equipped with a Radio Data System (RDS). RDS features are available for use only on FM stations that broadcast RDS information.


Seek to stations broadcasting the selected type of programming, receive announcements concerning local and national emergencies, display messages from radio stations, and seek to stations with traffic announcements.


This system relies upon receiving specific information from these stations and will only work when the information is avaiiabie. in rare cases, a radio station may broadcast incorrect information that will cause the radio features to work improperly. If this happens, contact the radio station. While you are tuned to an RDS station, the station name or the call letters will appear on the display instead of the frequency. RDS stations may also provide the time of day, a program type (PTY) for current programming and the name of the program being broadcast. XMTM Radio Satellite Service (USA Only): XMTM is a continental US. based satellite radio service that offers 100 coast to coast channels including music, news, sports, talk and children’s programming. XMTM provides digital quality audio and text information, including song title and artist name. A service fee is required in order to receive the XMTM service. For more information, contact XMTM at www.xmradio.com or call 1 -800-852-XMXM (9696). Playing the Radio PWR (Power): Press this knob to turn the system on and off. VOL (Volume): Turn this knob to decrease volume.


increase or to


AVC (Autematic \Jo!ume Cantro!): With AVC, you: audio system monitors the noise in the vehicle. Then, AVC adjusts the volume level so that it always sounds the same to you. To use AVC, press and hold the TONE button until AUTO VOLUME CONTROL OFF appears on the display. Then press the LEVEL plus symbol. AUTO VOLUME CONTROL ON will appear on the display. AVC VOLUME will appear on the display any time you adjust the volume while AVC is on. To turn AVC off, press and hold the TONE button until AUTO VOLUME CONTROL ON appears on the display. Then press the LEVEL minus symbol. AUTO VOLUME CONTROL OFF will appear on the display. HR (Hour) or MN (Minute): Display ignition off by pressing one of these buttons.


the time with the


SOURCE: Press this button to select a source, either cassette or compact disc. The audio source must be loaded to play. Available loaded sources are shown on the display. If a source is being used, it will be underlined on the display. If none of the audio sources are loaded, NO SOURCE LOADED will appear on the display. Press this button again or press BAND to switch back to the radio.


3-8 1


Setting Preset Stations The six numbered pushbuttons let you return to your favorite stations and associated tone and DSP settings. The RDS PTY mode must be off to use this mode. You can set up to 36 stations (six weather, six FM1, six FM2, six AM, six XMl and six XM2 if your radio is equipped with the XM Satellite Radio Service), by performing the following steps: 1. Turn the radio on. 2. Press BAND to select weather, FM1, FM2, AM, or


XM1 , XM2.


3. Tune in the desired station. 4. Press and hold one of the six numbered


pushbuttons for more than two seconds. Whenever you press that numbered pushbutton for less than two seconds, the station you set will return.


5. Repeat the steps for each pushbutton. When battery power is removed and later applied, you will not have to reset your radio presets because the radio remembers them.


Finding a Station BAND: Press this button to select weather, FMI, FM2, AM, or XMI, XM2 if your radio is equipped with XMTM Satellite Radio Service. - A TUNE SEEK Y : This button can be pressed to two positions. Press this button to the first position to manually tune to the next or to the previous stations. If this button is held at the first position for a few seconds, the radio will continue tuning until this button is released. Press this button to the second position and release it to seek to the next or to the previous radio station. The radio will seek only to stations that are in the selected band and only to those with a strong signal. SCAN: Press this button for less than two seconds to scan radio stations. The radio will go to a station, play for five seconds, then go on to the next station. Press this button again to stop scanning. To scan preset stations, press and hold SCAN for more than two seconds until you hear a beep. The radio will go to the first preset station stored on your pushbuttons, play for five seconds, then go on to the next preset station. Press SCAN again to stop scanning presets. The radio will scan only to the stations that are in the selected band and only to those with a strong signal. 3-82


Setting the Tone (Bass-/Treb!e)


TONE: Press and release this button until the desired tone BASS, TREBLE or MIDRANGE appears on the display. The radio keeps separate tone settings for each band, preset (except weather band presets) and source.


LEVEL +: After selecting the desired tone control, press the plus or minus symbol on this button to select the desired level. To save the tone settings for your presets, press and hold the numbered button for the desired preset for more than two seconds until you hear a beep. Adjusting the Speakers (Balance/Fade)


TONE: Press and release this button until BALANCE or FADE appears on the display. - LEVEL +: After selecting the desired control, press the plus or minus symbol on this button to select the desired level. To save the tone settings for your presets, press and hold the numbered pushbutton for the desired preset for more than two seconds until you hear a beep


DSP: This feature is used to provide a choice of four different listening experiences: talk, front seat, ambience and spacious. DSP can be used while listening to the radio, cassette, CD, or XMTM. Press this button to turn DSP on. Press and release this button until the desired selection appears on the display. To turn DSP off, press and hold this button until DSP OFF appears on the display. When DSP OFF is displayed, the system will provide the best overall audio performance. The radio keeps separate DSP settings for each band (except weather band, which is always set to talk), preset and source. TALK: This setting should be used when listening to non-musical material such as news, talk shows, sports broadcasts and books on tape. TALK makes spoken words sound very clear. FRONT SEAT: This setting adjusts the audio to give the driver the best possible sound qualities. Front Seat can be used at any time for any material. Rear seat passenaers in the vehicle may not set the same effect. AMBIENCE: This setting is used to enhance the stereo effect. SPACIOUS: This setting is used to make the listening space seem larger.


3-83


RDS Messages


ALERT!: Alert warns of local or continental U.S.-based emergencies. When an alert announcement comes on the current radio station or a related network station, you will hear it, even if the volume is muted, a cassette tape or compact disc is playing, or if RDS mode is turned off. ALERT will appear on the display when an alert announcement plays. The radio uses TA volume during these announcements. To increase or to decrease volume, turn the PWRNOL knob. TA VOLUME will appear on the display while the volume is being adjusted. If the radio tunes to a related network station for an alert announcement, it will return to the original station when the announcement is finished. If the cassette tape or compact disc player is playing, play will stop during the announcement. You will not be able to turn off alert announcements. TA (Traffic): When released, the radio will search for a station with TA if the current station is not TA capable. During the search TA will flash on the display. Once a TA station is found, TA will appear on the display and the traffic announcement will be played. If no station broadcasting traffic announcements is found, NO TRAFFIC STATION FOUND will appear on the display. If the TA button is pressed and held for two seconds, the radio will search for the next available TA station. Press the TA button again to turn TA off. 3-84


the TA button is pressed and


radio can interrupt the


Traffic Interrupt Feature: Your play of a cassette, CD, or XMTM station. Press the TA button. The radio will seek to a station that broadcasts traffic announcements. When the radio finds a station that broadcasts traffic announcements, it will stop. TA will appear on the display. When a traffic announcement comes on the station that was found, you will hear it. When the traffic announcement is over, the radio will resume play of the cassette, CD, or XMTM station. If no station is found, NO TRAFFIC STATION FOUND will appear on the display. Press the TA button again to turn TA off. MSG (Message): If the current station has a message, MSG will appear on the display. Press the MSG button, to see the message. If the whole message does not appear on the display, parts of the message will appear every three seconds until the message is completed. To see the parts of the message faster than every three seconds, press the MSG button repeatedly. A new group of words will appear on the display with each press. Once the complete message has been displayed, MSG will disappear from the display until another new MSG is received.


For XMTM (USA onlv, if your radio is equipped with XMTM Satellite Rad6 Service), press this button while in XM mode to retrieve various pieces of information related to the current song or channel. By pressing and releasing the MSG button, you may retrieve four different categories of information: Artist Name/Feature, Song/Program Title, Channel Category that may be broadcast on that channel. Each of the four information types may have multiple pages of text. To reach a category, press and release the MSG button consecutively until the desired type is displayed. If there are multiple pages of text for the information selected type, the radio will automatically display all the pages for that type at a rate of approximately one page every three seconds before timing out and returning to the default display. You may override this feature by pressing the MSG button to review all of the pages at your own pace.


Finding a PTY Stati~n (RDS and XMTM) To se!ect and find a desired PTY perform the following: 1. Press PTY. PTY will be displayed on the screen. 2. Select a category by pressing - LEVEL +. 3. Once the desired category is displayed, press


TUNE/SEEK to select the category and take you to the category’s first station.


4. If you want to go to another station within that category, press TUNE/SEEK once to display the category, then press TUNE/SEEK again to go to another station.


5. If PTY times out and is no longer on the display, go


back to Step 1.


SCAN: You can also scan through the channels within a category by performing the following: 1. Press PTY. PTY will be displayed on the screen. 2. Select a category by pressing - LEVEL +. 3. Once the desired category is displayed, press SCAN, and the radio will begin scanning within your chosen category.


