA-Localizing-U.S/Canada-9234768)
Service and Maintenance
329
. Used for taxi, police, or delivery
service.
Refer to the information in the Maintenance Schedule Additional Required Services - Severe chart.
{ Warning
Performing maintenance work can be dangerous and can cause serious injury. Perform maintenance work only if the required information, proper tools, and equipment are available. If they are not, see your dealer to have a trained technician do the work. See Doing Your Own Service Work 0 244.
changes and tire rotations and additional maintenance items like tires, brakes, batteries, and wiper blades.
Caution
Damage caused by improper maintenance can lead to costly repairs and may not be covered by the vehicle warranty. Maintenance intervals, checks, inspections, recommended fluids, and lubricants are important to keep the vehicle in good working condition.
The Tire Rotation and Required Services are the responsibility of the vehicle owner. It is recommended to have your dealer perform these services every 12 000 km/7,500 mi. Proper vehicle maintenance helps to keep the vehicle in good working condition, improves fuel economy, and reduces vehicle emissions. Because of the way people use vehicles, maintenance needs vary. There may need to be more
frequent checks and services. The Additional Required Services - Normal are for vehicles that: . Carry passengers and cargo within recommended limits on the Tire and Loading Information label. See Vehicle Load Limits 0 186.
. Are driven on reasonable road
surfaces within legal driving limits.
. Use the recommended fuel. See
Fuel 0 232.
Refer to the information in the Maintenance Schedule Additional Required Services - Normal chart. The Additional Required Services - Severe are for vehicles that are: . Mainly driven in heavy city traffic
in hot weather.
. Mainly driven in hilly or
mountainous terrain.
. Frequently towing a trailer. . Used for high speed or
competitive driving.
Cadillac XTS Owner Manual 2016 - crc - 5/19/15
(GMNA-Localizing-U.S/Canada-9234768)
330
Service and Maintenance
Cadillac requires that all Cadillac Premium Care Maintenance services be performed by a Cadillac authorized service dealer.
Cadillac Premium Care Maintenance Your vehicle comes with the Cadillac Premium Care Maintenance. It is a maintenance program that covers select maintenance services during the first 4 years or 80 000 km (50,000 mi), whichever comes first. Cadillac Premium Care Maintenance covers routine maintenance services, when scheduled in accordance with the owner manual, including: . Oil changes based on the
vehicle's oil life monitor system.
. Tire rotation every 12 000 km
(7,500 mi).
. Engine air cleaner filter
replacement.
. Passenger compartment air filter
replacement.
. Multi‐point vehicle inspection
(MPVI) performed by a qualified technician.
Maintenance Schedule
Owner Checks and Services
At Each Fuel Stop . Check the engine oil level. See
Engine Oil 0 250.
Once a Month . Check the tire inflation
pressures. See Tire Pressure 0 285. Inspect the tires for wear. See Tire Inspection 0 291.
. Check the windshield washer fluid level. See Washer Fluid 0 262.
Engine Oil Change When the CHANGE ENGINE OIL SOON message displays, have the engine oil and filter changed within the next 1 000 km/600 mi. If driven under the best conditions, the engine oil life system may not indicate the need for vehicle service for up to a year. The engine oil and filter must be changed at least once
Cadillac XTS Owner Manual 2016 - crc - 5/19/15
(GMNA-Localizing-U.S/Canada-9234768)
Service and Maintenance
331
a year and the oil life system must be reset. Your trained dealer technician can perform this work. If the engine oil life system is reset accidentally, service the vehicle within 5 000 km/3,000 mi since the last service. Reset the oil life system when the oil is changed. See Engine Oil Life System 0 252. Tire Rotation and Required Services Every 12 000 km/ 7,500 mi Rotate the tires, if recommended for the vehicle, and perform the following services. See Tire Rotation 0 291. . Check engine oil level and oil
life percentage. If needed, change engine oil and filter, and reset oil life system. See Engine Oil 0 250 and Engine Oil Life System 0 252.
