Your engine will not start in any other position — that is a safety feature. To restart when you are already moving, use NEUTRAL (N) only. The keyless access transmitter must be in the vehicle for the ignition to work. 2-25 Notice: Do not try to shift to PARK (P) if your vehicle is moving. If you do, you could damage the transmission. Shift to PARK (P) only when your vehicle is stopped. 1. With your foot on the brake pedal, press the START button located on the instrument panel. If there is not a keyless access transmitter present, the DIC will display NO FOB DETECTED. See DIC Warnings and Messages on page 3-79 for more information. When the engine begins cranking, let go of the button. The idle speed will go down as your engine gets warm. If the battery in the keyless access transmitter is weak, the DIC will display FOB BATTERY LOW. You can still drive the vehicle. See “Battery Replacement” under Keyless Access System Operation on page 2-5 for more information. Notice: Holding the button in for longer than 15 seconds at a time will cause the vehicle’s battery to be drained much sooner. This can also cause damage to the starter motor. Wait 15 seconds between each try to avoid draining your vehicle’s battery or damaging the starter. 2. If the engine does not start and no DIC message is displayed, wait 15 seconds before trying again. Notice: Your engine is designed to work with the electronics in your vehicle. If you add electrical parts or accessories, you could change the way the engine operates. Before adding electrical equipment, check with your dealer. If you do not, your engine might not perform properly. Any resulting damage would not be covered by your vehicle’s warranty. Stopping Your Engine Move the shift lever to PARK (P) and press the ACC button located on the instrument panel. If the shifter is not in PARK (P), the vehicle will go into the accessory mode, the engine will turn off and the DIC will display SHIFT TO PARK. When the shifter is moved to PARK (P), the vehicle will go into the RAP mode, if all doors are closed. The ignition mode will change to OFF, if a front door is opened. See Retained Accessory Power (RAP) on page 2-25 for more information. If the keyless access transmitter is not detected while going to off, the DIC will display NO FOB – OFF OR RUN?. See DIC Warnings and Messages on page 3-79 for more information. 2-26 Engine Coolant Heater Your vehicle may be equipped with an engine coolant heater. In very cold weather, 0°F (−18°C) or colder, the engine coolant heater can help. You will get easier starting and better fuel economy during engine warm-up. Usually, the coolant heater should be plugged in a minimum of four hours prior to starting your vehicle. At temperatures above 32°F (0°C), use of the coolant heater is not required. Your vehicle may also have an internal thermostat in the plug end of the cord. This will prevent operation of the engine coolant heater when the temperature is at or above 0°F (−18°C) as noted on the cord. To Use the Engine Coolant Heater 1. Turn off the engine. 2. Open the hood and unwrap the electrical cord. For the 3.6L V6 engine, the cord is located in the engine compartment on the passenger’s side of the vehicle in front of the fuse block. For the 4.6L V8 engine, the cord is located in the engine compartment on the driver’s side of the vehicle near the inner fender and above the strut. For the 4.4L V8 engine, the cord is located in the front of the engine compartment, on the passenger’s side of the vehicle. The plug will be inside the upper grille cutout. 3. You must remove the plastic cap to access the plug. 4. Plug it into a normal, grounded 110-volt AC outlet. {CAUTION: Plugging the cord into an ungrounded outlet could cause an electrical shock. Also, the wrong kind of extension cord could overheat and cause a ﬁre. You could be seriously injured. Plug the cord into a properly grounded three-prong 110-volt AC outlet. If the cord will not reach, use a heavy-duty three-prong extension cord rated for at least 15 amps. 5. Before starting the engine, be sure to unplug and store the cord as it was before to keep it away from moving engine parts. If you do not, it could be damaged. How long should you keep the coolant heater plugged in? The answer depends on the outside temperature, the kind of oil you have, and some other things. Instead of trying to list everything here, we ask that you contact your dealer in the area where you will be parking your vehicle. The dealer can give you the best advice for that particular area. 2-27 {CAUTION: It is dangerous to get out of your vehicle if the shift lever is not fully in PARK (P) with the parking brake ﬁrmly set. Your vehicle can roll. Do not leave your vehicle when the engine is running unless you have to. If you have left the engine running, the vehicle can move suddenly. You or others could be injured. To be sure your vehicle will not move, even when you are on fairly level ground, always set your parking brake and move the shift lever to PARK (P). See Shifting Into Park (P) on page 2-36. If you are pulling a trailer, see Towing a Trailer (STS Only) on page 4-40. Automatic Transmission Operation (STS) The shift lever is located on the center console between the front seats. There are several different positions for the shift lever. PARK (P): This position locks the rear wheels. It is the best position to use when you start the engine because your vehicle cannot move easily. 2-28 Ensure the shift lever is fully in PARK (P) before starting the engine. Your vehicle has an automatic transmission shift lock control system. You must fully apply your regular brakes before you can shift from PARK (P) when the ignition is on. If you cannot shift out of PARK (P), ease pressure on the shift lever. Push the shift lever all the way into PARK (P) while pressing the button on the shift lever as you maintain brake application. Then move the shift lever into the gear you wish. See Shifting Out of Park (P) on page 2-38. Notice: Shifting to REVERSE (R) while your vehicle is moving forward could damage the transmission. The repairs would not be covered by your warranty. Shift to REVERSE (R) only after your vehicle is stopped. REVERSE (R): Use this gear to back up. At low vehicle speeds, you can also use REVERSE (R) to rock your vehicle back and forth to get out of snow, ice or sand without damaging your transmission. See If Your Vehicle is Stuck in Sand, Mud, Ice or Snow on page 4-31 for additional information. NEUTRAL (N): In this position, the engine does not connect with the wheels. To restart when you are already moving, use NEUTRAL (N) only. You can also use NEUTRAL (N) when your vehicle is being towed. {CAUTION: Shifting into a drive gear while your engine is running at high speed is dangerous. Unless your foot is ﬁrmly on the brake pedal, your vehicle could move very rapidly. You could lose control and hit people or objects. Do not shift into a drive gear while your engine is running at high speed. Notice: Shifting out of PARK (P) or NEUTRAL (N) with the engine running at high speed may damage the transmission. The repairs would not be covered by your warranty. Be sure the engine is not running at high speed when shifting your vehicle. 2-29 If you drive your vehicle at high RPMs Driver Shift Control (DSC) Notice: without upshifting while using Driver Shift Control (DSC), you could damage your vehicle. Always upshift when necessary while using DSC. Your automatic transmission has a Driver Shift Control (DSC) feature that allows you to change gears similar to a manual transmission. To use the DSC feature: 1. Slide the shift lever over from AUTOMATIC OVERDRIVE (D) to the right into the DSC area. When the transmission is in DSC mode the sport symbol in the Driver Information Center (DIC) will come on. AUTOMATIC OVERDRIVE (D): This position is for normal driving. If you need more power for passing, and you are: (cid:127) Going less than 35 mph (55 km/h), push the accelerator pedal about halfway down. (cid:127) Going about 35 mph (55 km/h) or more, push the accelerator all the way down. The transmission will shift down to a lower gear and have more power. Notice: Spinning the tires or holding the vehicle in one place on a hill using only the accelerator pedal may damage the transmission. If you are stuck, do not spin the tires. When stopping on a hill, use the brakes to hold the vehicle in place. FOURTH (4): This position is also used for normal driving. However, it offers more power and lower fuel economy than AUTOMATIC OVERDRIVE (D). Here are examples for using FOURTH (4) instead of AUTOMATIC OVERDRIVE (D): (cid:127) When driving on hilly, winding roads. (cid:127) When going down a steep hill. This position may also offer improved trailer towing performance in certain driving conditions. 2-30 If you do not move the shift lever forward or rearward, the vehicle will be in sport mode. When you are in the sport mode the vehicle will still shift automatically. While driving in sport mode, the transmission may remain in a gear longer than it would in normal driving mode based on braking, throttle input and vehicle lateral acceleration. 2. Press the shift lever forward to upshift or rearward to downshift. The DIC will show the requested gear range when moving the shift lever forward or rearward. See Driver Information Center (DIC) on page 3-73 for more information on the DIC. While using the DSC feature the vehicle will have ﬁrmer shifting and increased performance. You can use this for sport driving or when climbing/descending hills to stay in gear longer or to down shift for more power or engine braking. The transmission will only allow you to shift into gears appropriate for the vehicle speed and engine Revolutions Per Minute (RPM). The transmission will not automatically shift to the next higher gear if the engine rpm is too high. If shifting is prevented for any reason, the currently selected gear will ﬂash multiple times in the DIC, indicating that the transmission has not shifted gears. The transmission will allow you to shift to the gear selected and will automatically downshift when the vehicle comes to a stop. This will allow for more power during take-off and passing. When accelerating your vehicle from a stop in snowy and icy conditions, you may want to shift into second gear. A higher gear allows you to gain more traction on slippery surfaces. 