4. Press SCAN again to stop at a particular section.


3-85


XMTM Radio Messages


Condition


Action Required


Radio Display


Message


XL (Explicit Language Channels)


XL on the radio display, after the channel name, indicates content with explicit language. Updating encryption code


No XM signal


Loss of signal


Loading XM


Acquiring channel audio (after 4 second delay)


Channel Off Air


Channel not in service


Channel Unavail


Channel no longer available


No Artist Info


No Title Info


3-86


Artist Name/Feature not available Song/Program Title not available


These channels, or any others, can be blocked at a customer’s request, by calling 1 -800-852-XMXM (9696).


The encryption code in your receiver is being updated, and no action is required. This process should take no longer than 30 seconds. Your system is functioning correctly, but you are in a location that is blocking the XM signal. When you move into an open area, the signal should return. Your radio system is acquiring and processing audio and text data. No action is needed. This message should disappear shortly. This channel is not currently in service. Tune in to another channel. ~~ This previously assigned channel is no longer assigned. Tune to another station. If this station was one of your presets, you may need to choose another station for that preset button. No artist information is available at this time on this channel. Your system is working properly. No song title information is available at this time on this channel. Your system is working properly.


Radio Display


Message


No CAT Info


XMTf4 Radio iviessages jconi'a j


Condition


XM Theftlocked


Theft lock active


XM Radio ID


Unknown


Radio ID label (channel 0)


Radio ID not known (should only be if I hardware failure)


Action Required


No category information is available at this time on this channel. Your system is working properly. There are no channels available for the category you selected. Your system is working properly. No text or informational messages are available at this time on this channel. Your system is working properly. The XM receiver in your vehicle may have previously been in another vehicle. For security purposes, XM receivers cannot be swapped between vehicles. If you receive this message after having your vehicle serviced, check with the servicing facility. If you tune to channel 0, you will see this message alternating with your XM Radio 8 digit radio ID label. This label is needed to activate your service. If you receive this message when you tune to channel 0, you may have a receiver fault. Consult with your dealer.


3-87


Playing a Cassette Tape With the radio on, insert a cassette tape. The tape will begin playing as soon as it is inserted. When one side of your cassette tape is done playing, auto reverse plays the other side of your cassette tape. A cassette tape may be loaded with the radio off but it will not start playing until the radio is on. If you want to insert a cassette tape when the ignition is off, first press the eject button. While the tape is playing, use the VOL, TONE, LEVEL and DSP controls just as you do for the radio. Other controls may have different functions when a tape is inserted. The display will show an underlined tape symbol. TAPE PLAY will appear on the display when a tape is playing, with an arrow to indicate which side of the tape is playing. If an error appears on the display, see “Cassette Tape Messages” later in this section. 1 PREV (Previous): Your seconds of silence between each selection for previous to work. Press this pushbutton to seek to the previous selection on the tape. 2 NEXT: Your tape must have at least three seconds of silence between each selection for next to work. Press this pushbutton to seek to the next selection on the tape.


tape must have at least three


3-88


this pushbutton to rewind


3 << RW (Rewind: Press the tape rapidly. The radio will play while the tape rewinds. Press RW again to return to playing speed. 4 FF >> (Fast Forward): Press forward to another part of the tape. The radio will play while the tape advances. Press FF again to return to playing speed.


this pushbutton to fast


A SEEK Y : Your tape must have at least three seconds of silence between each selection for the SEEK arrows to work. Press the up or the down arrow to seek to the next or to the previous selection on the tape. SCAN: Press this button to listen to selections for a few seconds. The tape will go to a selection, play for a few seconds, then go on to the next selection. Press this button again to stop scanning. SIDE: Press this button to play the other side of the tape. A (Eject): Press the cassette tape slot to stop a tape when it is playing or to eject a tape when it is not playing. Eject may be activated with the radio off and/or the ignition off.


this button, located to the right of


Cassette Tape Messages


If an error occurs while trying to play a cassette tape, it could be one of the following has occurred:


The cassette tape is tight and the cassette player cannot turn the hubs of the tape. Hold the cassette tape with the open end down and try turning the right hub counterclockwise with a pencil. Flip the tape over and repeat. If the hubs do not turn easily, your cassette tape may be damaged and should not be used in the player. Try a new tape to be sure your player is working properly The cassette tape is broken. (Check to see if your tape is broken. Try a new tape.)


the display,


CLEAN TAPE: If this message appears on the cassette tape player needs to be cleaned. It will still play tapes, but you should clean it as soon as possible to prevent damage to the tapes and player. See Care of Your Cassette Tape Player on page 3-96. If any error occurs repeatedly or if an error can’t be corrected, contact your dealer. Your cassette tape player automatically reduces background noise. Dolby Noise Reduction is manufactured under a license from Dolby Laboratories Licensing Corporation. Doiby and the doubie-D symboi are trademarks of Dolby Laboratories Licensing Corporation.


Auto Cr02 aiiows the cassette tape player to adjust to the type of cassette tape for clearer sound for Cr02 cassette tapes. Playing a Compact Disc Insert a disc partway into the slot, label side up. The player will pull it in. If the ignition and the radio are on and the underlined compact disc symbol appears on the display, the disc will begin playing. A compact disc may be loaded with the radio off but it will not start playing until the radio is on. If you want to insert a disc when the ignition is off, first press the eject button. The integral CD player can play the smaller 8 cm compact discs. Full-size compact discs and the smaller compact discs are loaded in the same manner. If an error appears on the display, see “Compact Disc Messages” later in this section. 1 PREV (Previous): Press this pushbutton to seek to the previous track on the compact disc. 2 NEXT: Press tnis pusnbutton to seek to the next track on the compact disc. 3 << RW (Rewind): Press this pushbutton to reverse the compact disc. Release it to return to playing speed. 4 FF >> i ~ a s t Forwardj: Press this pushbutton to fast forward to another part of the compact disc. Release it to return to playing speed.


3-89


6 RDM (Random): Press this pushbutton to listen to the tracks in random instead of sequential order. RDM will appear on the display. Press RDM to turn off random play. RDM will disappear from the display.


i K SEEK Y : Press the up or the down arrow to seek to the next or to the previous track. SIDE: Press this pushbutton to play a CD when listening to the radio.


SCAN: Press this button to listen to tracks for a few seconds. The compact disc will go to a track, play for a few seconds, then go on to the next track. Press this button again to stop scanning.


(Eject): Press this button, located to the right of


the CD slot, to stop a CD when it is playing or to eject a CD when it is not playing. Eject may be activated with the radio off and/or the ignition off.


Compact Disc Messages If the disc comes out, it could be for one of the following reasons:


You’re driving on a very rough road. When the road becomes smoother, the disc should play. It’s very hot. When the temperature returns normal, the disc should play. The disc is dirty, scratched, wet or upside down. The air is very humid. If so, wait about an hour and try again.


to


If the CD is not playing correctly, for any other reason. try a known good CD. If any error occurs repeatedly or if an error can’t be corrected, contact your dealer.


3-90


NavigationiRadio System


Consoie-Mounted CD Changer With the compact disc changer, you can play up to six discs continuously. Normal size discs may be played using the trays supplied in the magazine. The smaller discs (8 cm) can be played only with specially designed trays.


Navigation/Radio Display and Controls


The display screen is located in the center of the instrument panel. There are “hard” buttons and a touch sensitive screen. Your vehicle may be equipped with an AM-FM radio navigation radio system that includes digital sound processmg (LISP), a Hadio Data System (HUS) with program ”type” selections (PTY) that will seek out the kind of music you want to listen to. The radio system can also communicate with your navigation system to broadcast announcements on traffic, weather and emergency alert comml!nications. For information on how to use this system, see the “Navigation/Radio System Supplement”.


You must first load the magazine with discs before you can play a compact disc. Each of the six trays holds one disc. Load the trays from bottom to top, placing a disc in the tray label side up. If you load a disc label side down, the disc will not play and an error will occur. Repeat this procedure for loading up to 6 discs in the magazine.


3-91


Once you have loaded the discs in the magazine, slide open the door of the compact disc (CD) changer. Push the magazine into the changer in the direction of the arrow marked on top of the magazine.


3-92


Close the door by sliding it all the way to the right. When the door is closed, the changer will begin checking for discs in the magazine. This will continue for up to one and a half minutes, depending on the number of discs loaded. Whenever a CD magazine with discs changer, the CD changer symbol will appear on the radio display. If the CD changer is checking the magazine for CDs, the CD symbol will flash on the display until the changer is ready to play. When a CD begins playing, a disc and track number will be displayed. The disc numbers are listed on the front of the magazine. Features of CD changer may be different due to your vehicles audio system.


is loaded in the


i PREV (Previousj/X TUNE SEEK Y : Press this pushbutton to seek to the previotrs track on the CD. !f playing the first track of the CD, pressing the PREV pushbutton will seek to the last track of the CD.


2 NEXTDY TUNE SEEK Y : Press this pushbutton to seek to the next track on the CD. If playing last track of the CD, pressing the NEXT pushbutton will seek to the first track of the CD.


3 < RW (Rewind)/< RW (Rewind): Press and hold this pushbutton to reverse quickly through a track. 4 FF >> (Fast Forward)/FF >> (Fast Forward): Press and hold this pushbutton to advance quickly through a track. 5 DISC: Press this pushbutton to select the next disc in the changer. Each time you press this button, LOADING will appear on the display and the disc number on the radio display will go to that of the next available CD.