. Check engine coolant level. See
Engine Coolant 0 256.
. Check windshield washer fluid level. See Washer Fluid 0 262.
. Visually inspect windshield wiper
blades for wear, cracking, or contamination. See Exterior Care 0 319. Replace worn or damaged wiper blades. See Wiper Blade Replacement 0 266.
. Check tire inflation pressures.
See Tire Pressure 0 285. Inspect tire wear. See Tire Inspection 0 291.
. Visually check for fluid leaks.
Inspect engine air cleaner filter. See Engine Air Cleaner/Filter 0 253. Inspect brake system. See Exterior Care 0 319.
. Visually inspect steering, suspension, and chassis components for damaged, loose, or missing parts or signs of wear. See Exterior Care 0 319.
. Check restraint system
components. See Safety System Check 0 70.
. Visually inspect fuel system for
damage or leaks.
. Visually inspect exhaust system
and nearby heat shields for loose or damaged parts.
. Lubricate body components. See
Exterior Care 0 319.
. Check starter switch. See Starter
Switch Check 0 265.
. Check automatic transmission shift lock control function. See Automatic Transmission Shift Lock Control Function Check 0 265.
. Check parking brake and
automatic transmission park mechanism. See Park Brake and P (Park) Mechanism Check 0 266.
Cadillac XTS Owner Manual 2016 - crc - 5/19/15
(GMNA-Localizing-U.S/Canada-9234768)
332
Service and Maintenance
. Check accelerator pedal for
. Check tire sealant expiration
damage, high effort, or binding. Replace if needed.
. Visually inspect gas strut for
signs of wear, cracks, or other damage. Check the hold open ability of the strut. See your dealer if service is required.
date, if equipped. See Tire Sealant and Compressor Kit 0 299. Inspect sunroof track and seal, if equipped. See Sunroof 0 50.
Cadillac XTS Owner Manual 2016 - crc - 5/19/15
(GMNA-Localizing-U.S/Canada-9234768)
Service and Maintenance
333
Maintenance Schedule Additional Required Services - Normal
Rotate tires and perform Required Services. Check engine oil level and oil life percentage. Change engine oil and filter, if needed.
@ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @
Replace passenger compartment air filter. (1)
Inspect evaporative control system. (2)
Replace engine air cleaner filter. (3)
Replace spark plugs. Inspect ignition coils. (3.6L LFX)
Replace spark plugs. Inspect ignition coils. (3.6L LF3)
Drain and fill engine cooling system. (4)
Visually inspect accessory drive belts. (5)
Replace brake fluid. (6)
Footnotes — Maintenance Schedule Additional Required Services - Normal (1) Or every two years, whichever comes first. More frequent passenger compartment air filter
replacement may be needed if driving in areas with heavy traffic, poor air quality, high dust levels, or environmental allergens. Passenger compartment air filter replacement may also be needed if there is reduced airflow, window
fogging, or odors. Your GM dealer can help determine when to replace the filter. (2) Check all fuel and vapor lines and hoses for proper hook-up, routing, and condition.
Cadillac XTS Owner Manual 2016 - crc - 5/19/15
(GMNA-Localizing-U.S/Canada-9234768)
334
Service and Maintenance
(3) Or every four years, whichever comes first. If driving in dusty conditions, inspect the filter at each oil change or more often as needed. (4) Or every five years, whichever comes first. See Cooling System 0 255.
(5) Or every 10 years, whichever comes first. Inspect for fraying, excessive cracking, or damage; replace, if needed. (6) Or every three years, whichever comes first.
Cadillac XTS Owner Manual 2016 - crc - 5/19/15
(GMNA-Localizing-U.S/Canada-9234768)
Service and Maintenance
335
Maintenance Schedule Additional Required Services - Severe
Rotate tires and perform Required Services. Check engine oil level and oil life percentage. Change engine oil and filter, if needed.