2-31 {CAUTION: It is dangerous to get out of your vehicle if the shift lever is not fully in PARK (P) with the parking brake ﬁrmly set. Your vehicle can roll. Do not leave your vehicle when the engine is running unless you have to. If you have left the engine running, the vehicle can move suddenly. You or others could be injured. To be sure your vehicle will not move, even when you are on fairly level ground, always set your parking brake and move the shift lever to PARK (P). See Shifting Into Park (P) on page 2-36. If you are pulling a trailer, see Towing a Trailer (STS Only) on page 4-40. Automatic Transmission Operation (STS-V) The shift lever is located on the center console between the front seats. There are several different positions for the shift lever. PARK (P): This position locks the rear wheels. It is the best position to use when you start the engine because your vehicle cannot move easily. 2-32 Ensure the shift lever is fully in PARK (P) before starting the engine. Your vehicle has an automatic transmission shift lock control system. You must fully apply your regular brakes before you can shift from PARK (P) when the vehicle is running. If you cannot shift out of PARK (P), ease pressure on the shift lever. Push the shift lever all the way into PARK (P) while pressing the button on the shift lever as you maintain brake application. Then move the shift lever into the gear you wish. See Shifting Out of Park (P) on page 2-38. Notice: Shifting to REVERSE (R) while your vehicle is moving forward could damage the transmission. The repairs would not be covered by your warranty. Shift to REVERSE (R) only after your vehicle is stopped. REVERSE (R): Use this gear to back up. At low vehicle speeds, you can also use REVERSE (R) to rock your vehicle back and forth to get out of snow, ice, or sand without damaging your transmission. See If Your Vehicle is Stuck in Sand, Mud, Ice or Snow on page 4-31 for additional information. NEUTRAL (N): In this position, the engine does not connect with the wheels. To restart when you are already moving, use NEUTRAL (N) only. You can also use NEUTRAL (N) when your vehicle is being towed. {CAUTION: Shifting into a drive gear while your engine is running at high speed is dangerous. Unless your foot is ﬁrmly on the brake pedal, your vehicle could move very rapidly. You could lose control and hit people or objects. Do not shift into a drive gear while your engine is running at high speed. Notice: Shifting out of PARK (P) or NEUTRAL (N) with the engine running at high speed may damage the transmission. The repairs would not be covered by your warranty. Be sure the engine is not running at high speed when shifting your vehicle. AUTOMATIC OVERDRIVE (D): This position is for normal driving. If you need more power for passing, and you are: (cid:127) Going less than 35 mph (55 km/h), push the accelerator pedal about halfway down. (cid:127) Going about 35 mph (55 km/h) or more, push the accelerator all the way down. The transmission will shift down to a lower gear and have more power. 2-33 If you do not move the shift lever forward or rearward, the vehicle will be in sport mode. When you are in the sport mode the vehicle will still shift automatically. While driving in sport mode, the transmission may remain in a gear longer than it would in normal driving mode based on braking, throttle input, and vehicle lateral acceleration. 2. Press the shift lever forward to upshift or rearward to downshift. The DIC will show the requested gear range when moving the shift lever forward or rearward. See Driver Information Center (DIC) on page 3-73 for more information on the DIC. If you drive your vehicle at high RPMs Driver Shift Control (DSC) Notice: without upshifting while using Driver Shift Control (DSC), you could damage your vehicle. Always upshift when necessary while using DSC. Your automatic transmission has a Driver Shift Control (DSC) feature that allows you to change gears similar to a manual transmission. To use the DSC feature: 1. Slide the shift lever over from AUTOMATIC OVERDRIVE (D) to the right into the DSC area. When the transmission is in DSC mode the sport symbol in the Driver Information Center (DIC) will come on. 2-34 While using the DSC feature the vehicle will have ﬁrmer shifting and increased performance. You can use this for sport driving or when climbing/descending hills to stay in gear longer or to down shift for more power or engine braking. The transmission will only allow you to shift into gears appropriate for the vehicle speed and engine Revolutions Per Minute (RPM). The transmission will not automatically shift to the next higher gear if the engine rpm is too high. If shifting is prevented for any reason, the currently selected gear will ﬂash multiple times, indicating that the transmission has not shifted gears. The transmission will allow you to shift to the gear selected and will automatically downshift when the vehicle comes to a stop. This will allow for more power during take-off and passing. When accelerating your vehicle from a stop in snowy and icy conditions, you may want to shift into second gear. A higher gear allows you to gain more traction on slippery surfaces. Parking Brake The parking brake pedal is located on the lower portion of the instrument panel to the left of the steering wheel. This vehicle has a push-to-release parking brake pedal. To set the parking brake, hold the regular brake pedal down with your right foot and push the parking brake pedal down with your left foot. If the ignition is on, the brake system warning light on the instrument panel cluster should come on. If it does not, you need to have your vehicle serviced. See Brake System Warning Light on page 3-64 for more information. 2-35 To release the parking brake, hold the brake pedal down with your right foot and push the parking brake pedal with your left foot. When you lift your left foot, the parking brake pedal will follow it to the released position. Notice: Driving with the parking brake on can overheat the brake system and cause premature wear or damage to brake system parts. Verify that the parking brake is fully released and the brake warning light is off before driving. A warning chime will sound if the parking brake is set, the ignition is on and the vehicle begins to move. To stop the chime, fully release the parking brake. If you are towing a trailer and parking on a hill, see Towing a Trailer (STS Only) on page 4-40 for more information. 2-36 Shifting Into Park (P) {CAUTION: It can be dangerous to get out of your vehicle if the shift lever is not fully in PARK (P) with the parking brake ﬁrmly set. Your vehicle can roll. If you have left the engine running, the vehicle can move suddenly. You or others could be injured. To be sure your vehicle will not move, even when you are on fairly level ground, use the steps that follow. If you are pulling a trailer, see Towing a Trailer (STS Only) on page 4-40. To shift into PARK (P), use the following steps: 1. Hold the brake pedal down with your right foot. 2. Move the shift lever into PARK (P) by pressing the button on the front of the shift lever while pushing the lever all the way toward the front of the vehicle. Release the button. 3. With your right foot still holding the brake pedal down, set the parking brake with your left foot. See Parking Brake on page 2-35 for more information. 4. Turn the ignition off. Torque Lock If you are parking on a hill and you do not shift your transmission into PARK (P) properly, the weight of the vehicle may put too much force on the parking pawl in the transmission. You may ﬁnd it difficult to pull the shift lever out of PARK (P). This is called “torque lock.” To prevent torque lock, set the parking brake and then shift into PARK (P) properly before you leave the driver’s seat. To ﬁnd out how, see “Shifting Into PARK (P)” listed previously. If torque lock does occur, you may need to have another vehicle push yours a little uphill to take some of the pressure from the parking pawl in the transmission, so you can pull the shift lever out of PARK (P). Leaving Your Vehicle With the Engine Running {CAUTION: It can be dangerous to leave your vehicle with the engine running. Your vehicle could move suddenly if the shift lever is not fully in PARK (P) with the parking brake ﬁrmly set. And, if you leave the vehicle with the engine running, it could overheat and even catch ﬁre. You or others could be injured. Do not leave your vehicle with the engine running. If you have to leave your vehicle with the engine running, be sure your vehicle is in PARK (P) and your parking brake is ﬁrmly set before you leave it. After you have moved the shift lever into PARK (P), hold the regular brake pedal down. Then, see if you can move the shift lever away from PARK (P) without ﬁrst pushing the button on the shift lever. If you can, it means that the shift lever was not fully locked into PARK (P). 2-37 Shifting Out of Park (P) Your vehicle has an automatic transmission shift lock control system. You have to fully apply your regular brake before you can shift from PARK (P) when the vehicle is running. See Automatic Transmission Operation (STS) on page 2-28 or Automatic Transmission Operation (STS-V) on page 2-32. If you cannot shift out of PARK (P), ease pressure on the shift lever – push the shift lever all the way into PARK (P) and release the shift lever button as you maintain brake application. Then press the shift lever button and move the shift lever into the gear you wish. If you ever hold the brake pedal down but still cannot shift out of PARK (P), try this: 1. Press the ACC button twice to place the ignition in accessory mode. 2. Apply and hold the brake until the end of Step 4. 3. Shift to NEUTRAL (N). 4. Start the engine and then shift to the drive gear you want. 5. Have your vehicle inspected by your dealer as soon as possible. 