6 RDid jiiandomj: Press this pushbutton to hear the tracks in random, rather than sequential, order. RDM will appear on the display. Press the PREV or NEXT pushbuttons while RDM is on the display to randomly seek through discs. Press RDM again to turn off random play. This feature may not be available on your radio.


SCAN: Press this button. You will hear the first few seconds of the first track on each disc. The CD will mute while scanning and SCAN will appear on the display. Press this button again to stop scanning.


SOURCE: Press this button if you have a disc loaded in the changer and the radio is on, to play a compact disc. To return to playing the radio, press BAND. Pressing source also switches between a tape or compact disc if both are loaded.


EJECT: Slide the CD changer door all the way open. Press the EJECT button and the magazine will eject.


3-93


Compact Disc Changer Errors CD CHANGER ERROR: This message may be displayed for one of the following reasons:


You’re driving on a very rough road. When the road becomes smoother, the disc should play. The disc is dirty, scratched, wet or loaded label side up. The air is very humid. If so, wait about an hour and try again.


If any error occurs repeatedly or if an error cannot be corrected, contact your dealership. If your radio displays an error number, write it down and provide this information to your dealership when reporting the problem. Radio Personalization with Home and Away Feature If DRIVER 1 (HOME or AWAY) PRESETS or DRIVER 2 (HOME or AWAY) PRESETS appears in the display when the radio is first turned on, your vehicle is equipped with this feature. This feature allows the driver to return to the last used audio source (radio, cassette or CD) using the remote keyless entry transmitter. This feature can also store and recall AM and FM presets, volume, tone and the last selected radio station. The number on the 3-94


back of each transmitter (1 or 2) corresponds to driver 1 or 2. If transmitter 1 is used to enter the vehicle, the last used audio source and/or settings set by driver 1 will be recalled. If transmitter 2 is used to enter the vehicle, the last used audio source and/or settings set by driver 2 will be recalled. The settings can also be recalled by pressing the MEMORY seat buttons 1 or 2 located on the driver’s door. Your radio can store home and away presets. Home and away presets allow you to use one set of preset radio settings in the area where you live, and another set when you go out of town. That way, you will not need to reprogram your presets every time you travel. With the radio off and the clock displayed, use fast forward and reverse to select home or away presets. To select the away presets, press and hold FF for five seconds until you hear a beep. The next time the radio comes on, the away presets will be active. To select the home presets, press and hold RW for five seconds until you hear a beep. The next time the radio comes on, the home presets will be active. When battery power is removed and later applied, you will not have to reset your home radio presets because the radio remembers them. However, you will have to reset your away radio presets.


Theft-Deterrent Feature


THEFTLOCK@ is designed to discourage theft of your radio. Your vehicle has a “built in” theft-deterrent feature on each radio that is automatic - there is no programming required. The radio in your vehicle cannot be used in any other vehicle. When the radio was originally installed in your vehicle at the factory, it stored the Vehicle Identification Number (VIN). Each time the ignition is turned on, the VIN is verified. If the vehicle’s VIN does not match the VIN stored in the radio, THEFTLOCK@ will be activated and the audio system will not play. If the radio is removed from your vehicle, the original VIN in the radio can be used to trace the radio back to your vehicle.


Some audio controls can be adjusted at the steering wheel. They include the following:


A VOL v (Volume): Press the up or the down arrows to increase or to decrease volume. A SEL v (Select): When listening to the radio or to a XMTM Satellite Radio Service station, press the up or the down arrows to tune to the next or the previous preset radio station. When listening to a cassette tape, these arrows can be used to SEEK forward and rearward through the tape. Pressing these arrows when listening to a CD will cause the player to go to the next or the previous track.


3-95


Understanding Radio Reception


The range for most AM stations is greater than for FM, especially at night. The longer range, however, can cause stations to interfere with each other. AM can pick up noise from things like storms and power lines. Try reducing the treble to reduce this noise if you ever get it. FM Stereo FM stereo will give you the best sound, but FM signals will reach only about 10 to 40 miles (1 6 to 65 km). Tall buildings or hills can interfere with FM signals, causing the sound to come and go. XMTM Satellite Radio Service XMTM Satellite Radio Service gives you digital radio reception from coast to coast. Just as with FM, tall buildings or hills can interfere with Satellite radio signals, causing the sound to come and go. Your radio may display "NO XM SIGNAL" to indicate interference.


Cellular Phone Usage Cellular phone usage may cause interference with your vehicle's radio. This interference may occur when making or receiving phone calls, charging the phone's battery or simply having the phone "on". This interference is described as an increased level of static while listening to the radio. If you notice static while listening to the radio, unplug the cellular phone and turn it off. Weather Band Weather band is restricted to speech and the audio quality is not as good as with the AM or FM bands. Depending on location, the radio should receive one or two channels. Care of Your Cassette Tape Player A tape player that is not cleaned regularly can cause reduced sound quality, ruined cassettes or a damaged mechanism. Cassette tapes should be stored in their cases away from contaminants, direct sunlight and extreme heat. If they aren't, they may not operate properly or may cause failure of the tape player.


3-96


Your tape player should be cleaned regularly after every 50 hours of use. Your radio may display CLEAN TAPE to indicate that yog have used your tape player for 50 hours without resetting the tape clean timer. If this message appears on the display, your cassette tape player needs to be cleaned. It will still play tapes, but you should clean it as soon as possible to prevent damage to your tapes and player. If you notice a reduction in sound quality, try a known good cassette to see if the tape or the tape player is at fault. If this other cassette has no improvement in sound quality, clean the tape player. For best results, use a scrubbing action, non-abrasive cleaning cassette with pads which scrub the tape head as the hubs of the cleaner cassette turn. The recommended cleaning cassette is available through your dealership. The broken tape detection feature of your cassette tape player may identify the cleaning cassette as a damaged tape, in error. To prevent the cleaning cassette from being ejected, use the following steps:


1. Turn the ignition on. 2. Turn the radio off. 3. Press and hold the SOURCE button for two


seconds. The tape symbol on the display will flash three times.


4. Turn the radio on and insert the scrubbing action


cleaning cassette.


5. Eject the cleaning cassette after the manufacturer’s


recommended cleaning time.


After the cleaning cassette is ejected, the broken tape detection feature will be active again. You may also choose a non-scrubbing action, wet-type cleaner which uses a cassette with a fabric belt to clean the tape head. This type of cleaning cassette will not eject on its own. A non-scrubbing action cleaner may not clean as thoroughly as the scrubbing type cleaner. The use of a non-scrubbing action, dry-type cleaning cassette is not recommended. After you clean the player, press and hold the eject button for five seconds to reset the CLEAN TAPE indicator. The radio will display CLEAN TAPE MSG CLEARED to show the indicator was reset. Cassettes are subject to wear and the sound quality may degrade over time. Always make sure the cassette tape is in good condition before you have your tape player serviced.


3-97


Care of Your CDs Handle discs carefully. Store them in their original cases or other protective cases and away from direct sunlight and dust. If the surface of a disc is soiled, dampen a clean, soft cloth in a mild, neutral detergent solution and clean it, wiping from the center to the edge. Be sure never to touch the side without writing when handling discs. Pick up discs by grasping the outer edges or the edge of the hole and the outer edge. Care of Your CD Player The use of CD lens cleaner discs is not advised, due to the risk of contaminating the lens of the CD optics with lubricants internal to the CD mechanism. Diversity Antenna System


Your AM-FM antennas are located in the windshield and rear window. Be sure that the inside surfaces of the windshield and rear window are not scratched and that the lines on the glass are not damaged. If the inside surfaces are damaged, they could interfere with radio reception. Also, for proper radio reception, the antenna connector located on the passenger’s side top corner of the windshield and the antenna connector located on the driver’s side top corner of the rear window need to be properly attached to the buttons on the glass. 3-9%


Do not apply aftermarket glass tinting.The metallic film in some tinting materials will interfere with or distort the incoming radio reception. Notice: Do not try to clear frost or other material from the inside of the front windshield and rear window with a razor blade or anything else that is sharp. This may damage the rear window defogger grid and affect your radio’s ability to pickup stations clearly. The repairs wouldn’t be covered by your warranty. If, when you turn on your rear window defogger, you hear static on your radio station, it could mean that a defogger grid line has been damaged. If this is true, the grid line must be repaired. If you choose to add an aftermarket cellular telephone to your vehicle, and the antenna needs to be attached to the glass, be sure that you do not damage the grid lines for the AM-FM antennas or place the cellular telephone antenna over the grid lines. XMTM Satellite Radio Antenna System Your XMTM Satellite Radio antenna is located on the roof of your vehicle. Keep this antenna clear of snow and ice build up for clear radio reception.