2-38 Parking Over Things That Burn {CAUTION: Things that can burn could touch hot exhaust parts under your vehicle and ignite. Do not park over papers, leaves, dry grass, or other things that can burn. Engine Exhaust {CAUTION: Engine exhaust can kill. It contains the gas carbon monoxide (CO), which you cannot see or smell. It can cause unconsciousness and death. You might have exhaust coming in if: (cid:127) Your exhaust system sounds strange or different. (cid:127) Your vehicle gets rusty underneath. (cid:127) Your vehicle was damaged in a collision. CAUTION: (Continued) (cid:127) Your vehicle was damaged when driving over high points on the road or over road debris. (cid:127) Repairs were not done correctly. (cid:127) Your vehicle or exhaust system had been modiﬁed improperly. If you ever suspect exhaust is coming into your vehicle: (cid:127) Drive it only with all the windows down to blow out any CO; and (cid:127) Have your vehicle ﬁxed immediately. CAUTION: (Continued) 2-39 Running the Engine While Parked It is better not to park with the engine running. But if you ever have to, here are some things to know. {CAUTION: {CAUTION: Idling the engine with the climate control system off could allow dangerous exhaust into your vehicle. See the earlier caution under Engine Exhaust on page 2-39. Also, idling in a closed-in place can let deadly carbon monoxide (CO) into your vehicle even if the climate control fan is at the highest setting. One place this can happen is a garage. Exhaust — with CO — can come in easily. NEVER park in a garage with the engine running. Another closed-in place can be a blizzard. See Winter Driving on page 4-27. It can be dangerous to get out of your vehicle if the shift lever is not fully in PARK (P) with the parking brake ﬁrmly set. Your vehicle can roll. Do not leave your vehicle when the engine is running unless you have to. If you have left the engine running, the vehicle can move suddenly. You or others could be injured. To be sure your vehicle will not move, even when you are on fairly level ground, always set your parking brake after you move the shift lever to PARK (P). Follow the proper steps to be sure your vehicle will not move. See Shifting Into Park (P) on page 2-36. If you are parking on a hill and if you are pulling a trailer, also see Towing a Trailer (STS Only) on page 4-40. 2-40 Mirrors Automatic Dimming Rearview Mirror with Intellibeam™ and OnStar® Your vehicle may have an Intellibeam™ inside rearview mirror with OnStar® controls. For more information about OnStar®, see OnStar® System on page 2-45. To turn on and enable Intellibeam™, press and release the Intellibeam™ button on the inside rear view mirror. If the vehicle has the IntelliBeam™ Intelligent High-Beam Headlamp Control System, the on/off button can also be used to turn off or reset this system. See “IntelliBeam™ Intelligent High-Beam Headlamp Control System” under Headlamps on page 3-31. Automatic Dimming Rearview Mirror Your vehicle may have an automatic dimming rearview mirror. O(On/Off): Press and hold the button, located on the lower left side of the mirror face, for about three seconds to turn the automatic dimming feature on or off. The indicator light will illuminate when this feature is active. The automatic dimming feature is active each time the vehicle is started. Automatic Dimming Rearview Mirror with OnStar® Your vehicle may have an automatic dimming rearview mirror that also contains OnStar® controls. For more information on OnStar®, see OnStar® System on page 2-45. Mirror Operation O(On/Off): Press and hold the button, located on the lower left side of the mirror face, for about three seconds to turn the automatic dimming feature on or off. The indicator light will illuminate when this feature is active. The automatic dimming feature is active each time the vehicle is started. Cleaning the Mirror When cleaning the mirror, use a paper towel or similar material dampened with glass cleaner. Do not spray glass cleaner directly on the mirror as that may cause the liquid cleaner to enter the mirror housing. 2-41 Automatic Dimming Rearview Mirror with OnStar® and Compass Your vehicle may have an automatic dimming rearview mirror with a compass display. The mirror also contains OnStar® controls. For more information see OnStar® System on page 2-45. The mirror includes an eight-point compass display in the upper right corner of the mirror face. When on, the compass automatically calibrates as the vehicle is driven. Mirror Operation O(On/Off): Press and hold the button, located on the lower left side of the mirror face, for about three seconds to turn the automatic dimming feature on or off. The indicator light will illuminate when this feature is active. The automatic dimming feature is active each time the vehicle is started. Compass Operation Press the on/off button once to turn the compass on or off. When the ignition and the compass feature are on, the compass will show two character boxes for about two seconds. After two seconds, the mirror will display the compass heading. 2-42 Compass Calibration If after two seconds, the display does not show a compass heading (for example, N for North), there may be a strong magnetic ﬁeld interfering with the compass. Such interference may be caused by a magnetic antenna mount, magnetic note pad holder or a similar magnetic item. If the letter C should ever appear in the compass window, the compass may need calibration. The mirror can be calibrated by driving the vehicle in circles at 5 mph (8 km/h) or less until the display reads a direction. The compass can be placed in calibration mode manually by pressing and holding the on/off button until a C is shown in the compass display. Compass Variance The zone is set to zone eight upon leaving the factory. It will be necessary to adjust the compass to compensate for compass variance if you live outside zone eight. Under certain circumstances, as during a long distance cross-country trip, it will be necessary to adjust for compass variance. Compass variance is the difference between earth’s magnetic north and true geographic north. If not adjusted to account for compass variance, your compass could give false readings. To adjust for compass variance do the following: 1. Find the current location and variance zone number on the following zone map. Cleaning the Mirror When cleaning the mirror, use a paper towel or similar material dampened with glass cleaner. Do not spray glass cleaner directly on the mirror as that may cause the liquid cleaner to enter the mirror housing. Outside Power Heated Mirrors The power mirror control is on the driver’s door armrest and controls the driver’s side and passenger’s side mirrors. 2. Press and hold the on/off button until a zone number appears in the display. 3. Once the zone number appears in the display, press the on/off button quickly until the correct zone number appears in the display. Stop pressing the button and the mirror will return to normal operation. If C appears in the compass window, the compass may need calibration. See Compass Calibration listed previously. Move the selector switch left or right to choose the driver’s side or passenger’s side mirror. Use the arrows located on the control pad to adjust the position of each mirror. Adjust each mirror so you can see the side of your vehicle and the area behind your vehicle. 2-43 Return the selector switch to the center position when ﬁnished adjusting. This will prevent unwanted mirror movement in case the control pad is accidentally bumped while driving. The preferred mirror positions can be stored with the memory option. See Memory Seat, Mirrors and Steering Wheel on page 2-70. The mirrors can be manually folded inward to prevent damage when going through car washes or conﬁned spaces. To fold, push the mirror toward the vehicle. To return the mirror to its original position, push outward. Be sure to return both mirrors to their original unfolded position before driving. When the rear window defogger is turned on, both outside rear view mirrors are heated to help clear them of ice, snow, or condensation. See “Rear Window Defogger” under Dual Climate Control System on page 3-48. Outside Automatic Dimming Mirror The driver’s side mirror will adjust for the glare of headlamps behind you. This feature is controlled by the on and off settings on the automatic dimming rearview mirror. Outside Convex Mirror {CAUTION: A convex mirror can make things (like other vehicles) look farther away than they really are. If you cut too sharply into the right lane, you could hit a vehicle on your right. Check your inside mirror or glance over your shoulder before changing lanes. The passenger’s side mirror is convex. A convex mirror’s surface is curved so more can be seen from the driver’s seat. This mirror does not have a dimming feature. Outside Parallel Park Assist Mirror This feature assists the driver by improving rear obstacle detection and is useful in viewing the curb when parallel parking. Press the left or right mirror symbol on the selector control to choose the driver or passenger outside mirror. When the vehicle is shifted into REVERSE (R), the selected mirror will tilt to a factory programmed position. 2-44 If further mirror adjustment is needed press the arrows located on the outside mirror control pad. If the outside mirror selector switch is in the middle position, neither outside mirror will move. When the vehicle is shifted out of REVERSE (R), and a ﬁve-second delay has occurred, the mirror will return to its original position. The delay prevents movement of the mirror if multiple gear transitions REVERSE (R) to AUTOMATIC OVERDRIVE (D) to REVERSE (R) occur during a parallel parking maneuver. OnStar® System OnStar® uses global positioning system (GPS) satellite technology, wireless communications, and live advisors to provide you with a wide range of safety, security, information, and convenience services. If your airbags deploy, the system is designed to make an automatic call to OnStar® Emergency where we can request emergency services be sent to your location. If you lock your keys in the car, call OnStar® at 1-888-4-ONSTAR and they can send a signal to unlock your doors. if you need roadside assistance, press the OnStar® button and they will get you the help you need. A complete OnStar® User’s Guide and the Terms and Conditions of the OnStar® Subscription Service Agreement are included in the vehicle’s glove box literature. For more information, visit www.onstar.com or www.onstar.ca. Contact OnStar® at 1-888-4-ONSTAR (1-888-466-7827), or press the OnStar® button to speak to an OnStar® advisor 24 hours a day, 7 days a week. Terms and conditions of the Subscription Service Agreement can be found at www.onstar.com or www.onstar.ca. OnStar® Services The Directions and Connections® Plan is included on new vehicles for the ﬁrst year from the date of purchase. You can extend this plan beyond the ﬁrst year to meet your needs. For more information, press the OnStar® button to speak with an advisor. 2-45 Directions and Connections Plan (cid:127) Advanced Automatic Collision Notiﬁcation (cid:127) Automatic Notiﬁcation of Airbag Deployment (cid:127) Emergency Services (cid:127) Roadside Assistance (cid:127) Stolen Vehicle Tracking (cid:127) AccidentAssist (cid:127) Remote Door Unlock/Vehicle Alert (cid:127) Remote Diagnostics (cid:127) Online Concierge (cid:127) Driving Directions (cid:127) RideAssist Information and Convenience Services OnStar® Personal Calling As an OnStar® subscriber, the Personal Calling capability allows you to make hands-free calls using a wireless system that is integrated into the vehicle. Calls can be placed nationwide using simple voice commands with no additional contracts and no additional roaming charges. To ﬁnd out more about OnStar® Personal Calling, refer to the OnStar® User’s Guide in the vehicle’s glove box, visit www.onstar.com or www.onstar.ca, or speak to an OnStar® advisor by pressing the OnStar® button or calling 1-888-4-ONSTAR (1-888-466-7827). 2-46 OnStar® Virtual Advisor Your vehicle may have Virtual Advisor. It is a feature of OnStar® Personal Calling that uses your minutes to access weather, local traffic reports and sports updates. By pressing the phone button and giving a few simple voice commands, you can browse through the various topics. Customize your information proﬁle at www.myonstar.com. See the OnStar® user’s guide for more information. OnStar® Steering Wheel Controls Your vehicle may be equipped with a Talk/Mute button that can be used to interact with OnStar®. See the Audio Steering Wheel Control section for your speciﬁc vehicle operation. When calling into voice mail systems or to dial directory numbers, press this button once, wait for the response, say the number(s) to be dialed, wait for the number(s) to be repeated and then say “dial.” See the OnStar® User’s Guide for more information. (cid:127) Universal Home Remote System The Universal Home Remote System, a combined universal transmitter and receiver, provides a way to replace up to three hand-held transmitters used to activate devices such as gate operators, garage door openers, entry door locks, security systems, and home lighting. The Universal Home Remote transmitter will be disabled, and will not work, if the valet lockout switch is on. See Valet Lockout Switch on page 2-23. If your vehicle is equipped with the Universal Home Remote Transmitter, it complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This device complies with RSS-210 of Industry Canada. Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device. Changes and modiﬁcations to this system by other than an authorized service facility could void authorization to use this equipment. 2-47 Universal Home Remote System Operation Do not use the Universal Home Remote with any garage door opener that does not have the “stop and reverse” feature. This includes any garage door opener model manufactured before April 1, 1982. If you have a newer garage door opener with rolling codes, please be sure to follow Steps 6 through 8 to complete the programming of your Universal Home Remote Transmitter. Read the instructions completely before attempting to program the Universal Home Remote. Because of the steps involved, it may be helpful to have another person available to assist you in the programming steps. Keep the original hand-held transmitter for use in other vehicles as well as for future Universal Home Remote programming. It is also recommended that upon the sale of the vehicle, the programmed Universal Home Remote buttons should be erased for security purposes. See “Erasing Universal Home Remote Buttons” later in this section or, for assistance, see Customer Assistance Offices on page 7-4. Be sure that people and objects are clear of the garage door or gate operator you are programming. When programming a garage door, it is advised to park outside of the garage. It is recommended that a new battery be installed in your hand-held transmitter for quicker and more accurate transmission of the radio-frequency signal. 2-48 Programming Universal Home Remote Follow these steps to program up to three channels: 1. Press and hold down the two outside Universal Home Remote buttons, releasing only when the Universal Home Remote indicator light begins to ﬂash, after 20 seconds. Do not hold down the buttons for longer than 30 seconds and do not repeat this step to program a second and/or third hand-held transmitter to the remaining two Universal Home Remote buttons. 2. Position the end of your hand-held transmitter about 1 to 3 inches (3 to 8 cm) away from the Universal Home Remote buttons while keeping the indicator light in view. 3. Simultaneously press and hold both the desired Universal Home Remote button and the hand-held transmitter button. Do not release the buttons until Step 4 has been completed. Some entry gates and garage door openers may require you to substitute Step 3 with the procedure noted in “Gate Operator and Canadian Programming” later in this section. 4. The indicator light will ﬂash slowly at ﬁrst and then rapidly after Universal Home Remote successfully receives the frequency signal from the hand-held transmitter. Release both buttons. 5. Press and hold the newly-trained Universal Home Remote button and observe the indicator light. If the indicator light stays on constantly, programming is complete and your device should activate when the Universal Home Remote button is pressed and released. To program the remaining two Universal Home Remote buttons, begin with Step 2 under “Programming Universal Home Remote.” Do not repeat Step 1 as this will erase all of the programmed channels. If the indicator light blinks rapidly for two seconds and then turns to a constant light, continue with Steps 6 through 8 following to complete the programming of a rolling-code equipped device, most commonly, a garage door opener. 6. Locate in the garage, the garage door opener receiver (motor-head unit). Locate the “Learn” or “Smart” button. This can usually be found where the hanging antenna wire is attached to the motor-head unit. 7. Firmly press and release the “Learn” or “Smart” button. The name and color of the button may vary by manufacturer. You will have 30 seconds to start Step 8. 8. Return to the vehicle. Firmly press and hold the programmed Universal Home Remote button for two seconds, then release. Repeat the press/hold/release sequence a second time, and depending on the brand of the garage door opener, or other rolling code device, repeat this sequence a third time to complete the programming. The Universal Home Remote should now activate your rolling-code equipped device. To program the remaining two Universal Home Remote buttons, begin with Step 2 of “Programming Universal Home Remote.” You do not want to repeat Step 1, as this will erase all previous programming from the Universal Home Remote buttons. 2-49 Gate Operator and Canadian Programming Canadian radio-frequency laws require transmitter signals to time out or quit after several seconds of transmission. This may not be long enough for Universal Home Remote to pick up the signal during programming. Similarly, some U.S. gate operators are manufactured to time out in the same manner. If you live in Canada, or you are having difficulty programming a gate operator or garage door opener by using the “Programming Universal Home Remote” procedures, regardless of where you live, replace Step 3 under “Programming Universal Home Remote” with the following: Continue to press and hold the Universal Home Remote button while you press and release every two seconds (cycle) the hand-held transmitter button until the frequency signal has been successfully accepted by the Universal Home Remote. The Universal Home Remote indicator light will ﬂash slowly at ﬁrst and then rapidly. Proceed with Step 4 under “Programming Universal Home Remote” to complete. Using Universal Home Remote Press and hold the appropriate Universal Home Remote button for at least half of a second. The indicator light will come on while the signal is being transmitted. Erasing Universal Home Remote Buttons To erase programming from the three Universal Home Remote buttons do the following: 1. Press and hold down the two outside buttons until the indicator light begins to ﬂash, after 20 seconds. Do not hold the two outside buttons for longer than 30 seconds. 2. Release both buttons. The Universal Home Remote is now in the train (learning) mode and can be programmed at any time beginning with Step 2 under “Programming Universal Home Remote” shown earlier in this section. Individual buttons cannot be erased, but they can be reprogrammed. See “Reprogramming a Single Universal Home Remote Button” following this section. 2-50 Reprogramming a Single Universal Home Remote Button To program a device to Universal Home Remote using a Universal Home Remote button previously trained, follow these steps: 1. Press and hold the desired Universal Home Remote button. Do not release the button. 