Section 4 Driving Your Vehicle


four Driving. the Road. and Your Vehicle .......... 4-2 Defensive Driving ........................................... 4.2 Drunken Driving ............................................. 4-2 Control of a Vehicle ........................................ 4-5 Braking ......................................................... 4-6 Traction Control System (TCS) ......................... 4-8 Magnetic Ride Control ................................... 4-10 Steering ...................................................... 4-10 Off-Road Recovery ....................................... 4-12 Passing ....................................................... 4-13 Loss of Control ............................................. 4-14 Driving at Night ............................................ 4-15 ... -4-1 7 Driving in Rain and on Wet Roads


.......


City Driving .................................................. 4.20 Freeway Driving ........................................... 4.21 Before Leaving on a Long Trip ....................... 4-22 Highway Hypnosis ........................................ 4.22 Hill and Mountain Roads ................................ 4-23 Winter Driving .............................................. 4.24 If You Are Stuck: In Sand, Mud.


Towing ................................... Vehicle ..........


Ice or Snow .............................................. 4-29 . . . . . . . . . 4.30 ..... 4.30 Towing Your Recreational Vehicle Towing .................... 4-30 Loading Your Vehicle .................................... 4.31 Towing a Trailer ........................................... 4.33


4-1


Your Driving, the Road, and Your Vehicle


Defensive Driving The best advice anyone can give about driving is: Drive defensively. Please start with a very important safety device in your vehicle: Buckle up. See Safety Belts: They Are for Everyone on page 1-6. Defensive driving really means “be ready for anything.” On city streets, rural roads or freeways, it means “always expect the unexpected.” Assume that pedestrians or other drivers are going to be careless and make mistakes. Anticipate what they might do. Be ready for their mistakes. Rear-end collisions are about the most preventable of accidents. Yet they are common. Allow enough following distance. It’s the best defensive driving maneuver, in both city and rural driving. You never know when the vehicle in front of you is going to brake or turn suddenly. Defensive driving requires that a driver concentrate on the driving task. Anything that distracts from the driving task - such as concentrating on a cellular telephone call, reading, or reaching for something on


4-2


the floor - makes proper defensive driving more difficult and can even cause a collision, with resulting injury. Ask a passenger to help do things like this, or pull off the road in a safe place to do them yourself. These simple defensive driving techniques could save your life. Drunken Driving Death and injury associated with drinking and driving is a national tragedy. It’s the number one contributor to the highway death toll, claiming thousands of victims every year. Alcohol affects four things that anyone needs to drive a vehicle:


Judgment


e Muscular Coordination e Vision e Attentiveness. Police records show that almost half of all motor vehicle-related deaths involve alcohol. In most cases, these deaths are the result of someone who was drinking and driving. In recent years, more than 16,000 annual motor vehicle-related deaths have been associated with the use of alcohol, with more than 300,000 people injured.


!


Many adults - by some estimates, nearly half the adult population - choose never to drink alcohol, so they never drive after drinking. For persons under 21, it’s against the law in every U.S. state to drink alcohol. There are good medical, psychological and developmental reasons for these laws. The obvious way to eliminate the leading highway safety problem is for people never to drink alcohol and then drive. But what if people do? How much is “too much’’ if someone plans to drive? It’s a lot less than many might think. Although it depends on each person and situation, here is some general information on the problem. The Blood Alcohol Concentration (BAC) of someone who is drinking depends upon four things: 0 The amount of alcohol consumed


The drinker’s body weight


* The amount of food that is consumed before and


during drinking


0 The length of time it has taken the drinker to


curlsurrte ihe aicohoi.


According to the American Medical Association, a 180 Ib (82 kg) person who drinks three 12 ounce (355 ml) bottles of beer in an hour will end up with a BAC of about 0.06 percent. The person would reach the “ camp of wine or three mixed drinks if each had 1 - 1/2 ounces (45 ml) of a liquor like whiskey, gin or vodka.


three 4 e t ~ c e (120 E!> glasses


.v V J hw drinking


I S ” Y I R A P


U I , , 1 1 \ 1 1 ,


It’s the amount of alcohol that counts. For example, if the same person drank three double martinis (3 ounces or 90 ml of liquor each) within an hour, the person’s DlnP . UAU V V U U l U U t CIIUOC 1U U. I L PC1 LC1 ll. M fJCl3UI I who consumes food just before or during drinking will have a somewhat lower BAC level.


+- A 4 n


.--“-A-


- I - - -


I-.-


. I 4


. - .


4-3


There is a gender difference, too. Women generally have a lower relative percentage of body water than men. Since alcohol is carried in body water, this means that a woman generally will reach a higher BAC level than a man of her same body weight when each has the same number of drinks. The law in an increasing number of US. states, and throughout Canada, sets the legal limit at 0.08 percent. In some other countries, the limit is even lower. For example, it is 0.05 percent in both France and Germany. The BAC limit for all commercial drivers in the United States is 0.04 percent. The BAC will be over 0.1 0 percent after three to six drinks (in one hour). Of course, as we’ve seen, it depends on how much alcohol is in the drinks, and how quickly the person drinks them.


But the ability to drive is affected well below a BAC of 0.10 percent. Research shows that the driving skills of many people are impaired at a BAC approaching 0.05 percent, and that the effects are worse at night. All drivers are impaired at BAC levels above 0.05 percent. Statistics show that the chance of being in a collision increases sharply for drivers who have a BAC of 0.05 percent or above. A driver with a BAC level of 0.06 percent has doubled his or her chance of having a collision. At a BAC level of 0.10 percent, the chance of this driver having a collision is 12 times greater; at a level of 0.15 percent, the chance is 25 times greater! The body takes about an hour to rid itself of the alcohol in one drink. No amount of coffee or number of cold showers will speed that up. “1’11 be careful” isn’t the right answer. What if there’s an emergency, a need to take sudden action, as when a child darts into the street? A person with even a moderate BAC might not be able to react quickly enough to avoid the collision.


4-4


There’s something else about drinking and driving that many people don’t know. Medical research shows that aieshsi in a person’s system can make crash injuries worse, especially injuries to the brain, spinal cord or heart. This means that when anyone who has been drinking - driver or passenger - is in a crash, that person’s chance of being killed or permanently disabled is higher than if the person had


been drinking.


Contro! of 8 \’ehic!e You have three systems that make your vehicle go where you want it to go. They are the brakes, the steering and the accelerator. All three systems have to do their work at the places where the tires meet the road.


I nki - an


:hen driv 3 is very danS-- ous. Your reflexes, perceptions, attentiveness and judgement can be affected by even a small amount of alcohol. You can have a serious-or even fatal-collision if you drive after drinking. Please don’t drink and drive or ride with a driver who has been drinking. Ride home in a --L. _ I :c ..c... bau, u t II y u u I c VVILII a y ~ u u p , U G ~ I Y I I ~ L F ; a driver who will not drink.


... :+L. -


-I-..-


-I--:-....-&-


7,”.


Sometimes, as when you’re driving on snow or ice, it’s easy to ask more of those control systems than the tires and road can provide. That means you can !me control of your vehicle. Also see Traction Control System (TCS) on page 4-8.


4-5


Braking


Braking action involves perception time and reaction time. First, you have to decide to push on the brake pedal. That’s perception time. Then you have to bring up your foot and do it. That’s reaction time. Average reaction time is about 3/4 of a second. But that’s only an average. It might be less with one driver and as long as two or three seconds or more with another. Age, physical condition, alertness, coordination and eyesight all play a part. So do alcohol, drugs and frustration. But even in 3/4 of a second, a vehicle moving at 60 mph (1 00 km/h) travels 66 feet (20 m). That could be a lot of distance in an emergency, so keeping enough space between your vehicle and others is important. And, of course, actual stopping distances vary greatly with the surface of the road (whether it’s pavement Qr gravel); the condition of the road (wet, dry, icy); tire tread; the condition of your brakes; the weight of the vehicle and the amount of brake force applied. Avoid needless heavy braking. Some people drive in spurts - heavy acceleration followed by heavy braking - rather than keeping pace with traffic. This is a mistake. Your brakes may not have time to cool between hard stops. Your brakes will wear out much faster if you do a lot of heavy braking. If you keep pace 4-6


with the traffic and allow realistic following distances, you will eliminate a lot of unnecessary braking. That means better braking and longer brake life. If your engine ever stops while you’re driving, brake normally but don’t pump your brakes. If you do, the pedal may get harder to push down. If your engine stops, you will still have some power brake assist. But you will use it when you brake. Once the power assist is used up, it may take longer to stop and the brake pedal will be harder to push. Anti-lock Brake System (ABS) Your vehicle has anti-lock brakes. ABS is an advanced electronic braking system that will help prevent a braking skid. When you start your engine and begin to drive away, your anti-lock brake system will check itself. You may hear a momentary motor or clicking noise while this test is going on, and you may even notice that your brake pedal moves a little. This is normal.


If there’s a problem with the anti-lock brake system, this warning light will stay on. See Anti-Lock Brake System Warning Light on page 3-4 1.