2. The indicator light will begin to ﬂash after 20 seconds. While still holding the Universal Home Remote button, proceed with Step 2 under “Programming Universal Home Remote” shown earlier in this section. For additional information on Universal Home Remote, see Customer Assistance Offices on page 7-4. Storage Areas Glove Box To open the glove box, lift up on the lever. The glove box has a light inside. Cupholder(s) Your vehicle has two cupholders in the center console area. Center Console Storage Area Your vehicle has a center console storage area located between the front seats. It includes storage areas, and accessory power outlet(s) on the rear of the console. Convenience Net If your vehicle has a convenience net, the convenience net attaches to the ﬂoor or back wall of the rear of the vehicle using six anchor points. The net can be used like a hammock across the rear of the vehicle or hooked on the ﬂoor. Put small loads, like grocery bags, behind the net. It can help keep them from falling over during sharp turns or quick starts and stops. The net is not for larger, heavier loads. Store them in the rear of the vehicle as far forward as you can. 2-51 Sunroof The vehicle may have a power sunroof. The switches that operate the sunroof are located on the overhead console. To open or close the sunroof, the ignition must be ON or Retained Accessory Power (RAP) must be active. See Retained Accessory Power (RAP) on page 2-25. Express Open: The express open feature will operate from the closed or partially open position. To express open the power sunroof, fully press the driver’s side switch rearward once. To stop the sunroof glass in a desired position other than to the express-open position, press the switch again, in either direction, to stop the movement. If the sunshade is in the closed position, it will open with the sunroof, or it can be opened manually. 2-52 Vent Open: To open the power sunroof to the vent position from the closed position, press and hold the passenger’s side sunroof switch forward. The rear of the sunroof panel will tilt upward to the full vent position. The sunshade must be opened manually. Express Close: The express close feature will operate from the open or partially open position. To express close the power sunroof, fully press the driver’s side switch forward once. To stop the sunroof glass in a desired position other than closed, press the switch again in either direction. The sunshade must be closed manually. Close: To close the power sunroof, operate the controls according to one of the following: From the open position, press and hold the driver’s side sunroof switch forward. The sunshade must be closed manually. From the vent position, press and hold the passenger’s side sunroof switch rearward. Anti-Pinch: If an object is in the path of the sunroof while it is closing, the anti-pinch feature will detect the object and stop the sunroof from closing at the point of the obstruction. The sunroof will then return to the full-open or vent position. To close the sunroof once it has re-opened, refer to the two options previously described under the “Close” feature instructions. (cid:127) (cid:127) Vehicle Personalization Your vehicle has personalization that allows you to program certain features to a preferred setting for up to two drivers. The back of the keyless access transmitters are labelled 1 or 2. Additional keyless access transmitters programmed to the vehicle, as 3 and/or 4, do not have a number on the back and are not capable of being personalized. The number of programmable features varies depending upon which vehicle options are purchased. On all vehicles, features such as climate control settings, radio and XM™ preset settings, exterior lighting at unlock and remote lock unlock conﬁrmation, and language have already been programmed for your convenience. Your vehicle also has an automatic door locking feature that is always on. You cannot turn the automatic door locking feature off. See Programmable Automatic Door Locks on page 2-13. Some vehicles have additional features that can be programmed including the seat, steering column, and outside rearview mirror position. If your vehicle has the base audio system, the following information explains the vehicle personalization on your vehicle. If your vehicle has the Navigation system, see “Personalization” in the Index of the Navigation System manual for information on vehicle personalization. If your vehicle has the ability to program additional personalization features, the driver’s preferences are recalled by pressing any button on the keyless access transmitter, 1 or 2, by selecting Driver 1 or 2 on the radio display, or when a valid keyless access transmitter is detected upon opening the driver’s door. If more than one valid keyless access transmitter is detected upon opening the driver’s door, the driver preferences for the lowest driver number will be recalled. Certain features can be programmed not to recall until the ignition is turned off. To change feature preferences, use the following procedure. Entering the Personal Settings Menu To enter the feature programming mode, use the following procedure: 1. Be sure the ignition is either on, in ACC position, or in RAP and place the transmission in PARK (P) or the vehicle speed is less than 6 mph (9 km/h). 2. Press any button on the appropriate keyless access transmitter to identify yourself as Driver 1 or Driver 2. 2-53 3. Turn on the radio by pressing the power/volume knob. 4. Press the CNFG radio button or the tune/select knob located on the right side of the radio to enter the radio’s main menu. 5. Turn the tune/select knob and scroll to SETUP. 6. Press the tune/select knob to enter the SETUP menu. 7. Turn the tune/select knob and scroll to PERSONAL SETTINGS MENU, then press the tune/select knob to turn the feature on. A check mark appears after this selection when it is turned on and the entire list of personalization features will appear. 8. Turn the tune/select knob and scroll to the feature you want to change, then press the tune/select knob to turn the feature on or off. If the feature is turned on, a check mark will appear next to the feature name. Some features have submenus that show additional features that can be turned on or off. After entering a submenu, turn the tune/select knob and scroll to the feature you want to change, then press the tune/ select knob to turn the feature on or off. Personal Settings Menu Items The PERSONAL SETTINGS MENU must be selected with a check mark to program the personalization features. If it is not selected, press the tune/select knob until the check mark appears. If it is selected, the entire list of features will be available to program. DRIVER GREETING This feature allows you to type in a customized name or greeting that will appear on the display whenever the corresponding keyless access transmitter, 1 or 2, is used or Driver 1 or Driver 2 is selected on the radio display. If a customized name or greeting is not programmed, the system will show Driver 1 or Driver 2 to correspond with the numbers on the back of the keyless access transmitters. In this case, the customized driver greeting feature is factory shipped as off. To turn the driver greeting feature on and to program a customized name or greeting, use the following procedure: 1. Enter the PERSONAL SETTINGS MENU by following the instructions listed previously under “Entering the Personal Settings Menu.” 2. Turn the tune/select knob until DRIVER GREETING is highlighted. 2-54 3. Press the tune/select knob to turn on the DRIVER GREETING feature. You will see a cursor on the screen. 4. Turn the tune/select knob until you reach the ﬁrst letter you want; the letter will be highlighted. There is a complete alphabet with both upper and lower case letters and the numbers zero through nine. Also included are spaces and other non-letter characters such as the ampersand (&). 5. Press the tune/select knob once to select the letter. The letter will then appear on the display and the cursor will advance to the next letter. If you make a mistake, press the F5 button, located on the radio, repeatedly to cycle back through all of the characters until you reach the character you wish to change. Then turn the tune/select knob until the letter you want is highlighted and press the tune/select knob to select the new letter. 6. Repeat Steps 4 and 5 until the name or greeting you want is complete. You can program up to 16 characters. The name or greeting you programmed is now set. You can either exit the programming mode by following the instructions later in this section or program the next feature available on your vehicle by pressing the F6 (BACK) button, located on the radio, to return to the PERSONAL SETTINGS MENU. You will now see a check mark next to the driver greeting menu item, which means that the driver greeting feature is on and a customized driver greeting is being used. To turn off the customized driver greeting, and go back to displaying either Driver 1 or Driver 2, use the following procedure: 1. Enter the PERSONAL SETTINGS MENU by following the instructions listed previously under “Entering the Personal Settings Menu.” 2. Turn the tune/select knob until DRIVER GREETING is highlighted. 3. Press the tune/select knob to turn on the DRIVER GREETING feature. The check mark will be cleared and the customized driver greeting is off. The only way to correct a customized driver greeting once you have exited the screen to spell the name, is to turn the driver greeting feature off, and then turn it back on. 2-55 KEY FOB REMINDER This feature chirps the horn three times when the driver’s door is closed and there is a keyless access transmitter left inside of the vehicle. This will only occur when the vehicle is off. Programmable Modes Mode 1: ON Mode 2: OFF Before your vehicle was shipped from the factory, it was programmed to Mode 1. The mode to which the vehicle was programmed may have been changed since it left the factory. To program the vehicle to a different mode, use the following procedure: 1. Enter the PERSONAL SETTINGS MENU by following the instructions listed previously under “Entering the Personal Settings Menu.” 2. Turn the tune/select knob until KEY FOB REMINDER is highlighted. 3. Press the tune/select knob to switch back and forth between on and off. When the mode is turned on, a check mark will appear next to the feature name. The mode you selected is now set. You can either exit the programming mode by following the instructions later in this section or program the next feature available on your vehicle. 2-56 REMOTE START If your vehicle has this feature, it allows you to choose the features you would like to have activated when you engage the remote start on your vehicle. These features include the climate control system, the rear defogger, and the seat temperature, if your vehicle has this feature. Activating these features helps provide a more comfortable vehicle upon entry. See “Remote Vehicle Start” under Keyless Access System Operation on page 2-5 for more information. Mode 1: ON Mode 2: OFF Before your vehicle was shipped from the factory, it was programmed to Mode 1. The mode to which the vehicle was programmed may have been changed since it left the factory. To program the vehicle to a different mode, use the following procedure: 1. Enter the PERSONAL SETTINGS MENU by following the instructions listed previously under “Entering the Personal Settings Menu.” 2. Turn the tune/select knob until REMOTE START is highlighted. 3. Press the tune/select knob to switch back and forth between on and off. When REMOTE START is on, a check mark will appear next to the feature name. You can then choose to activate any or all of the following features by turning the tune/select knob to highlight the feature, then pressing the knob to turn it on. CLIMATE CONTROL: The climate control system will engage when the vehicle is started using the remote start feature. It will be at the same climate control setting that was last used by the driver using that keyless entry transmitter. REAR WINDOW DEFOG: If this feature is active, the rear defogger will engage when the vehicle is started using the remote start feature. SEAT TEMP (Temperature) CONTROL: If your vehicle has this feature and this feature is active, the seats will be heated or cooled when the vehicle is started using the remote start feature. The mode you selected is now set. You can either exit the programming mode by following the instructions later in this section or program the next feature available on your vehicle by pressing the F6 (BACK) button, located on the radio, to return to the PERSONAL SETTINGS MENU. REMOTE RECALL MEMORY If your vehicle has the optional memory package, you will have this feature. When this feature is turned on, you can recall any previously programmed seat position and mirror position when the unlock button on the keyless access transmitter is pressed. Programmable Modes Mode 1: ON Mode 2: OFF Before your vehicle was shipped from the factory, it was programmed to Mode 2 with the exception of recall seat to driver position which is on. The mode to which the vehicle was programmed may have been changed since it left the factory. To program the vehicle to a different mode, use the following procedure: 1. Enter the PERSONAL SETTINGS MENU by following the instructions listed previously under “Entering the Personal Settings Menu.” 2. Turn the tune/select knob until REMOTE RECALL MEMORY is highlighted. 3. Press the tune/select knob to switch back and forth between on and off. When the mode is turned on, a check mark will appear next to the feature name. 2-57 If this feature is selected, START BUTTON RECALL cannot be selected. The mode you selected is now set. You can either exit the programming mode by following the instructions later in this section or program the next feature available on your vehicle. START BUTTON RECALL If your vehicle has the optional memory package, you will have this feature. When this feature is turned on, you can recall any previously programmed seat, mirror, and steering column position when the start button on the ignition is pressed. Programmable Modes Mode 1: ON Mode 2: OFF Before your vehicle was shipped from the factory, it was programmed to Mode 2. The mode to which the vehicle was programmed may have been changed since it left the factory. To program the vehicle to a different mode, use the following procedure: 1. Enter the PERSONAL SETTINGS MENU by following the instructions listed previously under “Entering the Personal Settings Menu.” 2. Turn the tune/select knob until START BUTTON RECALL is highlighted. 2-58 3. Press the tune/select knob to switch back and forth between on and off. When the mode is turned on, a check mark will appear next to the feature name. If this feature is selected, REMOTE RECALL MEMORY cannot be selected. The mode you selected is now set. You can either exit the programming mode by following the instructions later in this section or program the next feature available on your vehicle. AUTO EXIT SEAT If your vehicle has the optional memory package, you will have this feature. When this feature is turned on, you can recall any previously programmed exit position for the driver’s seat when the vehicle is off, the shift lever is in PARK (P), and the driver’s door is opened. Programmable Modes Mode 1: ON Mode 2: OFF Before your vehicle was shipped from the factory, it was programmed to Mode 2. The mode to which the vehicle was programmed may have been changed since it left the factory. To program the vehicle to a different mode, use the following procedure: 1. Enter the PERSONAL SETTINGS MENU by following the instructions listed previously under “Entering the Personal Settings Menu.” 2. Turn the tune/select knob until AUTO EXIT SEAT is highlighted. 3. Press the tune/select knob to switch back and forth between on and off. When the mode is turned on, a check mark will appear in the box next to the feature name. The mode you selected is now set. You can either exit the programming mode by following the instructions later in this section or program the next feature available on your vehicle. AUTO EXIT COLUMN If your vehicle has the optional memory package, you will have this feature. When this feature is turned on, you can recall any previously programmed exit position for the steering column when the vehicle is off, the shift lever is in PARK (P), and the driver’s door is opened. Programmable Modes Mode 1: ON Mode 2: OFF Before your vehicle was shipped from the factory, it was programmed to Mode 2. The mode to which the vehicle was programmed may have been changed since it left the factory. To program the vehicle to a different mode, use the following procedure: 1. Enter the PERSONAL SETTINGS MENU by following the instructions listed previously under “Entering the Personal Settings Menu.” 2. Turn the tune/select knob until AUTO EXIT COLUMN is highlighted. 3. Press the tune/select knob to switch back and forth between on and off. When the mode is turned on, a check mark will appear in the box next to the feature name. The mode you selected is now set. You can either exit the programming mode by following the instructions later in this section or program the next feature available on your vehicle. 2-59 LIGHTS FLASH AT UNLOCK This feature allows the exterior lamps to ﬂash when the keyless access transmitter is used to unlock the vehicle. All doors must be closed for this feature to work, and the lamps will not ﬂash if the parking lamps or headlamps are on. If LIGHTS FLASH AT UNLOCK is turned on and either KEYLESS FT DOOR UNLOCK or KEYLESS DOORS UNLOCK is turned on, the exterior lamps will ﬂash when the doors are passively unlocked. See “KEYLESS FT (Front) DOOR UNLOCK” and “KEYLESS DOORS UNLOCK” later in this section for more information. Programmable Modes Mode 1: ON Mode 2: OFF Before your vehicle was shipped from the factory, it was programmed to Mode 1. The mode to which the vehicle was programmed may have been changed since it left the factory. To program the vehicle to a different mode, use the following procedure: 1. Enter the PERSONAL SETTINGS MENU by following the instructions listed previously under “Entering the Personal Settings Menu.” 2. Turn the tune/select knob until LIGHTS FLASH AT UNLOCK is highlighted. 2-60 3. Press the tune/select knob to switch back and forth between on and off. When the mode is turned on, a check mark will appear next to the feature name. The mode you selected is now set. You can either exit the programming mode by following the instructions later in this section or program the next feature available on your vehicle. LIGHTS FLASH AT LOCK This feature allows the exterior lamps to ﬂash once when the keyless access transmitter is used to lock the vehicle. All doors must be closed for this feature to work, and the lamps will not ﬂash if the parking lamps or headlamps are on. If LIGHTS FLASH AT LOCK is turned on and either KEYLESS FT DOOR UNLOCK or KEYLESS DOORS UNLOCK is turned on, the exterior lamps will ﬂash when the doors are passively unlocked. See “KEYLESS FT (Front) DOOR UNLOCK” and “KEYLESS DOORS UNLOCK” later in this section for more information. Programmable Modes Mode 1: ON Mode 2: OFF Before your vehicle was shipped from the factory, it was programmed to Mode 1. The mode to which the vehicle was programmed may have been changed since it left the factory. To program the vehicle to a different mode, use the following procedure: 1. Enter the PERSONAL SETTINGS MENU by following the instructions listed previously under “Entering the Personal Settings Menu.” 2. Turn the tune/select knob until LIGHTS FLASH AT LOCK is highlighted. 3. Press the tune/select knob to switch back and forth between on and off. When the mode is turned on, a check mark will appear next to the feature name. You can select this feature by itself, or you can combine it with Horn Chirps At Lock so that both the exterior lamps ﬂash and the horn chirps when you lock your vehicle. The mode you selected is now set. You can either exit the programming mode by following the instructions later in this section or program the next feature available on your vehicle. EXT. (Exterior) LIGHTS AT UNLOCK This feature turns on the exterior lamps when the keyless access transmitter is used to unlock the vehicle. The lamps will remain on for about 20 seconds unless a door is opened, the ignition is in ACC, on, or START, or the keyless access transmitter is used to lock the vehicle. Programmable Modes Mode 1: ON Mode 2: OFF Before your vehicle was shipped from the factory, it was programmed to Mode 1. The mode to which the vehicle was programmed may have been changed since it left the factory. To program the vehicle to a different mode, use the following procedure: 1. Enter the PERSONAL SETTINGS MENU by following the instructions listed previously under “Entering the Personal Settings Menu.” 2. Turn the tune/select knob until EXT. LIGHTS AT UNLOCK is highlighted. 