Let’s say the road is wet and you’re driving safely. Suddenly, an animal jumps out in front of you. You slam on the brakes and continue braking. Here’s what happens with ABS: A computer senses that wheels are slowing down. If one of the wheels is about to stop rolling, the computer will separately work the brakes at each front wheel and at both rear wheels. The anti-lock system can change the brake pressure faster than any driver could. The computer is programmed to make the most of available tire and road conditions. This can help you steer around the obstacle while braking hard.


4-7


Using Anti-Lock Don’t pump the brakes. Just hold the brake pedal down firmly and let anti-lock work for you. You may hear the anti-lock pump or motor operate, and feel the brake pedal pulsate, but this is normal. Braking in Emergencies With anti-lock, you can steer and brake at the same time. In many emergencies, steering can help you more than even the very best braking. Traction Control System (TCS)


Your vehicle has a traction control system that limits wheel spin. This is especially useful in slippery road conditions. The system operates only if it senses that one or both of the front wheels are spinning or beginning to lose traction. When this happens, the system works the front brakes and reduces engine power to limit wheel spin. The TRACTION ENGAGED message will display on the Driver Information Center when the traction control system is limiting wheel spin. See DIC Warnings and Messages on page 3-52. You may feel or hear the system working, but this is normal.


As you brake, your computer keeps receiving updates on wheel speed and controls braking pressure accordingly. Remember: Anti-lock doesn’t change the time you need to get your foot up to the brake pedal or always decrease stopping distance. If you get too close to the vehicle in front of you, you won’t have time to apply your brakes if that vehicle suddenly slows or stops. Always leave enough room up ahead to stop, even though you have anti-lock brakes.


4-a


If your vehicle is in cruise control when the traction control system begins to limit wheel spin, the cruise eontroi wiil auiomaiicaiiy disengage. When roaci conditions allow you to safely use it again, you may reengage the cruise control. See Cruise Control under Turn SignaVMultifunction Lever on page 3-8.


TRACTION CONTROL


United States


Canada


This warning light will come on to let you know if there’s a problem with your traction control system. See Traction Control System (TCS) Warning Light on page 3-42. When this warning light is on, the system will not limit wheel spin. Adjust your driving accordingly. The traction control system automatically comes on whenever you start your vehicle. To limit wheel spin, especially in slippery road conditions, you should always leave the system on. But you can turn the traction control system off if you ever need to.


You should turn the system off if your vehicle ever gets stuck in sand, mud or snow and rocking the vehicle is required. See Rocking Your Vehicle under If You Are Stuck: In Sand, Mud, Ice or Snow on page 4-29.


To turn the system off, press the TRAC ON/OFF button located on the center console.


!? \!!I!!


The TRACTION OFF message will display on the Driver Information Center. If the system is limiting wheel spin when you press the button, the TRACTION OFF message will display - but the system won’t turn off right


!Inti! them’s “5 !cn?ger 9 current need


.?n.ln)I. to limit wheel spin. You can turn the system back on at any time by pressing the button again. The TRACTION READY message should display briefly on the Driver Information Center.


\!!Zit


4-9


Magnetic Ride Control


Magnetic Ride Control automatically adjusts the ride of your vehicle. Automatic ride control is achieved through a computer used to control and monitor the suspension system. The controller receives input from various sensors to determine the proper system response. If the controller detects a problem within the system, the DIC will display a SERVICE SUSPENSION SYS message. See DIC Warnings and Messages on page 3-52 for more information. See your dealer for service.


Steering Power Steering If you lose power steering assist because the engine stops or the system is not functioning, you can steer but it will take much more effort. Magnetic Speed Variable Assist Steering Your vehicle may be equipped with a steering system that continuously adjusts the effort you feel when steering at all vehicle speeds. It provides ease when parking, yet a firm, solid feel at highway speeds.


4-1 0


Steering Tips Driving on Curves It’s important to take curves at a reasonable speed. A lot of the “driver lost control” accidents mentioned on the news happen on curves. Here’s why: Experienced driver or beginner, each of us is subject to the same laws of physics when driving on curves. The traction of the tires against the road surface makes it possible for the vehicle to change its path when you turn the front wheels. If there’s no traction, inertia will keep the vehicle going in the same direction. If you’ve ever tried to steer a vehicle on wet ice, you’ll understand this. The traction you can get in a curve depends on the condition of your tires and the road surface, the angle at which the curve is banked, and your speed. While you’re in a curve, speed is the one factor you can control. Suppose you’re steering through a sharp curve. Then you suddenly accelerate. Both control systems - steering and acceleration - have to do their work where the tires meet the road. Adding the sudden acceleration can demand too much of those places. You can lose control. See Traction Control System (TCS) on page 4-8. What should you do if this ever happens? Ease up on the accelerator pedal, steer the vehicle the way you want it to go, and slow down.


Since your vehicle is equipped with Stabilitrak@ you may see the STABILITY SYS ENGAGED message on the Driver Mxmatiori Center. See “Stabiiiiji System Engaged Message” under DIC Warnings and Messages on page 3-52. Speed limit signs near curves warn that you should adjust your speed. Of course, the posted speeds are based on good weather and road conditions. Under less favorable conditions you’ll want to go slower. If you need to reduce your speed as you approach a curve, do it before you enter the curve, while your front wheels are straight ahead. Try to adjust your speed so you can “drive” through the curve. Maintain a reasonable, steady speed. Wait to accelerate until you are out of the curve, and then accelerate gently into the straightaway. To help you steer in the direction you want to go, during certain sharp or sudden cornering maneuvers, gear selection is controlled. This will maximize the available drive wheel torque and minimize the transaxle thl- Ir;-rJ racnnncn timn qnrl rhift q n t i x r ; t > , n , , , ; , m maneuver, the transaxle shifts automatically as vehicle speed changes.


,II,,cI U l l U Q I 1 1 1 1 . U u L I v I C y . uu1111y L I l


-< l J I\lllU VI


I V V y V I


I U ”


There are times when steering can be more effective than braking. For example, you come over a hill and find a truck stopped in your lane, or a car suddenly pulls out from nowhere, or a child darts out from between parked cars and stops right in front of you. You can avoid these problems by braking - if you can stop in time. But sometimes you can’t; there isn’t room. That’s the time for evasive action - steering around the problem. Your vehicle can perform very well in emergencies like these. First apply your brakes. See Braking on page 4-6. It is better to remove as much speed as you can from a possible collision. Then steer around the problem, to the left or right depending on the space available.


4-1 1


Off -Road Recovery You may find that your right wheels have dropped off the edge of a road onto the shoulder while you’re driving.


An emergency like this requires close attention and a quick decision. If you are holding the steering wheel at the recommended 9 and 3 o’clock positions, you can turn it a full 180 degrees very quickly without removing either hand. But you have to act fast, steer quickly, and just as quickly straighten the wheel once you have avoided the object. The fact that such emergency situations are always possible is a good reason to practice defensive driving at all times and wear safety belts properly.


4-1 2


If the level of the shoulder is only slightly below the pavement, recovery should be fairly easy. Ease off the accelerator and then, if there is nothing in the way, steer so that your vehicle straddles the edge of the pavement. You can turn the steering wheel up to one-quarter turn until the right front tire contacts the pavement edge. Then turn your steering wheel to go straight down the roadway.


PassIng The driver of a vehicie about to pass another on a two-lane highway waits for just the right moment, accelerates, moves around the vehicle ahead, then goes back into the right lane again. A simple maneuver? Not necessarily! Passing another vehicle on a two-lane highway is a potentially dangerous move, since the passing vehicle occupies the same lane as oncoming traffic for several seconds. A miscalculation, an error in judgment, or a brief surrender to frustration or anger can suddenly put the passing driver face to face with the worst of all traffic accidents - the head-on collision. So here are some tips for passing: 0 “Drive ahead.” Look down the road, to the sides and to crossroads for situations that might affect your passing patterns. If you have any doubt whatsoever about making a successful pass, wait for a better time. Watch for traffic signs, pavement markings and iiiles. ii you can see a sign up ahead that mignt indicate a turn or an intersection, delay your pass. A broken center line usually indicates it’s all right to pass (providing the road ahead is clear). Never cross a solid line on your side of the lane or a double solid line, even if the road seems empty of approaching traffic.


0 Eo not get too close to the vehicle you want to pass while you’re awaiting an opportunity. For one thing, following too closely reduces your area of vision, especially if you’re following a larger vehicle. Also, you won’t have adequate space if the vehicle ahead suddenly slows or stops. Keep back a reasonable distance. When it looks like a chance to pass is coming up, start to accelerate but stay in the right lane and don’t get too close. Time your move so you will be increasing speed as the time comes to move into the other lane. If the way is clear to pass, you will have a “running start” that more than makes up for the distance you would lose by dropping back. And if something happens to cause you to cancel your pass, you need only slow down and drop back again and wait for another opportunity.


* If other vehicles are lined up to pass a slow vehicle,


wait your turn. But take care that someone isn’t trying to pass you as yo11 p ~ l l mrt to p s s the S!nw vehic!~. Remember to glance over your shoulder and check the blind spot.