3. Press the tune/select knob to switch back and forth between on and off. When the mode is turned on, a check mark will appear next to the feature name. The mode you selected is now set. You can either exit the programming mode by following the instructions later in this section or program the next feature available on your vehicle. 2-61 HORN CHIRPS AT LOCK This feature sounds the horn once when the keyless access transmitter is used to lock the vehicle. All doors must be closed for this feature to work. Programmable Modes Mode 1: ON Mode 2: OFF Before your vehicle was shipped from the factory, it was programmed to Mode 2. The mode to which the vehicle was programmed may have been changed since it left the factory. To program the vehicle to a different mode, use the following procedure: 1. Enter the PERSONAL SETTINGS MENU by following the instructions listed previously under “Entering the Personal Settings Menu.” 2. Turn the tune/select knob until HORN CHIRPS AT LOCK is highlighted. 3. Press the tune/select knob to switch back and forth between on and off. When the mode is turned on, a check mark will appear next to the feature name. The mode you selected is now set. You can either exit the programming mode by following the instructions later in this section or program the next feature available on your vehicle. 2-62 TWILIGHT DELAY This feature allows you to set the amount of time you want the exterior lamps to remain on after you exit the vehicle. Programmable Modes Mode 1: 0:00 seconds (off) Mode 2: 0:05 seconds Mode 3: 0:15 seconds Mode 4: 0:30 seconds Mode 5: 1:30 minutes Mode 6: 2:00 minutes Mode 7: 3:00 minutes Mode 8: 4:00 minutes Before your vehicle was shipped from the factory, it was programmed to Mode 2. The mode to which the vehicle was programmed may have been changed since the vehicle left the factory. To determine the mode to which the vehicle is programmed or to program the vehicle to a different mode, use the following procedure: 1. Enter the PERSONAL SETTINGS MENU by following the instructions listed previously under “Entering the Personal Settings Menu.” 2. Turn the tune/select knob until TWILIGHT DELAY is highlighted. 3. Press the tune/select knob to scroll through the available delay settings and set your selection. If you choose Mode 1, the exterior lamps will not illuminate when you exit the vehicle. Only one mode can be selected at a time. The mode you selected is now set. You can either exit the programming mode by following the instructions later in this section or program the next feature available on your vehicle. DRIVER UNLOCK AT OFF This feature allows the driver’s door to automatically unlock when the ignition is turned off. Programmable Modes Mode 1: ON Mode 2: OFF Before your vehicle was shipped from the factory, it was programmed to Mode 2. The mode to which the vehicle was programmed may have been changed since it left the factory. To program the vehicle to a different mode, use the following procedure: 1. Enter the PERSONAL SETTINGS MENU by following the instructions listed previously under “Entering the Personal Settings Menu.” 2. Turn the tune/select knob until DRIVER UNLOCK AT OFF is highlighted. 3. Press the tune/select knob to switch between on and off. When the mode is turned on, a check mark will appear next to the feature name. The mode you selected is now set. You can either exit the programming mode by following the instructions later in this section or program the next feature available on your vehicle. 2-63 DOORS UNLOCK AT OFF This feature allows all of the doors to automatically unlock when the ignition is turned off. Programmable Modes DRIVER UNLOCK IN PARK The feature allows the driver’s door to automatically unlock when the transmission is shifted into PARK (P). Programmable Modes Mode 1: ON Mode 1: ON Mode 2: OFF Before your vehicle was shipped from the factory, it was programmed to Mode 2. The mode to which the vehicle was programmed may have been changed since it left the factory. To program the vehicle to a different mode, use the following procedure: 1. Enter the PERSONAL SETTINGS MENU by following the instructions listed previously under “Entering the Personal Settings Menu.” 2. Turn the tune/select knob until DOORS UNLOCK AT OFF is highlighted. 3. Press the tune/select knob to switch between on and off. When the mode is turned on, a check mark will appear next to the feature name. Mode 2: OFF Before your vehicle was shipped from the factory, it was programmed to Mode 2. The mode to which the vehicle was programmed may have been changed since it left the factory. To program the vehicle to a different mode, use the following procedure: 1. Enter the PERSONAL SETTINGS MENU by following the instructions listed previously under “Entering the Personal Settings Menu.” 2. Turn the tune/select knob until DRIVER UNLOCK IN PARK is highlighted. 3. Press the tune/select knob to switch back and forth between on and off. When the mode is turned on, a check mark will appear next to the feature name. The mode you selected is now set. You can either exit the programming mode by following the instructions later in this section or program the next feature available on your vehicle. The mode you selected is now set. You can either exit the programming mode by following the instructions later in this section or program the next feature available on your vehicle. 2-64 DOORS UNLOCK IN PARK The feature allows all of the doors to automatically unlock when the transmission is shifted into PARK (P). Programmable Modes Mode 1: ON Mode 2: OFF Before your vehicle was shipped from the factory, it was programmed to Mode 1. The mode to which the vehicle was programmed may have been changed since it left the factory. To program the vehicle to a different mode, use the following procedure: 1. Enter the PERSONAL SETTINGS MENU by following the instructions listed previously under “Entering the Personal Settings Menu.” 2. Turn the tune/select knob until DOORS UNLOCK IN PARK is highlighted. 3. Press the tune/select knob to switch back and forth between on and off. When the mode is turned on, a check mark will appear next to the feature name. The mode you selected is now set. You can either exit the programming mode by following the instructions later in this section or program the next feature available on your vehicle. KEYLESS FT (Front) DOOR UNLOCK This feature automatically unlocks the appropriate front door when you approach the vehicle with your keyless access transmitter and pull the respective door handle. See Door Locks on page 2-12 for more information. Programmable Modes Mode 1: ON Mode 2: OFF Before your vehicle was shipped from the factory, it was programmed to Mode 2. The mode to which the vehicle was programmed may have been changed since it left the factory. To program the vehicle to a different mode, use the following procedure: 1. Enter the PERSONAL SETTINGS MENU by following the instructions listed previously under “Entering the Personal Settings Menu.” 2. Turn the tune/select knob until KEYLESS FT DOOR UNLOCK is highlighted. 3. Press the tune/select knob to switch back and forth between on and off. When the mode is turned on, a check mark will appear next to the feature name. The mode you selected is now set. You can either exit the programming mode by following the instructions later in this section or program the next feature available on your vehicle. 2-65 KEYLESS DOORS UNLOCK This feature automatically unlocks all of the doors when you approach the vehicle with your keyless access transmitter and pull either front door handle. See Door Locks on page 2-12 for more information. Programmable Modes Mode 1: ON Mode 2: OFF Before your vehicle was shipped from the factory, it was programmed to Mode 1. The mode to which the vehicle was programmed may have been changed since it left the factory. To program the vehicle to a different mode, use the following procedure: 1. Enter the PERSONAL SETTINGS MENU by following the instructions listed previously under “Entering the Personal Settings Menu.” 2. Turn the tune/select knob until KEYLESS DOORS UNLOCK is highlighted. 3. Press the tune/select knob to switch back and forth between on and off. When the mode is turned on, a check mark will appear next to the feature name. The mode you selected is now set. You can either exit the programming mode by following the instructions later in this section or program the next feature available on your vehicle. 2-66 LOCK DELAY This feature delays the locking of the vehicle’s doors for eight seconds after a power door lock switch or the lock button on the keyless access transmitter is pressed. The eight second delay occurs after the last door is closed. If the keyless access transmitter is left inside of the vehicle, the doors will not lock. Programmable Modes Mode 1: ON Mode 2: OFF Before your vehicle was shipped from the factory, it was programmed to Mode 1. The mode to which the vehicle was programmed may have been changed since it left the factory. To program the vehicle to a different mode, use the following procedure: 1. Enter the PERSONAL SETTINGS MENU by following the instructions listed previously under “Entering the Personal Settings Menu.” 2. Turn the tune/select knob until LOCK DELAY is highlighted. 3. Press the tune/select knob to switch back and forth between on and off. When the mode is turned on, a check mark will appear next to the feature name. The mode you selected is now set. You can either exit the programming mode by following the instructions later in this section or program the next feature available on your vehicle. KEYLESS LOCK DELAY This feature allows you to select whether the doors automatically lock when the ignition is turned off, the keyless access transmitter has been removed from the interior of the vehicle, and the doors have been closed for 10 seconds. If a keyless access transmitter is left inside of the vehicle, the doors will not lock. Programmable Modes Mode 1: ON Mode 2: OFF Before your vehicle was shipped from the factory, it was programmed to Mode 2. The mode to which the vehicle was programmed may have been changed since it left the factory. To program the vehicle to a different mode, use the following procedure: 1. Enter the PERSONAL SETTINGS MENU by following the instructions listed previously under “Entering the Personal Settings Menu.” 2. Turn the tune/select knob until KEYLESS LOCK DELAY is highlighted. 3. Press the tune/select knob to switch back and forth between on and off. When the mode is turned on, a check mark will appear next to the feature name. The mode you selected is now set. You can either exit the programming mode by following the instructions later in this section or program the next feature available on your vehicle. FRONT PASS (Passenger) WINDOW LOCK This feature allows you to choose whether or not to have the front passenger window deactivated as part of the window lockout button. If you would like the front passenger window to be deactivated when the window lockout button is pushed, turn this feature on. If this feature is left off, the window lockout button located on the door will deactivate only the rear windows. See Power Windows on page 2-18 for more information. 2-67 Programmable Modes Mode 1: ON Mode 2: OFF Before your vehicle was shipped from the factory, it was programmed to Mode 2. The mode to which the vehicle was programmed may have been changed since it left the factory. To program the vehicle to a different mode, use the following procedure: 1. Enter the PERSONAL SETTINGS MENU by following the instructions listed previously under “Entering the Personal Settings Menu.” 2. Turn the tune/select knob until FRONT PASS WINDOW LOCK is highlighted. 3. Press the tune/select knob to switch back and forth between on and off. When the mode is turned on, a check mark will appear next to the feature name. The mode you selected is now set. You can either exit the programming mode by following the instructions later in this section or program the next feature available on your vehicle. CHIME VOLUME HIGH This feature allows you to adjust the volume level of the vehicle’s warning chimes. The chime volume cannot be turned off, only adjusted. Programmable Modes Mode 1: NORMAL Mode 2: HIGH Before your vehicle was shipped from the factory, it was programmed to Mode 1. The mode to which the vehicle was programmed may have been changed since it left the factory. To program the vehicle to a different mode, use the following procedure: 1. Enter the PERSONAL SETTINGS MENU by following the instructions listed previously under “Entering the Personal Settings Menu.” 2. Turn the tune/select knob until CHIME VOLUME HIGH is highlighted. 3. Press the tune/select knob to switch back and forth between the normal and high settings. A check mark indicates that the chime volume is set to HIGH. The mode you selected is now set. You can either exit the programming mode by following the instructions later in this section or program the next feature available on your vehicle. 2-68 SUSPENSION MODE If your vehicle has this feature, you can select between performance or touring modes. Performance mode is used where road conditions or personal preference demand more control. This setting provides more “feel” or response to road conditions. Touring mode is used for normal city and highway driving. This setting provides a smooth, soft ride. Programmable Modes Mode 1: PERFORMANCE Mode 2: TOURING Before your vehicle was shipped from the factory, it was programmed to Mode 2. The mode to which the vehicle was programmed may have been changed since it left the factory. To program the vehicle to a different mode, use the following procedure: 1. Enter the PERSONAL SETTINGS MENU by following the instructions listed previously under “Entering the Personal Settings Menu.” 2. Turn the tune/select knob until SUSPENSION MODE is highlighted. 3. Press the tune/select knob to enter the SUSPENSION MODE submenu. 4. Turn the tune/select knob to highlight TOURING or PERFORMANCE. 5. Press the tune/select knob to select the setting. The mode you selected is now set. You can either exit the programming mode by following the instructions later in this section or program the next feature available on your vehicle by pressing the F6 (BACK) button, located on the radio, to return to the PERSONAL SETTINGS MENU. Exiting the Personal Settings Menu Once you have ﬁnished making your selections on the base audio system, you will automatically return to the main audio screen after 15 seconds. You can also press the F6 (BACK) button, located on the radio, to return to the main audio screen. 2-69 Memory Seat, Mirrors and Steering Wheel If your vehicle has the memory feature, you can program and recall memory settings for the following features for up to two drivers: The driver’s seat position The outside rearview mirrors position The telescopic steering column position The following settings and presets are set automatically: The language, radio and XM™ presets, tone, volume, playback mode (AM/FM or CD), last displayed stations, and compact disc position The last climate control setting The Head-Up Display (HUD) position, if your vehicle has this feature (cid:127) Other personalization settings, for example, remote start settings See Vehicle Personalization on page 2-53. For vehicles with the base audio system, memory features are programmed and recalled through the radio from the DRIVER SELECTION and the DRIVER EXIT SETTINGS submenus. See “Entering the Driver Selection Submenu” and “Entering the Driver Exit Settings Submenu” later in this section for more information on recalling and programming the memory settings using the base audio system. For vehicles with the Navigation system, memory features are programmed and recalled through the navigation display. See “Personalization” in the Index of the Navigation System manual for more information on programming and recalling the memory settings using the Navigation system. For vehicles with the Navigation system, you can also recall the memory features by using voice recognition, if your vehicle has this feature. See “Voice Recognition” in the Index of the Navigation System manual for more information. 2-70 (cid:127) (cid:127) (cid:127) (cid:127) (cid:127) (cid:127) Entering the Driver Selection Submenu To enter the memory programming mode for your driver settings, use the following procedure: 1. Be sure the ignition is either on, in ACC position, or in RAP and place the transmission in PARK (P) or the vehicle speed is less than 6 mph (9 km/h). 2. Press any button on the appropriate keyless access transmitter to identify yourself as Driver 1 or Driver 2. 3. Turn on the radio by pressing the power/volume knob. 4. Press the CNFG radio button to enter the main menu of the radio. 5. Turn the tune/select knob and scroll to SETUP. 6. Press the tune/select knob to enter the SETUP menu. 7. Turn the tune/select knob and scroll to DRIVER SELECTION. 8. Press the tune/select knob to enter the DRIVER SELECTION submenu. The following items will appear: (cid:127) DRIVER 1 (cid:127) DRIVER 2 (cid:127) RECALL DRIVER SETTINGS (cid:127) STORE DRIVER SETTINGS Driver Selection Submenu Items DRIVER 1/DRIVER 2 The numbers on the back of each keyless access transmitter correspond to DRIVER 1 and DRIVER 2. If you would like to recall or store driver settings for the driver that does not correspond to the number on the back of the keyless access transmitter that you are using, use the following procedure: 1. Enter the memory programming mode for your driver settings by following the instructions listed previously under “Entering the Driver Selection Submenu.” 2. From the DRIVER SELECTION submenu, turn the tune/select knob to highlight the driver number that you want, either DRIVER 1 or DRIVER 2. 3. Set your choice by pressing in the tune/select knob. If you would like to recall driver settings for the selected driver, see “RECALL DRIVER SETTINGS” later in this section. If you would like to store driver settings for the selected driver, see “STORE DRIVER SETTINGS” later in this section. If you would like to recall exit settings for the selected driver, see “RECALL EXIT SETTINGS” later in this section. If you would like to store exit settings for the selected driver, see “STORE EXIT SETTINGS” later in this section. 2-71 RECALL DRIVER SETTINGS To recall driver settings, use the following procedure: 1. Enter the memory programming mode for your driver settings by following the instructions listed previously under “Entering the Driver Selection Submenu.” 2. From the DRIVER SELECTION submenu, turn the tune/select knob to scroll to RECALL DRIVER SETTINGS and press in the knob. If the vehicle is in PARK (P), one beep will sound and your previously saved driving position will then be recalled. If the vehicle is not in PARK (P), three beeps will sound and your previously saved driving position will not be recalled. A memory recall can be stopped by pressing any memory seat or mirror position button. If you would like the stored driving positions to be recalled when unlocking your vehicle with the keyless access transmitter or when starting your vehicle, see “REMOTE RECALL MEMORY” or “START BUTTON RECALL” under Vehicle Personalization on page 2-53. STORE DRIVER SETTINGS To store driver settings, use the following procedure: 1. Adjust your settings for the driver’s seat, the outside rearview mirrors, and the steering column to a comfortable driving position. 2. Enter the memory programming mode for your driver settings by following the instructions listed previously under “Entering the Driver Selection Submenu.” 3. From the DRIVER SELECTION submenu, turn the tune/select knob to scroll to STORE DRIVER SETTINGS and press in the knob. Two beeps will sound to conﬁrm that your driver settings are saved. 4. Set the HUD position, if your vehicle has this feature, the climate control temperature, fan speed and mode settings, the radio presets, tone, volume, playback mode (AM/FM, XM™, or CD), and compact disc position. Your memory settings are now programmed. Any changes that are made to the HUD, audio system, and climate controls while driving will be automatically stored when the ignition is turned off. 5. Repeat the procedure for a second driver by programming the other driver number. 2-72