4-1 3


e


Check your mirrors, glance over your shoulder, and start your left lane change signal before moving out of the right lane to pass. When you are far enough ahead of the passed vehicle to see its front in your inside mirror, activate your right lane change signal and move back into the right lane. (Remember that your right outside mirror is convex. The vehicle you just passed may seem to be farther away from you than it really is.) Try not to pass more than one vehicle at a time on two-lane roads. Reconsider before passing the next vehicle. Don’t overtake a slowly moving vehicle too rapidly. Even though the brake lamps are not flashing, it may be slowing down or starting to turn. If you’re being passed, make it easy for the following driver to get ahead of you. Perhaps you can ease a little to the right.


Loss of Control Let’s review what driving experts say about what happens when the three control systems (brakes, steering and acceleration) don’t have enough friction where the tires meet the road to do what the driver has as ked. In any emergency, don’t give up. Keep trying to steer and constantly seek an escape route or area of less danger.


4-1 4


Skidding


In a skid, a driver can lose control of the vehicle. Defensive drivers avoid most skids by taking reasonable care suited to existing conditions, and by not “overdriving” those conditions. But skids are always possible. The three types of skids correspond to your vehicle’s three control systems. In the braking skid, your wheels aren’t rolling. In the steering or cornering skid, too much speed or steering in a curve causes tires to slip and lose cornering force. And in the acceleration skid, too much throttle causes the driving wheels to spin. A cornering skid is best handled by easing your foot off the accelerator pedal. Remember: Any traction control system helps avoid only the acceleration skid. If your traction control system is off, then an acceleration skid is also best handled by easing your foot off the accelerator pedal. If your vehicle starts to slide, ease your foot off the accelerator pedal and quickly steer the way you want the vehicle to go. If you start steering quickly enough, your vehicle may straighten out. Always be ready for a second skid if it occurs.


With Stahi!itrak@, yclu m q see !he ST,A.B!L!TY SYS ENGAGED message on the Driver Information Center. See “Stability Sys Engaged Message” under DIC Warnings and Messages on page 3-52. Of course, traction is reduced when water, snow, ice, gravel or other material is on the road. For safety, you’li want to slow down and adjust your driving to these conditions. It is important to slow down on slippery surfaces because stopping distance will be longer and vehicle control more limited. While driving on a surface with reduced traction, try your best to avoid sudden steering, acceleration or braking (including engine braking by shifting to a lower gear). Any sudden changes could cause the tires to slide. You may not realize the surface is slippery until your vehicle is skidding. Learn to recognize warning clues - such as enough water, ice or packed snow on the road to make a “mirrored surface” - and slow down when you have any doubt. !?er??a!??be:: !?ry x t i lcc!: b:L;kc sy.s:e;r, avoid only the braking skid.


( K S ) heips


Night driving is more dangerous than day driving. One , reason is tnat some drivers are Ilkely to be impaired - by alcohol or drugs, with night vision problems, or by fatigue.


4-1 5


Here are some tips on night driving. 0 Drive defensively. 0 Don’t drink and drive.


Since you can’t see as well, you may need to slow down and keep more space between you and other vehicles. Slow down, especially on higher speed roads. Your headlamps can light up only so much road ahead. In remote areas, watch for animals. If you’re tired, pull off the road in a safe place and rest.


No one can see as well at night as in the daytime. But as we get older these differences increase. A 50-year-old driver may require at least twice as much light to see the same thing at night as a 20-year-old. What you do in the daytime can also affect your night vision. For example, if you spend the day in bright sunshine you are wise to wear sunglasses. Your eyes will have less trouble adjusting to night. But if you’re driving, don’t wear sunglasses at night. They may cut down on glare from headlamps, but they also make a lot of things invisible.


You can be temporarily blinded by approaching headlamps. It can take a second or two, or even several seconds, for your eyes to readjust to the dark. When you are faced with severe glare (as from a driver who doesn’t lower the high beams, or a vehicle with misaimed headlamps), slow down a little. Avoid staring directly into the approaching headlamps. Keep your windshield and all the glass on your vehicle clean - inside and out. Glare at night is made much worse by dirt on the glass. Even the inside of the glass can build up a film caused by dust. Dirty glass makes lights dazzle and flash more than clean glass would, making the pupils of your eyes contract repeatedly. Remember that your headlamps light up far less of a roadway when you are in a turn or curve. Keep your eyes moving; that way, it’s easier to pick out dimly lighted objects. Just as your headlamps should be checked regularly for proper aim, so should your eyes be examined regularly. Some drivers suffer from night blindness - the inability to see in dim light - and aren’t even aware of it.


4-1 6


--I P..


Wet brakes can cause accidents. They won’t work as well in a quick stop and may cause pulling to one side. You could lose control of the vehicle. After driving through a large puddle of water or a car wash, apply your brake pedal lightly until your brakes work normally.


Driving too fast through large water puddles or even going through some car washes can cause problems, too. The water may affect your brakes. Try to avoid puddles. But if you can’t, try to slow down before you hit them.


4-1 8


Hydrop!anIng Hydropianing is dangerous. So much water can buiia up under your tires that they can actually ride on the water. This can happen if the road is wet enough and you’re going fast enough. When your vehicle is hydroplaning, it has little or no contact with the road. Hydroplaning doesn’t happen often. But it can if your tires do not have much tread or if the pressure in one or more is low. It can happen if a lot of water is standing on the road. If you can see from trees, telephone poles or other vehicles, and raindrops “dimple” the water’s surface, there could be hydroplaning. Hydroplaning usually happens at higher speeds. There just isn’t a hard and fast rule about hydroplaning. The best advice is to slow down when it is raining. Driving Through Deep Standing Water


reflections


.. 3-- -”””


a_-..--.


Nnjipn- If ~ ~ A I I rlriwa tnn m a s i - l r l a s +ClunsnAk rl--..r L Y W c(uIvm~Iy L I a a V U y l D UGGp puddles or standing water, water can come in through your engine’s air intake and badly damage your engine. Never drive through water that is slightly lower than the underbody of your vehicle. If you can’t avoid deep puddles or standing water, drive tnrougn them very siowiy.


--


lng


Flo ng or rushing water creates s forces. If you try to drive through flowing water, as you might at a low water crossing, your vehicle can be carried away. As little as six inches of flowing water can carry away a smaller vehicle. If this happens, you and other vehicle occupants could drown. Don’t ignore police warning signs, and otherwise be very cautious about trying to drive through flowing water.


Some Other Rainy Weather Tips


Besides slowing down, allow some extra following distance. And be especially cat-efld when ymr pass another vehicle. Allow yourself more clear room ahead, and be prepared to have your view restricted by road spray.


* Have good tires with proper tread depth. See Tires


on page 5-63.


4-1 9


City Driving


Here are ways to increase your safety in city driving:


Know the best way to get to where you are going. Get a city map and plan your trip into an unknown part of the city just as you would for a cross-country trip. Try to use the freeways that rim and crisscross most large cities. You’ll save time and energy. See the next part, “Freeway Driving.” Treat a green light as a warning signal. A traffic light is there because the corner is busy enough to need it. When a light turns green, and just before you start to move, check both ways for vehicles that have not cleared the intersection or may be running the red light.


One of the biggest problems with city streets is the amount of traffic on them. You’ll want to watch out for what the other drivers are doing and pay attention to traffic signals.


4-20


..


U I I


. Y . Y


UVUUll


is


-. ... -. .-- thw-0


-. .- nntranpa,


I ICI rally u a * raqp


that leads to the . thG freeway. If you have a clear view of the freeway as you drive aiong the entrance ramp, you should begin to check traffic. Try to determine where you expect to blend with the flow. Try to merge into the gap at close to the prevailing speed. Switch on your turn signal, check your mirrors and glance over your shoulder as often as necessary. Try to blend smoothly with the traffic flow. Once you are on the freeway, adjust your speed to the posted limit or to the prevailing rate if it’s slower. Stay in the right lane unless you want to pass. Before changing lanes, check your mirrors. Then use your turn signal. Just before you leave the lane, glance quickly over your shoulder to make sure there isn’t another vehicle in your “blind” spot. Once you are moving on the freeway, make certain you allow a reasonable following distance. Expect to move slightly slower at night. When you want to leave the freeway, move to the proper lane well in advance. If you miss your exit, do not, under any circumstances, stop and back up. Drive on to the next exit.


exit ramp can be curved, sometimes quite sharply.


The exit speed is usually posted. Reduce your speed according to your speedometer, not to your sense Gf mdim. After driving for aiiy distafie-e at higher speeds, you may tend to think you are going slower than you actually are.


4-2 1


Mile for mile, freeways (also called thruways, Parkways, expressways, turnpikes or superhlghways) are the safest of all roads. But they have their own special rules. The most Keep up with traffic and keep same speed most of the other drivers are driving. Too-fast or too-siow driving breaks a smooth traffic flow. Treat the left lane on a freeway as a passing lane.


freeway driving is: The to the right. Drive at the


important advice on


Before Leaving on a Long Trip Make sure you’re ready. Try to be well rested. If you must start when you’re not fresh - such as after a day’s work - don’t plan to make too many miles that first part of the journey. Wear comfortable clothing and shoes you can easily drive in. Is your vehicle ready for a long trip? If you keep it serviced and maintained, it’s ready to go. If it needs service, have it done before starting out. Of course, you’ll find experienced and able service experts in dealerships all across North America. They’ll be ready and willing to help if you need it. Here are some things you can check before a trip: 0 Windshield Washer Fluid: Is the reservior full? Are


all windows clean inside and outside? Wiper Blades: Are they in good shape?


0 Fuel, Engine Oil, Other Fluids: Have you checked


all levels? Lamps: Are they all working? Are the lenses clean?


0 Tires: They are vitally important to a safe,


trouble-free trip. Is the tread good enough for long-distance driving? Are the tires all inflated to the recommended pressure? Weather Forecasts: What’s the weather outlook along your route? Should you delay your trip a short time to avoid a major storm system? Maps: Do you have up-to-date maps?


4-22


Highway Hypnosis Is there actually such a condition as “highway hypnosis”? Or is it just plain falling asleep at the wheel? Call it highway hypnosis, lack of awareness, or whatever. There is something about an easy stretch of road with the same scenery, along with the hum of the tires on the road, the drone of the engine, and the rush of the wind against the vehicle that can make you sleepy. Don’t let it happen to you! If it does, your vehicle can leave the road in less than a second, and you could crash and be injured. What can you do about highway hypnosis? First, be aware that it can happen. Then here are some tips:


Make sure your vehicle is well ventilated, with a comfortably cool interior. Keep your eyes moving. Scan the road ahead and to the sides. Check your rearview mirrors and your instruments frequently. If you get sleepy, pull off the road into a rest, service or parking area and take a nap, get some exercise, or both. For safety, treat drowsiness on the highway as an emergency.


ririva regu!ar!)r IR steep countpj, or if you're


!f \ m l r J - - planning to visit there, here are some tips that can make your trips safer and more enjoyable.


Keep your vehicle in good shape. Check all fluid levels and also the brakes, tires, cooling system and transaxle. These parts can work hard on mountain roads.


O Know how to go down hills. The most important thing to know is this: let your engine do some of the slowing down. Shift to a lower gear when you go down a steep or long hili.


If you don't shift down, your brakes could get so hot that they wouldn't work well. You would then have poor braking or even none going down a hill. You could crash. Shift down to let your engine assist your Drakes on a steep downhill slope.


4-23


Driving on steep hills or mountains is different from A&, a -..I.- U I I V I I I ~ I I I l l a t V I I U I I I I I ~ L ~ ;


AI "-.ll:--


:- & I - +


:.- I ~ I


I


Winter Driving


Coasting downhill in NEUTRAL (N) or with the ignition off is dangerous. Your brakes will have to do all the work of slowing down. They could get so hot that they wouldn’t work well. You would then have poor braking or even none going down a hill. You could crash. Always have your engine running and your vehicle in gear when you go downhill.


Know how to go uphill. You may want to shift down to a lower gear. The lower gears help you climb the hill better.


0 Stay in your own lane when driving on two-lane roads in hills or mountains. Don’t swing wide or cut across the center of the road. Drive at speeds that let you stay in your own lane. As you go over the top of a hill, be alert. There could be something in your lane, like a stalled car or an accident. You may see highway signs on mountains that warn of special problems. Examples are long grades, passing or no-passing zones, a falling rocks area or winding roads. Be alert to these and take appropriate action.


4-24


Here are some tips for winter driving:


Have your vehicle in good shape for winter. YOU may want to put winter emergency supplies in your trunk.


<*.UL*-.2~:: x‘v, *.”.?^


.&d



Driving on SnQvlI or Ice


Most oi the time, those piaces where your tires meet the road probably have good traction. However, if there is snow or ice between your tires and the road, you can have a very slippery situation. You’ll have a lot less traction or “grip” and will need to be very careful.


Include an ice scraper, a small brush or broom, a supply of windshield washer fluid, a rag, some winter outer clothing, a small shovel, a flashlight, a red C!”fh 2nd 2 c!x!p!e d ref!ecti\,lz wxning t:ixg!es. Azd, if you will be driving under severe conditions, include a small bag of sand, a piece of old carpet or a couple of burlap bags to help provide traction. Be sure you properly secure these items in your vehicle.


4-25


Keep your traction control system on. It improves your ability to accelerate when driving on a slippery road. Even though your vehicle has a traction control system, you’ll want to slow down and adjust your driving to the road conditions. See Traction Control System (TCS) on page 4-8. Your anti-lock brakes improve your vehicle’s stability when you make a hard stop on a slippery road. Even though you have the anti-lock braking system, you’ll want to begin stopping sooner than you would on dry pavement. See Braking on page 4-6.


Allow greater following distance on any slippery road. Watch for slippery spots. The road might be fine until you hit a spot that’s covered with ice. On an otherwise clear road, ice patches may appear in shaded areas where the sun can’t reach: around clumps of trees, behind buildings or under bridges. Sometimes the surface of a curve or an overpass may remain icy when the surrounding roads are clear. If you see a patch of ice ahead of you, brake before you are on it. Try not to brake while you’re actually on the ice, and avoid sudden steering maneuvers.


What’s the worst time for this? “Wet ice.” Very cold snow or ice can be slick and hard to drive on. But wet ice can be even more trouble because it may offer the least traction of all. You can get wet ice when it’s about freezing (32°F; OOC) and freezing rain begins to fall. Try to avoid driving on wet ice until salt and sand crews can get there. Whatever the condition - smooth ice, packed, blowing or loose snow - drive with caution.


4-26


J -- -‘ - -*- !f \~nll 2t-p ctnpped by heavy snov.~, you could be in a serious situation. You should probably stay with your vehicle unless you know for sure that you are near help and you can hike through the snow. Here are some things to do to summon help and keep yourself and your passengers safe:


Turn on your hazard flashers. Tie a red cloth to your vehicle to alert police that you’ve been stopped by the snow. Put on extra clothing or wrap a blanket around you. If you have no blankets or extra clothing, make body insulators from newspapers, burlap bags, rags, floor mats - anything you can wrap around yourself or tuck under your clothing to keep warm.


4-27


Snow can trap exhaust gases under your vehicle. This can cause deadly CQ (carbon monoxide) gas to get inside. CO could overcome you and kill you. You can’t see it or smell it, so you might not know it is in your vehicle. Clear away snow from around the base of your vehicle, especially any that is blocking your exhaust pipe. And check around again from time to time to be sure snow doesn’t collect there. Open a window just a little on the side of the vehicle that’s away from the wind. This will help keep CO out.


Run your engine only as long as you must. This saves fuel. When you run the engine, make it go a little faster than just idle. That is, push the accelerator slightly. This uses less fuel for the heat that you get and it keeps the battery charged. You will need a well-charged battery to restart the vehicle, and possibly for signaling later on with your headlamps. Let the heater run for a while.


You can run the engine to keep warm, but be careful.


4-28


rhen, shut the engine off and close the window almost a!! the way to preserve the heat. Start the engine again and repeat Phis only when you ieei reaiiy uncomforiabie from the cold. But do it as little as possible. Preserve the fuel as long as you can. To help keep warm, you can get out of the vehicle and do some fairly vigorous exercises every half hour or so until help comes. If You Are Stuck: In Sand, Mud, Ice or Snow In order to free your vehicle when it is stuck, you will need to spin the wheels, but you don’t want to spin your wheels too fast. The method known as “rocking” can help you get out en you’re stuck, but you


must use caution.


-f you let your tires spi.. At t -h speed, ley can explode, and you or others could be ingred. And, the transaxle or other parts of the vehicle can overheat. That could cause an engine compartment fire or other damage. When you’re stuck, spin the wheels as little as possible. Don’t spin the wheels above 35 mph (55 km/h) as shown on the speedometer.


Notke: Spinning ynnr whee!~ CBR destroy parts of your vehicle as well as the tires. If you spin the wheeis too fast while shifting your transaxle back and forth, you can destroy your transaxle. See “Rocking Your Vehicle To Get It Out.” For information about using tire chains on your vehicle, see Tire Chains on page 5-72. Rocking Your Vehicle To Get It Out First, turn your steering wheel left and right. That will clear the area around your front wheels. You should turn your traction control system off. See Traction Control System (TCS) on page 4-8. Then shift back and forth between REVERSE (R) and a forward gear, spinning the wheels as little as possible. Release the accelerator pedal while you shift, and press lightly on the accelerator pedal when the transaxle is in gear. By slowly spinning your wheels in the forward and reverse directions, you will cause a rocking motion that may free your vehicle. If that doesn’t get you out after a few tries, you may need to be towed out.-If you do need to be towed out, see “Towing Your Vehicle” tollowing.


4-29


Towing


Towing Your Vehicle Consult your dealer or a professional towing service if you need to have your disabled vehicle towed. See Roadside Service on page 7-5. If you want to tow your vehicle behind another vehicle for recreational purposes (such as behind a motorhome), see Recreational Vehicle Towing following. Recreational Vehicle Towing Recreational vehicle towing means towing your vehicle behind another vehicle - such as behind a motorhome. The two most common types of recreational vehicle towing are known as “dinghy towing” (towing your vehicle with all four wheels on the ground) and “dolly towing” (towing your vehicle with two wheels on the ground and two wheels up on a device known as a “dolly”). With the proper preparation and equipment, many vehicles can be towed in these ways. See “Dinghy Towing” and “Dolly Towing,” following.


Here are some important things to consider before you do recreational vehicle towing:


What’s the towing capacity of the towing vehicle? Be sure you read the tow vehicle manufacturer’s recommendations. How far will you tow? Some vehicles have restrictions on how far and how long they can tow. Do you have the proper towing equipment? See your dealer or trailering professional for additional advice and equipment recommendations. Is your vehicle ready to be towed? Just as you would prepare your vehicle for a long trip, you’ll want to make sure your vehicle is prepared to be towed. See Before Leaving on a Long Trip on page 4-22.


Dinghy Towing Notice: Towing your vehicle with all four wheels on the ground will damage drivetrain components. Your vehicle was not designed to be towed with all four wheels on the ground. If your vehicle must be towed, you should use a dolly. See Dolly Towing following for more information.


4-30


Do!!y Towing


Your vehicle can be towed using a dolly. To tow your vehicle using a dolly, follow these steps: 1. Put the front wheels on the dolly. 2. Put the vehicle 3. Set the parking brake and then remove the key. 4. Clamp the steering wheel in a straight-ahead


in PARK (P).


position.


5. Release the parking brake.


TIRE-LOADING INFORMATION


OCCUPANTS


VEHICLE CAP


!kRS MANUAL FOR MORE INFORMATION


Two labels on your vehicle show how much weight it may properly carry. The Tire-Loading Information label found on the rear edge of the driver's door tells you the proper size, spec! r&.g z?c! rsc!x??!??e!?ded Inflzticn p:essu:cs for the tires on your vehicle. It also gives you important information about the number of people that can be in your vehicle and the total weight that you can carry. This weight is called the Vehicle Capacity Weight and includes the weight of all occupants, cargo and all options not installed in the factory.


4-3 1


-.Ian the


your ve :le any heavie.


Do no1 lad GVWR, or either the maximum front or rear GAWR. If you do, parts on your vehicle can break, and it can change the way your vehicle handles. These could cause you to lose control and crash. Also, overloading can shorten the life of your vehicle.


Notices Your warranty does not cover parts or components that fail because of overloading. If you put things inside your vehicle - like suitcases, tools, packages, or anything else - they will go as fast as the vehicle goes. If you have to stop or turn quickly, or if there is a crash, they’ll keep going.


MFD BY GENERAL MOTORS CORP


THIS VEHICLE


CONFORMS


TO ALL


~NTICIY-Y IWN ABOVE.


I ~IYDARDS IN


The other label is the Certification label, found on the rear edge of the driver’s door. It tells you the gross weight capacity of your vehicle, called the Gross Vehicle Weight Rating (GVWR). The GVWR includes the weight of the vehicle, all occupants, fuel and cargo. Never exceed the GVWR for your vehicle, or the Gross Axle Weight Rating (GAWR) for either the front or rear axle. If you do have a heavy load, you should spread it out. Don’t carry more than 176 Ibs. (80 kg) in your trunk.


4-32


Things you put inside your vehicle can strike and injure people in a sudden stop or turn, or in a crash.


Put things in the trunk of your vehicle. In a trunk, put them as far forward as you can. Try to spread the weight evenly. Never stack heavier things, like suitcases, inside the vehicle so that some of them are above the tops of the seats. Don’t leave an unsecured child restraint in your vehicle. When you carry something inside the vehicle, secure it whenever you can.


Automatic Level Control This feature keeps the rear of your vehicle level as the load changes. It’s automatic - you don’t need to adjust anything.


1. ,-- don’t use the CG.. ect equipmen. ,nd drive properly, you can lose control when you pull a trailer. For example, if the trailer is too heavy, the brakes may not work well -- or even at all. You and your passengers could be seriously injured. You may also damage your vehicle; the resulting repairs would not be covered by your warranty. Pull a trailer only if you have followed all the steps in this section. Ask your dealer for advice and information about towing a trailer with your vehicle.


Your vehicle can tow a trailer if it is equipped with the proper trailer towing equipment. To identify what the vehicle trailering capacity is for your vehicle, you should read the information in Weight of the Trailer that appears later in this section. But trailering is different than just driving your vehicle by itself. Trailering means changes in handling, durability and fuel economy. Successful, safe trailering takes correct equipment, and it has to be used properly.


4-33


That’s the reason for this part. In it are many time-tested, important trailering tips and safety rules. Many of these are important for your safety and that of your passengers. So please read this section carefully before you pull a trailer. Load-pulling components such as the engine, transaxle, wheel assemblies and tires are forced to work harder against the drag of the added weight. The engine is required to operate at relatively higher speeds and under greater loads, generating extra heat. What’s more, the trailer adds considerably to wind resistance, increasing the pulling requirements. If You Do Decide To Pull A Trailer If you do, here are some important points:


There are many different laws, including speed limit restrictions, having to do with trailering. Make sure your rig will be legal, not only where you live but also where you’ll be driving. A good source for this information can be state or provincial police. Consider using a sway control if your trailer will weigh 2,000 Ibs (900 kg) or less. You should always use a sway control if your trailer will weigh more than 2,000 Ibs (900 kg). You can ask a hitch dealer about sway controls. Don’t tow a trailer at all during the first 1,000 miles (1 600 km) your new vehicle is driven. Your engine, axle or other parts could be damaged.


4-34


Then, during the first 500 miles (800 km) that you tow a trailer, don’t drive over 50 mph (80 km/h) and don’t make starts at full throttle. This helps your engine and other parts of your vehicle wear in at the heavier loads. Obey speed limit restrictions when towing a trailer. Don’t drive faster than the maximum posted speed for trailers, or no more than 55 mph (90 km/h), to save wear on your vehicle’s parts.


Three important considerations have to do with weight:


the weight of the trailer, the weight of the trailer tongue and the total weight on your vehicle’s tires.


Weight of the Trailer How heavy can a trailer safely be? It depends on how you plan to use your rig. For example, speed, altitude, road grades, outside temperature and how much your vehicle is used to pull a trailer are all important. And, it can also depend on any special equipment that you have on your vehicle. It should never weigh more than 2,000 Ibs (900 kg) if you have an SLS model. If you have an STS model, the maximum trailer weight should never be more than 3,000 Ibs (1 350 kg). These are total maximum weights including the load. But even that can be too heavy.


The maximum trai!er weight fnr ynnr v e h i c ! ~ c m be determined from the Gross Combined Vehicle Weight (GCVW). The GCVW = curb weight + passenger’s weight + cargo weight +trailer weight. The GCVW should never be more than 7,100 Ibs (3 223 kg) total loaded vehicle and trailer for SLS models and 8,100 Ibs (3 677 kg) total loaded vehicle and trailer for STS models. You can ask your dealer for our trailering information or advice, or you can write us at: Cadillac Customer Assistance Center Cadillac Motor Car Division P.O. Box 33169 Detroit, MI 48232-51 69 In Canada write to: General Motors of Canada Limited Customer Communication Centre, 163-005 1908 Colonel Sam Drive Oshawa, Ontario LIH 8P7 Weight of the Trailer Tongue The tongue load (A) of any trailer is an important weight to measure because it affects the total or gross weight of your vehicle. The Gross Vehicle Weight (GVW) includes the curb weight of the vehicle, any cargo you may carry in it, and the people who will be riding in the vehicle. And if you tow a trailer, you must add the


tongue !cad to the G\!\.n! because your vehicle w i l l be carrying that weight, too. See Loading Your Vehicle on page 4-37 for more information about your vehicle’s maximum load capacity.


€3


A . . - . : I - . . I


If you’re using a weight-carrying hitch or a .“.-:.-.~a -I:-~.,:L..L: ._-. I - : ~ - I - AI-- VvGryl ll-Ul3LI ILJULll ly I I I l L I I, 11 le L I d l l e l LUI lyue \n) >I I U U l U weigh 10-15 percent of the total loaded trailer weight (B). After you’ve loaded your trailer, weigh the trailer and then the tongue, separately, to see if the weights are proper. If they aren’t, you may be able to get them right simply by moving some items around in the trailer.


< n \ _ I


1 - 1


4-35


Total Weight on Your Vehicle’s Tires Be sure your vehicle’s tires are inflated to the upper limit for cold tires. You’ll find these numbers on the Tire-Loading Information label at the rear edge of the driver’s door or see Loading Your Vehicle on page 4-31. Then be sure you don’t go over the GVW limit for your vehicle, including the weight of the trailer tongue. Hitches It’s important to have the correct hitch equipment. Crosswinds, large trucks going by and rough roads are a few reasons why you’ll need the right hitch. Here

Loading...
x
